BASIC SETTING FOR NEWLY INSTALLED CSC ROOF Volkswagen Eos I

Convertible Top 10 illustrations ~791 words

BASIC SETTING FOR NEWLY INSTALLED CSC ROOF

Note. The procedure for adjusting individual buffers can be derived from this procedure. The other buffers described are to be ignored when adjusting a single buffer. The basic setting should be performed in the sequence described. Always perform work evenly on left and right. The following describes only one side. Check whether a bolted stop buffer is installed. If an inserted stop buffer -1- is installed, replaced this with a bolted stop buffer.

Scheme 97

Scheme 97: BASIC SETTING FOR NEWLY INSTALLED CSC ROOF

Open roof with convertible top operating switch until rear window frame is stored and rear lid with rear shelf tips up.

Switch off ignition.

Adjust -dimension a- from 5.5 mm between stop buffer -1- and the glass panel -2-. To do this, loosen lock nut -4- on stop screw -3- and adjust stop screw until -dimension a- has reached 5.5 mm. Re-tighten lock nut.

Slide C-Segment Pretensioning Clamps VAS 6369 -5- onto glass panel -2- and rear window frame -6-.

Note. Construct the stop buffer adjustment caps -4- with two stop buffer cover caps. To do this, cut a 20 mm hole in center of cover caps.

Scheme 98

Scheme 98

Remove locating lug cover cap -5-.

Loosen the bolts -6- but do not remove them, loosen the guide wedge and pull the wedge out as far as possible.

The guide wedges -5- adjust themselves during the following basic setting procedure.

Remove covers from storage buffers -4- and press adjusting caps on.

Loosen storage buffer screws -3-.

Loosen lock nuts -1- on adjusting screws -2- on main hinge and install adjusting screw in 2 - 3 turns.

Scheme 99

Scheme 99

Loosen screws -1- on stop buffer -2- on rear shelf and remove buffer completely.

The stop buffers -2- adjust themselves during the following basic setting procedure.

Open -arrow- stop covers -6- on side rails -7- on assembly frame.

Remove cover caps -3- for stop buffer -4- on installation frame.

Scheme 100

Scheme 100

Open roof farther with convertible top operating switch until roof is stored in luggage compartment. Rear lid with rear shelf remains tipped up.

Switch off ignition.

Turn stop buffer -2- as far as "stop" on roof center section -1-.

Check whether mount on main hinge -5- is aligned with storage buffer with adjusting cap -3-.

Tighten storage buffer screw -4-. Tightening specification: 20 Nm.

Scheme 101

Scheme 101

Operate convertible top operating switch until the top closing procedure is complete.

Open tailgate.

Lay one paper strip -4- each with necessary lengths between stop buffer -1-, rear shelf -2- and rear window -3-.

Lay an additional paper strip -4- each with necessary length between stop buffer -6- on rear window frame -5- and glass panel -7-.

Close tailgate.

Scheme 102

Scheme 102

Open tailgate.

Check if side guide -1- on installation frame rests on locking bracket -2- -arrow-.

Check if stop buffer -4- on installation frame -3- contacts rear window frame striker pin -5-. Adjust stop buffer if necessary.

Scheme 103

Scheme 103

Remove paper strips between stop buffers on rear shelf and rear window. Paper strips may be removed only with difficulty.

Remove paper strips between stop buffers on rear window frame and glass panel. Paper strips may be removed only with difficulty.

Scheme 104

Scheme 104

Close roof with convertible top operating switch until roof pillars rest on windshield frame. Rear window frame remains resting on roof center section and rear lid with rear shelf remains tipped up.

Remove the pretensioning clamps for rear window frame VAS 6369 between the glass panel and the rear window frame.

Close -arrow c- covers -6- for side guides -7- on assembly frame.

Press -arrow b- cover cap -5- on stop buffer -4- onto assembly frame -3-.

Pull stop buffer -2- on rear shelf out 2 stops -arrow a- and tighten screw -1-.

Scheme 105

Scheme 105

Remove adjustment cap from stop buffer -3- and press -arrow a- cap onto stop buffer -3-.

Remove the stop buffer -2- 2 turns and tighten lock nut -1-.

Tighten the screws -6- and install the caps -5-.

Close roof completely.

Scheme 106

Scheme 106: INTERIOR TRIM ASSEMBLY OVERVIEW
  1. Sun shade Removing, refer to «SUN SHADE, REMOVING»(ref-475629-S24344021762012052300000) Installing, refer to «SUN SHADE, INSTALLING»(ref-475629-S29833042642012052300000)
  2. Connecting rod Moving connecting rod from front rail to rear rail on sun shade.
  3. Tensioned headliner rail Removing, refer to «TENSIONED HEADLINER RAIL, REMOVING»(ref-475629-S24281947452012052300000) Installing, refer to «TENSIONED HEADLINER RAIL, INSTALLING»(ref-475629-S20700140442012052300000)
  4. Tensioned headliner Removing, refer to «TENSIONED HEADLINER, REMOVING»(ref-475629-S16920673362012052300000) Installing, refer to «TENSIONED HEADLINER, INSTALLING»(ref-475629-S00240094042012052300000)
  5. Rear Window Frame Upper Trim Removing and Installing, refer to «REAR WINDOW FRAME UPPER TRIM»(ref-475629-S16669893892012052300000)
  6. Rear Window Frame Lower Trim Removing and Installing, refer to «REAR WINDOW FRAME LOWER TRIM»(ref-475629-S14373645002012052300000)
  7. Tensioned Headliner Tensioning Bands Removing and Installing, refer to «TENSIONED HEADLINER TENSIONING BANDS»(ref-475629-S21754956662012052300000)
  8. Roof pillar trim tensioning bands
  9. Roof pillar trim Removing and Installing, refer to «ROOF PILLAR TRIM»(ref-475629-S16623590902012052300000)
