Maintenance Information: Overview Volvo 960 I рестайлинг

Procedures 4 illustrations ~1134 words

INTERIOR FUSE PANEL IDENTIFICATION (1992-94)

Note. The ABS System is protected by an additional 10 Amp fuse which is located under the instrument panel to the left of the steering wheel.

Scheme 2

Scheme 2: INTERIOR FUSE PANEL IDENTIFICATION (1992-94)
Scheme 2: INTERIOR FUSE PANEL IDENTIFICATION (1992-94)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp Left & Rear Parking Lights, License Plate Lights
  2. 2 - 10 Amp Right Parking Lights
  3. 3 - 15 Amp Left Headlight (High Beam)
  4. 4 - 15 Amp Right Headlight (High Beam)
  5. 5 - SRS Test Socket
  6. 6 - 15 Amp Left Headlight (Low Beam)
  7. 7 - 15 Amp Right Headlight (Low Beam)
  8. 8 - 15 Amp Front Fog Lamps
  9. 9 - 10 Amp Rear Fog Lamps
  10. 10 - 5 Amp Instrument/Panel Lights
  11. 11 - 15 Amp Back-up Lights, Turn Signals, Cruise Control
  12. 12 - 15 Amp Shift-Lock
  13. 13 - 25 Amp Heated Rear Window, Heated Door Mirrors
  14. 14 - 10 Amp Overdrive, Sunroof, Power Window Relays, Heated Seats, Seat Belt Reminder
  15. 15 - Not Used
  16. 16 - 30 Amp Heated Seats
  17. 17 - Not Used
  18. 18 - 5 Amp Radio/Cassette Tape Player
  19. 19 - 15 Amp (1992) ECC, Power Door Mirrors, Rear Washer/Wiper (Wagon), Power Seats, Cigar Lighter 15 Amp (1993) ECC, Power Door Mirrors, Rear Washer/Wiper (Wagon), Power Seats, Cigar Lighter, Ambient Air Temperature Sensor
  20. 20 - 25 Amp Windshield Wipers/Washers, Horn
  21. 21 - 5 Amp (1992) Transmission Mode Selectors, Diagnostic Socket, Cooling Fan, EGR Valve 5 Amp (1993) Transmission Mode Selectors
  22. 22 - 5 Amp ABS
  23. 23 - 10 Amp Transmission Control
  24. 24 - 10 Amp Transmission/Engine Controls
  25. 25 - 25 Amp Hazard Warning Flashers, Central Locking System
  26. 26 - 10 Amp Clock, Interior Lights, Door Open Warning Lights, Cargo Space Vanity Mirror Lights
  27. 27 - 15 Amp Brake Lights, Shift-Lock Release
  28. 28 - 30 Amp ECC, Air Conditioning
  29. 29 - 30 Amp Power Antenna, Electrical Connector For Trailer
  30. 30 - 10 Amp Fuel Pump (In-Tank), Electrically Heated Lambda-Sond
  31. 31 - 25 Amp Fuel Injection, Main Fuel Pump, Ignition
  32. 32 - 10 Amp Radio/Amplifier (If Equipped)
  33. 33 - 10 Amp Radio/Cassette Tape Player
  34. 34 - 30 Amp (Circuit Breaker) Power Windows, Power Sunroof
  35. 35 - 30 Amp (Circuit Breaker) Power Seats

Relay Identification

  1. A - Headlight Relay with Bulb Malfunction Indicator
  2. B - Fuel Injection Relay, Fuel Pump Relay
  3. C - Central Locking Relay
  4. D - Foglight Relay
  5. E - Headlight Relay with Bulb Malfunction Indicator
  6. F - Overdrive Relay
  7. G - Bypass Relay 15I
  8. H - Intermittent Wiper Relay (Rear Tailgate - Wagon)
  9. I - Intermittent Windshield Wiper Relay
  10. J - Seat Belt Reminder Relay

INTERIOR FUSE PANEL IDENTIFICATION (1995-96)

Note. The ABS System is protected by an additional 10 Amp fuse which is located under the instrument panel to the left of the steering wheel.

