ADJUSTING METHOD FOR JAM PROTECTION
Note. Use this procedure when power window motor has been replaced, when separating window regulator from power window motor or when operating window regulator with door glass removed.
To adjust limit switch to OFF position, connect motor to harness connector and operate power window motor in UP direction for 4-5 seconds. This sets limit switch to full UP position (OFF).
HIGHLANDER
| Problem Symptom | Suspected Area | See Fig. |
|---|---|---|
| B1221/21 Door ECU SW ON | Power Window Regulator Master Switch | (Scheme 12) |
| B1231/31 Driver Side Jam Protection Limit Switch Fault | Left Power Window Regulator Motor Assembly | (Scheme 13) |
| B1232/32 Driver Side Jam Protection Sensor Fault | Left Power Window Regulator Motor Assembly | (Scheme 13) |
| Driver Side AUTO UP/AUTO DOWN Does Not Operate | Left Power Window Regulator Motor Assembly Power Window Regulator Master Switch | (Scheme 13) |
| Driver Side Power Window Operation Is Impossible By Operation Interlocked With Key | (1) Left Front Door Lock Assembly Power Window Regulator Master Switch | (Scheme 14) |
| Driver Side Operation Is Impossible After Key OFF | (2) Front Door Courtesy Light Switch Multiplex Network Body ECU | (Scheme 15) |
| Driver Side Power Window Does Not Operate | D FR DOOR Fuse (20-Amp) ECU B Fuse (7.5-Amp) IG1 Fuse (7.5-Amp) Power Window Regulator Master Switch Left Power Window Regulator Motor Assembly Wiring Harness | (Scheme 16) - (Scheme 18) |
| Windows Cannot Be Operated Via Regulator Switch In Each Seat | D FR DOOR Fuse (20-Amp) P FR DOOR Fuse (25-Amp) D RR DOOR Fuse (20-Amp) P RR DOOR Fuse (20-Amp) Power Window Regulator Switch Rear Power Window Regulator Switch Right Power Window Regulator Motor Left Power Window Regulator Motor Wiring Harness | (Scheme 19) - (Scheme 25) |
| Remote Operation Of Other Seat Via Master Switch Is Impossible | Power Window Regulator Master Switch Multiplex Network Body ECU Wiring Harness | (Scheme 26) - (Scheme 28) |
| (1) Check driver's door lock master switch. See POWER DOOR LOCKS - TRUCKS (EXCEPT SEQUOIA) article. (2) Check door courtesy light switch. See INSTRUMENT PANELS - TRUCKS article. | ||
| (1) | Check driver's door lock master switch. See POWER DOOR LOCKS - TRUCKS (EXCEPT SEQUOIA) article. |
| (2) | Check door courtesy light switch. See INSTRUMENT PANELS - TRUCKS article. |
PROBLEM SYMPTOMS
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Land Cruiser
Place window lock switch to UNLOCK position. Disconnect 20-pin power window master switch connector. Connect positive battery lead to connector terminal No. 15. Connect negative battery lead to connector terminal No. 16. (Scheme 45) Ensure all switch lights illuminate. Connect positive DVOM lead to connector terminal No. 9, and negative DVOM lead to connector terminal No. 16. Ensure DVOM reads battery voltage. Set window lock switch to LOCK position. Ensure all passenger's power window switches do not illuminate. Ensure DVOM reads no voltage. If operation is not as specified, replace power window master switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION.
Sienna
Place window lock switch in UNLOCK position. Disconnect 18-pin power window master switch connector. Connect jumper wire from 12-volt battery positive terminal to terminal No. 7 (White/Blue wire) at master switch harness connector. Connect another jumper wire from negative battery terminal to master switch harness connector terminal No. 1 (White/Black wire). (Scheme 47) Ensure all switch lights illuminate. Place window lock switch in LOCK position and ensure passenger power window switches do not illuminate. If operation is not as specified, replace power window master switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION.
- Disconnect 20-pin power window master switch connector from switch. Inspect connector on wire harness side. See «POWER WINDOW MASTER SWITCH CIRCUIT TEST - CONNECTOR DISCONNECTED (LAND CRUISER)»(ref-131083-S08096945392001121000000) table. (Scheme 45) If circuit is not as specified, inspect circuits connected to other components.
- Connect 20-pin power window master switch. Inspect connector from back side of connector. See «POWER WINDOW MASTER SWITCH CIRCUIT TEST - CONNECTOR CONNECTED (LAND CRUISER)»(ref-131083-S20549790722001121000000) table. (Scheme 45) If circuit is not as specified, inspect circuits connected to other components.
