Audio / Visual System (Service Information): Overview Toyota RAV4 IV

Entertainment Systems 19 illustrations ~1500 words

Scheme 45

Scheme 45: ILLUSTRATION
Scheme 45: ILLUSTRATION

Scheme 46

Scheme 46: ILLUSTRATION
Scheme 46: ILLUSTRATION

Scheme 47

Scheme 47: REMOVAL
Scheme 47: REMOVAL

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56
  1. PRECAUTION NOTE: After turning the ignition switch off, waiting time may be required before disconnecting the cable from the battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal notice before proceeding with work. Refer to «PRECAUTION»(ref-493289-S42810490842012081000000).
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  3. REMOVE NO. 2 INSTRUMENT CLUSTER FINISH PANEL CENTER . Refer to «REMOVAL - Step 8»(/toyota/rav4/iv-2012-2015/remont/gauges-instrument-panels/#instrument-panel-service-information)
  4. REMOVE NO. 1 INSTRUMENT CLUSTER FINISH PANEL CENTER . Refer to «REMOVAL - Step 9»(/toyota/rav4/iv-2012-2015/remont/gauges-instrument-panels/#instrument-panel-service-information)
  5. REMOVE RADIO RECEIVER ASSEMBLY WITH BRACKET for Not Standard Type: Remove the 4 bolts. Pull the radio receiver assembly to detach the 2 claws and 4 clips on the backside of the radio receiver assembly. Disconnect all the connectors and remove the radio receiver assembly with bracket. for Standard Type: Remove the 4 bolts. Pull the radio receiver assembly to detach the 2 claws and 4 clips on the backside of the radio receiver assembly. Disconnect all the connectors and remove the radio receiver assembly with bracket.
  6. REMOVE RADIO AND DISPLAY RECEIVER ASSEMBLY WITH BRACKET Remove the 4 bolts. Pull the radio and display receiver assembly to detach the 2 claws and 4 clips on the backside of the radio and display receiver assembly. Disconnect all the connectors and remove the radio and display receiver assembly with bracket. for Not Standard Type
  7. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY Detach the 4 claws and remove the instrument cluster finish panel.
  8. REMOVE NO. 1 RADIO BRACKET for Not-standard Type: Remove the 4 bolts and No. 1 radio bracket from the radio receiver assembly. for Standard Type: Remove the 4 bolts and No. 1 radio bracket from the radio receiver assembly. for Radio and display Type: Remove the 4 bolts and No. 1 radio bracket from the radio and display receiver assembly.
  9. REMOVE NO. 2 RADIO BRACKET for Not-standard Type: Remove the 4 bolts and No. 2 radio bracket from the radio receiver assembly. for Standard Type: Remove the 4 bolts and No. 2 radio bracket from the radio receiver assembly. for Radio and display Type: Remove the 4 bolts and No. 2 radio bracket from the radio and display receiver assembly.

Scheme 57

Scheme 57
Scheme 57
  1. INSTALL NO. 1 RADIO BRACKET for Radio and display Type: Install the No. 1 radio bracket to the radio and display receiver assembly with the 4 bolts. for Standard Type: Install the No. 1 radio bracket to the radio receiver assembly with the 4 bolts. for Not-standard Type: Install the No. 1 radio bracket to the radio receiver assembly with the 4 bolts.
  2. INSTALL NO. 2 RADIO BRACKET for Radio and display Type: Install the No. 2 radio bracket to the radio and display receiver assembly with the 4 bolts. for Standard Type: Install the No. 2 radio bracket to the radio receiver assembly with the 4 bolts. for Not-standard Type: Install the No. 2 radio bracket to the radio receiver assembly with the 4 bolts.
  3. INSTALL INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY Attach the 4 claws to install the instrument cluster finish panel.
  4. INSTALL RADIO AND DISPLAY RECEIVER ASSEMBLY WITH BRACKET Connect all the connectors. Insert the radio and display receiver assembly with the bracket to attach the 2 claws and 4 clips on its backside. Install the 4 bolts. Torque: 12.8 N*m (130 kgf*cm, 9 ft.*lbf)
  5. INSTALL RADIO RECEIVER ASSEMBLY WITH BRACKET for Not-standard Type: Connect all the connectors. Insert the radio receiver assembly with the bracket to attach the 2 claws and 4 clips on its backside. Install the 4 bolts. Torque: 12.8 N*m (130 kgf*cm, 9 ft.*lbf) for Standard Type: Connect all the connectors. Insert the radio receiver assembly with the bracket to attach the 2 claws and 4 clips on its backside. Install the 4 bolts. Torque: 12.8 N*m (130 kgf*cm, 9 ft.*lbf)
  6. INSTALL NO. 1 INSTRUMENT CLUSTER FINISH PANEL CENTER . Refer to «INSTALLATION - Step 8»(/toyota/rav4/iv-2012-2015/remont/gauges-instrument-panels/#instrument-panel-service-information)
  7. INSTALL NO. 2 INSTRUMENT CLUSTER FINISH PANEL CENTER . Refer to «INSTALLATION - Step 9»(/toyota/rav4/iv-2012-2015/remont/gauges-instrument-panels/#instrument-panel-service-information)
  8. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 58

