Power Window Control System (Diagnostic Codes & Symptom Tests): Overview Toyota Venza I

Windows 13 illustrations ~1302 words

DESCRIPTION

The power window regulator motor is operated by the power window regulator master switch assembly or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.

This DTC is output when the power window regulator motor assembly has a malfunction, or the ECU built into the regulator motor assembly determines that the fully closed window position has deviated approximately 20 mm (0.787 in.) or more from the normal position.

HINT

DTC B2311 can be stored in each power window regulator motor assembly (power window ECU).

DTC No.DTC Detection ConditionTrouble Area
B2311Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal positionBattery disconnected when ignition switch ON Power window regulator motor assembly (for driver side) Incorrect installation of power window components Overheated power window regulator motor assembly

D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE))

DTC No.DTC Detection ConditionTrouble Area
B2311Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal positionBattery disconnected when ignition switch ON Power window regulator motor assembly (for front passenger side) Incorrect installation of power window components Overheated power window regulator motor assembly

P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE))

DTC No.DTC Detection ConditionTrouble Area
B2311Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal positionBattery disconnected when ignition switch ON Power window regulator motor assembly (for rear LH side) Incorrect installation of power window components Overheated power window regulator motor assembly

RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE))

DTC No.DTC Detection ConditionTrouble Area
B2311Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal positionBattery disconnected when ignition switch ON Power window regulator motor assembly (for rear RH side) Incorrect installation of power window components Overheated power window regulator motor assembly

RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE))

The power window regulator motor assembly is operated by the power window regulator master switch assembly or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.

This DTC is output when the ECU built into the regulator motor determines that the power window regulator master switch assembly or power window regulator switch assembly is stuck.

HINT

DTC B2312 can be stored in the power window regulator master switch assembly and in each power window regulator motor assembly (power window ECU).

DTC No.DTC Detection ConditionTrouble Area
B2312Power window regulator master switch assembly stuck Power window regulator master switch assembly held in same position for more than 20 secondsPower window regulator master switch assembly

MASTER SWITCH (POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY)

DTC No.DTC Detection ConditionTrouble Area
B2312Power window regulator master switch assembly (for driver side) stuck Power window regulator master switch assembly held in same position for more than 20 secondsPower window regulator master switch assembly Power window regulator motor assembly (for driver side) Wire harness or connector

D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE))

DTC No.DTC Detection ConditionTrouble Area
B2312Power window regulator switch assembly (for front passenger side) stuck Power window regulator switch assembly held in same position for more than 20 secondsPower window regulator switch assembly (for front passenger side) Power window regulator motor assembly (for front passenger side) Wire harness or connector

P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE))

DTC No.DTC Detection ConditionTrouble Area
B2312Power window regulator switch assembly (for rear LH side) stuck Power window regulator switch assembly held in same position for more than 20 secondsPower window regulator switch assembly (for rear LH side) Power window regulator motor assembly (for rear LH side) Wire harness or connector

RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE))

DTC No.DTC Detection ConditionTrouble Area
B2312Power window regulator switch assembly (for rear RH side) stuck Power window regulator switch assembly held in same position for more than 20 secondsPower window regulator switch assembly (for rear RH side) Power window regulator motor assembly (for rear RH side) Wire harness or connector

RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE))

Scheme 122

Scheme 122: WIRING DIAGRAM
Scheme 122: WIRING DIAGRAM

Scheme 123

Scheme 123
Scheme 123

Scheme 124

Scheme 124
Scheme 124

Scheme 125

Scheme 125
Scheme 125
  1. for Driver Side
  2. for Front Passenger Side
  3. for Rear LH Side
  4. for Rear RH Side

The power window regulator motor assembly is operated by the power window regulator master switch assembly or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.

When the ECU determines that the power window regulator motor assembly has not been initialized, DTC B2313 is set.

HINT

DTC B2313 can be stored in each power window regulator motor assembly (power window ECU).

DTC No.DTC Detection ConditionTrouble Area
B2313Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctionsPower window regulator motor assembly (for driver side) not initialized Power window regulator motor assembly (for driver side)

D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE))

DTC No.DTC Detection ConditionTrouble Area
B2313Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctionsPower window regulator motor assembly (for front passenger side) not initialized Power window regulator motor assembly (for front passenger side)

P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE))

DTC No.DTC Detection ConditionTrouble Area
B2313Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctionsPower window regulator motor assembly (for rear LH side) not initialized Power window regulator motor assembly (for rear LH side)

RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE))

DTC No.DTC Detection ConditionTrouble Area
B2313Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctionsPower window regulator motor assembly (for rear RH side) not initialized Power window regulator motor assembly (for rear RH side)

RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE))

When the ignition switch is ON, the power window regulator master switch assembly sends remote up/down signals to each power window regulator motor assembly via the LIN communication line.

