Transmission Control System Transaxle: Other Toyota Prius I рестайлинг

COMPONENTS

See COMPONENTS .

Scheme 172

1. DRAIN TRANSAXLE OIL
2. REMOVE HYBRID TRANSAXLE WITH ENGINE (See «REMOVAL»(ref-182298-S32919980372005080800000) )
3. SEPARATE HYBRID TRANSAXLE AND ENGINE Remove the 8 bolts. (Scheme 172): Removing Hybrid Transaxle To Engine Bolts Torque: 33 N.m (332 kgf.cm, 24 ft.lbf) Separate the hybrid transaxle and the engine.

See REMOVAL (PRIUS) .

Check Tapered Roller Bearing

Check that burnt spots, deformation or play due to the wear is not identified.

Identifying Tapered Roller Bearing. Scheme 173

If they are identified, replace the tapered roller bearing.

1. INSTALL NEW TAPERED ROLLER BEARING (MG1 SIDE) Using SST and a press, press in a new tapered roller bearing. SST 09608-06041 see scheme 177: Installing Tapered Roller Bearing (MG1 Side)
2. INSTALL NEW TAPERED ROLLER BEARING (MG2 SIDE)

Using SST and a press, press in a new tapered roller bearing. SST 09608-06041, 09950-60010 (09951-00370)

Installing Tapered Roller Bearing (MG2 Side). Scheme 174

Exploded View Of Differential Case Components. Scheme 175

Scheme 176

1. REMOVE TAPERED ROLLER BEARING RH Using SST, remove the tapered roller bearing RH. (Scheme 176): Removing Tapered Roller Bearing RH SST 09950-40011 (09951-04010, 09952-04010, 09953-04020, 09954-04010, 09955-04060, 09958-04010)
2. REMOVE TAPERED ROLLER BEARING LH Using SST, remove the tapered roller bearing LH. (Scheme 177): Removing Tapered Roller Bearing LH SST 09950-40011 (09951-04010, 09952-04010, 09953-04020, 09954-04010, 09955-04060, 09958-04010)
3. DISASSEMBLE DIFFERENTIAL CASE

Scheme 177

Scheme 178

1. Using a pin punch and a hammer, drive out the straight pin. (Scheme 178): Removing Straight Pin
2. Remove the pinion shaft, 2 pinions, 2 pinion thrust washers, 2 side gears and 2 side gear thrust washers from the case. see scheme 183: Removing Pinion Shaft, Pinions, Pinion Thrust Washers, Side Gears And Side Gear Thrust Washers

Check that burnt spots, deformation or play due to the wear is not identified.

Identifying Tapered Roller Bearing. Scheme 179

If they are identified, replace the tapered roller bearing.

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

1. ASSEMBLE DIFFERENTIAL CASE Coat the 2 side gear thrust washers and 2 pinion thrust washers with ATF. Install the 2 side gears, 2 pinions and 4 thrust washers to the case. (Scheme 180): Installing Side Gears, Pinions And Thrust Washers To Differentials Case Check the side gear backlash. Measure the side gear backlash while pushing one pinion gear toward the case. (Scheme 181): Measuring Side Gear Backlash Standard backlash: 0.05 - 0.20 mm (0.0020 - 0.0079 in.) Referring to the table below, select thrust washers which backlash is surely within the specified range. Select washers of the same size for both sides. Thrust washer thickness THRUST WASHER THICKNESS SPECIFICATIONS Thickness Thickness 0.95 mm (0.0374 in.) 1.10 mm (0.0433 in.) 1.00 mm (0.0394 in.) 1.15 mm (0.0453 in.) 1.05 mm (0.0414 in.) 1.20 mm (0.0472 in.) If the backlash is not within the specified range, install a thrust washer of a different thickness. (Scheme 182): Installing Straight Pin Using a pin punch and a hammer, install the straight pin. Stake the differential case.
2. INSTALL 2 TAPERED ROLLER BEARINGS CAUTION: A: The one which has bigger rollers (The number of rollers is 22.) B: The one which has smaller rollers (The number of rollers is 24.) (Scheme 183): Installing Tapered Roller Bearings Using SST and a press, press in the tapered roller bearing RH. (Bearing B) SST 09710-22021 (09710-01031), 09950-70010 (09951-07100) (Scheme 184): Installing Tapered Roller Bearing RH Using SST and a press, press in the tapered roller bearing LH. (Bearing A) SST 09710-22021 (09710-01031), 09950-70010 (09951-07100) see scheme 190: Installing Tapered Roller Bearing LH

Exploded View Of Drive Sprocket Components. Scheme 185

Scheme 186

1. Using a screwdriver, remove the snap ring. (Scheme 186): Removing Snap Ring
2. Remove the needle bearing and spacer. see scheme 193: Removing Needle Bearing And Spacer

Check Needle Bearing

Check that burnt spots, deformation or play due to the wear is not identified.

