ENGINE CODE
Engines are identified by a 3-letter code stamped on the engine. For engine code locations (Scheme 11)- (Scheme 14). Engine codes are also located on the vehicle data plate.
Note. Engine number for 1.8L turbo can be found on mating flange between engine and transmission. Additionally there is a sticker on cylinder head (valve) cover with engine code and serial number.
Scheme 11
Note. Engine code for 1.9L TDI is located between diesel injection pump and exhaust manifold, on engine block. Additionally there is a sticker on the timing belt guard containing engine code and serial number. Engine code is also included on vehicle data plate.
Scheme 12
Note. Engine code and serial number for 2.0L is located can be found on flange between engine/transmission. Additionally there is a sticker on the timing belt guard containing engine code and serial number. Engine code is also included on vehicle data plate.
Scheme 13
Note. Engine code - arrow A - and engine number - arrow B ("serial number") 2.5L is located on rear side of engine, above partition of cylinder block/upper section of oil pan.
Scheme 14
| WARNING | Never replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and cause a fire. On no account should fuses be repaired (e.g. with tin foil or wire) as this may cause serious damage elsewhere in the electrical circuit or cause a fire. |
FUSE COLOR IDENTIFICATION
| Fuse Color | Amp Rating |
|---|---|
| Black | 1A |
| Violet | 2A |
| Lilac | 3A |
| Beige | 5A |
| Brown | 7.5A |
| Red | 10A |
| Blue | 15A |
| Yellow | 20A |
| White | 25A |
| Green | 30A |
| Orange | 40A |
| Red | 50A |
| Blue | 60A |
| Transparent | 80A |
FUSE COLOR/AMP RATING
Scheme 15
| Location No. | Description | Refer to |
|---|---|---|
| 1 | Fuse Arrangements On Fuse Panel/Battery | FUSE ARRANGEMENTS IN FUSE BRACKET/BATTERY - ENGINE COMPARTMENT |
| 2 | Fuse Arrangements On Relay Panel | FUSES ON RELAY PANEL |
| Relay Arrangements On Thirteen Position Auxiliary Relay Panel Above Relay Panel | RELAYS ON THIRTEEN POSITION AUXILIARY RELAY PANEL | |
| Fuse Arrangements On Thirteen Position Auxiliary Relay Panel | FUSE ARRANGEMENTS ON THIRTEEN POSITION AUXILIARY RELAY PANEL | |
| 3 | Fuse Arrangements In Fuse Panel, Instrument Panel, Left Side | FUSE ARRANGEMENTS IN FUSE PANEL, INSTRUMENT PANEL - LEFT SIDE |
Scheme 16
| Location No. | Description | Refer to |
|---|---|---|
| 1 | Identifying Relay Panel (Located below the Thirteen Position Auxiliary Relay Panel) | LOCATION OF RELAYS ON RELAY PANEL |
| 1 | Identifying Thirteen Position Auxiliary Relay Panel (Located above the Relay Panel) | LOCATION OF RELAYS ON THIRTEEN POSITION AUXILIARY RELAY PANEL - Above Relay Panel |
| 2 | Inside Housing Relay (Engine compartment near brake fluid reservoir) | LOCATION OF INSIDE HOUSING RELAYS - ENGINE COMPARTMENT - LEFT SIDE |
| 3 | Additional Relay Panel (In plenum chamber engine compartment) | LOCATION OF ADDITIONAL RELAY PANEL IN PLENUM CHAMBER, CENTER - FROM JUNE 2003 TO DECEMBER 2006 |
FUSE ARRANGEMENTS ON FUSE BRACKET/BATTERY - ENGINE COMPARTMENT
The fuse bracket is assembled on top of the battery on the left side of engine compartment.
