Power Window Control System (Diagnostics - Introduction): Diagnosis Toyota Prius C I facelift

HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]

HINT

1. Use the following procedure to troubleshoot the power window control system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS HINT: In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points for problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Driving conditions, weather conditions How did it happen? Problem symptoms NEXT: Go to next step
3. PRE-CHECK Measure the auxiliary battery voltage with the ignition switch off. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the auxiliary battery before proceeding to the next step. Check the fuses and relays. Check the connector connections and terminals to make sure that there are no abnormalities such as loose connections, deformation, etc. NEXT: Go to next step
4. INSPECT COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Use the Techstream to check if the LIN communication system is functioning normally. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-651382-S26694655632014081900000) . Result Result Proceed to No DTCs output A DTCs output B B --> GO TO LIN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]»(ref-651382-S36827887332014081900000) A: Go to next step
5. CHECK FOR DTC* Check for DTCs and note any codes that are output. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-651192-S32308319922014081900000) . Clear the DTCs. Recheck for DTCs. Result Result Proceed to No DTCs output A DTCs output B B --> GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-651192-S40817878592014081900000) A: Go to next step
6. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [12/2013 - ]»(ref-651192-S26171119982014081900000) . Result Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B B --> Go to step 8 A: Go to next step
7. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check. Refer to «OPERATION CHECK [12/2013 - ]»(ref-651192-S34636272022014081900000) . Terminals of ECU. Refer to «TERMINALS OF ECU [12/2013 - ]»(ref-651192-S37258246482014081900000) . Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST [12/2013 - ]»(ref-651192-S01530603052014081900000) . NEXT: Go to next step
8. ADJUST, REPAIR OR REPLACE Check if driver door window regulator, power window regulator motor assembly LH (for driver door), door glass or door glass run has been removed and reinstalled. Result Result Proceed to Driver door window regulator, power window regulator motor assembly LH (for driver door), door glass or door glass run has been removed and reinstalled. A None of the driver door window regulator, power window regulator motor assembly LH (for driver door), door glass or door glass run has been removed and reinstalled. B B --> Go to step 10 A: Go to next step
9. INITIALIZE POWER WINDOW CONTROL SYSTEM If the driver door window regulator or power window regulator motor assembly LH (for driver door) have been removed and reinstalled, perform "Initialize Power Window Control System" (initialization of the pulse sensor) for the driver door glass. Refer to «INITIALIZATION [12/2013 - ]»(ref-651192-S32286614642014081900000) . HINT: If "Initialize Power Window Control System" (initialization of the pulse sensor) has not been performed, the auto operation function, jam protection function and key-off operation function will not operate or will operate incorrectly. NEXT: Go to next step
10. CONFIRMATION TEST NEXT --> END

