VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 9
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Service is recommended at mileage intervals based on vehicle operation and engine type. Service schedules are based on the following primary operating conditions
Normal Service
- Driven More Than 10 Miles Daily
- No Operating Conditions From Severe Service Schedule
Severe Service (Unique Driving Conditions)
- Towing A Trailer, Using A Camper Or Car Top Carrier
- Repeated Short Trips Less Than 5 Miles When Temperatures Are Below Freezing
- Extensive Idling Conditions (Taxi Or Delivery Type Service)
- Operating On Dusty, Rough, Muddy Or Salt Spread Roads
CAMSHAFT TIMING BELT
| CAUTION | Failure to replace a faulty camshaft timing belt may result in serious engine damage. |
The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".
Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.
Belts or components should be inspected and replaced if any of the following conditions exist
- Cracks Or Tears In Belt Surface
- Missing, Damaged, Cracked Or Rounded Teeth
- Oil Contamination
- Damaged Or Faulty Tensioners
- Incorrect Tension Adjustment
Replace the timing belt every 72 months or 60,000 miles if the vehicle is operated under Severe Service conditions such as frequent idling or extensive long distance driving at low speeds (taxi, police or door-to-door delivery).
Scheme 10
SERVICE LABOR TIMES
Note. Labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.
TIRE INFLATION
All regular tires should be inflated to 32 psi (2.2 kg/cm 2 ). Compact spare tires should be inflated to 60 psi (4.2 kg/cm 2 ). Tire inflation pressure can be found on the tire information label located on the inside of the glove compartment lid.
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM
Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.
The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.
When performing maintenance on air bag equipped vehicles always observe proper safety precautions.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
ANTI-LOCK BRAKE SYSTEM (ABS)
| CAUTION | Never mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors. |
BATTERY WARNING
| WARNING | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below. |
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
CATALYTIC CONVERTER
Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
| CAUTION | To avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C). |
| CAUTION | Propylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C) |
| CAUTION | Propylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
ENGINE OIL
| CAUTION | Never use non-detergent or straight mineral oil. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off. |
TURBOCHARGED MODELS
| CAUTION | Do not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings. |
WARRANTY INFORMATION
| CAUTION | Always refer to customer's copy of warranty information for specific model application and/or coverage limitations. |
NEW VEHICLE LIMITED WARRANTY
Covers any repair or replacement of parts which becomes necessary due to defects in materials or workmanship under normal use for 36 months or 36,000 miles from in-service date.
POWERTRAIN WARRANTY
Engine, transmission, front wheel drive, rear wheel drive and restraint system are warranted against defects in materials or workmanship under normal use for 5 years or 60,000 miles, whichever occurs first. See copy of warranty for specific components covered.
CORROSION PERFORATION WARRANTY
Covers any repair or replacement to body sheet metal which develops corrosion perforation (hole through panel), in normal use, due to defects in material or workmanship for a period of 5 years, regardless of mileage.
BATTERY WARRANTY
Covers replacement of defective original battery for first 12 months or 12,000 miles. After the first 12 months or 12,000 miles, warranty covers a pro-rated amount based on months in service, up to a maximum of 36 months.
AIR CONDITIONER REFRIGERANT CHARGE WARRANTY
Covers the air conditioner refrigerant for the first 12 months, regardless of mileage, unless done as a warranty repair.
EMISSION SYSTEM DEFECT WARRANTY (EXCEPT CALIFORNIA)
Warrants to the retail purchaser, and subsequent purchaser(s), that vehicle was designed, built, and equipped so as to conform at the time of sale with applicable emission regulations and that it is free from defects in materials or workmanship which may cause the vehicle to fail to conform with applicable regulations for 5 years or 50,000 miles, whichever occurs first.
EMISSION SYSTEM PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)
Covers all repairs, adjustments, or replacements if vehicle fails to conform to applicable emission standards and such failure results in the vehicle owner having to bear a penalty or other sanction under local, state or federal law for 5 years or 50,000 miles, whichever comes first. If the vehicle has been in use for more than 24 months or 24,000 miles, the manufacturer will make the necessary adjustments, repairs or replacements at no cost to the owner only when noncompliance is caused by failure of components which have been installed in the vehicle for the sole or primary purpose of reducing vehicle emissions. See copy of warranty for specific components covered.
