STARTER SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Carbon Brush Minimum Length | ||
| 0 001 108 088/089/090 | .17" (4.5 mm) | |
| 0 001 110 063/068 | .23" (6 mm) | |
| 0 001 115 002 | .42" (10.7 mm) | |
| 0 001 218 017 130 | .27" (7 mm) | |
| Commutator Diameter | ||
| 0 001 108 088/089/090 | 1.14" (31.2 mm) | |
| 0 001 110 063/068 | 1.14" (31.2 mm) | |
| 0 001 115 002 | 1.28" (32.7 mm) | |
| 0 001 218 017 130 | 1.13" (28.9 mm) | |
| Commutator Runout | ||
| 0 001 108 088/089/090 | .002" (.05 mm) | |
| 0 001 110 063/068 | .0004" (.010 mm) | |
| 0 001 115 002 | .0004" (.010 mm) | |
| 0 001 218 017 130 | .0004" (.010 mm) | |
| Core Runout | .002" (.05 mm) | |
| End Play | ||
| 0 001 108 088/089/090 | .002-.015" (.05-.40 mm) | |
| 0 001 110 063/068 | .002-.015" (.05-.40 mm) | |
| 0 001 115 002 | .008-.028" (.20-.70 mm) | |
| 0 001 218 017 130 | .002-.012" (.05-.30 mm) | |
BOSCH STARTER SPECIFICATIONS