Scheme 1

Scheme 2

1. CHECK WINDOW LOCK SWITCH HINT: Before performing the window lock switch operation check, make sure that the window lock switch is off (the switch is not pushed in). Check that the front passenger and rear windows* cannot be operated when the window lock switch of the power window regulator master switch assembly is pushed in. OK Front passenger and rear windows* are disabled. *: w/ Rear Power Window Check that the front passenger and rear windows* can be operated when the window lock switch of the power window regulator master switch assembly is pushed in again. OK Front passenger and rear windows* operate normally. *: w/ Rear Power Window
2. CHECK MANUAL UP / DOWN FUNCTION Check that the driver door power window operates as follows: OK Condition Master Switch Switch Operation Power Window Ignition switch ON (IG) Driver door Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Check that the front passenger door window and rear power windows operate as follows: OK Condition Regulator Switch Switch Operation Power Window Ignition switch ON (IG) Window lock switch off Front passenger door Pulled up UP (Closes) Pushed down DOWN (Opens) Rear LH door* Pulled up UP (Closes) Pushed down DOWN (Opens) Rear RH door* Pulled up UP (Closes) Pushed down DOWN (Opens) *: w/ Rear Power Window
3. CHECK AUTO UP / DOWN FUNCTION Check that the driver door power window operates as follows: OK Condition Master Switch Switch Operation Power Window Ignition switch ON (IG) Driver door Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens)
4. CHECK REMOTE MANUAL UP / DOWN FUNCTION Check that the front passenger door window and rear power windows operate as follows: OK Condition Master Switch Switch Operation Power Window Ignition switch ON (IG) Window lock switch off Front passenger door Pulled up UP (Closes) Pushed down DOWN (Opens) Rear LH door* Pulled up UP (Closes) Pushed down DOWN (Opens) Rear RH door* Pulled up UP (Closes) Pushed down DOWN (Opens) *: w/ Rear Power Window
5. CHECK POWER WINDOW OPERATION FUNCTION AFTER IGNITION SWITCH IS TURNED OFF Check that all the power windows can be operated with the power widow regulator master switch assembly and power window regulator switch assemblies (for front passenger door, rear LH and RH doors*) after the ignition switch is turned off. HINT: If the window lock switch is on, the power windows cannot be operated besides the driver door power window. Therefore, turn the window lock switch off before checking the window operation. *: w/ Rear Power Window Check that the key-off operation function does not operate after the driver door or front passenger door is opened immediately. HINT: If the driver door or front passenger door is opened during automatic window operation while the key-off operation function is on, the window will stop operating. Check that all the power windows cannot be operated after more than approximately 43 seconds have elapsed since the ignition switch was turned off.
6. CHECK JAM PROTECTION FUNCTION Check the basic function. WARNING: Do not put your fingers between the door frame and door glass to check the jam protection function. Also, prevent any part of your body from being caught during inspection. HINT: The jam protection function operates during both the auto up and manual up operations while the hybrid control system is started or the ignition switch is ON (IG), and also 43 seconds have elapsed after the ignition switch was turned off. Fully open the driver door window. Set a check jig wrapped with a piece of cloth near the window fully closed position. TEXT IN ILLUSTRATION *a Check Jig *b Cloth Operate the auto up or manual up function to check that the power window stops and goes down after the check jig is caught between the window and door frame, and stops when the opening reaches approximately 200 mm (7.87 in.) or until approximately 5 seconds elapse. HINT: If the check jig is caught when the opening is approximately 75 mm (2.95 in.) or more, the power window goes down for approximately 125 mm (4.93 in.) or until approximately 2.5 seconds elapse. While the power window is moving down, check that the door glass cannot be raised when the power window switch is used.
7. CHECK POWER WINDOW REGULATOR MASTER SWITCH LED ILLUMINATION Check the LED illumination (power window regulator master switch assembly). Check that the LED located on the power window regulator master switch assembly illuminates when the ignition switch is turned to ON (IG).

PROBLEM SYMPTOMS TABLE [12/2013 - ]

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to this system before inspecting the suspected areas below.