| Connector Terminal No. To Ground | Condition | Result |
|---|---|---|
| 9 | Constant | Continuity |
| 1 | Constant | Battery Voltage |
| 3 | Ignition Switch In LOCK Position | No Voltage |
| 3 | Ignition Switch In ACC Or ON Position | Battery Voltage |
POWER WINDOW MASTER SWITCH CIRCUIT TEST - CONNECTOR DISCONNECTED (LAND CRUISER)
| Connector Terminal No. To Ground | Condition | Result |
|---|---|---|
| 6 | (1) Window Lock Switch OFF | Battery Voltage |
| 6 | (1) Window Lock Switch ON | No Voltage |
| 8 | (1) Master Switch OFF | No Voltage |
| 8 | (1) Master Switch DOWN | 9 Volts Or Greater |
| 8 | (1) Driver Door Glass Closed | No Voltage |
| 8 | (1) Master Switch AUTO DOWN | 9 Volts Or Greater |
| 8 | (1) Driver Door Glass Open | No Voltage |
| 10 | Constant | Continuity |
| 12 | Power Window Operating | Approximately 5.5 Volts |
| 13 | Master Switch DOWN (Driver Door Glass Open) | Less Than 1 Volt |
| 13 | Master Switch UP (Driver Door Glass Closed) | 10-14 Volts |
| 13 | Master Switch OFF | No Voltage |
| 18 | (1) | 2.5 Volts |
| 20 | (1) Master Switch OFF | No Voltage |
| 20 | (1) Master Switch DOWN | 9 Volts Or Greater |
| 20 | (1) Driver Door Glass Is Closed | No Voltage |
| 20 | (1) Master Switch AUTO UP | 9 Volts Or Greater |
| 20 | (1) Driver Door Glass Is Open | No Voltage |
| (1) Ignition switch in ON position. | ||
| (1) | Ignition switch in ON position. |
POWER WINDOW MASTER SWITCH CIRCUIT TEST - CONNECTOR CONNECTED (LAND CRUISER)
Scheme 45
RAV4
Disconnect 18-pin power window master switch connector. (Scheme 46) Continuity should exist between all terminals listed in table. See POWER WINDOW MASTER SWITCH CIRCUIT TEST (RAV4) table. If continuity is not as specified, replace master switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION.
| Application & Switch Position | Terminals No. | ||
|---|---|---|---|
| Driver's Switch | |||
| Locked & Unlocked | |||
| UP | 4 & 7; 1, 3 & 9 | ||
| OFF | 1, 3 & 4; 1, 3, & 9 | ||
| DOWN | 3 & 4; 5 & 6 | ||
| Front Passenger's Switch | |||
| Locked | |||
| UP | 6 & 13 | ||
| OFF | 13 & 15 | ||
| DOWN | 6 & 15 | ||
| Unlocked | |||
| UP | 6 & 13; 1, 3 & 15 | ||
| OFF | 1, 3 & 13; 1, 3 & 15 | ||
| DOWN | 6 & 15; 1, 3 & 13 | ||
| Left Rear Switch | |||
| Locked | |||
| UP | 6 & 12 | ||
| OFF | 10 & 12 | ||
| DOWN | 6 & 10 | ||
| Unlocked | |||
| UP | 6 & 12; 1, 3 & 10 | ||
| OFF | 1, 3 & 12; 1, 3 & 10 | ||
| DOWN | 6 & 10; 1, 3 & 12 | ||
| Right Rear Switch | |||
| Locked | |||
| UP | 6 &18 | ||
| OFF | 16 & 18 | ||
| DOWN | 6 & 16 | ||
| Unlocked | |||
| UP | 6 & 18; 1, 3 & 16 | ||
| OFF | 1, 3 & 18; 1, 3 & 16 | ||
| DOWN | 6 & 16; 1, 3 & 18 | ||
POWER WINDOW MASTER SWITCH CIRCUIT TEST (RAV4)
Scheme 46
Disconnect 18-pin power window master switch connector. (Scheme 47) Continuity should exist between all terminals listed in table. See POWER WINDOW MASTER SWITCH CIRCUIT TEST (RAV4) table. If continuity is not as specified, replace power window master switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION.
| Application & Switch Position | Terminals No. | ||
|---|---|---|---|
| Driver's Switch | |||
| Unlocked | |||
| AUTO UP | 1 & 9; 4 & 7 | ||
| UP | 1 & 9; 4 & 7 | ||
| OFF | 1, 4 & 9 | ||
| DOWN | 1 & 4; 7 & 9 | ||
| AUTO DOWN | 1 & 4; 7 & 9 | ||
| Front Passenger's Switch | |||
| Locked | |||
| UP | 6 & 13 | ||
| OFF | 13 & 15 | ||
| DOWN | 6 & 15 | ||
| Unlocked | |||
| UP | 1 & 15; 6 & 13 | ||
| OFF | 1, 13 & 15 | ||
| DOWN | 1 & 13; 6 & 15 | ||
POWER WINDOW MASTER SWITCH CIRCUIT TEST (SIENNA)
Scheme 47
Tacoma
Disconnect 10-pin or 14-pin power window master switch connector. (Scheme 48)and (Scheme 49). Continuity should exist between all terminals listed in table. See POWER WINDOW MASTER SWITCH CIRCUIT TEST (TACOMA) table. If continuity is not as specified, replace power window master switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION.
