ENGINE IDENTIFICATION
Engine is identified by sixth and seventh character of Vehicle Identification Number (VIN). The VIN is a 17 character stamped plate, attached to upper left side of instrument panel and is visible through windshield.
| Application | Code | |
|---|---|---|
| 240 DL & GL (2.3L B230F) | 88 | |
| 740 & 760 Series | ||
| Turbo (2.3L B230FT) | 87 | |
| Non-Turbo (2.3L B230F) | 88 | |
ENGINE CODE
ENGINE COMPRESSION
Warm engine to normal operating temperature. Disconnect single wire from negative terminal of ignition coil. Check compression with all spark plugs removed, throttle valve wide open and at normal cranking speed (250-300 RPM). Maximum variation between cylinders must not exceed 28 psi (2 kg/cm 2 ).
Note. On vehicles with LH-Jetronic injection, failure to disconnect ignition coil negative terminal may cause damage to ignition system control unit(s).
| Application | Specification | |
|---|---|---|
| Compression Ratio | ||
| Non-Turbo | 9.8:1 | |
| Turbo | 8.7:1 | |
| Compression Pressure (Minimum) | 128 psi (9 kg/cm 2 ) | |
COMPRESSION SPECIFICATIONS
VALVE CLEARANCE
- Remove valve cover. Turn crankshaft center bolt until camshaft is in position for firing No. 1 cylinder (TDC). Both cam lobes should point up at equally large angles. Pulley timing mark should be at zero degree mark.
- Using a feeler gauge, check valve clearance of No. 1 cylinder between camshaft lobe and adjusting discs. Intake and exhaust valves have same clearance.
- If clearances are incorrect, adjust by changing thickness of disc(s). Discs are available in .002" (.05 mm) increments. Install disc with markings facing down. Use Valve Depressor (5022) and Pliers (5026) to depress and remove disc(s).
- After valves for No. 1 cylinder are properly adjusted, rotate crankshaft to firing position for No. 3, No. 4, and No. 2 cylinders in sequence and repeat procedure. Install valve cover.
| Application | In. (mm) | |
|---|---|---|
| Cold | ||
| When Checking | .012-.016 (.30-.40) | |
| When Setting | .014-.016 (.35-.40) | |
| Warm | ||
| When Checking | .014-.018 (.35-.45) | |
| When Setting | .016-.018 (.40-.45) | |
VALVE CLEARANCE SPECIFICATIONS
VALVE ARRANGEMENT
- E-I-E-I-E-I-E-I (Front-to-rear).
Firing Order & Distributor Rotation (200 Series). Scheme 5
Firing Order & Distributor Rotation (700 Series). Scheme 6
IGNITION TIMING
Timing is preset and programmed in ECU (Electronic Control Unit) and cannot be adjusted.
| Application | Timing |
|---|---|
| All Models | 12 @ 750 |
IGNITION TIMING (DEGREES BTDC @ RPM)
IDLE SPEED & MIXTURE
Note. The engine is equipped with CIS (Constant Idle Speed) integrated with the LH-Jetronic 2.2 system. Basic idle speed is factory preset to about 750 RPM. Adjustment under normal conditions is not necessary.
Idle Speed
- Warm engine to normal operating temperature. Turn A/C off (if equipped). On 740 and 760 models ground Red/White wire of test point connector located at right front wheel housing. (Scheme 7) On 240 models ground Blue/White wire of test point connector located by air flow meter. This will close air valve completely.
- Turn idle adjustment knob/screw to set idle speed to 700 RPM. Disconnect Red/White wire. Idle speed should increase to 730-770 RPM. Turn A/C on (if equipped). Idle speed should increase to 900 RPM.
Scheme 7
Note. Mixture adjustment is NOT a normal tune-up procedure and should not be performed unless mixture control unit is replaced or vehicle fails emissions testing.
Idle Mixture
- Warm engine to normal operating temperature. Check idle speed and ignition timing. Disconnect oxygen sensor. Check CO level.
- If CO level is incorrect, turn off engine. Drill two 5/16" holes in adjustment plug. Pull out plug with snap ring pliers. Start engine and adjust CO level. (Scheme 8)
- Turning screw counterclockwise decreases CO level. Turning screw clockwise increases level. Connect oxygen sensor lead and remove test equipment. Seal CO adjustment screw with a new plug.