POWER WINDOW CONTROL SYSTEM

1. *: w/ Rear Power Window

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (w/ Rear Power Window) Disconnect the J1 power window regulator master switch assembly connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition J1-1 (E) - Body ground LA - Body ground Ground Always Below 1 ohms J1-6 (B) - J1-1 (E) LA-GR - LA Power supply Ignition switch ON (IG) 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the J1 power window regulator master switch assembly connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition J1-8 (U) - J1-1 (E) R - LA Power window motor UP output Ignition switch ON (IG), driver door power window switch OFF --> UP (Manual operation) 11 to 14 V --> Below 1 V J1-4 (AUTO) - J1-1 (E) R - LA Power window motor AUTO UP output Ignition switch ON (IG), driver door power window fully open --> driver door power window switch UP (AUTO UP position) --> driver door power window fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V Power window motor AUTO DOWN output Ignition switch ON (IG), driver door power window fully closed --> driver door power window switch DOWN (AUTO DOWN position) --> driver door power window fully open 11 to 14 V --> Below 1 V --> 11 to 14 V J1-5 (D) - J1-1 (E) G - LA Power window motor DOWN output Ignition switch ON (IG), driver door power window switch OFF --> DOWN (Manual operation) 11 to 14 V --> Below 1 V J1-16 (U) - J1-1 (E) LA-W - LA Power window motor UP output Ignition switch ON (IG), front passenger door power window switch OFF --> UP (Manual operation) Below 1 V --> 11 to 14 V J1-15 (D) - J1-1 (E) LA-P - LA Power window motor DOWN output Ignition switch ON (IG), front passenger door power window switch OFF --> DOWN (Manual operation) Below 1 V --> 11 to 14 V J1-12 (U) - J1-1 (E) LA-Y - LA Power window motor UP output Ignition switch ON (IG), rear LH door power window switch OFF --> UP (Manual operation) Below 1 V --> 11 to 14 V J1-13 (D) - J1-1 (E) LA-B - LA Power window motor DOWN output Ignition switch ON (IG), rear LH door power window switch OFF --> DOWN (Manual operation) Below 1 V --> 11 to 14 V J1-10 (U) - J1-1 (E) LA-R - LA Power window motor UP output Ignition switch ON (IG), rear RH door power window switch OFF --> UP (Manual operation) Below 1 V --> 11 to 14 V J1-18 (D) - J1-1 (E) LA-G - LA Power window motor DOWN output Ignition switch ON (IG), rear RH door power window switch OFF --> DOWN (Manual operation) Below 1 V --> 11 to 14 V If the result is not as specified, the power window regulator master switch assembly may be malfunctioning.
2. POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (w/o Rear Window) Disconnect the J1 power window regulator master switch assembly connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition J1-7 (E) - Body ground LA - Body ground Ground Always Below 1 ohms J1-15 (B) - J1-7 (E) LA-GR - LA Power supply Ignition switch ON (IG) 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the J1 power window regulator master switch assembly connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition J1-18 (U) - J1-7 (E) R - LA Power window motor UP output Ignition switch ON (IG), driver door power window switch OFF --> UP (Manual operation) 11 to 14 V --> Below 1 V J1-1 (AUTO) - J1-7 (E) R - LA Power window motor AUTO UP output Ignition switch ON (IG), driver door power window fully open --> driver door power window switch UP (AUTO UP position) --> driver door power window fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V Power window motor AUTO DOWN output Ignition switch ON (IG), driver door power window fully closed --> driver door power window switch DOWN (AUTO DOWN position) --> driver door power window fully open 11 to 14 V --> Below 1 V --> 11 to 14 V J1-16 (D) - J1-7 (E) LA-P - LA Power window motor DOWN output Ignition switch ON (IG), driver door power window switch OFF --> DOWN (Manual operation) 11 to 14 V --> Below 1 V J1-12 (U) - J1-7 (E) LA-W - LA Power window motor UP output Ignition switch ON (IG), front passenger door power window switch OFF --> UP (Manual operation) Below 1 V --> 11 to 14 V J1-16 (D) - J1-7 (E) LA-P - LA Power window motor DOWN output Ignition switch ON (IG), front passenger door power window switch OFF --> DOWN (Manual operation) Below 1 V --> 11 to 14 V If the result is not as specified, the power window regulator master switch assembly may be malfunctioning.
3. CHECK POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Front Passenger Door) Disconnect the H2 power window regulator switch assembly (for front passenger door) connector. Measure the voltage according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition H2-3 (B) - Body ground LA-L - Body ground Power supply Ignition switch ON (IG) 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the H2 power window regulator switch assembly (for front passenger door) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition H2-4 (U) - Body ground LA-R - Body ground Power window motor UP output Ignition switch ON (IG), front passenger door power window switch OFF --> UP (Manual operation) Below 1 V --> 11 to 14 V H2-1 (D) - Body ground LA-G - Body ground Power window motor DOWN output Ignition switch ON (IG), front passenger door power window switch OFF --> DOWN (Manual operation) Below 1 V --> 11 to 14 V If the result is not as specified, the power window regulator switch assembly (for front passenger door) may be malfunctioning.
4. CHECK POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear LH Door) (w/ Rear Power Window) Disconnect the L1 power window regulator switch assembly (for rear LH door) connector. Measure the voltage according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition L1-3 (B) - Body ground LA-SB - Body ground Power supply Ignition switch ON (IG) 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the L1 power window regulator switch assembly (for rear LH door) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition L1-4 (U) - Body ground LA-Y - Body ground Power window motor UP output Ignition switch ON (IG), rear LH door power window switch OFF --> UP (Manual operation) Below 1 V --> 11 to 14 V L1-1 (D) - Body ground LA-B - Body ground Power window motor DOWN output Ignition switch ON (IG), rear LH door power window switch OFF --> DOWN (Manual operation) Below 1 V --> 11 to 14 V If the result is not as specified, the power window regulator switch assembly (for rear LH door) may be malfunctioning.
