REMOVAL & INSTALLATION
Note. When battery is disconnected on Sienna, power sliding doors will need to be initialized. See SLIDING DOOR INITIALIZATION PROCEDURE (SIENNA) in COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION. When battery is disconnected on Celica, power moon roof may need to be initialized for proper operation. See SUN ROOF INITIALIZATION (CELICA) in COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION.
Remove door trim panel and waterproof shield. Remove glass retaining bolts and glass. Remove window regulator bolts, and remove window regulator/power window motor assembly. Remove power window motor retaining screws, and remove motor from window regulator. To install, reverse removal procedure. Tighten window regulator motor retaining bolts or nuts to 44 INCH lbs. (5 N.m). Apply multipurpose grease to window regulator rollers.
Disconnect negative battery cable. Using a small flat-blade screwdriver, pry and lift power window switch from door panel. Disconnect power window switch harness connector(s) and remove switch. To install, reverse removal procedure.
Power Window System Wiring Diagram (Highlander). Scheme 1
Scheme 1: Power Window System Wiring Diagram (Highlander)
Power Window System Wiring Diagram (Land Cruiser). Scheme 2
Scheme 2: Power Window System Wiring Diagram (Land Cruiser)
Power Rear Quarter Window Wiring Diagram (Land Cruiser). Scheme 3
Scheme 3: Power Rear Quarter Window Wiring Diagram (Land Cruiser)
Power Window System Wiring Diagram (RAV4). Scheme 4
Scheme 4: Power Window System Wiring Diagram (RAV4)
Power Window System Wiring Diagram (Sequoia 1 Of 2). Scheme 5
Scheme 5: Power Window System Wiring Diagram (Sequoia 1 Of 2)
Power Window System Wiring Diagram (Sequoia 2 Of 2). Scheme 6
Scheme 6: Power Window System Wiring Diagram (Sequoia 2 Of 2)
Power Window System Wiring Diagram (Sienna). Scheme 7
Scheme 7: Power Window System Wiring Diagram (Sienna)
Power Window System Wiring Diagram (Tacoma). Scheme 8
Scheme 8: Power Window System Wiring Diagram (Tacoma)
Power Window System Wiring Diagram (Tundra). Scheme 9
Scheme 9: Power Window System Wiring Diagram (Tundra)
Power Window System Wiring Diagram (4Runner). Scheme 10
Scheme 10: Power Window System Wiring Diagram (4Runner)
Tailgate Power Window System Wiring Diagram (4Runner). Scheme 11
Scheme 11: Tailgate Power Window System Wiring Diagram (4Runner)
