2.0L - Fuel Supply - Engine Code(s): Cjaa: Component Locations Volkswagen Golf Mk7

INSTALLED LOCATION OF THE FUEL DELIVERY UNIT FLANGE

Note. Ignore the fuel level sensor 2 (second graphic)

Scheme 173

The mark on the flange must align with the mark on the fuel tank -arrow- (first graphic).

Note. The mark on the fuel tank is difficult to see.

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

1. Fuel Extracting Adapter VAS 5190/3
2. Pressure Tester (diesel) VAS 6551
3. Multi-Meter V.A.G 1526 D
4. Current Clamp V.A.G 1526 B/2
5. Fuel Extracting Device VAS 5190
6. Wrench T10202
7. Test Instrument Adapter/DSO (5-pin) VAS 5565
8. Fuel Inj. Pressure Gauge CIS V.A.G 1318
9. Release Tool T10238
10. Torque Wrench (40-200 Nm) V.A.G 1332
11. Torque Wrench (5-50 Nm) V.A.G 1331
12. Engine-/Gearbox Jack V.A.G 1383 A
13. Suction Pump VAS 5226
14. Special Wrench, Long Reach VAS 6543
15. Hose Clip Pliers VAS 6340