Scheme 126

Scheme 126: WIRING DIAGRAM
Scheme 126: WIRING DIAGRAM

When the engine is running or the ignition switch is ON, the power window regulator motor assembly (for driver side) is operated by the power window regulator master switch assembly. The power window regulator motor assembly (for driver side) has motor, regulator, and ECU functions.

HINT

If the pulse sensor built into the power window regulator motor assembly (for driver side) malfunctions, the power window control system enters fail-safe mode. The remote up/down and auto up/down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the power window regulator master switch assembly at the auto up position, and opened manually by pushing down the power window regulator master switch assembly.

Scheme 127

Scheme 127: WIRING DIAGRAM
Scheme 127: WIRING DIAGRAM

When the engine is running or the ignition switch is ON, the power window regulator motor assembly (for front passenger side) is operated by the power window regulator switch assembly (for front passenger side). The power window regulator motor assembly (for front passenger side) has motor, regulator, and ECU functions.

HINT

If the pulse sensor built into the power window regulator motor assembly (for front passenger side) malfunctions, the power window control system enters fail-safe mode. The remote up/down and auto up/down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the power window regulator switch assembly (for front passenger side) at the auto up position, and opened manually by pushing down the power window regulator switch assembly (for front passenger side).

Scheme 128

Scheme 128: WIRING DIAGRAM
Scheme 128: WIRING DIAGRAM

When the engine is running or the ignition switch is ON, the power window regulator motor assembly (for rear LH side) is operated by the power window regulator switch assembly (for rear LH side). The power window regulator motor has motor, regulator, and ECU functions.

HINT

If the pulse sensor built into the power window regulator motor assembly (for rear LH side) malfunctions, the power window control system enters fail-safe mode. The remote up/down and auto up/down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the power window regulator switch assembly (for rear LH side) at the auto up position, and opened manually by pushing down the power window regulator switch assembly (for rear LH side).

Scheme 129

Scheme 129: WIRING DIAGRAM
Scheme 129: WIRING DIAGRAM

When the engine is running or the ignition switch is ON, the power window regulator motor assembly (for rear RH side) is operated by the power window regulator switch assembly (for rear RH side). The power window regulator motor assembly (for rear RH side) has motor, regulator, and ECU functions.

HINT

If the pulse sensor built into the power window regulator motor (for rear RH side) malfunctions, the power window control system enters fail-safe mode. The remote up/down and auto up/down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the power window regulator switch assembly (for rear RH side) at the auto up position, and opened manually by pushing down the power window regulator switch assembly (for rear RH side).

Scheme 130

Scheme 130: WIRING DIAGRAM
Scheme 130: WIRING DIAGRAM

If the manual up/down function can be performed but the auto up/down function cannot, then the fail-safe mode may be functioning.

If the power window initialization. Refer to INITIALIZATION has not been performed, the auto up/down function will not operate.

Scheme 131

Scheme 131: WIRING DIAGRAM
Scheme 131: WIRING DIAGRAM

If the manual up/down function can be performed but the auto up/down function cannot, the fail-safe mode may be functioning.

If the power window initialization. Refer to INITIALIZATION has not been performed, the auto up/down function will not operate.

Scheme 132

Scheme 132: WIRING DIAGRAM
Scheme 132: WIRING DIAGRAM

If the manual up/down function can be performed but the auto up/down function cannot, the fail-safe mode may be functioning.

If the power window initialization. Refer to INITIALIZATION has not been performed, the auto up/down function will not operate.

Scheme 133

Scheme 133: WIRING DIAGRAM
Scheme 133: WIRING DIAGRAM

If the manual up/down function can be performed but the auto up/down function cannot, the fail-safe mode may be functioning.

If the power window initialization. Refer to INITIALIZATION has not been performed, the auto up/down function will not operate.

Scheme 134

Scheme 134: WIRING DIAGRAM
Scheme 134: WIRING DIAGRAM
  1. When the front doors are closed, each power window regulator motor assembly can control its power window operation for approximately 45 seconds after the ignition switch is turned from ON to off by receiving operation permission signals from the main body ECU (driver side junction block assembly).
  2. However, when approximately 45 seconds have elapsed, or the driver side door or front passenger side door is opened within approximately 45 seconds of the ignition switch being turned off, the power window regulator motor assembly stops operating.
  3. During an auto operation, when 45 seconds have passed and key-off operation is prohibited, the window operation stops immediately.

If a door glass or a power window regulator motor assembly does not operate smoothly, the jam protection function may be triggered automatically, resulting in the auto up function being unable to fully close the window.

HINT

This symptom may occur for any of the windows.

This symptom may occur for any of the windows.

The jam protection function operates within a specified range during the manual up or auto up operation.