| Application & Switch Position | Terminals No. | |||
|---|---|---|---|---|
| 2-Door Models | ||||
| Driver's Switch | ||||
| Locked & Unlocked | ||||
| UP | 1 & 4; 3 & 9 | |||
| OFF | 1, 3 & 4 | |||
| DOWN | 1 & 3; 4 & 9 | |||
| DOWN AUTO | 1 & 3; 4 & 9 | |||
| Passenger's Switch | ||||
| Locked | ||||
| UP | 8 & 9 | |||
| OFF | 8 & 10 | |||
| DOWN | 9 & 10 | |||
| Unlocked | ||||
| UP | 1 & 10; 8 & 9 | |||
| OFF | 1, 8 & 10 | |||
| DOWN | 1 & 8; 9 & 10 | |||
| 4-Door Models | ||||
| Driver's Switch | ||||
| Locked & Unlocked | ||||
| UP | 1 & 10; 3 & 5 | |||
| OFF | 1, 3 & 5 | |||
| DOWN | 1 & 3; 5 & 10 | |||
| DOWN AUTO | 1 & 3; 5 & 10 | |||
| Front Passenger's Switch | ||||
| Locked | ||||
| UP | 10 & 14 | |||
| OFF | 6 & 14 | |||
| DOWN | 6 & 10 | |||
| Unlocked | ||||
| UP | 3 & 6; 10 & 14 | |||
| OFF | 3, 6 & 14 | |||
| DOWN | 3 & 14; 6 & 10 | |||
| Left Rear Switch | ||||
| Locked | ||||
| UP | 9 & 10 | |||
| OFF | 9 & 12 | |||
| DOWN | 10 & 12 | |||
| Unlocked | ||||
| UP | 3 & 12; 9 & 10 | |||
| OFF | 3, 9 & 12 | |||
| DOWN | 3 & 9; 10 & 12 | |||
| Right Rear Switch | ||||
| Locked | ||||
| UP | 8 &10 | |||
| OFF | 8 & 13 | |||
| DOWN | 10 & 13 | |||
| Unlocked | ||||
| UP | 3 & 13; 8 & 10 | |||
| OFF | 3, 8 & 13 | |||
| DOWN | 3 & 8; 10 & 13 | |||
POWER WINDOW MASTER SWITCH CIRCUIT TEST (TACOMA)
Scheme 48
Scheme 49
Tundra
Disconnect 10-pin power window master switch connector. (Scheme 50) Check switch for voltage or continuity. See POWER WINDOW MASTER SWITCH CIRCUIT TEST - CONNECTOR DISCONNECTED (TUNDRA) and POWER WINDOW MASTER SWITCH CIRCUIT TEST - CONNECTOR CONNECTED (TUNDRA) tables.
| Connector Terminal No. To Ground | Condition | (1) Result |
|---|---|---|
| 1 | Constant | Continuity |
| 3 | Constant | No Continuity |
| 4 | Constant | No Continuity |
| 8 | Constant | No Continuity |
| 9 | Constant | Battery voltage |
| 10 | Constant | No Continuity |
| (1) If circuit is not as specified, inspect circuits connected to other components. | ||
| (1) | If circuit is not as specified, inspect circuits connected to other components. |
POWER WINDOW MASTER SWITCH CIRCUIT TEST - CONNECTOR DISCONNECTED (TUNDRA)
| Application & Switch Position | Terminals No. (1) | ||
|---|---|---|---|
| Driver's Switch | |||
| UP | 1 & 4; 3 & 9 | ||
| OFF | 1, 3 & 4 | ||
| DOWN | 1 & 3; 4 & 9 | ||
| Passenger's Switch | |||
| Locked | |||
| UP | 8 & 9 | ||
| OFF | 8 & 10 | ||
| DOWN | 9 & 10 | ||
| Unlocked | |||
| UP | 1 & 10; 8 & 9 | ||
| OFF | (2) 1, 8 & 10 | ||
| DOWN | 1 & 8; 9 & 10 | ||
| (1) Continuity should exist at all terminals unless otherwise specified. If continuity is not as specified, replace power window master switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION. (2) Continuity should not exist at these terminals. | |||
| (1) | Continuity should exist at all terminals unless otherwise specified. If continuity is not as specified, replace power window master switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION. |
| (2) | Continuity should not exist at these terminals. |
POWER WINDOW MASTER SWITCH CIRCUIT TEST - CONNECTOR CONNECTED (TUNDRA)
Scheme 50
4Runner
Note. 4Runner is equipped with 2 master switches (one 7-pin and one 14-pin). For the purpose of these tests, the 14-pin connector is used.
Disconnect power window master switch 14-pin connector. (Scheme 51) Connect positive lead from battery to connector terminals No. 3 (Blue wire) and 10 (Blue/Red wire). Connect negative lead from battery to connector terminal No. 4 (White/Black wire). Check for continuity at switch. See POWER WINDOW MASTER SWITCH CIRCUIT CONTINUITY TEST (4RUNNER), POWER WINDOW MASTER SWITCH CIRCUIT VOLTAGE TEST (4RUNNER) and POWER WINDOW MASTER SWITCH POWER SUPPLY TEST (4RUNNER) tables. If results are not as specified, replace power window master switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION.
