Maintenance Information: Overview Toyota Tercel L50

Fuse & Circuit Breaker Identification

1. 1 - 15 Amp Cigarette Lighter, Radio & Clock
2. 2 - 10 Amp Turn Signal Lights
3. 3 - 20 Amp Windshield Washer/Wipers
4. 4 - 15 Amp Taillights, Park Lights, License Lights, Instrument Panel Lights
5. 5 - 10 Amp Stoplights, High-Mounted Stoplights
6. 6 - 30 Amp Rear Window Defogger (W/O Timer)
7. 7 - 15 Amp Gauges & Meters, Warning & Back-Up Lights
8. 8 - 30 Amp A/C System & A/C Fuse, Rear Window Defogger (W/Timer)
9. 9 - 10 Amp A/C System

Scheme 1

1. 1 - Blank
2. 2 - Blank
3. 3 - 30 Amp Electric Underhood Cooling Fan
4. 4 - 30 Amp Electric Underhood Cooling Fan
5. 5 - 10 Amp Left Headlight
6. 6 - 10 Amp Right Headlight
7. 7 - 15 Amp Interior & Trunk Lights, Open Door Warning Light, Clock & Radio
8. 8 - 15 Amp Ignition System
9. 9 - 15 Amp Horns & Turn Signal Lights
10. 10 - 15 Amp EFI System
11. 11 - 50 Amp Ignition System
12. 12 - 100 Amp Charging System

Relay Identification

1. A - A/C Fan No. 3 (Head)
2. B - A/C Fan No. 2 (Dimmer)
3. C - Main
4. D - EFI
5. E - Horn
6. F - Fan

Scheme 2

Driver's Side Instrument Panel Fuse Identification

1. 1 - 15 Amp Cigarette Lighter, Radio & Clock
2. 2 - 10 Amp Turn Signal Lights
3. 3 - 20 Amp Windshield Washer/Wipers
4. 4 - 15 Amp Taillights, Park Lights, License Lights, Instrument Panel Lights
5. 5 - 10 Amp Stoplights, High-Mounted Stoplights
6. 6 - 30 Amp Rear Window Defogger (W/O Timer)
7. 7 - 15 Amp Gauges & Meters, Warning & Back-Up Lights
8. 8 - 7.5 Amp SRS Airbag System
9. 9 - 10 Amp ABS System

Passenger's Side Kick Panel Fuse Identification

1. 10 - 30 Amp A/C System & A/C Fuse, Rear Window Defogger (W/Timer)
2. 11 - 10 Amp A/C System

Engine Compartment Fuse & Relay Identification

1. 12 - 7.5 Amp Charging System
2. 13 - 10 Amp Left Headlight
3. 14 - 10 Amp Right Headlight
4. 15 - 10 Amp SRS Airbag System
5. 16 - 15 Amp Interior & Trunk Lights, Door Warning Light, Clock, Radio
6. 17 - 15 Amp Electronic Ignition System
7. 18 - 15 Amp Horns & Turn Signal Lights
8. 19 - 15 Amp Fuel Injection System
9. 20 - 30 Amp Electric Underhood Cooling Fan
10. 21 - 30 Amp Electric Underhood Cooling Fan
11. 22 - 50 Amp Electronic Ignition System
12. 23 - 100 Amp Charging System
13. 24 - 60 Amp ABS System

1. A - EFI Main
2. B - A/C Fan No. 3
3. C - Engine Main
4. D - Headlight
5. E - A/C Fan No. 2
6. F - Radiator Fan No. 1
7. G - Horn

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7