EMISSION SYSTEM PERFORMANCE WARRANTY (CALIFORNIA)
For a period of 3 years or 50,000 miles, manufacturer will make all necessary repairs and adjustments to ensure vehicle passes a required Smog Check inspection.
EMISSION SYSTEM DEFECT WARRANTY (CALIFORNIA)
For a period of 5 years or 50,000 miles, whichever occurs first, vehicle is free from defects in materials or workmanship which may cause it to fail to conform with applicable California emission regulations. Certain emission-related parts are covered for repair or replacement for 7 years or 70,000 miles, whichever occurs first. See copy of warranty for specific components covered.
Fuses (Type A)
- 1 - 10 Amp Left-hand headlight (U.S.A.)
- 2 - 10 Amp Right-hand headlight (U.S.A.)
- 3 - 15 Amp Ignition system, Charging system, Multiport fuel injection system/sequential multiport fuel injection system/sequential multiport fuel injection system, SRS airbag system, Starter system
- 4 - 15 Amp Horns, Turn signal lights, Emergency flashers, Theft deterrent system
- 5 - 15 Amp Multiport fuel injection system/sequential multiport fuel injection system, Air conditioning system
- 6 - 10 Amp Interior light, Open door warning light, Clock, Car audio system, Anti-lock brake system, Theft deterrent system
- 7 - 7.5 Amp No circuit
- 8 - 5 Amp Charging system
- 9 - 5 Amp Daytime running light system (Canada)
- 10 - 10 Amp Right-hand headlight (low beam) (Canada)
- 11 - 10 Amp Left-hand headlight (low beam) (Canada)
- 12 - 10 Amp Right-hand headlight (high beam) (Canada)
- 13 - 10 Amp Left-hand headlight (high beam) (Canada)
- 14 - 10 Amp Stop lights, High mounted stoplight, Anti-lock brake system, Shift lock control system
- 15 - 10 Amp Air conditioning system
- 16 - 15 Amp Tail lights, Parking lights, License plate lights, Instrument panel lights, Emergency flashers, Air conditioning system, Rear window defogger, Car audio system, Cigarette lighter, Clock
- 17 - 10 Amp Gauges and meters, Service reminder indicator and warning buzzers (except discharge and open door warning lights), Back-up lights, rear window defogger
- 18 - 7.5 Amp Turn signal lights, Emergency flashers
- 19 - 20 Amp Windshield wipers and washer
- 20 - 5 Amp Anti-lock brake system, Air conditioning system
- 21 - 15 Amp Cigarette lighter, Car audio system, Clock, Anti-lock brake system, Theft deterrent system, Shift lock control system
- 22 - 5 Amp Charging system, Discharge warning light, Multiport fuel injection system/sequential multiport fuel injection system, SRS airbag system
- 23 - 5 Amp SRS airbag warning light
Fuses (Type B)
- 24 - 30 Amp Electric cooling fans
- 25 - 30 Amp Electric cooling fans
- 26 - 40 Amp Air conditioning system,"A/C" fuses
- 27 - 30 Amp "HEAD (RH-UPR)", "HEAD (LH-UPR)", "HEAD (RH-LWR)", "HEAD (LH-LWR)" fuses
- 28 - 30 Amp Starter system
- 29 - 30 Amp Rear window defogger
- 30 - 30 Amp Power windows, Power door lock system
Fuses (Type C)
- 31 - 60 Amp Anti-lock brake system
- 32 - 50 Amp "DEF", "WIPER", "GAUGE", "ECU-IG", "TURN", "IGN" and "PWR" Fuses
- 33 - 100 Amp "ABS", "STOP", "TAIL", "SRS", "DEF", "AM1", "WIPER", "GAUGE", "ECU-IG", "TURN", "IGN" and "PWR" fuses
