Differentials - Automatic Disconnecting: Specifications Toyota Tundra I

Differentials & Drive Axles 6 illustrations

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
4WD Position Switch27 (37)
L4 Position Switch27 (37)

TORQUE SPECIFICATIONS

Differential Lock System Wiring Diagram (4Runner). Scheme 16

Scheme 16: Differential Lock System Wiring Diagram (4Runner)
Scheme 16: Differential Lock System Wiring Diagram (4Runner)

Differential Lock System Wiring Diagram (Sequoia). Scheme 17

Scheme 17: Differential Lock System Wiring Diagram (Sequoia)
Scheme 17: Differential Lock System Wiring Diagram (Sequoia)

Differential Lock System Wiring Diagram (Tacoma With 2-4 Select Switch). Scheme 18

Scheme 18: Differential Lock System Wiring Diagram (Tacoma With 2-4 Select Switch)
Scheme 18: Differential Lock System Wiring Diagram (Tacoma With 2-4 Select Switch)

Differential Lock System Wiring Diagram (Tacoma Without 2-4 Select Switch). Scheme 19

Scheme 19: Differential Lock System Wiring Diagram (Tacoma Without 2-4 Select Switch)
Scheme 19: Differential Lock System Wiring Diagram (Tacoma Without 2-4 Select Switch)

Differential Lock System Wiring Diagram (Tundra). Scheme 20

Scheme 20: Differential Lock System Wiring Diagram (Tundra)
Scheme 20: Differential Lock System Wiring Diagram (Tundra)

Differential Lock System Wiring Diagram (Tundra). Scheme 21

Scheme 21: Differential Lock System Wiring Diagram (Tundra)
Scheme 21: Differential Lock System Wiring Diagram (Tundra)