| Application & Switch Position | Terminals No. | ||
|---|---|---|---|
| Driver's Switch | |||
| Locked & Unlocked | |||
| UP | (1) 2 & 4 | ||
| DOWN | (1) 1 & 4 | ||
| Left Rear Switch | |||
| Locked | |||
| UP | (2) 11 & 4 | ||
| DOWN | (2) 9 & 4 | ||
| Unlocked | |||
| UP | (1) 11 & 4 | ||
| DOWN | (1) 9 & 4 | ||
| Right Rear Switch | |||
| Locked | |||
| UP | (2) 14 & 4 | ||
| DOWN | (2) 13 & 4 | ||
| Unlocked | |||
| UP | (1) 14 & 4 | ||
| DOWN | (1) 13 & 4 | ||
| (1) Continuity should exist at these terminals. (2) Continuity does not exist at these terminals. | |||
| (1) | Continuity should exist at these terminals. |
| (2) | Continuity does not exist at these terminals. |
POWER WINDOW MASTER SWITCH CIRCUIT CONTINUITY TEST (4RUNNER)
| Application & Switch Position | (1) Terminals No. | ||
|---|---|---|---|
| Driver's Switch | |||
| Locked & Unlocked | |||
| UP | 1 & 3 | ||
| DOWN | 2 & 3 | ||
| Front Passenger's Switch | |||
| Locked & Unlocked | |||
| UP | 7 & 10 | ||
| DOWN | 8 & 10 | ||
| Left Rear Switch | |||
| Locked & Unlocked | |||
| UP | 9 & 10 | ||
| DOWN | 11 & 10 | ||
| Right Rear Switch | |||
| Locked & Unlocked | |||
| UP | 13 & 10 | ||
| DOWN | 14 & 10 | ||
| (1) battery voltage should exist at these terminals. | |||
| (1) | Battery voltage should exist at these terminals. |
POWER WINDOW MASTER SWITCH VOLTAGE TEST (4RUNNER)
| Connector Terminal No. To Ground | Condition | Result |
|---|---|---|
| 3 | Constant | Battery voltage |
| 4 | Constant | Continuity |
| 10 | Ignition Switch Position In LOCK Or ACC Position | (1) No Voltage |
| 10 | Ignition Switch In ON Position | Battery voltage |
| (1) Voltage will be present for up to 45 seconds after ignition switch is turned to OFF position, or until driver or passenger door is opened. | ||
| (1) | Voltage will be present for up to 45 seconds after ignition switch is turned to OFF position, or until driver or passenger door is opened. |
POWER WINDOW MASTER SWITCH POWER SUPPLY TEST (4RUNNER)
Scheme 51
- Disconnect 12-pin connector from power window switch. Check for continuity or voltage on wire harness side. See «POWER WINDOW SWITCH CIRCUIT TEST - CONNECTOR DISCONNECTED (LAND CRUISER)»(ref-131083-S22494545662001121000000) table. (Scheme 52) If circuit is not as specified, inspect circuits connected to other components.
- Connect power window switch. Check for continuity or voltage at back side of connector. See «POWER WINDOW SWITCH CIRCUIT TEST - CONNECTOR CONNECTED (LAND CRUISER)»(ref-131083-S04666145172001121000000) table. (Scheme 52) If results are not as specified, inspect circuits connected to other components.
| Connector Terminal No. To Ground | Condition | Result |
|---|---|---|
| 9 | Constant (Front Left Side Only) | Continuity |
| 10 | Constant (Rear Left Side Only) | Continuity |
| 12 | Constant | Continuity |
| 7 | Constant | Battery voltage |
| 8 | Ignition Switch In LOCK Position | No Voltage |
| 8 | Ignition Switch In ACC Or ON Position | Battery voltage |
| 11 | (1) Power Window Master Lock Switch Off | Battery voltage |
| 11 | (1) Power Window Master Lock Switch On | No Voltage |
| (1) Ignition switch in ON position. | ||
| (1) | Ignition switch in ON position. |
POWER WINDOW SWITCH CIRCUIT TEST - CONNECTOR DISCONNECTED (LAND CRUISER)
| Connector Terminal No. To Ground | Condition | Result |
|---|---|---|
| 2 | Constant | Continuity |
| 8 | (1) | 2.5 Volts |
| 1 | (1) Master Switch OFF | No Voltage |
| 1 | (1) Master Switch DOWN | 9 Volts Or Greater |
| 1 | (1) Driver Door Glass Closed | No Voltage |
| 1 | (1) Master Switch AUTO UP | 9 Volts Or Greater |
| 1 | (1) Driver Door Glass Open | No Voltage |
| 3 | Master Switch UP (Driver Door Glass Open) | Less Than 1 Volt |
| 3 | Master Switch UP (Driver Door Glass Closed) | 10-14 Volts |
| 3 | Master Switch OFF | No Voltage |
| 4 | Power Window Operating | Approximately 5.5 Volts |
| 6 | (1) Master Switch OFF | No Voltage |
| 6 | (1) Master Switch DOWN | 9 Volts Or Greater |
| 6 | (1) Driver Door Glass Closed | No Voltage |
| 6 | (1) Master Switch AUTO DOWN | 9 Volts Or Greater |
| 6 | (1) Driver Door Glass Open | No Voltage |
| (1) Ignition switch in ON position. | ||
| (1) | Ignition switch in ON position. |
POWER WINDOW SWITCH CIRCUIT TEST - CONNECTOR CONNECTED (LAND CRUISER)
Scheme 52
RAV4, Sequoia, Sienna, Tacoma, Tundra & 4Runner
Note. For connector terminal identification (Scheme 53)- (Scheme 56).
- Test passenger's, rear and back door power window switches for continuity. See «POWER WINDOW SWITCH CONTINUITY TEST (RAV4, SEQUOIA, SIENNA, TACOMA, TUNDRA & 4RUNNER)»(ref-131083-S25459953452001121000000) table. Continuity should exist between all terminals unless otherwise specified. If continuity is not as specified, replace appropriate power window switch. See «POWER WINDOW SWITCH»(ref-131083-S42919744332001121000000) under REMOVAL & INSTALLATION.
- On 4Runner, test front passenger power window switch for power supply. Connect positive battery lead to 12-pin connector terminal No. 7 (Blue wire), and negative battery lead to connector terminal No. 12 (White/Black wire). See «POWER WINDOW SWITCH POWER SUPPLY TEST (4RUNNER)»(ref-131083-S08822643122001121000000) . battery voltage should exist between all terminals. If voltage is not as specified, replace power window switch. See «POWER WINDOW SWITCH»(ref-131083-S42919744332001121000000) under REMOVAL & INSTALLATION.
