Removal & Installation
Remove door trim panel and waterproof shield. Remove glass retaining bolts and glass. Remove window regulator bolts, and remove window regulator/power window motor assembly. Remove power window motor retaining screws, and remove motor from window regulator. To install, reverse removal procedure. Tighten window regulator motor retaining bolts or nuts to 44 INCH lbs. (5 N.m). Apply multipurpose grease to window regulator rollers.
Disconnect negative battery cable. Using a small flat-blade screwdriver, pry and lift power window switch from door panel. Disconnect power window switch harness connector(s) and remove switch. To install, reverse removal procedure.
Power Window System Wiring Diagram (Land Cruiser). Scheme 5
Scheme 5: Power Window System Wiring Diagram (Land Cruiser)
Power Window Rear Quarter Windows Wiring Diagram (Land Cruiser). Scheme 6
Scheme 6: Power Window Rear Quarter Windows Wiring Diagram (Land Cruiser)
Power Window System Wiring Diagram (RAV4 2-Door). Scheme 7
Scheme 7: Power Window System Wiring Diagram (RAV4 2-Door)
Power Window System Wiring Diagram (RAV4 4-Door). Scheme 8
Scheme 8: Power Window System Wiring Diagram (RAV4 4-Door)
Power Window System Wiring Diagram (Sienna). Scheme 9
Scheme 9: Power Window System Wiring Diagram (Sienna)
Power Window System Wiring Diagram (Tacoma). Scheme 10
Scheme 10: Power Window System Wiring Diagram (Tacoma)
Power Window System Wiring Diagram (Tundra). Scheme 11
Scheme 11: Power Window System Wiring Diagram (Tundra)
Power Window System Wiring Diagram (4Runner). Scheme 12
Scheme 12: Power Window System Wiring Diagram (4Runner)
Tailgate Power Window System Wiring Diagram (4Runner). Scheme 13
Scheme 13: Tailgate Power Window System Wiring Diagram (4Runner)
