Scheme 1
ENGINE TEMPERATURE GAUGE
Indicates engine coolant temperature. Gauge should register below "HOT" range while driving.
LOW OIL PRESSURE WARNING LIGHT
If this light flickers or comes on while driving, the oil pressure is probably low. If this occurs, stop the vehicle immediately and check the oil level. If oil level is okay and light remains on, have the system serviced as soon as possible.
DISCHARGE WARNING LIGHT
Indicates that the battery is not charging properly. Check the alternator belt tension. If belt tension is okay, have the system serviced as soon as possible.
BRAKE SYSTEM WARNING LIGHT
This light indicates that either the parking brake is on or the brake fluid level is low.
ENGINE SYSTEM WARNING LIGHT
If this light comes on while driving, it indicates a problem with the engine electrical system. On California vehicles, it also indicates a malfunction in the emission control system and may be used to access fault codes. Have the system serviced as soon as possible.