- On 4Runner, test front passenger power window switch circuit. Disconnect connector from switch. Test connector on wire harness side. See «POWER WINDOW SWITCH CIRCUIT TEST (4RUNNER)»(ref-131083-S38160815682001121000000) . If circuit is not as specified, inspect circuits connected to other components.
| Application & Switch Position | Terminals No. | ||
|---|---|---|---|
| RAV4, Sienna & Tundra | |||
| UP | 1 & 2; 3 & 4 | ||
| OFF | 1 & 2; 3 & 5 | ||
| DOWN | 1 & 4; 3 & 5 | ||
| Sequoia | |||
| Rear Doors | |||
| UP | 2 & 3; 4 & 5 | ||
| OFF | 2, 3 & 5 | ||
| DOWN | 2 & 4; 3 & 5 | ||
| Back Door | |||
| UP | 3 & 6 | ||
| OFF (1) | — | ||
| DOWN | 3 & 5 | ||
| Tacoma | |||
| Front Door | |||
| UP | 1 & 2; 3 & 4 | ||
| OFF | 1 & 2; 3 & 5 | ||
| DOWN | 1 & 4; 3 & 5 | ||
| Rear Doors | |||
| UP | 1 & 3; 4 & 5 | ||
| OFF | 1 & 2; 4 & 5 | ||
| DOWN | 1 & 2; 3 & 5 | ||
| 4Runner | |||
| Front Door (2) | |||
| UP | 6 & 12 | ||
| DOWN | 1 & 12 | ||
| Rear Doors | |||
| UP | 1 & 2; 3 & 4 | ||
| OFF | 1 & 2; 3 & 5 | ||
| DOWN | 1 & 4; 3 & 5 | ||
| (1) Continuity should not exist. (2) Connect positive battery lead to 12-pin connector No. 7, and negative battery lead to terminal No. 12. | |||
| (1) | Continuity should not exist. |
| (2) | Connect positive battery lead to 12-pin connector No. 7, and negative battery lead to terminal No. 12. |
POWER WINDOW SWITCH CONTINUITY TEST (RAV4, SEQUOIA, SIENNA, TACOMA, TUNDRA & 4RUNNER)
| Switch Position | Terminals No. |
|---|---|
| UP | 6 & 12 |
| DOWN | 1 & 12 |
POWER WINDOW SWITCH POWER SUPPLY TEST (4RUNNER)
| Connector Terminal No. To Ground | Condition | Result |
|---|---|---|
| 7 | Ignition Switch In LOCK Or ACC Position | No Voltage (1) |
| 7 | Ignition Switch In ON Position | Battery voltage |
| 12 | Constant | Continuity |
| (1) Voltage will be present for up to 60 seconds after ignition switch is turned to OFF position, or until driver or passenger door is opened. | ||
| (1) | Voltage will be present for up to 60 seconds after ignition switch is turned to OFF position, or until driver or passenger door is opened. |
POWER WINDOW SWITCH CIRCUIT TEST (4RUNNER)
Scheme 53
Scheme 54
Scheme 55
Scheme 56
| CAUTION | Wire harness must be connected properly or damage to sensor may result. |
Disconnect 5-pin power window motor harness connector located in power window regulator assembly. Connect positive ohmmeter lead to connector terminal No. 2 and negative ohmmeter lead to connector terminal No. 5. (Scheme 64) Connect positive battery lead to connector terminal No. 1 and negative battery lead to connector terminal No. 4. Ensure continuity exists when window goes up. Ensure no continuity exists when window is in fully closed position. If operation is not as specified, replace motor. See POWER WINDOW MOTOR under REMOVAL & INSTALLATION.
| CAUTION | Wire harness must be connected properly or damage to sensor may result. |
- Disconnect connector from master switch. To test with window up, connect positive ohmmeter lead to connector terminal No. 17, and negative ohmmeter lead to connector terminal No. 2. (Scheme 46) Connect positive battery lead to connector terminal No. 4, and negative battery lead to connector terminal No. 9. Ensure continuity exists when window goes up. Ensure no continuity exists when window is in fully closed position. If operation is not as specified, replace motor. See «POWER WINDOW MOTOR»(ref-131083-S19157245562001121000000) under REMOVAL & INSTALLATION.
- To test with window down, connect positive ohmmeter lead to connector terminal No. 17, and negative ohmmeter lead to connector terminal No. 2. (Scheme 46) Connect positive battery lead to connector terminal No. 9, and negative battery lead to connector terminal No. 4. Ensure continuity exists when window goes up. Ensure no continuity exists when window is in fully opened position. If operation is not as specified, replace motor. See «POWER WINDOW MOTOR»(ref-131083-S19157245562001121000000) under REMOVAL & INSTALLATION.
Sequoia
| CAUTION | Wire harness must be connected properly or damage to sensor may result. |
Disconnect back door window limit switch. Connect positive ohmmeter lead to connector terminal No. 1 and negative ohmmeter lead to connector terminal No. 2. Continuity should exist with switch lever in ON position. Continuity should not exist with switch lever in OFF position. If operation is not as specified, replace back door power window regulator assembly.
| CAUTION | Wire harness must be connected properly or damage to sensor may result. |
Disconnect power window motor harness connector. Connect positive ohmmeter lead to connector terminal No. 4, and negative ohmmeter lead to connector terminal No. 6. (Scheme 66) Connect positive battery lead to connector terminal No. 2 and negative battery lead to connector terminal No. 1. Ensure continuity exists when window goes up. Ensure no continuity exists when window is in fully closed position. If operation is not as specified, replace motor. See POWER WINDOW MOTOR under REMOVAL & INSTALLATION.
