BACKREST SEAT ADJUSTMENT SWITCH

Note. Removing and installing on the left side of the vehicle is described here. Removing and installing on the right side is identical.

Removing

Switch off ignition.

Remove backrest release operating knob -1-.

Scheme 44

Scheme 44: BACKREST SEAT ADJUSTMENT SWITCH

Position a screwdriver in -direction of arrow- and pry trim -2- out of mounts.

Note. When installing, operating knob securing spring must be replaced.

Loosen switch -1- from trim -2-.

Scheme 45

Scheme 45

Disconnect wiring harness from switch.

Installation

Install in reverse order of removal.

POWER FORWARD/BACK ADJUSTMENT UNIT

The following describes removing and installing the seat forward/back adjustment on the left front seat frame. Removal and installation of the right seat longitudinal adjuster is performed in the same way.

Removing

Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095.

Remove front seat. Refer to FRONT SEAT

Attach the seat to the fixture for seat repair VAS 6136.

Remove the trim from on the tunnel side from the seat. Refer to SEAT TRIM, TUNNEL-SIDE

Remove the trim on the sill-side from the power seat. Refer to POWER SEAT SILL-SIDETRIM

Remove retainer and power seat bracket. Refer to BRACKET AND SUPPORT, POWER SEAT

Remove seat drawer mount. Refer to SEAT DRAWER MOUNT

Remove front seat backrest. Refer to LEFT FRONT SEAT BACKREST

Remove cover and cushion from front seat backrests. Refer to FRONT SEAT PAN COVERS AND UPHOLSTERY

Remove screws -1- and -2- on right side.

Remove screw -3- in rear area.

Note. Screw -3- in installation position points from inside toward outside.

Remove screw -4- in front area.

Remove seat pan -5- from longitudinal adjuster -6-.

Scheme 46

Scheme 46: POWER FORWARD/BACK ADJUSTMENT UNIT

Installation

Install in reverse order of removal.

POWER SEAT ANGLE ADJUSTMENT UNIT

Removal and installation of seat inclination adjuster is described for left backrest frame. Removal and installation of the right seat inclination adjuster is performed in the same way.

Removing

Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095.

Remove front seat. Refer to FRONT SEAT

Attach the seat to the fixture for seat repair VAS 6136.

Remove the trim from on the tunnel side from the seat. Refer to SEAT TRIM, TUNNEL-SIDE

Remove the trim on the sill-side from the power seat. Refer to POWER SEAT SILL-SIDETRIM

Remove retainer and power seat bracket. Refer to BRACKET AND SUPPORT, POWER SEAT

Remove seat drawer mount. Refer to SEAT DRAWER MOUNT

Remove front seat backrest. Refer to LEFT FRONT SEAT BACKREST

Remove cover and cushion from front seat backrests. Refer to FRONT SEAT PAN COVERS AND UPHOLSTERY

Disconnect wiring harness -1- from inclination adjuster -2-.

Remove the bolt -3-.

Remove the two sets of bolts -4- and -5-.

Remove inclination adjustment -2- from seat frame.

Scheme 47

Scheme 47: POWER SEAT ANGLE ADJUSTMENT UNIT

Installation

Install in reverse order of removal.

POWER SEAT HEIGHT ADJUSTMENT UNIT

Removal and installation of seat height adjuster is described for left backrest frame. Removal and installation of the right seat height adjuster is performed in the same way.

Removing

Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095.

Remove front seat. Refer to FRONT SEAT

Attach the seat to the fixture for seat repair VAS 6136.

Remove the trim from on the tunnel side from the seat. Refer to SEAT TRIM, TUNNEL-SIDE

Remove the trim on the sill-side from the power seat. Refer to POWER SEAT SILL-SIDETRIM

Remove retainer and power seat bracket. Refer to BRACKET AND SUPPORT, POWER SEAT

Remove seat drawer mount. Refer to SEAT DRAWER MOUNT

Remove front seat backrest. Refer to LEFT FRONT SEAT BACKREST

Remove cover and cushion from front seat backrests. Refer to FRONT SEAT PAN COVERS AND UPHOLSTERY

Remove screw -1- in rear area of seat base.

Note. Screw -1- in installation position points from inside toward outside.

Disconnect wiring harness -2- from height adjuster -3-.

Remove the two bolts -4-.

Remove height adjuster -3- from mounts in seat base.

Scheme 48

Scheme 48: POWER SEAT HEIGHT ADJUSTMENT UNIT

Installation

Install in reverse order of removal.

POWER SEAT BACKREST ADJUSTMENT MOTOR

The backrest adjustment motor cannot be replaced separately. In this case, the backrest frame must be replaced.

The instructions for removing the backrest frame are integrated in the information "Front Seat Pan Covers and Upholstery, Removing and Installing", refer to FRONT SEAT BACKREST COVERS AND UPHOLSTERY
