Differential - Automatic Disconnecting: Specifications Toyota Tacoma I

Differentials & Drive Axles 12 illustrations ~121 words

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
ADD Indicator Switch30 (41)
Transfer Indicator Switch (T100)27 (37)
4WD Switch (Tacoma & 4Runner)27 (37)

TORQUE SPECIFICATIONS

Wiring Diagram (1997 Tacoma With 2-4 Select Switch). Scheme 29

Scheme 29: Wiring Diagram (1997 Tacoma With 2-4 Select Switch)
Scheme 29: Wiring Diagram (1997 Tacoma With 2-4 Select Switch)

Wiring Diagram (1997 Tacoma Without 2-4 Select Switch). Scheme 30

Scheme 30: Wiring Diagram (1997 Tacoma Without 2-4 Select Switch)
Scheme 30: Wiring Diagram (1997 Tacoma Without 2-4 Select Switch)

Wiring Diagram (1997 T100 With A/T). Scheme 31

Scheme 31: Wiring Diagram (1997 T100 With A/T)
Scheme 31: Wiring Diagram (1997 T100 With A/T)

Wiring Diagram (1997 T100 With M/T). Scheme 32

Scheme 32: Wiring Diagram (1997 T100 With M/T)
Scheme 32: Wiring Diagram (1997 T100 With M/T)

Wiring Diagram (1998 T100 With A/T). Scheme 33

Scheme 33: Wiring Diagram (1998 T100 With A/T)
Scheme 33: Wiring Diagram (1998 T100 With A/T)

Wiring Diagram (1998 T100 With M/T). Scheme 34

Scheme 34: Wiring Diagram (1998 T100 With M/T)
Scheme 34: Wiring Diagram (1998 T100 With M/T)

Wiring Diagram (1997 4Runner With 2-4 Select Switch). Scheme 35

Scheme 35: Wiring Diagram (1997 4Runner With 2-4 Select Switch)
Scheme 35: Wiring Diagram (1997 4Runner With 2-4 Select Switch)

Wiring Diagram (1997 4Runner Without 2-4 Select Switch). Scheme 36

Scheme 36: Wiring Diagram (1997 4Runner Without 2-4 Select Switch)
Scheme 36: Wiring Diagram (1997 4Runner Without 2-4 Select Switch)

Wiring Diagram (1998 Tacoma With 2-4 Select Switch). Scheme 37

Scheme 37: Wiring Diagram (1998 Tacoma With 2-4 Select Switch)
Scheme 37: Wiring Diagram (1998 Tacoma With 2-4 Select Switch)

Wiring Diagram (1998 Tacoma Without 2-4 Select Switch). Scheme 38

Scheme 38: Wiring Diagram (1998 Tacoma Without 2-4 Select Switch)
Scheme 38: Wiring Diagram (1998 Tacoma Without 2-4 Select Switch)

Wiring Diagram (1998 4Runner With 2-4 Select Switch). Scheme 39

Scheme 39: Wiring Diagram (1998 4Runner With 2-4 Select Switch)
Scheme 39: Wiring Diagram (1998 4Runner With 2-4 Select Switch)

Wiring Diagram (1998 4Runner Without 2-4 Select Switch). Scheme 40

Scheme 40: Wiring Diagram (1998 4Runner Without 2-4 Select Switch)
Scheme 40: Wiring Diagram (1998 4Runner Without 2-4 Select Switch)