Disconnect back door limit switch. Connect positive ohmmeter lead to limit switch connector terminal No. 1 on wire harness side. Connect negative ohmmeter lead to connector terminal No. 2. With switch lever pushed (in OFF position), continuity should not exist between terminals. With switch lever released (in ON position), continuity should exist between terminals. If continuity is not as specified, replace back door limit switch.
| CAUTION | Wire harness must be connected properly or damage to sensor may result. |
Disconnect 5-pin power window motor connector located in power window regulator assembly. Connect positive lead of DVOM to connector terminal No. 3, and negative lead to connector terminal No. 5. (Scheme 64) Connect positive battery lead to connector terminal No. 1 and negative battery lead to connector terminal No. 4. Ensure pulse is generated while motor is running. Reverse polarity. Ensure pulse is generated. If operation is not as specified, replace motor. See POWER WINDOW MOTOR under REMOVAL & INSTALLATION.
| CAUTION | Wire harness must be connected properly or damage to sensor may result. |
Disconnect power window motor connector. Connect positive lead of DVOM to connector terminal No. 14, and negative lead of tester to connector terminal No. 2. (Scheme 46) Connect positive battery lead to connector terminal No. 4, and negative battery lead to connector terminal No. 9. Ensure pulse is generated while motor is running. Reverse polarity. Ensure pulse is generated. If operation is not as specified, replace motor. See POWER WINDOW MOTOR under REMOVAL & INSTALLATION.
| CAUTION | Wire harness must be connected properly or damage to sensor may result. |
Disconnect 7-pin driver's side power window motor connector. Connect positive lead of DVOM to connector terminal No. 5 (Gray wire), and negative lead of tester to connector terminal No. 6 (Brown wire). (Scheme 66) Connect positive battery lead to connector terminal No. 2 (Green wire), and negative battery lead to connector terminal No. 1 (Red wire). Ensure pulse is generated while motor is running. Reverse polarity. Ensure pulse is generated. If operation is not as specified, replace motor. See POWER WINDOW MOTOR under REMOVAL & INSTALLATION.
Land Cruiser & Sienna
Disconnect power quarter window switch. Test switch for continuity. See POWER QUARTER WINDOW SWITCH CONTINUITY TEST. (Scheme 57)and (Scheme 58). Continuity should exist between specified terminals. If continuity is not as specified, replace switch.
| Application & Switch Position | Test Between Connector Terminals No. | |
|---|---|---|
| Land Cruiser | ||
| OPEN | 3 & 4; 5 & 6 | |
| OFF | — | |
| CLOSED | 3 & 6; 4 & 5 | |
| Illumination Circuit | 1 & 2 | |
| Sienna | ||
| OPEN | 3 & 8; 6 & 7 | |
| OFF | 6 & 7; 8 & 9 | |
| CLOSED | 3 & 7; 8 & 9 | |
| Illumination Circuit | 1 & 5 | |
POWER QUARTER WINDOW SWITCH CONTINUITY TEST
Scheme 57
Scheme 58
JAM PROTECTION FUNCTION
Ensure window fully closes when AUTO UP function is selected. Place handle of a hammer in window. Operate AUTO UP function. Ensure window descends when it touches the handle of the hammer. Ensure window will then stop after descending about 7.87" (200 mm). If jam protection function does not operate properly, adjust power window motor reset (limit) switch and pulse switch. See ADJUSTING METHOD FOR JAM PROTECTION under ADJUSTMENTS.
RAV4, Sequoia & Tundra
Note. System circuit breaker opens 4-40 seconds after window operation stops. Ensure circuit test is performed before circuit breaker operates.
- To test system with an ammeter, disconnect electrical connector from master switch. On RAV4, connect positive ammeter lead to connector terminal No. 4 on wire harness side of connector. Connect negative ammeter lead to negative battery terminal. Connect positive battery lead to connector terminal No. 9 on wire harness side of connector. (Scheme 46)
- On Sequoia and 4Runner, connect positive ammeter lead to connector terminal No. 1 on wire harness side. Connect negative ammeter lead to negative battery terminal. Connect positive battery lead to connector terminal No. 2 on wire harness. (Scheme 51) See «WIRING DIAGRAMS»(ref-131083-S27799278492001121000000).
- On Tundra, connect positive ammeter lead to connector terminal No. 3 on wire harness side. Connect negative ammeter lead to negative battery terminal. Connect positive battery lead to connector terminal No. 4 on wire harness side. (Scheme 50)
- To test system with an ammeter with a current-measuring probe, remove master switch with connector connected. On RAV4, attach a current-measuring probe to connector terminal No. 5 on wire harness side. On Tundra, attach probe to connector terminal No. 9 on wire harness side. On 4Runner, attach probe to connector terminal No. 3 on wire harness side. Turn ignition switch to ON position. Set power window switch in down position.
- As window goes down, current flow should be approximately 7 amps. Current should increase to approximately 14.5 amps when window stops going down. If operation is not as specified, replace master switch. See «POWER WINDOW SWITCH»(ref-131083-S42919744332001121000000) under REMOVAL & INSTALLATION.
Except Highlander
Remove relay located in driver side junction block. Continuity should exist between relay terminals No. 1 and 2 at all times. (Scheme 59)and (Scheme 60). Continuity should not exist between relay terminals No. 3 and 5. Apply battery voltage across relay terminals No. 1 and 2. Continuity should now exist between relay terminals No. 3 and 5. If continuity is not as specified, replace relay. If continuity is as specified, inspect wire harness and connector between power main relay and ECU, and between battery and power main relay. Repair or replace wire harness and/or connector as necessary.
