2.5L - Engine Assembly - Engine Code(s): Cbta & Cbua: Specifications Volkswagen Golf Mk7

FASTENER TIGHTENING SPECIFICATIONS

Scheme 254

1. = 40 Nm + an additional 90° (1/4) turn 1
2. = 20 Nm + an additional 90° (1/4) turn 1
3. = 60 Nm + an additional 90° (1/4) turn 1

Scheme 255

A - = 40 Nm + an additional 90° (1/4) turn 1

B - = 60 Nm + an additional 90° (1/4) turn 1

Scheme 256

Note. First secure the pendulum support to the transmission and then to the subframe.

A - Strength category 8.8: = 40 Nm + an additional 90° (1/4) turn 1

A - Strength category 10.9: = 50 Nm + an additional 90° (1/4) turn 1

B - = 100 Nm + an additional 90° (1/4) turn 1

Removing: First remove the bolt -B-, then the bolts -A-.

Installing: First install the bolts -A-, then the bolt -B-.

1. 1 Always replace

Scheme 257

1. There must be at least 10 to 13 mm -a- between the engine mount bracket -2- and the right longitudinal member.
2. The casting edge on the engine mount bracket -2- must be parallel to the engine mount support arm -1- ; dimension -x- must be the same at the front and the rear.

Note. Distance -a- can also be checked with corresponding round stock.

Only if there is a noise (the engine or transmission hitting the longitudinal member when driving around curves) and dimension -a- is not within 10 to 13 mm

Adjust the engine mount.