Scheme 17
| Fuse No. | Wiring ID. | Rating (Amps) | Function/Component | Signal |
|---|---|---|---|---|
| 1 | S162 | 50A | V101- Secondary Air Injection (AIR) Pump Motor (1) -J359- Preheating Coolant, Low Heat Output Relay (2) -J360- Preheating Coolant, High Heat Output Relay (2) | 30 |
| 2 | S163 | 50A | J17- Fuel Pump (FP) Relay (17/30) -J370- Glow Plug Activation Control Module (3) | 30 |
| 3 | S164 | 40A | J293- Coolant Fan Control (FC) Control Module C1781, (T4e/1) -V7- Coolant Fan | 30 |
| 4 | S176 | 110A | J59- Load Reduction Relay, (7/30) | 30a |
| 5 | S177 | 110A 150A | C- Gen (GEN) (90 Amp) -C- Generator (GEN) (120 Amp) | 30 |
| 6 | S178 | 30A | J104- A35 Control Module (T47a/1) | 30 |
| 7 | S179 | 30A | J104- ABS Control Module, (T47a/32) | 30 |
| 8 | S180 | 30A | F18- Coolant Fan Control (FC) Thermal Switch -J293- Coolant Fan Control (FC) Control Module C1781, (T4e/3) | 30 |
| 9 | T3-3 Pin Connector | From: -J104- ABS Control Module (T47a/1) to T3/1 (S178) -J104- ABS Control Module (T47a/32) to T3/2 (S179) -J293- Coolant Fan Control (FC) Control Module (T4a/3) to T3/3 (S180) | 30 | |
| (1) Only vehicles with Secondary Air Injection (AIR) Pump. (2) Only Diesel engines with manual transmission. (3) Only Diesel engines. Note: The number(s) in parentheses indicates production control number stamped on relay housing. | ||||
| (1) | Only vehicles with Secondary Air Injection (AIR) Pump. |
| (2) | Only Diesel engines with manual transmission. |
| (3) | Only Diesel engines. |
FUSE IDENTIFICATION (ON FUSE BRACKET/BATTERY)
FUSE ARRANGEMENTS IN FUSE PANEL, INSTRUMENT PANEL - LEFT SIDE - FROM JULY 2005
Fuse (holder) panel "S" is located behind trim panel on far left side of dashboard. (Scheme 18)
Note. Fuses from S23 to S44 are identified with additional prefix 2, in wiring diagram. For Example, fuse S23 on fuse panel is listed as S223 in wiring diagram.
Scheme 18
Scheme 19
| Fuse No. | Wiring ID. | Rating (Amp) | Function/Component | Signal |
|---|---|---|---|---|
| 1 | S1 | 10A | J99- Heated Mirror Relay (1) -J131- Drivers Heated Seat Control Module, (T6/5) -J132- Front Passengers Heated Seat Control Module, (T6b/5) -W6- Glove Compartment Light -Z20/ Z21- Washer Nozzle Heaters | X |
| 2 | S2 | 10A | E3 - Emergency Flasher Switch, (T8d/7) -M5/ M7 - Left/Right Front Turn Signal Lamp -M6/ M8 - Left/Right Rear Turn Signal Lamp | X |
| 3 | S3 | 5A | E1 - Light Switch -E20- Instrument Panel Illumination Dimmer Switch, (T3k/2) -J5- Fog Light Relay (4/86) | 58 |
| 4 | S4 | 5A | X - License plate light | 58 |
| 5 | S5 | 7.5A | E45- Cruise Control Switch (T10s/6) (2) -E159- Fresh Air/Recirculating Flap Switch, (T8n/5) (3) -E231- Outside Heated Mirror Switch -F36- Clutch Pedal Switch, (T4m/3) (4) -F47- Brake Pedal Switch, (T4y/3) -G65- High Pressure Sensor, (T3c/3) -J89- Daytime Running Lights Change-over Relay (T9c/8) -J255- Climatronic Control Module, (T16c/9) -J293- Coolant Fan Control (FC) Control Module (T14/9) -J386- Driver Door Control Module, (T18d/3) -R- Radio (T8g/4) (5) -T16- 16 Pin Connector (OBD), (T16/1) (6) -V35- Right Coolant Fan (T4b/2) -V48- Left Headlamp Beam Adjustment Motor (7) -V49- Right Headlamp Beam Adjustment Motor (7) | 15 |
