Glass, Window Regulators (Sedan) (A5 Platform): Overview Volkswagen Jetta V

Windows 8 illustrations ~580 words

WINDOW OVERVIEW

Note. The illustration shows a right door hinge. The left door hinge is identical. Bolt -4- is accessible from inside and outside. The bolt as viewed from the outside has a right-hand thread. Perspective: seen from the outside, bolt is loosened by turning toward left, seen from the inside, bolt is loosened by turning toward right.

Scheme 1

Scheme 1: WINDOW OVERVIEW
Scheme 1: WINDOW OVERVIEW
  1. Door Window Removing and installing, refer to «WINDOW»(ref-479569-S30297102692012061300000) .
  2. Window Guide Removing and installing, refer to «WINDOW GUIDE»(ref-479569-S02813204312012061300000) .
  3. Mount
  4. Bolt 8 Nm Accessible from outside (right-hand thread), loosen by turning toward left (it is necessary to remove outer door plate, refer to «OUTER DOOR PANEL»(ref-479611-S22097902592012061300000) ). Accessible from inside, loosen by turning toward right (it is necessary to remove front door trim, refer to «Removal and Installation»(ref-479602-S11173424082012061300000) ). Quantity: 2
  5. Window Regulator Removing and installing, refer to «WINDOW REGULATOR»(ref-479569-S04870208512012061300000) .
  6. Cover Quantity: 2
  7. Window Regulator Motor Removing and installing, refer to «WINDOW REGULATOR MOTOR»(ref-479569-S12715183442012061300000) .

WINDOW GUIDE OVERVIEW

Note. The illustration shows a right door hinge. The left door hinge is identical. For reasons of clarity, outer door plate is not depicted in the illustration.

Scheme 2

Scheme 2: WINDOW GUIDE OVERVIEW
Scheme 2: WINDOW GUIDE OVERVIEW
  1. Window Guide
  2. Trim
  3. Screw 2 Nm Quantity: 2
  4. Window Frame At Inner Door Part
  5. Trim Molding Fastener Expanding rivet or bolt.
  6. Window Guide Trim Molding Depending on equipment Removing and installing, refer to «WINDOW GUIDE TRIM MOLDING»(ref-479569-S17302135622012061300000) .

WINDOW REGULATOR OVERVIEW

Note. The illustration shows a right door regulator. The left door regulator is identical.

Scheme 3

Scheme 3: WINDOW REGULATOR OVERVIEW
Scheme 3: WINDOW REGULATOR OVERVIEW
  1. Window Regulator Removing and installing, refer to «WINDOW REGULATOR»(ref-479569-S04870208512012061300000) .
  2. Bolt 8 Nm Quantity: 4
  3. Bolt 8 Nm Quantity: 5
  4. Drive Motor
  5. Mounting Plate

WINDOW REGULATOR MOTOR OVERVIEW

Note. The illustration shows a right door motor. The left door motor is identical.

Scheme 4

Scheme 4: WINDOW REGULATOR MOTOR OVERVIEW
Scheme 4: WINDOW REGULATOR MOTOR OVERVIEW
  1. Window Regulator Motor Removing and installing, refer to «WINDOW REGULATOR MOTOR»(ref-479569-S12715183442012061300000) .
  2. Bolt 3.5 Nm Quantity: 3

Note. The illustration shows a right door. The left door is identical.

Scheme 5

Scheme 5: WINDOW OVERVIEW
Scheme 5: WINDOW OVERVIEW
  1. Door Window Removing and installing, refer to «WINDOW»(ref-479569-S01217538692012061300000) .
  2. Window Guide Component of fixed door window. Removing and installing, refer to «FIXED DOOR WINDOW WITH WINDOW GUIDE»(ref-479569-S24112377942012061300000) .
  3. Fixed Door Window Component of window guide Removing and installing, refer to «FIXED DOOR WINDOW WITH WINDOW GUIDE»(ref-479569-S24112377942012061300000) .
  4. Window Regulator Guide
  5. Spreader Plug Always replace when performing assembly work at door window.
  6. Spreader Pin Always replace when performing assembly work at door window.
  7. Cover
  8. Window Regulator Removing and installing, refer to «WINDOW REGULATOR»(ref-479569-S31562781892012061300000) .
  9. Window Regulator Motor Removing and installing, refer to «WINDOW REGULATOR MOTOR»(ref-479569-S17067132732012061300000) .

Note. The illustration shows a right door regulator. The left door regulator is identical.

Scheme 6

Scheme 6: WINDOW REGULATOR OVERVIEW
Scheme 6: WINDOW REGULATOR OVERVIEW
  1. Window Regulator Removing and installing, refer to «WINDOW REGULATOR»(ref-479569-S31562781892012061300000) .
  2. Bolt 8 Nm Quantity: 4
  3. Mounting Plate
  4. Drive Motor
  5. Bolt 8 Nm Quantity: 2

Note. The illustration shows a right door motor. The left door motor is identical.

Scheme 7

Scheme 7: WINDOW REGULATOR MOTOR OVERVIEW
Scheme 7: WINDOW REGULATOR MOTOR OVERVIEW
  1. Connector
  2. Bolt 3.5 Nm Quantity: 3
  3. Window Regulator Motor Removing and installing, refer to «WINDOW REGULATOR MOTOR»(ref-479569-S17067132732012061300000) .

FIXED DOOR WINDOW WITH WINDOW GUIDE OVERVIEW

Note. The illustration shows a right door. The left door is identical.

Scheme 8

Scheme 8: FIXED DOOR WINDOW WITH WINDOW GUIDE OVERVIEW
Scheme 8: FIXED DOOR WINDOW WITH WINDOW GUIDE OVERVIEW
  1. Window Guide Component of fixed door window. Removing and installing, refer to «FIXED DOOR WINDOW WITH WINDOW GUIDE»(ref-479569-S24112377942012061300000) .
  2. Fixed Door Window Component of window guide. Removing and installing, refer to «FIXED DOOR WINDOW WITH WINDOW GUIDE»(ref-479569-S24112377942012061300000) .
  3. Window Frame At Inner Door Part
  4. Window Guide Trim Molding Depending on equipment. Removing and installing, refer to «WINDOW GUIDE TRIM MOLDING»(ref-479569-S11607178792012061300000) .
  5. Expanding Rivet