Identifying Needle Bearing. Scheme 187

If they are identified, replace the needle bearing.

Scheme 188

1. Install the needle bearing and spacer. (Scheme 188): Installing Needle Bearing And Spacer
2. Using a screwdriver, install the snap ring. see scheme 196: Installing Snap Ring

Exploded View Of Input Shaft Components. Scheme 189

1. REMOVE PLANETARY SUN GEAR FROM INPUT SHAFT see scheme 198: Removing Planetary Sun Gear From Input Shaft
2. REMOVE NEEDLE ROLLER BEARING AND BEARING RACE

Using a screwdriver, remove the needle roller bearing and 2 bearing races.

Inserting Tool In To Case. Scheme 190

Removing Needle Roller Bearing And Bearing Races. Scheme 191

Scheme 192

1. INSPECT BUSH OF SUN GEAR (MG1 SIDE) Using a dial indicator, measure the inside diameter of the bush. (Scheme 192): Measuring Inside Diameter Of Bush (MG1 Side) Standard diameter: 25.525 - 25.546 mm (1.00492 - 1.00575 in.) Maximum diameter: 25.596 mm (1.00771 in.) Visually check and make sure that burnt spots and scratches are not identified. If the inside diameter exceeds the limit, replace the sun gear assembly.
2. INSPECT BUSH OF SUN GEAR (MG2 SIDE) Using a dial indicator, measure the inside diameter of the bush. see scheme 202: Measuring Inside Diameter Of Bush (MG2 Side) Standard diameter: 25.525 - 25.546 mm (1.00492 - 1.00575 in.) Maximum diameter: 25.596 mm (1.00771 in.) Visually check and make sure that burnt spots and scratches are not identified. If the inside diameter exceeds the limit, replace the sun gear assembly.
3. CHECK NEEDLE ROLLER BEARING

Check that burnt spots, deformation or play due to the wear is not identified.

Identifying Needle Roller Bearing. Scheme 193

If they are identified, replace the needle roller bearing.

Scheme 194

1. INSTALL NEEDLE ROLLER BEARING AND BEARING RACE (Scheme 194): Installing Needle Roller Bearing And Bearing Race
2. INSTALL PLANETARY SUN GEAR TO INPUT SHAFT see scheme 205: Installing Planetary Sun Gear To Input Shaft

Exploded View Of Counter Drive Gear Components. Scheme 195

Scheme 196

1. REMOVE BALL BEARING LH (MG2 SIDE) Using SST and a press, drive out the ball bearing. SST 09950-00020, 09950-60010 (09951-00330), 09950-70010 (09951-07100) (Scheme 196): Removing Ball Bearing LH (MG2 Side)
2. REMOVE BALL BEARING RH (MG2 SIDE) Using SST and a press, drive out the ball bearing. SST 09950-00020, 09950-60010 (09951-00330), 09950-70010 (09951-07100) see scheme 208: Removing Ball Bearing RH (MG2 Side)

Check 2 Ball Bearings

Check that burnt spots, deformation or play due to the wear is not identified.

If they are identified, replace the ball bearing.

Identifying Ball Bearings. Scheme 197

1. INSTALL BALL BEARING RH (MG1 SIDE) Using SST and a press, press in the ball bearing. SST 09950-60010 (09951-00460), 09950-70010 (09951-07100) see scheme 210: Installing Ball Bearing RH (MG1 Side)
2. INSTALL BALL BEARING LH (MG2 SIDE)

Using SST and a press, press in the ball bearing.

SST 09950-60010 (09951-00330, 09951-00460), 09950-70010 (09951-07100)

Installing Ball Bearing LH (MG2 Side). Scheme 198