| 6 | S6 | 5A | J393- Comfort System Central Control Module (T23/5) | 15 |
| 7 | S7 | 10A | F4- Back-Up Light Switch -F125- Multi-Function Transmission Range (TR) Switch (T10t/10) (8) -F189- Tiptronic Switch, (T8s/7) (8) -G22- Speedometer Vehicle Speed Sensor (VSS) -J226- Park/Neutral Position (PNP) Relay, (T9/5) (9) -K142 - Selector Lever Position P/N Indicator Lamp -M16 / M17- Left/Right Back-Up Lamps -T16- 16 Pin Connector (OBD), (T16/1) | 15 |
| 8 | S8 | Not Used | ||
| 9 | S9 | 5A | E256- ASR/ESP Button, (T6j/6) -J104- ABS Control Module (T47a/4) -G85- Steering Angle Sensor (T6k/5) (10) | 15 |
| 10 | S10 | 10A | J285- Instrument Cluster Control Module, (T32/30) -J393- Comfort System Central Control Module, (T23/17) (11) -R- Radio, (T8g/4) -Y2- Digital Clock | 86s |
| 11 | S11 | 5A | J285- Instrument Cluster Control Module, (T32/1) -N110- Shift Lock Solenoid | 15 |
| 12 | S12 | 7.5A | T16- 6 Pin Connector (OBD), (T16/16) (5) | 30 |
| 13 | S13 | 10A | F- Brake Light Switch (T4y/1) | 30 |
| 14 | S14 | 10A | J220 - Motronic Engine Control Module (ECM), in plenum chamber, center, (T121/62) -J271- Motronic Engine Control Module (ECM) Power Supply -J393- Comfort System Central Control Module (T23/22) (11) | 30 |
| 15 | S15 | 5A | G85- Steering Angle Sensor, (T6k/4) (10) -J217- Transmission Control Module (TCM), (T68/45) -J217- Transmission Control Module (TCM) vehicles with Tiptronic -J285- Instrument Cluster Control Module (T32/23) (21) -Y2- Digital Clock, (T10d/10) (13) | 30 |
| 16 | S16 | 10A | J293- Coolant Fan Control (FC) Control Module, (T14a/4) (12) | 30 |
| 17 | S17 | Not Used | ||
| 18 | S18 | 15A | J5- Fog Lamp Relay, (6/85) -J285- Instrument Cluster Control Module (T32/17) -J607- Right High/Low Beam Switch-Over Relay (7) -M32- Right High Beam Headlamp (T12b/4) | 56a |
| 19 | S19 | 15A | J606- Left High/Low Beam Switch-Over Relay (7) -M30- Left High Beam Headlamp | 56a |
| 20 | S20 | 10A | J607- Right High/Low Beam Switch-Over Relay (7) -M31- Right Low Beam Headlamp (T12b/9) | 56b |
| 21 | S21 | 10A | J606- Left High/Low Beam Switch-Over Relay (7) -M29- Left Low Beam Headlamp (T12a/9) | 56b |
| 22 | S22 | 5A | J285- Instrument Cluster Control Module, (T32/26) -M3- Right Parking Lamp (T12b/8) -M22- Right Brake/Taillight Lamp (T3b/1) -M34- Right Front Side Marker Lamp -M36- Front Turn Signal/Side Marker Lamp -M38- Right Rear Side Marker Lamp | 58r |
| 23 | S23 | 5A | J285- Instrument Cluster Control Module, (T32/27) -M1- Left Parking Lamp (T12a/8) -M21- Left Brake/Taillight Lamp (T3a/1) -M33- Left Front Side Marker Lamp -M35- Left Front Turn Signal/Side Marker Lamp -M37- Left Rear Side Marker Lamp | 58l |
| 24 | S24 | 20A | E22- Windshield Wiper/Washer Switch (T8c/8) -J31-Wiper/Washer Intermittent Relay (T18a/13) | X |
| 25 | S25 | 25A | E9- Fresh Air Blower Switch (T6p/2) | X |
| 26 | S26 | 25A | E15- Rear Window Defogger Switch (T6f/5) -Z1- Heated Rear Window | X |
| 27 | S27 | 15A | U1- Cigarette Lighter from model year 2007 -J29- Blocking Diode, from model year 2007 | X |