5. CHECK POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear RH Door) (w/ Rear Power Window) Disconnect the K1 power window regulator switch assembly (for rear RH door) connector. Measure the voltage according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition K1-3 (B) - Body ground LA-SB - Body ground Power supply Ignition switch ON (IG) 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the K1 power window regulator switch assembly (for rear RH door) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition K1-4 (U) - Body ground LA-Y - Body ground Power window motor UP output Ignition switch ON (IG), rear RH door power window switch OFF --> UP (Manual operation) Below 1 V --> 11 to 14 V K1-1 (D) - Body ground LA-B - Body ground Power window motor DOWN output Ignition switch ON (IG), rear RH door power window switch OFF --> DOWN (Manual operation) Below 1 V --> 11 to 14 V If the result is not as specified, the power window regulator switch assembly (for rear RH door) may be malfunctioning.
6. CHECK POWER WINDOW REGULATOR MOTOR ASSEMBLY LH (for Driver Door) Disconnect the J3 power window regulator motor assembly LH (for driver door) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition J3-1 (GND) - Body ground LA - Body ground Ground Always Below 1 ohms J3-2 (B) - Body ground LA-G - Body ground Power supply Ignition switch off 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the J3 power window regulator motor assembly LH (for driver door) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition J3-4 (AUTO) - J3-1 (GND) R - LA Power window motor AUTO UP input Ignition switch ON (IG), driver door power window fully open 11 to 14 V J3-4 (AUTO) - J3-1 (GND) R - LA Power window motor AUTO UP input Ignition switch ON (IG), driver door power window moving, power window regulator switch assembly fully pulled up (Automatic operation) Below 1 V J3-4 (AUTO) - J3-1 (GND) R - LA Power window motor AUTO UP input Ignition switch ON (IG), driver door power window fully closed 11 to 14 V J3-4 (AUTO) - J3-1 (GND) R - LA Power window motor AUTO DOWN input Ignition switch ON (IG), driver door power window fully closed 11 to 14 V J3-4 (AUTO) - J3-1 (GND) R - LA Power window motor AUTO DOWN input Ignition switch ON (IG), driver door power window moving, power window regulator switch assembly fully pushed down (Automatic operation) Below 1 V J3-4 (AUTO) - J3-1 (GND) R - LA Power window motor AUTO DOWN input Ignition switch ON (IG), driver door power window fully open 11 to 14 V J3-5 (LED) - J3-1 (GND) W - LA LED illumination signal Ignition switch ON (IG) 11 to 14 V J3-5 (LED) - J3-1 (GND) W - LA LED illumination signal Approximately 43 seconds after ignition switch turned off Below 1 V J3-7 (DOWN) - J3-1 (GND) G - LA Power window motor DOWN input Ignition switch ON (IG), driver door power window regulator switch not pushed or pulled 11 to 14 V J3-7 (DOWN) - J3-1 (GND) G - LA Power window motor DOWN input Ignition switch ON (IG), driver door power window regulator switch pushed halfway down (Manual operation) Below 1 V J3-7 (DOWN) - J3-1 (GND) G - LA Power window motor DOWN input Ignition switch ON (IG), driver door power window fully closed 11 to 14 V J3-7 (DOWN) - J3-1 (GND) G - LA Power window motor DOWN input Ignition switch ON (IG), driver door power window regulator switch fully pushed down (Automatic position) Below 1 V J3-7 (DOWN) - J3-1 (GND) G - LA Power window motor DOWN input Ignition switch ON (IG), driver door power window fully open 11 to 14 V J3-10 (UP) - J3-1 (GND) R - LA Power window motor UP input Ignition switch ON (IG), driver door power window regulator switch not pushed or pulled 11 to 14 V J3-10 (UP) - J3-1 (GND) R - LA Power window motor UP input Ignition switch ON (IG), driver door power window regulator switch pulled halfway up (Manual operation) Below 1 V J3-10 (UP) - J3-1 (GND) R - LA Power window motor UP input Ignition switch ON (IG), driver door power window fully open 11 to 14 V J3-10 (UP) - J3-1 (GND) R - LA Power window motor UP input Ignition switch ON (IG), driver door power window regulator switch fully pulled up (Automatic operation) Below 1 V J3-10 (UP) - J3-1 (GND) R - LA Power window motor UP input Ignition switch ON (IG), driver door power window fully closed 11 to 14 V If the result is not as specified, the power window regulator motor assembly LH (for driver door) may be malfunctioning.
7. CHECK INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY AND MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) Disconnect the MB main body ECU (multiplex network body ECU) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connectors disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition MB-11 (GND1) - Body ground - Ground Always Below 1 ohms MB-30 (BECU) - Body ground - Auxiliary battery power supply Ignition switch off 11 to 14 V MB-29 (ACC) - Body ground - ACC power supply Ignition switch ACC 11 to 14 V MB-29 (ACC) - Body ground - ACC power supply Ignition switch off Below 1 V MB-32 (IG) - Body ground - Ignition switch power supply Ignition switch ON (IG) 11 to 14 V MB-32 (IG) - Body ground - Ignition switch power supply Ignition switch off Below 1 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the MB main body ECU (multiplex network body ECU) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition G59-2 (KOFF) - Body ground L - Body ground Power window relay operation signal Ignition switch ON (IG) 11 to 14 V G59-2 (KOFF) - Body ground L - Body ground Power window relay operation signal Approximately 43 seconds after ignition switch turned off Below 1 V 3D-36 (FLCY) - Body ground R - Body ground Front door courtesy switch LH input Front door LH open Below 1 V 3D-36 (FLCY) - Body ground R - Body ground Front door courtesy switch LH input Front door LH closed Pulse generation G59-19 (FRCY) - Body ground R - Body ground Front door courtesy switch RH input Front door RH open Below 1 V G59-19 (FRCY) - Body ground R - Body ground Front door courtesy switch RH input Front door RH closed Pulse generation If the result is not as specified, the main body ECU (multiplex network body ECU) or instrument panel junction block assembly may be malfunctioning.

