Power Window Control (Diagnostics - Introduction): Other Toyota Venza I

PRECAUTION

1. EXPRESSIONS OF IGNITION SWITCH The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this information. Switch Type Ignition Switch (Position) Engine Switch (Condition) Expression Ignition switch off LOCK Off Ignition switch ON ON On (IG) Ignition switch ACC ACC On (ACC) Engine Start START Start
2. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected: System Name See Procedure Back Door Closer System Refer to «INITIALIZATION»(ref-394610-S11154682782011040800000) Power Back Door System
3. POWER WINDOW CONTROL SYSTEM PRECAUTIONS WARNING: The power window control system prohibits the auto up/down function when the jam protection function malfunctions. Therefore, troubleshoot the power window control system after confirming that no trouble codes are output. When a power window regulator or a power window regulator motor assembly is replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operation at least 5 times: Close the power window by fully pulling up the power window regulator master switch assembly or power window regulator switch assembly and holding it at the auto up position. Open the power window by fully pushing down the power window regulator master switch assembly or power window regulator switch assembly. The jam protection function may operate unexpectedly even when the power window control system is normal due to detection of a value different from the operation learned value when the door glass moving speed changes sharply under any of the following conditions: A power window is being opened or closed while the vehicle is driven on a rough road. A power window is being opened or closed while the door is being opened or closed. The voltage changes abruptly. NOTE: Do not disconnect the battery while the ignition switch is ON. Otherwise, DTC B2311 will be output.

Scheme 18

Scheme 19

Scheme 20

Scheme 21

COMMUNICATION TABLE

INITIALIZATION

1. INITIALIZE POWER WINDOW CONTROL SYSTEM (POWER WINDOW REGULATOR MOTOR ASSEMBLY (ALL DOORS)) WARNING: When the power window regulator motor assembly is reinstalled or replaced, the power window control system must be initialized. Functions such as the auto up/down, jam protection, remote control and key-off operation do not operate if the initialization is not performed. HINT: When the battery is replaced, it is not necessary to initialize the power window regulator motor assembly. NOTE: When the power window regulator motor assembly is replaced, DTC B2313 is output. Clear the DTC after the initialization. When performing initialization, do not perform any other procedures. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used, due to detection of a value different from the operation learned value of the door glass movement speed. In such cases, the auto up function can be reinitialized by repeating the following operation at least 5 times: Open the power window by fully pushing down the power window regulator master switch assembly or power window regulator switch assembly. Close the power window by fully pulling up the power window regulator master switch assembly or power window regulator switch assembly and holding it at the auto up position. If the initialization is not completed properly, the LIN communication system may have a malfunction. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-394859-S32846538212011040800000) . Initialization procedure when replacing the power window regulator motor assembly with a new one: Connect the battery and turn the ignition switch to ON (at this time, the LED on the power window regulator master switch assembly or power window regulator switch assembly blinks to indicate that it is ready for initialization). Fully open the window by fully pushing down the power window regulator master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Fully close the power window by fully pulling up the power window regulator master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully closed to reset the glass position. The LED on the power window regulator master switch assembly or power window regulator switch assembly stops blinking and illuminates to indicate that the initialization is complete. Initialization procedure when removing/installing the power window regulator motor assembly: Connect the battery and turn the ignition switch to ON. Fully close the power window by fully pulling up the power window regulator master switch assembly or power window regulator switch assembly, and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the power window regulator master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Release the power window regulator master switch assembly or power window regulator switch assembly. Then fully push down and hold the switch for 4 seconds or more. Fully close the power window by fully pulling up the power window regulator master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization. Initialization procedure when the power window does not fully open: Connect the battery and turn the ignition switch to ON. Fully close the power window by fully pulling up the power window regulator master switch assembly or power window regulator switch assembly, and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the power window regulator master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Release the power window regulator master switch assembly or power window regulator switch assembly. Then fully push down and hold the switch for 4 seconds or more. Fully close the power window by fully pulling up the power window regulator master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization.