Scheme 59
Scheme 60
Disconnect power regulator switch electrical connector. Connect positive battery lead to connector terminal No. 8, and negative battery lead to connector terminal No. 1. (Scheme 61) With switch in UP position, continuity should exist between connector terminals No. 3 and 7, and between connect terminals No. 1 and 6. With switch in DOWN position, continuity should exist between connector terminals No. 1 and 3, and between connector terminals No. 6 and 7. If continuity is not as specified, replace power window regulator switch.
Scheme 61
Test 10-pin tailgate power window switch (on switch side) for continuity. See TAILGATE POWER WINDOW SWITCH CONTINUITY TEST (4RUNNER) table. (Scheme 62) Continuity should exist between specified terminals. If continuity is not as specified, replace tailgate power window switch.
| Switch Position | Terminals No. |
|---|---|
| UP | 2 & 6 |
| DOWN | 1 & 6 |
| Illumination Circuit (UP, DOWN, OFF) | 5 & 8 |
TAILGATE POWER WINDOW SWITCH CONTINUITY TEST (4RUNNER)
Scheme 62
Test back door control switch for continuity. See BACK DOOR CONTROL SWITCH CONTINUITY (SEQUOIA) table. See WIRING DIAGRAMS . If results are not as specified, replace switch.
| Switch Position | Test Between Connector Terminals No. | Result |
|---|---|---|
| UP | 3 & 5 | Continuity |
| OFF | — | No Continuity |
| DOWN | 3 & 6 | Continuity |
BACK DOOR CONTROL SWITCH CONTINUITY (SEQUOIA)
Test 3-pin back door control switch for continuity. See BACK DOOR CONTROL SWITCH CONTINUITY (4RUNNER) table. (Scheme 63) If results are not as specified, replace switch.
| Switch Position | Test Between Connector Terminals No. | Result |
|---|---|---|
| UP | 2 & 3 | Continuity |
| OFF | — | No Continuity |
| DOWN | 1 & 3 | Continuity |
BACK DOOR CONTROL SWITCH CONTINUITY (4RUNNER)
Scheme 63
Disconnect 5-pin power window motor harness connector. Test power window motor operation on wire harness side of connector. See POWER WINDOW MOTOR OPERATION (LAND CRUISER) table. (Scheme 64) If operation is not as specified, replace motor.
| Application | Power To Terminal No. | Ground Terminal No. | Motor Operating Direction |
|---|---|---|---|
| Driver & Rear Right Door | 1 | 4 | Counterclockwise |
| Driver & Rear Right Door | 4 | 1 | Clockwise |
| Passenger & Rear Left Door | 4 | 1 | Clockwise |
| Passenger & Rear Left Door | 1 | 4 | Counterclockwise |
POWER WINDOW MOTOR OPERATION (LAND CRUISER)
Scheme 64
Disconnect 6-pin power window motor harness connector. Test power window motor operation on wire harness side of connector. See POWER WINDOW MOTOR OPERATION (RAV4) table. (Scheme 65) If operation is not as specified, replace motor.
| Application | Power To Terminal No. | Ground Terminal No. | Motor Operating Direction |
|---|---|---|---|
| Driver & Rear Right Door | 1 | 4 | Counterclockwise |
| Driver & Rear Right Door | 4 | 1 | Clockwise |
| Passenger & Rear Left Door | 5 | 4 | Clockwise |
| Passenger & Rear Left Door | 4 | 5 | Counterclockwise |
POWER WINDOW MOTOR OPERATION (RAV4)
Scheme 65
Disconnect 7-pin (driver's side) or 2-pin (passenger's side) power window motor harness connectors. Test power window motor operation on wire harness side of connector. See POWER WINDOW MOTOR OPERATION (SIENNA) table. (Scheme 66)and (Scheme 67). If operation is not as specified, replace appropriate motor.
| Application | Power To Terminal No. | Ground Terminal No. | Motor Operating Direction |
|---|---|---|---|
| Driver's & Passenger's Door | 2 | 1 | Clockwise |
| Driver's & Passenger's Door | 1 | 2 | Counterclockwise |
POWER WINDOW MOTOR OPERATION (SIENNA)
Scheme 66
Scheme 67
Sequoia & Tundra
Disconnect 6-pin (driver's and passenger's side) and 2-pin (rear) power window motor harness connectors. Test power window motor operation on wire harness side of connector. See POWER WINDOW MOTOR OPERATION (SEQUOIA & TUNDRA) table. (Scheme 68)and (Scheme 69). See WIRING DIAGRAMS. If operation is not as specified, replace appropriate motor.
| Application | Power To Terminal No. | Ground Terminal No. | Motor Operating Direction |
|---|---|---|---|
| All Doors | 1 | 2 | Clockwise |
| All Doors | 2 | 1 | Counterclockwise |
POWER WINDOW MOTOR OPERATION (SEQUOIA & TUNDRA)
Scheme 68
Scheme 69
Disconnect 2-pin (all doors) power window motor harness connector. Test power window motor operation on wire harness side of connector. See POWER WINDOW MOTOR OPERATION (TACOMA) table. If operation is not as specified, replace motor.
