LIFTING PRECAUTIONS
- In order to prevent vehicle damage, use a suitable wood or rubber block between jack and body.
- Vehicle must NEVER be lifted on engine oil pan, transmission, rear axle, front axle or bottom sill.
- Hoists with liquid cushions must NOT be used to raise the vehicle.
LIFT POINTS FOR FLOOR JACK & HOISTS
On front of vehicle, lift at reinforcing plate welded to floor panel. (Scheme 1) Position support so rear edge aligns with center of sill depression.
| CAUTION | DO NOT lift vehicle on vertical sill reinforcement or damage to vehicle could result. |
On rear of vehicle, lift at reinforcing plate welded to floor panel. (Scheme 1)Position support so that rear edge aligns with center of sill depression.
Scheme 1
Front
- To adjust front camber, install Camber Adjustment Tool (3270). Loosen lower strut mounting bolt.
- Adjust camber by turning spindle to specified setting.
- Tighten strut-to-wheel spindle mounting bolt. See «TORQUE SPECIFICATIONS»(ref-62276-S35905816892004022300000) . Recheck camber setting. Repeat adjustment, if necessary.
Scheme 2
CALCULATING THRUST ANGLE
Note. VW also refers to thrust angle as direction of travel. (Scheme 3)
