WIRING DIAGRAM

Refer to WIRING DIAGRAM under DTC P0010.

Refer to WIRING DIAGRAM under DTC P0335: CRANKSHAFT POSITION SENSOR "A" CIRCUIT MALFUNCTION, DTC P0339: CRANKSHAFT POSITION SENSOR "A" CIRCUIT INTERMITTENT.

Refer to WIRING DIAGRAM under DTC P2195: OXYGEN (A/F) SENSOR SIGNAL STUCK LEAN (BANK 1 SENSOR 1), DTC P2196: OXYGEN (A/F) SENSOR SIGNAL STUCK RICH (BANK 1 SENSOR 1).

Refer to WIRING DIAGRAM under DTC P0136: OXYGEN SENSOR CIRCUIT MALFUNCTION (BANK 1 SENSOR 2).

Refer to WIRING DIAGRAM under DTC P0100: MASS OR VOLUME AIR FLOW CIRCUIT MALFUNCTION, DTC P0102: MASS OR VOLUME AIR FLOW CIRCUIT LOW INPUT, DTC P0103: MASS OR VOLUME AIR FLOW CIRCUIT HIGH INPUT.

Refer to WIRING DIAGRAM under DTC P2195: OXYGEN (A/F) SENSOR SIGNAL STUCK LEAN (BANK 1 SENSOR 1), DTC P2196: OXYGEN (A/F) SENSOR SIGNAL STUCK RICH (BANK 1 SENSOR 1).

Refer to WIRING DIAGRAM under DTC P0335: CRANKSHAFT POSITION SENSOR "A" CIRCUIT MALFUNCTION, DTC P0339: CRANKSHAFT POSITION SENSOR "A" CIRCUIT INTERMITTENT.

Refer to DTC P0441. See DTC P0441: EVAPORATIVE EMISSION CONTROL SYSTEM INCORRECT PURGE FLOW, DTC P0446: EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT, DTC P2418: EVAPORATIVE EMISSION SYSTEM VALVE CONTROL CIRCUIT/OPEN .

Scheme 220

Scheme 220: First Trip Procedure
  1. The vehicle must be cold, and ambient temperature is between approximately 10°C (50°F) and 35°C (95°F).
  2. Intake Air Temperature (IAT) and Engine Coolant Temperature (ECT) sensors indicate almost the same value.
  3. Clear DTCs. Disconnect the battery terminals or EFI fuse for more than 60 seconds. READINESS TESTS will show INCMPL (incomplete).
  4. Drive the vehicle on a freeway. Write down the state of READINESS TESTS. They will change to COMPL as the evaluation monitors operate and if the system passes. This procedure may take approximately 20 minutes or more. NOTE: Do not shut off the engine - the results will be invalid.

Pass Condition - No Problem Found by the ECM

If the EVAP evaluation monitor shows COMPL, go to the NON-CONTINUOUS TESTS screen.

Note. Do not shut off the engine - the results will be invalid.

Scheme 221

Scheme 221

Scheme 222

Scheme 222
  1. To get there, go to Advanced OBD II, Onboard Tests, NON-CONTINUOUS TESTS.
  2. If all of the tests in the time $02 category Tests show "Pass", the evaluation monitor has operated and no problem was detected.

Fail Condition - Problem Detected in the ECM

If the EVAP evaluation monitor shows INCMPL, go to the NON-CONTINUOUS TESTS screen.

Scheme 223

Scheme 223

Scheme 224

Scheme 224

Scheme 225

Scheme 225
  1. If all tests show "Pass", the following may have occurred. The EVAP evaluation monitor did not operate. The EVAP evaluation monitor did not finish. The ECM withheld judgement.
  2. If one or more tests in the time $02 category show "Fail", the EVAP evaluation monitor did operate and the ECM detected a problem.
  3. Go to CONTINUOUS TESTS screen. This is the only place where first trip DTC's are listed. NOTE: The listed DTCs may not be valid. A second trip is needed to confirm the DTCs.

Scheme 226

Scheme 226: Second Trip Procedure
  1. The vehicle must be cold, and the ambient temperature is between approximately 10°C (50°F) and 35°C (95°F).
  2. Go to READINESS TESTS screen.
  3. Drive the vehicle on a freeway. Write down the state of the EVAP evaluation monitor. This procedure may take approximately 20 minutes or more. NOTE: Do not shut off the engine - the results will be invalid.

If READINESS TESTS changes to COMPL, the EVAP evaluation monitor has operated. Check for any stored DTCs.

Scheme 227

Scheme 227
  1. If a DTC Is stored, the problem has been detected and confirmed by the ECM.
  2. If no DTC Is found, the EVAP monitor has operated but no problem Is detected.

Refer to DTC P0441 DTC P0441: EVAPORATIVE EMISSION CONTROL SYSTEM INCORRECT PURGE FLOW, DTC P0446: EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT, DTC P2418: EVAPORATIVE EMISSION SYSTEM VALVE CONTROL CIRCUIT/OPEN

Refer to DTC P0705 (see WIRING DIAGRAM under DTC: P0705 TRANSMISSION RANGE SENSOR CIRCUIT MALFUNCTION (PRNDL INPUT) in AUTOMATIC TRANSAXLE DIAGNOSTICS article).

Refer to DTC P2102. See DTC P2102: THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT LOW, DTC P2103: THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT HIGH .

Refer to DTC P2102. see DTC P2102: THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT LOW, DTC P2103: THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT HIGH .

Refer to DTC P2120. See DTC P2120: THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT, DTC P2122: THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT LOW INPUT, DTC P2123: THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT HIGH INPUT, DTC P2125: THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT, DTC P2127: THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT LOW INPUT, DTC P2128: THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT HIGH INPUT, DTC P2138: THROTTLE/PEDAL POSITION SENSOR/SWITCH "D"/"E" VOLTAGE CORRELATION .

Refer to DTC P2195. See DTC P2195: OXYGEN (A/F) SENSOR SIGNAL STUCK LEAN (BANK 1 SENSOR 1), DTC P2196: OXYGEN (A/F) SENSOR SIGNAL STUCK RICH (BANK 1 SENSOR 1) .

Refer to DTC P2195. See DTC P2195: OXYGEN (A/F) SENSOR SIGNAL STUCK LEAN (BANK 1 SENSOR 1), DTC P2196: OXYGEN (A/F) SENSOR SIGNAL STUCK RICH (BANK 1 SENSOR 1) .
