Park Assist/monitoring: Removal & Installation Toyota Sienna II рестайлинг

Collision/avoidance 16 illustrations ~514 words

INSTALLATION

  1. INSTALL CLEARANCE WARNING ECU Install the clearance warning ECU with the nut. Connect each connector.
  2. INSTALL NO. 1 INSTRUMENT PANEL SAFETY PAD INSERT SUB-ASSEMBLY (See «INSTALLATION»(ref-282145-S25779427752008032900000) )
  3. INSTALL INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY LOWER LH
  4. INSTALL COWL SIDE TRIM BOARD LH
  5. INSTALL FRONT DOOR SCUFF PLATE LH

Scheme 70

Scheme 70: COMPONENTS
Scheme 70: COMPONENTS

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73: REMOVAL
Scheme 73: REMOVAL

Scheme 74

Scheme 74
Scheme 74
  1. REMOVE FRONT FENDER LINER LH
  2. REMOVE FRONT FENDER LINER RH
  3. REMOVE FRONT BUMPER COVER (See «REMOVAL»(ref-282144-S04707980072008032900000) )
  4. REMOVE REAR BUMPER COVER (See «REMOVAL»(ref-282144-S02635631832008032900000) )
  5. REMOVE NO. 1 ULTRASONIC SENSOR RETAINER Remove the No. 1 ultrasonic sensor retainer as shown in the illustration.
  6. REMOVE NO. 1 ULTRASONIC SENSOR Disconnect the connector and remove the No. 1 ultrasonic sensor.

Scheme 75

Scheme 75: INSPECTION
Scheme 75: INSPECTION
  1. INSPECT NO.1 ULTRASONIC SENSOR Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester connection Condition Specified condition 1 - 2 Always 8 to 12 kohms If the result is not as specified, replace No.1 ultrasonic sensor.
  1. INSTALL NO. 1 ULTRASONIC SENSOR Connect the connector and install the No. 1 ultrasonic sensor.
  2. INSTALL NO. 1 ULTRASONIC SENSOR RETAINER Install the No. 1 ultrasonic sensor retainer.
  3. INSTALL REAR BUMPER COVER (See «INSTALLATION»(ref-282144-S28987888892008032900000) )
  4. INSTALL FRONT BUMPER COVER (See «INSTALLATION»(ref-282144-S20417765232008032900000) )
  5. INSTALL FRONT FENDER LINER LH
  6. INSTALL FRONT FENDER LINER RH

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77: REMOVAL
Scheme 77: REMOVAL

Scheme 78

Scheme 78
Scheme 78
  1. REMOVE REAR BUMPER COVER (See «REMOVAL»(ref-282144-S02635631832008032900000) )
  2. REMOVE NO. 1 ULTRASONIC SENSOR RETAINER Remove the No. 1 ultrasonic sensor retainer as shown in the illustration.
  3. REMOVE NO. 2 ULTRASONIC SENSOR Disconnect the connector and remove the No. 2 ultrasonic sensor.

Scheme 79

Scheme 79: INSPECTION
Scheme 79: INSPECTION
  1. INSPECT NO.2 ULTRASONIC SENSOR Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester connection Condition Specified condition 1 - 2 Always 8 to 12 kohms If the result is not as specified, replace No.2 ultrasonic sensor.
  1. INSTALL NO. 2 ULTRASONIC SENSOR Connect the connector and install the No. 2 ultrasonic sensor.
  2. INSTALL NO. 1 ULTRASONIC SENSOR RETAINER Install the No. 1 ultrasonic sensor retainer.
  3. INSTALL REAR BUMPER COVER (See «INSTALLATION»(ref-282144-S28987888892008032900000) )

Scheme 80

Scheme 80: COMPONENTS
Scheme 80: COMPONENTS

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85: REMOVAL
Scheme 85: REMOVAL
  1. REMOVE BACK DOOR GARNISH CENTER HINT: Back Door: See «DISASSEMBLY»(ref-282156-S25892841012008032900000) Power Back Door: See «DISASSEMBLY»(ref-282156-S15127667202008032900000)
  2. REMOVE BACK DOOR SIDE GARNISH LH HINT: Back Door: See «DISASSEMBLY»(ref-282156-S25892841012008032900000) Power Back Door: See «DISASSEMBLY»(ref-282156-S15127667202008032900000)
  3. REMOVE BACK DOOR SIDE GARNISH RH Back Door: See «DISASSEMBLY»(ref-282156-S25892841012008032900000) Power Back Door: See «DISASSEMBLY»(ref-282156-S15127667202008032900000)
  4. REMOVE BACK DOOR PULL STRAP Back Door: See «DISASSEMBLY»(ref-282156-S25892841012008032900000) Power Back Door: See «DISASSEMBLY»(ref-282156-S15127667202008032900000)
  5. REMOVE BACK DOOR TRIM BOARD ASSEMBLY Back Door: See «DISASSEMBLY»(ref-282156-S25892841012008032900000) Power Back Door: See «DISASSEMBLY»(ref-282156-S15127667202008032900000)
  6. REMOVE BACK DOOR GARNISH SUB-ASSEMBLY OUTSIDE Back Door: See «DISASSEMBLY»(ref-282156-S25892841012008032900000) Power Back Door: See «DISASSEMBLY»(ref-282156-S15127667202008032900000)
  7. REMOVE TELEVISION CAMERA ASSEMBLY Release the 2 claw fittings and remove the television camera assembly.
  1. INSTALL TELEVISION CAMERA ASSEMBLY
  2. INSTALL BACK DOOR GARNISH SUB-ASSEMBLY OUTSIDE
  3. INSTALL BACK DOOR TRIM BOARD ASSEMBLY
  4. INSTALL BACK DOOR PULL STRAP HINT: Back Door: See «REASSEMBLY»(ref-282156-S00248025952008032900000) Power Back Door: See «REASSEMBLY»(ref-282156-S05837739472008032900000)
  5. INSTALL BACK DOOR SIDE GARNISH RH
  6. INSTALL BACK DOOR SIDE GARNISH LH
  7. INSTALL BACK DOOR GARNISH CENTER
