Sfi System: Removal & Installation Toyota RAV4 II рестайлинг

REPLACEMENT

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

1. REMOVE LH REAR SEAT
2. REMOVE FLOOR SERVICE HOLE COVER
3. DISCONNECT FUEL PUMP & SENDER GAUGE CONNECTOR
4. DISCONNECT VAPOR PRESSURE SENSOR CONNECTOR
5. DISCONNECT FUEL TANK MAIN TUBE CAUTION: Disconnect the fuel tube connector (quick type) observing the precaution (see «SFI SYSTEM»(ref-239091-S33576169842006072600000) ). As there is retained pressure in the fuel line, prevent it from splashing inside the luggage compartment. Remove the tube joint clip and disconnect the main tube.
6. REMOVE FUEL PUMP AND SENDER GAUGE ASSEMBLY FROM FUEL TANK Remove the 8 bolts and fuel tank vent tube set plate. Lift up the fuel pump and sender gauge assembly, and disconnect the fuel sub suction hose from the fuel return jet tube. Remove the fuel pump, sender gauge assembly and gasket. NOTE: Do not damage the fuel suction filter. Be careful not to bend the arm of the sender gauge. Remove the gasket from the suction plate.
7. REMOVE FUEL SUCTION SUPPORT Using a screwdriver, pry out the fuel suction support. NOTE: Be careful not to damage the suction support. Remove the rubber cushion.
8. REMOVE FUEL SUCTION PLATE Disconnect the fuel sender gauge connector and ground plate. Using 2 screwdrivers, pry out the fuel suction plate. NOTE: Be careful not to damage the suction support and suction plate. Remove the fuel pump harness.
9. REMOVE FUEL PUMP Pull out the fuel pump.
10. REMOVE FUEL SUCTION FILTER FROM FUEL PUMP Using a small screwdriver, pry out the clip. Pull out the suction filter.
11. REINSTALL FUEL SUCTION FILTER Install the suction filter with a new clip.
12. REINSTALL FUEL PUMP Push into the fuel pump.
13. REINSTALL FUEL SUCTION PLATE Connect the fuel pump harness. Install the fuel suction plate and fuel filter assembly. Connect the fuel sender gauge connector and ground plate.
14. INSTALL FUEL SUCTION SUPPORT Install the rubber cushion. Install the fuel suction support to the fuel filter assembly.
15. REINSTALL FUEL PUMP AND SENDER GAUGE ASSEMBLY TO FUEL TANK Install a new gasket to the suction plate. Connect the sub suction hose to the fuel return jet tube. Insert the fuel pump assembly into the fuel tank. NOTE: Do not damage the fuel suction filter. Be careful not to bend the arm of the sender gauge. Align the positioning mark of the set plate with bolt hole position A. Install the fuel tank vent tube set plate with the 8 bolts. Torque: 4.0 N.m (40 kgf.cm, 35 in.lbf)
16. RECONNECT FUEL TANK MAIN TUBE Connect the main tube with the tube joint clip. NOTE: Check that the connector is inserted fully and securely. Check that the clip of the tube joint is on the collar of the connector. After installing the clip of the tube joint, check that the connector is not pulled off.
17. RECONNECT VAPOR PRESSURE SENSOR CONNECTOR
18. RECONNECT FUEL PUMP and SENDER GAUGE CONNECTOR
19. CHECK FOR FUEL LEAK (See «SFI SYSTEM»(ref-239091-S33576169842006072600000) )
20. REINSTALL FLOOR SERVICE HOLE COVER
21. REINSTALL LH REAR SEAT

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. REMOVE FUEL PUMP AND SENDER GAUGE ASSEMBLY FROM FUEL TANK (See «REPLACEMENT»(ref-239091-S31830604712006072600000) )
2. REMOVE FUEL SUCTION PLATE Disconnect the fuel sender gauge connector and ground plate. Using 2 screwdrivers, pry out the fuel suction plate. NOTE: Be careful not to damage the suction support and fuel suction plate. Disconnect the fuel pump connector.
3. REMOVE FUEL PRESSURE REGULATOR Disconnect the fuel return jet tube from the clamp. Pull out the pressure regulator. Remove the O-ring from the pressure regulator.
4. REINSTALL FUEL PRESSURE REGULATOR Install a new O-ring to the pressure regulator. Apply a light coat of gasoline to the O-ring, and push into the pressure regulator. Connect the fuel return jet tube to the clamp.
5. REINSTALL FUEL SUCTION PLATE Connect the fuel pump connector. Install the fuel suction plate to the fuel filter and fuel pump assembly. Connect the fuel sender gauge connector and ground plate.
6. REINSTALL FUEL PUMP AND SENDER GAUGE ASSEMBLY TO FUEL TANK (See «REPLACEMENT»(ref-239091-S31830604712006072600000) )

