2.0L - Cooling System - Engine Code(s): Cbfa & Ccta (Sedan) (A5 Platform): Overview Volkswagen Jetta V

COOLANT PIPES OVERVIEW

Note. Install only approved clamps for securing hose connections. The arrows on the coolant pipes and ends of the coolant hoses must align when installing.

Coolant hose connection diagram. Refer to one of the following

1. With a manual transmission, refer to «COOLANT HOSE CONNECTION DIAGRAM»(ref-479585-S07807026032012061300000) .
2. With a Direct Shift Gearbox (DGS), refer to «COOLANT HOSE CONNECTION DIAGRAM»(ref-479585-S16389889522012061300000) .

Scheme 147

1. Front Coolant Pipes Removing and installing, refer to «FRONT COOLANT PIPES»(ref-479585-S02464388712012061300000) .
2. Coolant Hose From the turbocharger.
3. Coolant Hose To the coolant expansion tank.
4. Bolt 5 Nm
5. O-ring Always replace.
6. Coolant Hose To the heater core.
7. Small Coolant Pipe Removing and installing, refer to «SMALL COOLANT PIPE»(ref-479585-S30103644822012061300000) .
8. Bolt 9 Nm
9. Coolant Hose
10. Bolt 5 Nm
11. Coolant Hose From the After-Run Coolant Pump -V51-.
12. Coolant Hose To the after-run coolant pump.

Scheme 148

1. Bracket
2. Bolt 40 Nm
3. Coolant Hose Coolant hose connection diagram. Refer to one of the following: With a manual transmission, refer to «COOLANT HOSE CONNECTION DIAGRAM»(ref-479585-S07807026032012061300000) . With a Direct Shift Gearbox (DGS), refer to «COOLANT HOSE CONNECTION DIAGRAM»(ref-479585-S16389889522012061300000) .
4. Coolant Hose Coolant hose connection diagram. Refer to one of the following: With a manual transmission, refer to «COOLANT HOSE CONNECTION DIAGRAM»(ref-479585-S07807026032012061300000) . With a Direct Shift Gearbox (DGS), refer to «COOLANT HOSE CONNECTION DIAGRAM»(ref-479585-S16389889522012061300000) .
5. After-Run Coolant Pump -V51
6. Bracket
7. Bolt 8 Nm
