2.5L - Engine Assembly - Engine Code(s): Bpr & Bps (Hatchback): Specifications Volkswagen Beetle A4 facelift

Mechanical 3 illustrations ~110 words

FASTENER TIGHTENING SPECIFICATIONS

ComponentFastener SizeNm
Bolts and Nuts
M610
M715
M828
M1040
M1260

Engine Mount

Scheme 48

Scheme 48
Scheme 48
  1. Mount to engine - 40 Nm + 90° (1/4) additional turn 1
  2. Mount to chassis - 40 Nm + 90° (1/4) additional turn 1
  3. Support to engine/chassis - 20 Nm + 90° (1/4) additional turn 1

Transmission Mount

Scheme 49

Scheme 49
Scheme 49
  1. Mount to chassis - 40 Nm + 90° (1/4) additional turn 1
  2. Mount to chassis - 25 Nm
  3. Mount to transmission mount bracket - 100 Nm

Pendulum Support

Scheme 50

Scheme 50
Scheme 50
  1. To transmission - 50 Nm 1
  2. To transmission - 50 Nm 1
  3. To subframe - 25 Nm 1
  1. 1 Replace bolts

More articles — 2.5L - Engine Assembly - Engine Code(s): Bpr & Bps (Hatchback)