| Application | Power To Terminal No. | Ground Terminal No. | Motor Operating Direction |
|---|---|---|---|
| Driver's, Front Passenger's & Rear Right Side Doors | 1 | 2 | Clockwise |
| Driver's, Front Passenger's & Rear Right Side Doors | 2 | 1 | Counterclockwise |
| Rear Left Side Door | 1 | 2 | Counterclockwise |
| Rear Left Side Door | 2 | 1 | Clockwise |
POWER WINDOW MOTOR OPERATION (TACOMA)
Disconnect 2-pin (all doors) power window motor harness connector. Test power window motor operation on wire harness side of connector. See POWER WINDOW MOTOR OPERATION (4RUNNER) table. If operation is not as specified, replace motor.
| Application | Power To Terminal No. | Ground Terminal No. | Motor Operating Direction |
|---|---|---|---|
| Driver's, Front Passenger's, Rear Left Side & Back Doors | 1 | 2 | Clockwise |
| Driver's, Front Passenger's, Rear Left Side & Back Doors | 2 | 1 | Counterclockwise |
| Rear Right Side Door, Rear Right Side Door | 1 | 2 | Counterclockwise |
| Rear Right Side Door, Rear Right Side Door | 2 | 1 | Clockwise |
POWER WINDOW MOTOR OPERATION (4RUNNER)
Disconnect 2-pin electrical connector. For left side, connect positive battery lead to connector terminal No. 1 and negative battery lead to connector terminal No. 2. Window link should move to OPEN position. Reverse polarity. Window link should now move to CLOSE position. For right side, connect positive battery lead to connector terminal No. 2 and negative battery lead to connector terminal No. 1. Window link should move to OPEN position. Reverse polarity. Window link should now move to CLOSE position. If operation is not as specified, replace window motor. See POWER WINDOW MOTOR under REMOVAL & INSTALLATION.
Except Sequoia & Sienna
Disconnect connector from master switch. Connect positive battery lead and negative battery lead to appropriate connector terminals on wire harness side of connector. See POWER WINDOW MOTOR CIRCUIT BREAKER OPERATION TEST (EXCEPT SEQUOIA & SIENNA) table. Raise window to fully closed position. Continue to apply voltage. Ensure there is an operational noise present within approximately 4 to 90 seconds. Reverse polarity. Ensure window begins to descend within approximately 60 seconds. If operation is not as specified, replace motor. See POWER WINDOW MOTOR under REMOVAL & INSTALLATION.
| Application | Switch Location | Power To Terminal No. | Ground Terminal No. |
|---|---|---|---|
| Land Cruiser (1) | Driver Side | 20 | 8 |
| Land Cruiser (1) | Passenger Side | 1 | 6 |
| RAV4 (2) | Driver Side | 4 | 9 |
| RAV4 (2) | Passenger Side | 3 | 1 |
| Tacoma 2-Door (3) | Driver Side | 3 | 4 |
| Tacoma 4-Door (4) | Driver Side | 1 | 5 |
| Tundra (5) | Driver Side | 3 | 4 |
| Tundra (5) | Passenger Side | 3 | 1 |
| 4Runner (6) | Driver Side | 1 | 2 |
| 4Runner (6) | Passenger Side | 1 | 6 |
| (1) (Scheme 45)and (Scheme 52). (2) (Scheme 46)and (Scheme 53). (3) (Scheme 48) (4) (Scheme 49) (5) (Scheme 50)and (Scheme 53). (6) (Scheme 51)and (Scheme 54). | |||
| (1) | (Scheme 45)and (Scheme 52). |
| (2) | (Scheme 46)and (Scheme 53). |
| (3) | (Scheme 48) |
| (4) | (Scheme 49) |
| (5) | (Scheme 50)and (Scheme 53). |
| (6) | (Scheme 51)and (Scheme 54). |
POWER WINDOW MOTOR CIRCUIT BREAKER OPERATION TEST (EXCEPT SEQUOIA & SIENNA)
- Disconnect connector from power window motor. Connect negative lead from ammeter to connector terminal No. 1 on wire harness connector, and positive lead of ammeter to negative terminal of battery. (Scheme 68)and (Scheme 69). Connect positive battery lead to connector terminal No. 2 on wire harness side connector. Raise window to fully open position. Continue to apply voltage. Ensure current changes to less than one amp within 4-90 seconds.
- Disconnect leads from terminals. Approximately 90 seconds later, connect positive battery lead to connector terminal No. 1 and negative battery lead to connector terminal No. 2. Ensure window begins to descend. If operation is not as specified, replace motor. See «POWER WINDOW MOTOR»(ref-131083-S19157245562001121000000) under REMOVAL & INSTALLATION.
- Disconnect connector from power window motor. On drivers's side, connect positive lead from ammeter to connector terminal No. 1 (Red wire) on wire harness connector, and negative lead of ammeter to negative terminal of battery. (Scheme 66) Connect positive battery lead to connector terminal No. 2 (Green wire) on wire harness side connector. On passenger's side, connect positive lead from ammeter to connector terminal No. 2 (Red/Blue wire) on wire harness connector, and negative lead of ammeter to negative terminal of battery. (Scheme 67) Connect positive battery lead to connector terminal No. 1 (Red wire) on wire harness side connector. On both sides, raise window to fully open position. Continue to apply voltage. Ensure current changes to less than one amp within 4-90 seconds.
- Disconnect leads from terminals. Approximately 60 seconds later, connect positive battery lead to connector terminal No. 1 (Red wire), and negative battery lead to connector terminal No. 2 (Green wire on driver's side, or Red/Blue wire on passenger's side). Ensure window begins to descend. If operation is not as specified, replace motor. See «POWER WINDOW MOTOR»(ref-131083-S19157245562001121000000) under REMOVAL & INSTALLATION.