| S27 | 20A | J29- Blocking Diode (13) -U18- 12V Socket 2, (T3o/3) (13) -U19- 12V Socket 3, (T3ab/2) (13) | X | |
| 28 | S28 | 15A | G6 - Transfer Fuel Pump (FP) | 87 |
| 29 | S29 | 15A | J220- Motronic Engine Control Module (ECM), (T121/3) -J220- Motronic Engine Control Module (ECM) (T121/21) (3) -J248- Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM), (T121/37) -J623- Engine Control Module (ECM), (T80/4) (15) -N30, N31, N33, N83- Fuel Injectors -N83- Cylinder 5 Fuel Injector (3) | 30 |
| 30 | S30 | 20A | J245- Power Sunroof Control Module (T6s/4) | 30 |
| 31 | S31 | 20A | F125- Multi-Function Transmission Range (TR) Switch (T8a/7) -J217- Transmission Control Module (TCM), (T68/23) -J217- Transmission Control Module (TCM) (T52/27) (16) -J539- Brake Booster Control Module, (T6k/3) -J539- Brake Booster Control Module, (T6j/3) (17) | 15 |
| 32 | S32 | 10A | N30, N31, N33, N83- Fuel Injectors (15) -N280- A/C Compressor Regulator Valve (3) | 87 |
| S32 | 15A (18) | J248- Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM), (T121/2) -N146- Quantity Adjuster | 87 | |
| 33 | S33 | Not Used | ||
| 34 | S34 | 10A | J52- Glow Plug Relay (19) -N18- EGR Vacuum Regulator Solenoid Valve (19) -N75- Wastegate Bypass Regulator Valve -N108- Cold Start Injector (19) -N239- Intake Manifold Flap Change-over Valve (19) -N205- Camshaft Adjustment Valve 1 (19) -N249- Turbocharger Recirculating Valve (19) | 87 |
| 35 | S35 | 30A | U19- 2V Socket 3 (in luggage compartment) | 30 |
| 36 | S36 | 15A | E23 - Fog Lamp Switch, (T17/2) | X |
| 37 | S37 | 20A | J220- Motronic Engine Control Module (ECM), (T121/62) (20) -J248- Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM), (T121/88) (19) -J271- Motronic Engine Control Module (ECM) Power Supply Relay (T9/2) (20) , and (2/30) (15) -J623- Engine Control Module (ECM), (T80/15) (15) -J283- Brake Vacuum Pump Fuse | 30 |
| 38 | S38 | 15A | E204- Remote Tank Flap Switch -E233- Rear Lid Remote Control Lock Switch -J386- Driver Door Control Module, (T29/19) (11) -J387- Front Passenger Door Control Module, (T29a/19) (11) | 30 |
| 39 | S39 | 15A | E3- Emergency Flasher Switch, (T8d/8) | 30 |
| 40 | S40 | 20A | H2- High Tone Horn -H7- Low Tone Horn -J4- Horn Relay (3/30) | 30 |
| 41 | S41 | 15A | U1- Cigarette Lighter -U5- 12V Socket -U18- 12V Socket 2 (T3o/3) (22) -U19- 12V Socket 2 (T3ab/2) (22) | 30 |
| 42 | S42 | 25A | R- Radio (T8a/5 T8a/7) | 30 |
| 43 | S43 (3) | 10A | G39- Heated Oxygen Sensor (HO2S) (T6w/4) -G70- Mass Air Flow (MAF) Sensor / G42 Intake Air Temperature (IAT) Sensor (T5j/2) -G130- Oxygen Sensor (02S) Behind Three Way Catalytic Converter (TWC) (T4ao/1) -G465- Oxygen Sensor (02S) in Center Three Way Catalytic Converter, (TWC), Bank 1 (T4v/1) (14) -J299- Secondary Air Injection (AIR) Pump Relay, (1/30) -N80- Evaporative Emission (EVAP) Canister Purge Regulator Valve (T2/1) -N112- Secondary Air Injection (AIR) Solenoid Valve -V144- Leak Detection Pump (LDP), (T3d/3) | 87 |