Scheme 8
| Application | Idle RPM | CO% |
|---|---|---|
| All Models | 750 | (1) .4-.8 |
| (1) With oxygen sensor disconnected. Less than 0.6% with oxygen sensor connected. | ||
| (1) | With oxygen sensor disconnected. Less than 0.6% with oxygen sensor connected. |
CO LEVEL SPECIFICATIONS
Distributor
All models are equipped with Bosch EZ-117K ignition system. No adjustments are required.
EMISSION CONTROL
See EMISSIONS section.
OXYGEN SENSOR REPLACEMENT
Disconnect oxygen sensor lead and remove oxygen sensor. Coat new oxygen sensor threads with anti-seize compound. DO NOT apply anti-seize compound to slotted part of oxygen sensor. Tighten oxygen sensor to 36-44 ft. lbs. (50-60 N.m). Connect oxygen sensor lead.
Fuel Injection
All models are equipped with Bosch LH-Jetronic 2.2 fuel injection with integrated Constant Idle Speed.
Fuel Pump
Check fuel pump with full battery charge and clean fuel filter.
| Application | Pressure psi (kg/cm 2 ) | Volume in 30 seconds Pints (Liters) |
|---|---|---|
| Non-Turbo | 64-76 (4.5-5.3) (1) | 1.7 (.8) |
| Turbo | 75-83 (5.2-5.8) | 2.1 (1.0) |
| (1) Line pressure above intake manifold is 36 psi (2.5 kg/cm 2 ). | ||
| (1) | Line pressure above intake manifold is 36 psi (2.5 kg/cm 2 ). |
FUEL PUMP PERFORMANCE
BATTERY
| Application | Amp Hr. Rating |
|---|---|
| All Models | 60 |
BATTERY SPECIFICATIONS
STARTER
All models are equipped with Bosch overrunning clutch starters.
| Application | Volts | Amps | Test RPM |
|---|---|---|---|
| All Models | 11.5 | 30-50 | 5500-7500 |
STARTER SPECIFICATIONS
ALTERNATOR
All models are equipped with Bosch alternators with integral voltage regulators.
| Application | Rated Amp. Output |
|---|---|
| 240 DL & 240 GL | 55 |
| 740 & 760 Series | 70 |
ALTERNATOR SPECIFICATIONS
ALTERNATOR REGULATOR
All models are equipped with Bosch alternator regulators.
| Application | Voltage |
|---|---|
| All Models | 13.8-14.8 |
REGULATOR OPERATING VOLTAGE @ 68°F (20°C)
SERVICE INTERVALS
| Component | Interval (Miles) | |
|---|---|---|
| Air Filter | 30,000 | |
| Fuel Filter | ||
| Non-Turbo | 45,000 | |
| Turbo | 30,000 | |
| In Fuel Tank | 60,000 | |
| Oil Filter | ||
| Non-Turbo | 5000 | |
| Turbo | 3750 | |
| Oxygen Sensor | 30,000 | |
| PCV (Service) | 50,000 | |
| Spark Plugs | 30,000 | |
REPLACEMENT INTERVALS
BELT ADJUSTMENT
| Application | (1) Deflection In. (mm) |
|---|---|
| All Belts | .2-.4 (5-10) |
| (1) Deflection is measured with moderate thumb pressure applied midway on longest belt run. | |
| (1) | Deflection is measured with moderate thumb pressure applied midway on longest belt run. |
BELT ADJUSTMENT
CAPACITIES
| Application | Quantity | |
|---|---|---|
| Crankcase (Including Filter) | ||
| Non-Turbo | 4.0 qts. (3.8L) | |
| Turbo | 4.7 qts. (4.5L) | |
| Auto. Trans. (Dexron) (1) | ||
| With Overdrive | 7.8 qts. (7.4L) | |
| Without Overdrive | 7.1 qts. (6.7L) | |
| (1) For refill, 3.2 qts. (3.0L). | ||
| (1) | For refill, 3.2 qts. (3.0L). |
FLUID CAPACITIES
SPARK PLUGS
| Application | Bosch No. |
|---|---|
| All Models | WR7DC |
SPARK PLUG TYPE
| Application | Gap: In. (mm) | Torque: Ft. Lbs. (N.m) |
|---|---|---|
| All Models | .030 (.75) | 18 (24) |
SPARK PLUG SPECIFICATIONS
