Heating: Overview Volkswagen Tiguan I

Automatic HVAC System 3 illustrations ~381 words

Disconnect battery before removing components marked with **. .

Scheme 1

Scheme 1: HEATING COMPONENTS OVERVIEW
Scheme 1: HEATING COMPONENTS OVERVIEW
  1. Dash Panel **
  2. Center Vents Removing vents, refer to «CENTER VENT»(ref-514669-S15863726902012112100000)
  3. Passenger Vent Removing vents, refer to «DRIVER OR PASSENGER VENTS»(ref-514669-S01778828092012112100000)
  4. Fresh Air and Heated Air Controls With Fresh Air/Recirculating Door Switch -E159- Also with Immediate Heating Button -E537- in vehicles with an auxiliary heater Removing controls, refer to «HEATER CONTROLS»(ref-514669-S17892405722012112100000) On vehicles with heated seals also with Heated Driver Seat Adjuster -E94- and Heated Front Passenger Seat Adjuster -E95
  5. Fresh/Recirculating Air Door Motor -V154- Removing and installing, refer to «FRESH/RECIRCULATING AIR DOOR MOTOR»(ref-514669-S29280767892012112100000)
  6. Right Footwell Vent Removing and installing, refer to «RIGHT FOOTWELL VENT»(ref-514669-S01696475322012112100000)
  7. Fresh Air Blower -V2- Removing and installing, refer to «FRESH AIR BLOWER»(ref-514669-S08975465182012112100000)
  8. Fresh Air Blower Series Resistor with Fuse -N24- Removing and installing, refer to «FRESH AIR BLOWER SERIES RESISTOR WITH FUSE»(ref-514669-S37919780382012112100000)
  9. Heating Unit Partition Removing and installing (Scheme 2)
  10. Sealing Caps Only in vehicles without air duct to vent installed in center console at rear
  11. Air Guide To remove, the center console must be removed. Refer to «Removal and Installation»(ref-514666-S38414190312012112100000)
  12. Dust and Pollen Filter With EVAP canister Removing and installing, refer to «DUST AND POLLEN FILTER»(ref-514669-S25375442072012112100000)
  13. Connection For the center console air duct To remove, the center console must be removed. Refer to «Removal and Installation»(ref-514666-S38414190312012112100000)
  14. Air Outlet Grille Depending on vehicle equipment
  15. Rear Channel for Right Footwell Removing and installing, refer to «REAR VENT»(ref-514669-S29631352932012112100000)
  16. Rear Channel for Left Footwell Removing and installing, refer to «REAR VENT»(ref-514669-S29631352932012112100000)
  17. Screw Quantity: 8
  18. Adapter for Controls
  19. Heat Exchanger After replacing the heater core, the coolant must be replaced completely. Refer to «[For transmission(s) 0A6, 09M] [For engine(s) CCTA] General Information»(ref-514704-S32310804012012112100000). Removing and installing, refer to «HEAT EXCHANGE»(ref-514669-S39561283732012112100000)
  20. Left Footwell Vent Removing and installing, refer to «LEFT FOOTWELL VENT»(ref-514706-S23465377572012112100000)
  21. Bowden Cable for Temperature Door Removing and installing, refer to «AIR DISTRIBUTION FLAP ADJUSTER CABLE»(ref-514669-S14410404412012112100000)
  22. Flexible Shaft Removing and installing, refer to «FLEXIBLE AIR DISTRIBUTION SHAFT»(ref-514669-S31409855782012112100000)
  23. Heater Unit Removing and installing, refer to «HEATER»(ref-514669-S39372737912012112100000) Disassembling and assembling, refer to «HEATER»(ref-514669-S09036815002012112100000)

Scheme 2

Scheme 2
Scheme 2

Unscrew plastic screws -2- and remove partition -1-.

Scheme 3

Scheme 3
Scheme 3

First insert the seal into the plenum chamber bulkhead between the heater and engine compartment -A- and then place on the heater core.

Note. To prevent water from entering vehicle interior, note the installation position.