| 43 | S43 | 10A | G39- Heated Oxygen Sensor (HO2S) (T4s/1), Eng. Code CBPA -G39- Heated Oxygen Sensor (HO2S) (T6/1), Eng. Code BEJ -G39- Heated Oxygen Sensor (HO2S) (T4c/1), Eng. Code BHP -G130- Oxygen Sensor (02S) Behind Three Way Catalytic Converter (TWC) (T4ao/1), (Engine Code CBPA) -G130- Oxygen Sensor (02S) Behind Three Way Catalytic Converter (TWC) (T4/1), (Engine Code BEJ) -G130- Oxygen Sensor (02S) Behind Three Way Catalytic Converter (TWC) (T4d/1), (Engine Code BHP) -N80- Evaporative Emission (EVAP) Canister Purge Regulator Valve (T2/1), (Engine Code CBPA, BEJ, BHP) | 87 |
| 43 | S43 (23) | 10A | F36- Clutch Pedal Switch, (T4m/3) -F47- Brake Pedal Switch, (14y/2) -G39- Heated Oxygen Sensor (HO2S) (T6w/4) -J359- Preheating Coolant Low Heat Output Relay (4/86) -J360- Reheating Coolant High Heat Output Relay, (3/86) -N79- Positive Crankcase Ventilation (PCV) Heating Element, (T2/1) | 87 |
| 44 | S44 | 15A | J131- Driver's Heated Seat Control Module, (T6/4) -J132- Front Passengers Heated Seat Control Module (T6b/4) | 30 |
| (1) Only vehicles without power windows. (2) Vehicles with engine BPS w/GRA. (3) Vehicles with engine codes BPS and BPR. (4) Only vehicles with manual transmission. (5) From July 2008. (6) Through June 2008. (7) Vehicles with High Intensity Gas Discharge (HID) Lamps. (8) With Tiptronic 09G. (9) With Auto Transmission 01M. (10) Only vehicles with ASR and ESP. (11) Vehicles with power windows. (12) Vehicles with engine code CBPA. (13) From July 2007. (14) Vehicles with engine codes BPR. (15) Vehicles with engine code CBPA. (16) Vehicles with automatic transmission 09G. (17) Vehicles with 1.8L engine AWV. (18) Diesel engine only. (19) Vehicles with engine codes ALH and BEW. (20) Vehicles with engine code BPS. (21) Through June 2007. (22) From July 2007 through June 2007 (23) Vehicles with engine code BEW. Note: The number(s) in parentheses indicates production control number stamped on relay housing. | ||||
| (1) | Only vehicles without power windows. |
| (2) | Vehicles with engine BPS w/GRA. |
| (3) | Vehicles with engine codes BPS and BPR. |
| (4) | Only vehicles with manual transmission. |
| (5) | From July 2008. |
| (6) | Through June 2008. |
| (7) | Vehicles with High Intensity Gas Discharge (HID) Lamps. |
| (8) | With Tiptronic 09G. |
| (9) | With Auto Transmission 01M. |
| (10) | Only vehicles with ASR and ESP. |
| (11) | Vehicles with power windows. |
| (12) | Vehicles with engine code CBPA. |
| (13) | From July 2007. |
| (14) | Vehicles with engine codes BPR. |
| (15) | Vehicles with engine code CBPA. |
| (16) | Vehicles with automatic transmission 09G. |
| (17) | Vehicles with 1.8L engine AWV. |
| (18) | Diesel engine only. |
| (19) | Vehicles with engine codes ALH and BEW. |
| (20) | Vehicles with engine code BPS. |
| (21) | Through June 2007. |
| (22) | From July 2007 through June 2007 |
| (23) | Vehicles with engine code BEW. |
IDENTIFYING FUSES (INSTRUMENT PANEL - LEFT SIDE - FROM JULY 2005)
AUTOMATIC CIRCUIT BREAKERS
The electric seat adjusters or heaters (if applicable) are protected with circuit breakers which reset automatically after the circuit overload has been corrected.