Scheme 58: ILLUSTRATION
Scheme 58: ILLUSTRATION

Scheme 59

Scheme 59: ILLUSTRATION
Scheme 59: ILLUSTRATION

Scheme 60

Scheme 60: ILLUSTRATION
Scheme 60: ILLUSTRATION

Scheme 61

Scheme 61: REMOVAL
Scheme 61: REMOVAL
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  2. REMOVE REAR DOOR SCUFF PLATE RH . Refer to «REMOVAL - Step 21»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  3. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH . Refer to «REMOVAL - Step 23»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  4. REMOVE PACKAGE TRAY TRIM POCKET SUB-ASSEMBLY (w/o Rear No. 2 Seat) . Refer to «REMOVAL - Step 28»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  5. REMOVE TONNEAU COVER ASSEMBLY (w/o Rear No. 2 Seat) . Refer to «REMOVAL - Step 29»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  6. REMOVE REAR FLOOR NO. 1 BOARD (w/o Rear No. 2 Seat) . Refer to «REMOVAL - Step 30»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  7. REMOVE DECK BOARD ASSEMBLY (w/o Rear No. 2 Seat) . Refer to «REMOVAL - Step 31»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  8. REMOVE NO. 2 SEAT HINGE COVER LH (w/ Rear No. 2 Seat). Refer to «REMOVAL - Step 1»(ref-493526-S39146154962012081000000)
  9. REMOVE NO. 2 SEAT HINGE COVER RH (w/ Rear No. 2 Seat). Refer to «REMOVAL - Step 1»(ref-493526-S39146154962012081000000)
  10. REMOVE NO. 2 SEAT LEG COVER LH (w/ Rear No. 2 Seat). Refer to «REMOVAL - Step 2»(ref-493526-S39146154962012081000000)
  11. REMOVE NO. 2 SEAT LEG COVER RH (w/ Rear No. 2 Seat). Refer to «REMOVAL - Step 2»(ref-493526-S39146154962012081000000)
  12. REMOVE REAR NO. 2 SEAT ASSEMBLY LH (w/ Rear No. 2 Seat). Refer to «REMOVAL - Step 3»(ref-493526-S39146154962012081000000)
  13. REMOVE REAR NO. 2 SEAT ASSEMBLY RH (w/ Rear No. 2 Seat). Refer to «REMOVAL - Step 3»(ref-493526-S39146154962012081000000)
  14. REMOVE REAR FLOOR NO. 3 BOARD . Refer to «REMOVAL - Step 38»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  15. REMOVE REAR FLOOR NO. 2 BOARD . Refer to «REMOVAL - Step 39»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  16. REMOVE REAR FLOOR NO. 1 MAT SUPPORT SIDE PLATE . Refer to «REMOVAL - Step 40»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  17. REMOVE BACK DOOR WEATHERSTRIP . Refer to «REMOVAL - Step 41»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  18. REMOVE REAR FLOOR FINISH PLATE . Refer to «REMOVAL - Step 42»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  19. REMOVE REAR DECK TRIM COVER RH (w/ Rear No. 2 Seat) . Refer to «REMOVAL - Step 44»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  20. REMOVE RECLINING REMOTE CONTROL LEVER BEZEL RH (w/o Rear No. 2 Seat). Refer to «REMOVAL - Step 10»(ref-493526-S22106647992012081000000)
  21. REMOVE TETHER ANCHOR BRACKET SUB-ASSEMBLY (w/o Rear No. 2 Seat) . Refer to «REMOVAL - Step 47»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  22. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (w/o Rear No. 2 Seat) . Refer to «REMOVAL - Step 50»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  23. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (w/ Rear No. 2 Seat) . Refer to «REMOVAL - Step 51»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  24. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY Disconnect the connectors. Remove the 3 bolts and remove the stereo component amplifier.

