Engine/transmission assembly, tightening torques
| Fastener connection | Tightening torque | |
|---|---|---|
| Engine to transmission | ||
| M10 | 60 Nm (44 ft lb) | |
| M12 | 80 Nm (59 ft lb) | |
| Axle shafts to drive flanges | 45 Nm (33 ft lb) | |
| Front exhaust pipe to exhaust manifold | 40 Nm (30 ft lb) | |
| Front exhaust pipe to Three Way Catalytic Converter (TWC) | 25 Nm 18 ft lb) | |
| Engine carrier to body | 80 Nm (59 ft lb) | |
TIGHTENING TORQUES (ENGINE/TRANSMISSION ASSEMBLY)
Engine/transmission mounts, tightening torques
(Bolts oiled)
Front engine mount
A - 60 Nm (44 ft lb)
B - 60 Nm (44 ft lb)
C = 55 Nm (41 ft lb)
Identifying Front Engine Mount. Scheme 144
Right rear engine mount
A = 60 Nm (44 ft lb)
B = 60 Nm (44 ft lb)
C - 25 Nm (18 ft lb)
Identifying Right Rear Engine Mount. Scheme 145
Left rear engine mount
A = 60 Nm (44 ft lb)
B = 25 Nm (18 ft lb)
C - 25 Nm (18 ft lb)
Identifying Left Rear Engine Mount. Scheme 146
Loosening and tightening
- Mount counter-hold tool VW 558 to drive plate with hex bolt (M8x45). Place two M10 hex nuts between counter - hold tool and drive plate.
Identifying Counter-Holding Points On Camshaft. Scheme 147
- Mount drive plate on crankshaft.
- Install at least 3 old mounting bolts and tighten. Tightening torque: 30 Nm (22 ft lb)
- Check dimension -a- by using a straight edge and depth gauge to measure through the three holes for mounting torque converter. Calculate the average. see scheme 44: Checking Dimension -a- By Using Straight Edge And Depth Gauge
- Compare average measurement with specification. Specification (measured distance + thickness of straight edge): 15.7-16.5 mm (0.606-0.650 in.)
If the specified dimension is not obtained
- Remove drive plate again and fit appropriate shim -1-.
If the specification is obtained
Scheme 148
- Install drive plate using new mounting bolts and tighten. Tightening torque: Stage I: 60 Nm (44 ft lb) Stage II: an additional 1/4 turn (90 °) see scheme 45: Fitting Shim To Drive Plate