Note. Whenever replacing a fuse, always consult the sticker on the inside of the fuse panel cover. It contains the most up-to-date information regarding the fuse arrangement.
FUSE ARRANGEMENTS ON RELAY PANEL, INSTRUMENT PANEL - LEFT SIDE
The relay/fuse (holder) panel is located on left side of the instrument panel, refer to COMPONENT LOCATION . The relay/fuse panel consist of a lower relay panel, the upper thirteen position auxiliary relay panel (above the relay panel) and assorted fuse locations.
Scheme 20
Location Of Fuses On Relay Panel - From July 2005
| Fuse Location | Function/Component |
|---|---|
| A | S43- Power Window Circuit Breaker, (30A) |
| B | Not Used |
| C | S130- Secondary Air Injection (AIR) Pump Fuse, (10A) (1) -S329- Rear Spoiler Motor Fuse (30A) (2) |
| (1) From July 2005. (2) Vehicles with 1.8L engines, model years 2003-05. | |
| (1) | From July 2005. |
| (2) | Vehicles with 1.8L engines, model years 2003-05. |
IDENTIFYING FUSES ON RELAY PANEL (INSTRUMENT PANEL - LEFT SIDE - FROM JULY 2005)
Location Of Fuses On Thirteen Position Auxiliary Relay Panel - Above Relay Panel - From July 2005
Note. The thirteen position auxiliary relay panel is located above the lower relay panel.
| Fuse Location | Function/Component |
|---|---|
| F | Not Used |
| G | Not Used |
| H | S111- Alarm System and Anti-theft Immobilizer Fuse, (15A) |
| H | S338- Telematics Fuse (15A) |
| J | S283- Brake Vacuum Pump Fuse (20A) (1) (2) |
| J | S337- Mechatronic Direct Shift Gearbox (DSG) Fuse (20A) (3) (4) |
| (1) Only vehicles with automatic transmission. (2) From model year 2004. (3) Vehicles with 1.9L engine code BEW. (4) Only vehicles with Direct Shift Gearbox (DSG) 02E. | |
| (1) | Only vehicles with automatic transmission. |
| (2) | From model year 2004. |
| (3) | Vehicles with 1.9L engine code BEW. |
| (4) | Only vehicles with Direct Shift Gearbox (DSG) 02E. |
IDENTIFYING FUSES ON THIRTEEN POSITION AUXILIARY RELAY PANEL (INSTRUMENT PANEL - LEFT SIDE - FROM JULY 2005)
RELAY ARRANGEMENTS ON RELAY PANEL, INSTRUMENT PANEL - LEFT SIDE
The relay/fuse (holder) panel is located on left side of the instrument panel, refer to COMPONENT LOCATION . The relay/fuse panel consist of a lower relay panel, the upper thirteen position auxiliary relay panel (above the relay panel) and assorted fuse locations.
For fuse number, position number, amperage rating and circuits protected, see the appropriate IDENTIFYING FUSES table under FUSES .
