FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|
| Chain Tensioner with Tensioning Rail to Oil Pump with Balance Shaft Drive Bolt | | 15 |
| Charge Air Pipe to Oil Pan Bolt | | 8 |
| Cover to Oil Pump with Balance Shaft Drive Bolt (3) |
| | 9 |
| 40 |
| Oil Cooler/Bracket to Oil Filter Bracket Bolt | | 25 |
| Oil Drain Plug to Oil Pan (1) | | 30 |
| Oil Filter Bracket to Cylinder Block Bolt (1) | | 15 + 90° |
| Oil Filter Housing to Oil Filter Bracket | | 25 |
| Oil Intake Pipe to Oil Pump with Balance Shaft Drive Bolt | | 8 |
| Oil Pressure Switch Ground Wire to Cylinder Block Bolt (1) , (4) | | 15 + 90° |
| Oil Pressure Switch to Oil Filter Bracket | | 20 |
| Oil Pump with Balance Shaft Drive to Cylinder Block Bolt (1) , (2) | | 15 + 90° |
| Oil Pump Chain Sprocket Bolt (1) | | 20 + 90° |
| Oil Pump Cover to Oil Pump with Balance Shaft Drive Bolt | | 8 |
| Sealing Flange to Cylinder Block Bolt | | 15 |
| (1) Always replace (2) Note the different length of bolts see scheme 30 (3) For the bolt tightening clarification, see -items 6 and 8- in OIL PUMP WITH BALANCE SHAFT DRIVE. (4) Ground wire is for the 1 pin oil pressure switch only. |
| (2) | Note the different length of bolts see scheme 30 |
| (3) | For the bolt tightening clarification, see -items 6 and 8- in OIL PUMP WITH BALANCE SHAFT DRIVE . |
| (4) | Ground wire is for the 1 pin oil pressure switch only. |
Oil Pan Bolt Tightening Sequence and Specification
Scheme 1
Tighten the oil pan bolt as follows
- Tighten the oil pan to cylinder block bolts -1 through 14- very lightly in a diagonal sequence.
- Tighten the oil pan to transmission bolts -arrows- lightly.
- Tighten the oil pan to cylinder block bolts -1 through 14- again, lightly in a diagonal sequence.
- Tighten the oil pan to transmission bolts -arrows- to 40 Nm.
- Tighten the oil pan to cylinder block bolts -1 through 14- in a diagonal sequence to 15 Nm.
