Engine Controls - Tests W/codes - Non-Turbo: Overview Toyota Supra A80

Testing & Diagnostics 9 illustrations

TROUBLE CODE IDENTIFICATION

CodeSystem Affected(1) Normal Mode(1) Test ModeProbable Cause
12RPM SignalONN/ADistributor, Starter Or Circuit, ECM
13RPM Signal(2)(3)Distributor Or Circuit, ECM
14Ignition SignalONN/AIgnitor Or Circuit To ECM, ECM
16 (4)A/T Control SignalONN/AECM
21Oxygen Sensor SignalON(5)Oxygen Sensor/Heater Or Circuit, ECM
22Engine Coolant Temperature Sensor SignalONONEngine Coolant Temp. Sensor Or Circuit, ECM
24Intake Air Temperature Sensor SignalONONIntake Air Temp. Sensor Or Circuit, ECM
25Lean Air/Fuel MixtureONONInjector Or Circuit, Oxygen Sensor/Heater Or Circuit, Fuel Pressure, Ignition System, Compression, Airflow Meter, ECM
26Rich Air/Fuel MixtureONONInjector Or Circuit, Oxygen Sensor/Heater Or Circuit, Fuel Pressure, Ignition System, Airflow Meter, Compression, ECM
27 (6)Sub-Oxygen Sensor SignalON(5)Sub-Oxygen Sensor/ Heater Or Circuit, ECM
28Oxygen Sensor SignalON(5)Oxygen Sensor/Heater Or Circuit, ECM
31Airflow Meter SignalONN/AAirflow Meter Or Circuit, ECM
35BARO SensorONONECM
41Throttle Position Sensor SignalONONThrottle Position Sensor Or Circuit, ECM
42Vehicle Speed Sensor SignalOFFOFFVehicle Speed Sensor Or Circuit, ECM
43Starter SignalN/AOFFStarter Signal Circuit, Starter Relay, Ignition Switch Or Circuit, ECM
51Switch Condition SignalN/AOFFA/C Switch Circuit, Park/Neutral Switch Or Circuit, TPS Or Circuit, ECM
52Front Knock Sensor SignalONN/AFront Knock Sensor Or Circuit, ECM
53Knock Control SignalONN/AECM
55Rear Knock Sensor SignalONN/ARear Knock Sensor Or Circuit, ECM
71EGR System MalfunctionONONEGR System, EGR Temp. Sensor Or Circuit, EGR-VSV, ECM
78Fuel Pump Control SignalOFFONFuel Pump ECU Or Circuit, Fuel Pump, ECM Power Source Or ECM
(1) ON indicates MIL on instrument panel will be illuminated. N/A indicates item is not included in malfunction diagnosis when using this mode. OFF indicates MIL on instrument panel will not be illuminated even if malfunction is detected. (2) The MIL will be illuminated if no "NE" signal to ECM is received with engine at 1000 RPM or more. (3) The MIL will be illuminated if "NE" signal does not pulse 12 times to ECM during interval between "G1" and "G2" pulses. (4) Applies only to models with electronic-controlled automatic transaxle. (5) The MIL will be illuminated if problem exists in oxygen sensor circuit. The MIL will not be illuminated if problem exists in oxygen sensor heater or circuit. (6) Applies to California models only.
(1)ON indicates MIL on instrument panel will be illuminated. N/A indicates item is not included in malfunction diagnosis when using this mode. OFF indicates MIL on instrument panel will not be illuminated even if malfunction is detected.
(2)The MIL will be illuminated if no "NE" signal to ECM is received with engine at 1000 RPM or more.
(3)The MIL will be illuminated if "NE" signal does not pulse 12 times to ECM during interval between "G1" and "G2" pulses.
(4)Applies only to models with electronic-controlled automatic transaxle.
(5)The MIL will be illuminated if problem exists in oxygen sensor circuit. The MIL will not be illuminated if problem exists in oxygen sensor heater or circuit.
(6)Applies to California models only.

TROUBLE CODE IDENTIFICATION

Scheme 70

Scheme 70: ECM TERMINAL IDENTIFICATION

Scheme 71

Scheme 71: DIAGNOSTIC CIRCUIT CHECK ("TE1" & "TE2" TERMINAL CIRCUIT)

Scheme 72

Scheme 72: ECM POWER SOURCE CIRCUIT CHECK

Scheme 73

Scheme 73

Scheme 74

Scheme 74

Scheme 75

Scheme 75

Scheme 76

Scheme 76: ECM BACK-UP POWER SOURCE CIRCUIT CHECK

Scheme 77

Scheme 77: DTC 12 - RPM SIGNAL

Scheme 78

Scheme 78