Scheme 21
| Relay Location | Function/Component |
|---|---|
| 1 | J4- Horn Relay (53) |
| 2 | J59- Load Reduction Relay, (100)(213) |
| 3 | Not Used |
| 4 | J17- Fuel Pump (FP) Relay (409) (1) (2) (3) |
| 5 | J31- Wiper/Washer Intermittent Relay/Rain Sensor (377), (192), (389) |
| (1) Engine 1.8L, code AWV, AWP BKF, BNU. (2) Engine 2.0L, code AVH, AZG, BEV, BHP, CBPA (3) Engine 2.5L, code BPR, BPS Note: The number(s) in parentheses indicates production control number stamped on relay housing. | |
| (1) | Engine 1.8L, code AWV, AWP BKF, BNU. |
| (2) | Engine 2.0L, code AVH, AZG, BEV, BHP, CBPA |
| (3) | Engine 2.5L, code BPR, BPS |
IDENTIFYING RELAYS ON RELAY PANEL (INSTRUMENT PANEL - LEFT SIDE)
Location Of Relays On Thirteen Position Auxiliary Relay Panel - Above Relay Panel
The thirteen position auxiliary relay panel is located above the lower relay panel.
Scheme 22
| Relay Location | Function/Component |
|---|---|
| 1 | J434- Starter Lock/Clutch Pedal Switch Relay (449) (1) (2) |
| 2 | Not Used |
| 3 | J219- Back-Up Light Relay (53) (3) |
| 4 | J5- Fog Light Relay (53) |
| 4 | J207- Starting Interlock Relay (465) (1) |
| 5 | J17- Fuel Pump (FP) Relay (53) (5) |
| 6 | Not Used |
| 7 | J89- Daytime Running Lights Change over Relay (173) (6) (7) |
| 8 | J99- Heated Mirror Relay (53) (7) (1) -J677- Fuel Filler Lid Unlock Relay (53) |
| 9 | J641- Alarm Horn Relay (8) |
| 10 | J237- Alarm System Light Flasher Relay (8) |
| 10 | J135- Third Speed Coolant Fan Control (FC) Relay (100) (9) |
| 10 | J17- Fuel Pump (FP) Relay (53) (10) |
| 10 | J299- Secondary Air Injection (AIR) Pump Relay (100) (11) |
| 10 | J359- Preheating Coolant, Low Heat Output Relay (100) (12) |
| 11 | J226- Park/Neutral Position (PNP) Relay (126) (13) (3) |
| 11 | J207- Starting interlock Relay (176), From model year 2005 (13) |
| 12 | J317- Power Supply relay (terminal 30, B+)(109) (15) |
| 13 | J360- Preheating Coolant High Heat Output Relay (53) (12) |
| (1) Vehicles with manual transmission. (2) Vehicles with 2.5L engine code BPS (ULEV) (3) Vehicles with Direct Shift Automatic Transmission (DSG) 02E. () Vehicles with 2.5L engine, code BPR (SULEV). (5) Vehicles with 1.9L engine, code BEW, from July 2005 (model year 2006). (6) Only vehicles with Daytime Running Lights. (7) Only USA/CAN. (8) Vehicles with Telematics. (9) Vehicles with 1.8L engine, code AWV, AWP, BKF, BNU. (10) Vehicles with 1.9L engine, code BEW, from model year 2004 to model year 2005. (11) Vehicles with 2.5L engine, code BPR, BPS. (12) Vehicles with 1.9 L engine, code BEW, from June 2003 to December 2006. (13) Vehicles with 6 speeds automatic transmission 09G, with Tiptronic. () From model year 2005. (15) Vehicles with 1.9L engine, code ALH, BEW. Note: The number(s) in parentheses indicates production control number stamped on relay housing. | |
| (1) | Vehicles with manual transmission. |
| (2) | Vehicles with 2.5L engine code BPS (ULEV) |
