Illuminated Entry Function
When the body ECU detects that the doors are unlocked after the unlock operation has been made, it will light up the key slot, overhead J/B and interior light for approx. 15 sec. If all the doors are locked during this time, the lighting will be cancelled and the lights will immediately fade out.
| Code | See | Relay Blocks (Relay Block Location) |
|---|
| 3 | ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT | Engine Room R/B (Engine Compartment Left) |
| Code | See | Ground Points Location |
|---|
| BL | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Rear Side of Left Quarter Panel |
| BQ | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Rear Side of Right Quarter Panel |
| EE | CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS AND GROUND POINTS LOCATIONS | Left Side of the Suspension Tower |
| IH | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Cowl Side Panel LH |
Scheme 344
Scheme 344: Luggage Compartment Door Opener System
Scheme 345
If the vehicle is stationary (Slower than 5 km/h) and the luggage compartment door is unlocked, the luggage compartment door opener motor activates when the luggage compartment door opener SW is pushed. This results in the luggage compartment door latch being released and the luggage compartment door being opened.
| Code | See | Relay Blocks (Relay Block Location) |
|---|
| 3 | ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT | Engine Room R/B (Engine Compartment Left) |
| Code | See | Ground Points Location |
|---|
| BL | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Rear Side of Left Quarter Panel |
| BO | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Center of the Back Door Panel |
| IH | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Cowl Side Panel LH |
| II | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Instrument Panel Brace LH |
Scheme 346
Scheme 346: Theft Deterrent System
Scheme 347
Scheme 348
Scheme 349
Scheme 350
Scheme 351
Scheme 352
| Code | See | Relay Blocks (Relay Block Location) |
|---|
| 3 | ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT | Engine Room R/B (Engine Compartment Left) |
| Code | See | Ground Points Location |
|---|
| BL | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Rear Side of Left Quarter Panel |
| BQ | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Rear Side of Right Quarter Panel |
| EC | CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS AND GROUND POINTS LOCATIONS | Engine Block |
| EF | CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS AND GROUND POINTS LOCATIONS | Left Side of the Suspension Tower |
| IH | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Cowl Side Panel LH |
| II | LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS | Instrument Panel Brace LH |
Scheme 353
Scheme 353: Shift Control System
Scheme 354
Scheme 355
Scheme 356
Scheme 357
Scheme 358
Scheme 359
Scheme 360
Scheme 361
Scheme 362
Within this system, the operating signal of the shift lever is sent to the hybrid vehicle control ECU to control the hybrid motor, which changes the shift position (R, N, D, B) electronically. When the shift lever is put in the P position, the transmission control ECU receives an operating signal from the hybrid vehicle control ECU and electronically activates the parking lock.
