WINDSHIELD WASHER SYSTEM OVERVIEW

Note. Two different versions of reservoir for windshield washer and headlamp cleaning systems are installed, depending on equipment. Illustration shows the version for vehicles without parking heater.

Scheme 13

1. Washer Nozzles For Front Windshield Washer System Removing and installing, refer to «SPRAY NOZZLES FOR WINDSHIELD WASHER SYSTEM»(ref-475564-S05758830022012052300000) . Adjusting, refer to «WINDSHIELD WASHER SYSTEM SPRAY NOZZLES, ADJUSTING»(ref-475564-S29116140212012052300000) .
2. Angle Coupling Connection at washer nozzle for front windshield washer system. Washer hose couplings, overview, refer to «WASHER FLUID LINE HOSE CONNECTIONS»(ref-475564-S21787323492012052300000) .
3. Y-Connection Divides washer fluid line to the windshield washer spray nozzles.
4. Filler Tube For Tank For Windshield Washer System and Headlamp Cleaning System Removing and installing, refer to «WINDSHIELD AND HEADLAMP WASHER FLUID RESERVOIR»(ref-475564-S41149381022012052300000) .
5. Washer Fluid Reservoir Removing and installing, refer to «WINDSHIELD AND HEADLAMP WASHER FLUID RESERVOIR»(ref-475564-S41149381022012052300000) .
6. Windshield Washer Pump -V5- Removing and installing, refer to «WINDSHIELD WASHER PUMP -V5»(ref-475564-S16139848892012052300000) .
7. Angle Coupling Connection on Windshield Washer Pump -V5-. Washer hose couplings, overview, refer to «WASHER FLUID LINE HOSE CONNECTIONS»(ref-475564-S21787323492012052300000) .
8. Windshield Washer Fluid Level Sensor -G33- Removing and installing, refer to «WINDSHIELD WASHER FLUID LEVEL SENSOR -G33»(ref-475564-S10283307212012052300000) .
9. Hose Hose repair, refer to «HOSES, REPAIRING»(ref-475564-S15392606942012052300000) .

Scheme 14

1. Spray Nozzle Holder With Spray Nozzle, Right Washer jet retainer, removing and installing, refer to «HEADLAMP SPRAY NOZZLE HOLDER»(ref-475564-S06577390972012052300000) . Spray Nozzles, adjusting, refer to «HEADLAMP WASHER SYSTEM SPRAY NOZZLES, ADJUSTING»(ref-475564-S05769461602012052300000) . Lift cylinder for spray nozzles, removing and installing, refer to «SPRAY JET TELESCOPING CYLINDER»(ref-475564-S02605039592012052300000) .
2. Spray Nozzle Holder With Spray Nozzle, Left Washer jet retainer, removing and installing, refer to «HEADLAMP SPRAY NOZZLE HOLDER»(ref-475564-S06577390972012052300000) . Spray Nozzles, adjusting, refer to «HEADLAMP WASHER SYSTEM SPRAY NOZZLES, ADJUSTING»(ref-475564-S05769461602012052300000) . Lift cylinder for spray nozzles, removing and installing, refer to «SPRAY JET TELESCOPING CYLINDER»(ref-475564-S02605039592012052300000) .
3. Angle Coupling Connection to lift cylinder for left spray nozzle. Washer hose couplings, overview, refer to «WASHER FLUID LINE HOSE CONNECTIONS»(ref-475564-S21787323492012052300000) .
4. T-Connection Divides washer fluid line to spray nozzles of headlamp cleaning system.
5. Angle Coupling Connection to lift cylinder for right spray nozzle. Divides washer fluid line to spray nozzles of headlamp cleaning system. Washer hose couplings, overview, refer to «WASHER FLUID LINE HOSE CONNECTIONS»(ref-475564-S21787323492012052300000) .
6. Angle Coupling
7. Filler Tube For Tank For Windshield Washer System And Headlamp Cleaning System Removing and installing, refer to «WINDSHIELD AND HEADLAMP WASHER FLUID RESERVOIR»(ref-475564-S41149381022012052300000) .
8. Washer Fluid Reservoir Removing and installing, refer to «WINDSHIELD AND HEADLAMP WASHER FLUID RESERVOIR»(ref-475564-S41149381022012052300000) .
9. Angle Coupling Connection on Headlamp Washer Pump -V11-. Washer hose couplings, overview, refer to «WASHER FLUID LINE HOSE CONNECTIONS»(ref-475564-S21787323492012052300000) .
10. Headlamp Washer System Pump -V11- Removing and installing, refer to «HEADLAMP WASHER PUMP -V11»(ref-475564-S05881414732012052300000) .
11. Windshield Washer Fluid Level Sensor -G33- Removing and installing, refer to «WINDSHIELD WASHER FLUID LEVEL SENSOR -G33»(ref-475564-S10283307212012052300000) .

Scheme 15

Note. Wiper cannot be activated with hood open and vehicle at standstill. In the service-/winter position, the wiper blades can be changed without hindrance or the wiper arms brought upward to prevent freezing against the front windshield.

Briefly switch ignition on and off again.

Move the windshield wiper stalk down into the one-touch wiping position within 10 seconds after switching off ignition.

The windshield wipers assume the service position.