| (3) | Vehicles with Direct Shift Automatic Transmission (DSG) 02E. |
| () | Vehicles with 2.5L engine, code BPR (SULEV). |
| (5) | Vehicles with 1.9L engine, code BEW, from July 2005 (model year 2006). |
| (6) | Only vehicles with Daytime Running Lights. |
| (7) | Only USA/CAN. |
| (8) | Vehicles with Telematics. |
| (9) | Vehicles with 1.8L engine, code AWV, AWP, BKF, BNU. |
| (10) | Vehicles with 1.9L engine, code BEW, from model year 2004 to model year 2005. |
| (11) | Vehicles with 2.5L engine, code BPR, BPS. |
| (12) | Vehicles with 1.9 L engine, code BEW, from June 2003 to December 2006. |
| (13) | Vehicles with 6 speeds automatic transmission 09G, with Tiptronic. |
| () | From model year 2005. |
| (15) | Vehicles with 1.9L engine, code ALH, BEW. |
IDENTIFYING RELAYS ON THIRTEEN POSITION AUXILIARY RELAY PANEL (INSTRUMENT PANEL - LEFT SIDE)
Location Of Inside Housing Relays - Engine Compartment - Left Side
Inside housing relays, in engine compartment, left side, to the left of brake fluid reservoir, inside housing, from model year 2003 to model year 2005.
Scheme 23
| Relay Location | Function/Component |
|---|---|
| 1 | J299- Secondary Air Injection (AIR) Pump Relay (100) (1) (2) |
| 2 | J271- Motronic Engine Control Module (ECM) Power Supply Relay (428)(429) (3) (4) |
| 1 | J360- Preheating Coolant, High Heat Output Relay (100) (5) |
| 2 | J359- Preheating Coolant, Low Heat Output Relay (53) (5) |
| (1) Engine 1.8L, code AWV, AWP BKF, BNU. (2) Engine 2.0L, code AVH, AZG, BEV. (3) Engine 1.8L, code AWV, AWP BKF, BNU. (4) Engine 2.0L, code AVH, AZG, BEV, BHP. (5) Engine 1.9L, codes ALH, BEW, from model year 2003 to model year 2005. Note: The number(s) in parentheses indicates production control number stamped on relay housing. | |
| (1) | Engine 1.8L, code AWV, AWP BKF, BNU. |
| (2) | Engine 2.0L, code AVH, AZG, BEV. |
| (3) | Engine 1.8L, code AWV, AWP BKF, BNU. |
| (4) | Engine 2.0L, code AVH, AZG, BEV, BHP. |
| (5) | Engine 1.9L, codes ALH, BEW, from model year 2003 to model year 2005. |
IDENTIFYING INSIDE HOUSING RELAYS (ENGINE COMPARTMENT - LEFT SIDE)
Location Of Additional Relay Panel In Plenum Chamber, Center - From June 2003 To December 2006
The additional relay panel is located in the center of the plenum chamber in the engine compartment. The Automatic Glow Time Control Module (-J179-) is located at the additional relay panel, refer to illustration below.
Scheme 24
See also:
• FUSE ARRANGEMENTS IN FUSE BRACKET/BATTERY - ENGINE COMPARTMENT
• FUSES ON RELAY PANEL
• RELAYS ON THIRTEEN POSITION AUXILIARY RELAY PANEL
• FUSE ARRANGEMENTS ON THIRTEEN POSITION AUXILIARY RELAY PANEL
• FUSE ARRANGEMENTS IN FUSE PANEL, INSTRUMENT PANEL - LEFT SIDE
• LOCATION OF RELAYS ON RELAY PANEL
• LOCATION OF INSIDE HOUSING RELAYS - ENGINE COMPARTMENT - LEFT SIDE
• LOCATION OF ADDITIONAL RELAY PANEL IN PLENUM CHAMBER, CENTER - FROM JUNE 2003 TO DECEMBER 2006
