Engine Controls - Tests W/codes - Turbo: Overview Toyota Supra A80

Testing & Diagnostics 9 illustrations

TROUBLE CODE IDENTIFICATION

CodeSystem Affected(1) Normal Mode(1) Test ModeProbable Cause
12RPM SignalONN/ACamshaft Or Crankshaft Position Sensors Or Circuits, Starter Or Circuit, ECM
13RPM Signal(3)(2)Camshaft Or Crankshaft Position Sensors Or Circuit, ECM
14Ignition SignalONN/AIgnitor Or Circuit To ECM, ECM
16 (4)A/T Control SignalONN/AECM
21Oxygen Sensor SignalON(5)Oxygen Sensor/Heater Or Circuit, ECM
22Engine Coolant Temperature Sensor SignalONONEngine Coolant Temp. Sensor Or Circuit, ECM
24Intake Air Temperature Sensor SignalONONIntake Air Temp. Sensor Or Circuit, ECM
25Lean Air/Fuel MixtureONONInjector Or Circuit, Oxygen Sensor/Heater Or Circuit, Fuel Pressure, Ignition System, Compression Pressure Airflow Meter, ECM
26Rich Air/Fuel MixtureONONInjector Or Circuit, Oxygen Sensor/Heater Or Circuit, Fuel Pressure, Ignition System, Airflow Meter Compression Pressure, ECM
27Sub-Oxygen Sensor SignalON(5)Sub-Oxygen Sensor/ Heater Or Circuit, ECM
31Airflow MeterONN/AAirflow Meter Or Circuit, ECM
34Turbocharging Pressure SignalONN/AWastegate VSV Or Circuit, Wastegate Actuator, ECM
35Turbo Pressure BARO SensorONONTurbo Pressure Sensor Or Circuit, ECM
41Throttle Position Sensor SignalONONThrottle Position Sensor Or Circuit, ECM
42Vehicle Speed Sensor SignalOFFOFFVehicle Speed Sensor Or Circuit, ECM
43Starter SignalN/AOFFStarter Signal Circuit, Starter Relay, Ignition Switch Or Circuit, ECM
47Sub-Throttle Position Sensor SignalOFFONSub-Throttle Position Sensor Or Circuit, ECM
51Switch Condition SignalN/AOFFA/C Switch Circuit, Park/Neutral Switch Or Circuit, TPS Or Circuit, ECM
52Front Knock Sensor SignalONN/AFront Knock Sensor Or Circuit, ECM
53Knock Control SignalONN/AECM
55Rear Knock Sensor SignalONN/ARear Knock Sensor Or Circuit, ECM
71EGR System MalfunctionONONEGR System, EGR Temp. Sensor Or Circuit, EGR-VSV, ECM
78Fuel Pump Control SignalOFFONFuel Pump ECU Or Circuit, Fuel Pump, ECM Power Source Or ECM
(1) ON indicates MIL on instrument panel will be illuminated. N/A indicates item is not included in malfunction diagnosis when using this mode. OFF indicates MIL on instrument panel will not be illuminated even if malfunction is detected. (2) The MIL will be illuminated if "NE" signal does not pulse 12 times to ECM during interval between "G1" and "G2" pulses. (3) The MIL will be illuminated if no "NE" signal to ECM is received with engine at 1000 RPM or if deviation in "G", "G1", "G2" or "NE" signal exists during idling with engine warm. (4) Applies only to models with electronic-controlled automatic transaxle. (5) The MIL will be illuminated if problem exists in oxygen sensor circuit. The MIL will not be illuminated if problem exists in oxygen sensor heater or circuit.
(1)ON indicates MIL on instrument panel will be illuminated. N/A indicates item is not included in malfunction diagnosis when using this mode. OFF indicates MIL on instrument panel will not be illuminated even if malfunction is detected.
(2)The MIL will be illuminated if "NE" signal does not pulse 12 times to ECM during interval between "G1" and "G2" pulses.
(3)The MIL will be illuminated if no "NE" signal to ECM is received with engine at 1000 RPM or if deviation in "G", "G1", "G2" or "NE" signal exists during idling with engine warm.
(4)Applies only to models with electronic-controlled automatic transaxle.
(5)The MIL will be illuminated if problem exists in oxygen sensor circuit. The MIL will not be illuminated if problem exists in oxygen sensor heater or circuit.

TROUBLE CODE IDENTIFICATION

Scheme 117

Scheme 117: ECM TERMINAL IDENTIFICATION

Scheme 118

Scheme 118: DIAGNOSTIC CIRCUIT CHECK ("TE1" & "TE2" TERMINAL CIRCUIT)

Scheme 119

Scheme 119: ECM POWER SOURCE CIRCUIT CHECK

Scheme 120

Scheme 120

Scheme 121

Scheme 121

Scheme 122

Scheme 122

Scheme 123

Scheme 123: ECM BACK-UP POWER SOURCE CIRCUIT CHECK

Scheme 124

Scheme 124: DTC 12 - RPM SIGNAL

Scheme 125

Scheme 125
