Auto Cancel Function Toyota Prius II facelift

Oem System Circuits 14 illustrations ~258 words

Auto Cancel Function

  1. The set speed will be cleared and the cruise control will be canceled under the following conditions. The cruise main indicator blinks until the main switch is turned OFF. The speed control is unavailable unless the main switch is turned ON again. * When the stop light switch is open or short-circuits. * When a signal indicating a sudden change in the vehicle speed is received.
  2. The set speed will be cleared and the cruise control will be canceled under the following conditions. * When there is malfunction in the stop light switch input circuit. * When the vehicle speed falls below 40 km/h. * When the vehicle speed falls to more than 16 km/h below the set speed.
CodeSeeRelay Blocks (Relay Block Location)
3ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFTEngine Room R/B (Engine Compartment Left)
CodeSeeGround Points Location
ECCONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS AND GROUND POINTS LOCATIONSEngine Block
ED
EECONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS AND GROUND POINTS LOCATIONSLeft Side of the Suspension Tower
EF
IHLOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESSCowl Side Panel LH
IILOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESSInstrument Panel Brace LH

Scheme 373

Scheme 373: EPS System

Scheme 374

Scheme 374

Scheme 375

Scheme 375

Scheme 376

Scheme 376

This is a system to assist the driver with steering the vehicle by reducing the required steering force. Based on the steering torque signals received from the power steering torque sensor, the vehicle speed and other vehicle information from the skid control ECU, the power steering ECU calculates the assisting current required to control the power steering motor.

If the system experiences an abnormality, the power source relay and the motor relay in the power steering ECU will be shut down and the master warning lamp on combination meter will blink. The P/S warning light will be illuminated also, resulting in the assistance being stopped.

CodeSeeRelay Blocks (Relay Block Location)
3ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFTEngine Room R/B (Engine Compartment Left)
CodeSeeGround Points Location
IGLOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESSCowl Side Panel LH
IH
IILOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESSInstrument Panel Brace LH

Scheme 377

Scheme 377: ABS, TRAC and VSC System

Scheme 378

Scheme 378

Scheme 379

Scheme 379

Scheme 380

Scheme 380

Scheme 381

Scheme 381

Scheme 382

Scheme 382

Scheme 383

Scheme 383

Scheme 384

Scheme 384

Scheme 385

Scheme 385

Scheme 386

Scheme 386