Scheme 62

Scheme 62: INSTALLATION
Scheme 62: INSTALLATION
  1. INSTALL STEREO COMPONENT AMPLIFIER ASSEMBLY Install the stereo component amplifier with the 3 bolts. HINT: Install the bolts in the order shown in the illustration. Torque: 7.4 N*m (75 kgf*cm, 65 in.*lbf) Connect the connectors.
  2. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (w/ Rear No. 2 Seat) . Refer to «INSTALLATION - Step 30»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  3. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (w/o Rear No. 2 Seat) . Refer to «INSTALLATION - Step 29»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  4. INSTALL TETHER ANCHOR BRACKET SUB-ASSEMBLY (w/o Rear No. 2 Seat) . Refer to «INSTALLATION - Step 31»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  5. INSTALL RECLINING REMOTE CONTROL LEVER BEZEL RH (w/o Rear No. 2 Seat). Refer to «INSTALLATION - Step 11»(ref-493526-S19958740712012081000000)
  6. INSTALL REAR DECK TRIM COVER RH (w/ Rear No. 2 Seat) . Refer to «INSTALLATION - Step 35»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  7. INSTALL REAR FLOOR FINISH PLATE . Refer to «INSTALLATION - Step 36»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  8. INSTALL BACK DOOR WEATHERSTRIP . Refer to «INSTALLATION - Step 37»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  9. INSTALL REAR FLOOR NO. 1 MAT SUPPORT SIDE PLATE . Refer to «INSTALLATION - Step 38»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  10. INSTALL REAR FLOOR NO. 2 BOARD . Refer to «INSTALLATION - Step 40»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  11. INSTALL REAR FLOOR NO. 3 BOARD . Refer to «INSTALLATION - Step 39»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  12. INSTALL REAR NO. 2 SEAT ASSEMBLY RH (w/ Rear No. 2 Seat). Refer to «INSTALLATION - Step 3»(ref-493526-S28011967862012081000000)
  13. INSTALL REAR NO. 2 SEAT ASSEMBLY LH (w/ Rear No. 2 Seat). Refer to «INSTALLATION - Step 3»(ref-493526-S28011967862012081000000)
  14. INSTALL NO. 2 SEAT LEG COVER RH (w/ Rear No. 2 Seat). Refer to «INSTALLATION - Step 4»(ref-493526-S28011967862012081000000)
  15. INSTALL NO. 2 SEAT LEG COVER LH (w/ Rear No. 2 Seat). Refer to «INSTALLATION - Step 4»(ref-493526-S28011967862012081000000)
  16. INSTALL NO. 2 SEAT HINGE COVER RH (w/ Rear No. 2 Seat). Refer to «INSTALLATION - Step 5»(ref-493526-S28011967862012081000000)
  17. INSTALL NO. 2 SEAT HINGE COVER LH (w/ Rear No. 2 Seat). Refer to «INSTALLATION - Step 5»(ref-493526-S28011967862012081000000)
  18. INSTALL DECK BOARD ASSEMBLY (w/o Rear No. 2 Seat) . Refer to «INSTALLATION - Step 47»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  19. INSTALL REAR FLOOR NO. 1 BOARD (w/o Rear No. 2 Seat) . Refer to «INSTALLATION - Step 48»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  20. INSTALL TONNEAU COVER ASSEMBLY (w/o Rear No. 2 Seat) . Refer to «INSTALLATION - Step 49»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  21. INSTALL PACKAGE TRAY TRIM POCKET SUB-ASSEMBLY (w/o Rear No. 2 Seat) . Refer to «INSTALLATION - Step 50»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  22. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH . Refer to «INSTALLATION - Step 56»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  23. INSTALL REAR DOOR SCUFF PLATE RH . Refer to «INSTALLATION - Step 58»(/toyota/rav4/iv-2012-2015/remont/exteriorinterior-trim/#interior-trim-service-information)
  24. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 63

Scheme 63: ILLUSTRATION
Scheme 63: ILLUSTRATION