Scheme 3

Scheme 3: INTERIOR FUSE PANEL IDENTIFICATION (1995-96)
Scheme 3: INTERIOR FUSE PANEL IDENTIFICATION (1995-96)
  1. 1 - 25 Amp Heated Rear Window
  2. 2 - 20 Amp Central Locking, Anti-Theft Alarm
  3. 3 - 15 Amp Brake Light, Light Switch
  4. 4 - 10 Amp Ignition Switch, SRS (Air Bag)
  5. 5 - Spare
  6. 6 - 25 Amp Windshield Wiper/Washer, Headlight Wiper/Washer, Horn Relay
  7. 7 - 20 Amp Climate Control
  8. 8 - 15 Amp Power Seats, Power Mirrors, Instrument Lighting Ambient Temperature Sensor, Tailgate Wiper/Washer (Wagon)
  9. 9 - 15 Amp (1995) Audio System 15 Amp (1996) Radio, Remote Control Module (Keyless Entry)
  10. 10 - 15 Amp Cigarette Lighter, Horn
  11. 11 - 5 Amp Central Locking System, Transmission Mode Selector Interior Lighting Delay
  12. 12 - 5 Amp ABS
  13. 13 - 10 Amp (1995) Clock, Interior/Glove Compartment Lamps, Vanity Mirror Door Open Warning Light, Cargo Space Lighting, 10 Amp Clock, Interior/Glove Compartment Lamps, Vanity Mirror Door Open Warning Light, Cargo Space Lighting, Remote Control Module (Keyless Entry), Electronic Start Inhibitor (Immobilizer)
  14. 13 - 10 Amp (1995) Horn 5 Amp (1996) Anti-Theft Alarm, Data Link Connector (DLC)
  15. 15 - 20 Amp Power Antenna, Headlight Flasher, Trailer Harness
  16. 16 - 20 Amp Mobile Telephone (If Equipped), Parking Heater (If Equipped)
  17. 17 - 20 Amp Hazard Warning Flasher, Anti-Theft Alarm
  18. 18 - 15 Amp Audio Amplifier, Radio, Compact Disc Changer
  19. 19 - 15 Amp Back-up Lights, Turn Indicators, Cruise Control
  20. 20 - 15 Amp Light Switch, High/Low Beam Relay
  21. 21 - 5 Amp Seat Belt Reminder, Rear Window Defroster - Timer P-Shift Lock, Heated Mirrors
  22. 22 - 15 Amp Heated Driver's Seat
  23. 23 - 15 Amp Heated Passenger's Seat
  24. 24 - 15 Amp Rear Fog Lamp
  25. 25 - 30 Amp (Circuit Breaker) Power Seats
  26. 26 - 30 Amp (Circuit Breaker) Power Windows, Power Sunroof
  1. Overload Relay
  2. Fuel Pump Relay
  3. Overload Relay

Scheme 4

Scheme 4: UNDER HOOD MAIN FUSE BOX IDENTIFICATION (1995-96)
Scheme 4: UNDER HOOD MAIN FUSE BOX IDENTIFICATION (1995-96)
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Maxi-Fuse Identification

  1. 1 - 50 Amp Heated Rear Window, Central Locking System, Hazard Flashers, Power Supply Relay "B".
  2. 2 - 50 Amp Audio, Power Seats, Climate Control, Compartment Lights, Power Antenna, Trailer Power, Fog Light Relay, Diagnostics
  3. 3 - 50 Amp Power Supply Relay "A"
  4. 4 - 50 Amp Fuel Supply Relay, Ignition Supply Relay
  5. 5 - 50 Amp ABS Unit
  6. 6 - 50 Amp Air Pump, Starter Solenoid, Horn
  7. 7 - 50 Amp Electric Cooling Fan
  8. 8 - 50 Amp Position/Parking Light Relay, Headlight Relay

Scheme 5

Scheme 5: UNDER HOOD FUSE/RELAY BOX IDENTIFICATION (1995-96)
Scheme 5: UNDER HOOD FUSE/RELAY BOX IDENTIFICATION (1995-96)

Fuse & Relay Identification

  1. 1 - 5 Amp Engine Control Module, Automatic Transmission Control Module
  2. 2 - 5 Amp (1995) Air Pump System 5 Amp (1996) A/C Relay
  3. 3 - 5 Amp (1995) EGR Valve, Relay, Air Pump 5 Amp (1996) Oxygen Sensor (HO2S) Auxiliary Air System Relay, EVAP Valve, Auxiliary Air System Solenoid, EGR Converter
  4. 4 - 15 Amp Fuel Pump
  5. 5 - 15 Amp Fuel Injection Valve, Mass Air Flow (MAF) Sensor, Idle Air Control (IAC) System, Engine Control Module
  6. 6 - 15 Amp Automatic Transmission Control Module
  7. 7 - 25 Amp Ignition Coil, Heated Oxygen Sensor
  8. 8 - 25 Amp Fog Lamps
  9. 9 - Spare Fuse
  10. 10 - 15 Amp Positioning/Parking Lights (Left)
  11. 11 - 15 Amp Positioning/Parking Lights (Right)
  12. 12 - 15 Amp Left High-Beam
  13. 13 - 15 Amp Right High-Beam, High-Beam Indicator (Instrument Panel)
  14. 14 - 15 Amp Left Low-Beam
  15. 15 - 15 Amp Right Low-Beam
  16. 16 - 15 Amp A/C Compressor
  17. 17 - 15 Amp Horn
  18. 18 - Accessories (Various Amp) Optional Equipment
  1. A - Air Pump Relay
  2. B - Spare
  3. C - Main Relay, Fuel System
  4. D - Spare
  5. E - Spare
  6. F - A/C Compressor Relay
  7. G - Fog Lamp Relay
  8. H - Spare
  9. J - Ignition Coil Relay
  10. K - Starter Motor Relay
  11. L - Fog Lamps Relay
  12. M - Parking Lights Relay
  13. N - Horn Relay
  1. A - Timer Relay, Rear Window Defroster
  2. B - Cruise Control Module
  3. C - Alarm Relay
  4. D - Central Locking Relay
  5. E - Cruise Control Module
  6. F - Alarm Relay
  7. G - Central Locking Relay
  8. I - Not Used
  9. J - Not Used
  10. K - Not Used
  11. L - Intermittent Windshield Wiper Relay
  12. M - Not Used
  13. N - Not Used

Note. The Engine Cooling Fan has a separately mounted relay in the engine compartment.