Scheme 87

Scheme 88

1. REMOVE AIR CLEANER ASSEMBLY Disconnect the MAF meter connector. Disconnect the VSV hose for CCV. Remove the 3 bolts and air cleaner assembly, air cleaner inlet, MAF meter together in one piece.
2. INSPECT INJECTOR OPERATION Check the each injectors for operation sound. With the engine running or cranking, use a sound scope to check that there is normal operating noise in proportion to the engine speed. If you have no sound scope, you can check it by feeling the injector operating vibration with your finger. If no sound or unusual sound is heard, check the wiring connector, injector or injection signal from the ECM.
3. INSPECT INJECTOR RESISTANCE Disconnect the injector connector. Using an ohmmeter, measure the resistance between the terminals. Resistance: 11.6 to 12.4 ohm at 20°C (68°F) If the resistance is not as specified, replace the injector. Reconnect the injector connector.
4. REINSTALL AIR CLEANER ASSEMBLY

Scheme 89

Scheme 90

1. DISCONNECT PCV HOSE
2. REMOVE AIR CLEANER INLET AND AIR CLEANER ASSEMBLY WITH MAF METER Disconnect the MAF meter connector. Disconnect the VSV hose for CCV. Remove the 3 bolts and air cleaner assembly, air cleaner inlet, MAF meter together in one piece.
3. REMOVE INJECTORS Disconnect the 4 injector connectors. Remove the 2 bolts holding the delivery pipe to the cylinder head. Disconnect the delivery pipe together with the 4 injectors from the cylinder head. NOTE: Be careful not to drop the injectors when disconnecting the delivery pipe. Remove the 2 spacers and 4 grommets. Pull out the 4 injectors from the delivery pipe. Remove the O-ring from each injector.

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

1. INSPECT INJECTOR INJECTION CAUTION: Keep injector clear of sparks during the test. Disconnect the fuel pipe clamp from the fuel tube connector. Disconnect the fuel inlet tube (fuel tube connector) from the fuel pipe. CAUTION: Disconnect the fuel tube connector (quick type) observing the precaution (see «SFI SYSTEM»(ref-239091-S33576169842006072600000) ). As there is retained pressure in the fuel line, prevent it from splashing inside the engine compartment. Purchase a new fuel tube. Remove the fuel tube connector from its pipe. Fuel tube: Part No. 23901-22110 Connect SST (hose) and fuel tube connector to the fuel pipe. SST 09268-41047 CAUTION: Disconnect the fuel tube connector (quick type) observing the precautions (see «SFI SYSTEM»(ref-239091-S33576169842006072600000) ). Install the grommet and O-ring to the injector. Connect SST (union and hose) to the injector. SST 09268-41047 (09268-41110, 09268-41300) Put the injector into a graduated cylinder. CAUTION: Install a suitable vinyl hose onto the injector to prevent gasoline from splashing out. Connect the hand-held tester to the DLC3. Connect the hand-held tester to the DLC3. Connect the battery negative (-) terminal cable to the battery. Turn the ignition switch ON and push the hand-held tester main switch ON. NOTE: Do not start the engine. Select the ACTIVE TEST mode on the hand-held tester. HINT: Please refer to the hand-held tester operator's manual for further details. If you have no hand-held tester, connect the positive (+) and negative (-) leads from the battery to the fuel pump connector (see «FUEL PUMP»(ref-239091-S02930303862006072600000) ). Connect the battery to the injector with SST (wire) for 15 seconds, and measure the injection volume with a graduated cylinder. Test each injector 2 or 3 times. SST 09842-30080 Injection volume: 76 to 92 cm 3 (4.6 to 5.6 cu in.) per 15 seconds. Difference between each injector: 16 cm 3 (1.0 cu in.) or less If the injection volume is not as specified, replace the injector.
2. INSPECT LEAKAGE In the above condition, disconnect the tester probes of SST (wire) from the battery and check the fuel leak from the injector. SST 09842-30080 Fuel drop: 1 drop or less per 12 minutes. Turn the ignition switch OFF. Disconnect the negative (-) terminal cable from the battery. Remove SST and fuel tube connector. SST 09268-41047 Disconnect the hand-held tester from the DLC3. Reconnect the fuel tube (fuel tube connector). CAUTION: Disconnect the fuel tube connector (quick type) observing the precaution (see «SFI SYSTEM»(ref-239091-S33576169842006072600000) ). Reconnect the fuel pipe clamp to the fuel tube connector.

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. INSTALL INJECTORS AND DELIVERY PIPES Apply a light coat of spindle oil or gasoline to a new O-ring, and install it to each injector. Install the 2 spacers and 4 new grommets to the cylinder head. Apply a light coat of spindle oil or gasoline to the place where a delivery pipe touches the O-ring. Push the injector to the delivery pipes turning the injector (Scheme 104) Then install the 4 injectors. Position the injector connector downward. Attach the delivery pipe together with the 4 injectors to the cylinder head. Temporarily install the 2 bolts holding the delivery pipe to the cylinder head. Check that the injectors rotate smoothly. HINT: If injectors do not rotate smoothly, the possible cause is incorrect installation of the O-ring. Replace the O-ring. Position the injector connector downward. Tighten the 2 bolts holding the delivery pipe to the cylinder head. Torque: 20 N.m (205 kgf.cm, 15 ft.lbf) Connect the 4 injector connectors.
2. INSTALL AIR CLEANER ASSEMBLY WITH MAF METER
3. CONNECT PCV HOSE

Scheme 108

Scheme 109

1. REMOVE AIR CLEANER HOSE
2. DISCONNECT ACCELERATOR CABLE
3. REMOVE FUEL PRESSURE PULSATION DAMPER Disconnect the fuel tube connector (metallic connector) (see «SFI SYSTEM»(ref-239091-S33576169842006072600000) ). CAUTION: Disconnect the fuel tube connector (metallic connector) after observing the precautions. As there is retained pressure in the fuel pipe line, prevent it from splashing inside the engine compartment. Remove the 2 bolts and pulsation damper.
4. REINSTALL FUEL PRESSURE PULSATION DAMPER Install the pulsation damper with the 2 bolts. Torque: 9 N.m (90 kgf.cm, 80 in.lbf) Connect the fuel tube connector (metallic connector) (see «SFI SYSTEM»(ref-239091-S33576169842006072600000) ).
5. RECONNECT ACCELERATOR CABLE
6. RECONNECT AIR CLEANER HOSE

Scheme 110

Scheme 111

Scheme 112

1. Check the fuel lines for cracks or leak, and all connections for deformation.
2. Check the fuel tank for deformation, cracks fuel leak or tank band looseness.
3. Check the filter neck for damage or fuel leak.
4. Check that hose and tube connections are (Scheme 112) If a problem is found, repair or replace the part as necessary.

Scheme 113

Scheme 114

Scheme 115

Scheme 116

1. DISCONNECT MAF METER CONNECTOR
2. REMOVE MAF METER Remove the 2 screws and MAF meter.
3. INSPECT MAF METER Using an ohmmeter, measure the resistance between terminals THA and E2. Resistance: RESISTANCE SPECIFICATION -20°C (-4°F) 13.6 to 18.4 ohm 20°C (68°F) 2.21 to 2.69 ohm 60°C (140°F) 0.49 to 0.67 ohm If the resistance is not as specified, replace the MAF meter. Inspect operation. Connect the MAF meter connector. Connect the negative (-) terminal cable to the battery. Turn the ignition switch ON. Using a voltmeter, connect the positive (+) tester probe to terminal VG, and negative (-) tester probe to terminal E2G. Blow air into the MAF meter, and check that the voltage fluctuates. If operation is not as specified, replace the MAF meter. Turn the ignition switch OFF. Disconnect the negative (-) terminal cable from the battery. Disconnect the MAF meter connector.
4. REINSTALL MAF METER Install the MAF meter with the 2 screws.
5. RECONNECT MAF METER CONNECTOR