DIAGNOSIS SYSTEM [12/2013 - ]

1. DESCRIPTION The power window control system data can be read from the Data Link Connector 3 (DLC3) of the vehicle. When the system seems to be malfunctioning, use the Techstream to check for malfunctions and perform repairs.
2. CHECK DLC3 Check the DLC3. Refer to «GENERAL INFORMATION [12/2013 - ]»(ref-651169-S36066967812014081900000) .
3. INSPECT AUXILIARY BATTERY VOLTAGE Measure the auxiliary battery voltage with the ignition switch off. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the auxiliary battery.

DTC CHECK / CLEAR [12/2013 - ]

1. CHECK DTC Connect the Techstream to the DLC3. Turn the ignition switch ON (IG). Turn the Techstream on. Enter the following menus: Body Electrical / D-Door Motor / Trouble Codes. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-651192-S40817878592014081900000) .
2. CLEAR DTC Connect the Techstream to the DLC3. Turn the ignition switch ON (IG). Turn the Techstream on. Enter the following menus: Body Electrical / D-Door Motor / Trouble Codes. Clear the DTCs.

Scheme 9

Scheme 10

1. POWER WINDOW OPERATION IN FAIL-SAFE MODE The power window control system prohibits the following power window operations when the pulse sensor for the jam protection function has problems and the window position or the learned value is abnormal. HINT: If the pulse sensor built into the power window regulator motor malfunctions, the power window control system enters fail-safe mode. POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Power Window Operation Condition Ignition switch ON (IG) Ignition switch off (Key-off operation permitted) Ignition switch off (Key-off operation prohibited) Manual up (Driver door window) X X - Manual down (Driver door window) o X - Auto up (Driver door window) (hold switch at auto up position) o* X - Auto up (Driver door window) X X - Auto down (Driver door window) X X - HINT: o: Operates X: Operation prohibited *: Operates in manual mode without jam protection Power window regulator master switch LED control HINT: During normal operation (fail-safe is not operating), or during fail-safe mode when there is a pulse sensor malfunction or the window position or learned value is abnormal, the LED illuminates as shown in the illustration. For driver door: Fail-safe deactivation condition When the pulse sensor is normal, to deactivate fail-safe mode, pull up the power window switch to the auto up position and hold it for at least 1 second to fully close the window from the fully open position. As a result, the auto up/down function will return. Initialization failure HINT: During initialization of the power window regulator motor ECU, when the window position or initialization complete status cannot be properly read from the EEPROM, the power window control system prohibits operation as follows: POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Power Window Operation Condition Ignition switch ON (IG) Ignition switch off (Key-off operation permitted) Ignition switch off (Key-off operation prohibited) Manual up (Driver door window) X X - Manual down (Driver door window) o X - Auto up (Driver door window) (hold switch at auto up position) o* X - Auto up (Driver door window) X X - Auto down (Driver door window) X X - HINT: o: Operates X: Operation prohibited *: Operates in manual mode without jam protection Power window regulator master switch LED control HINT: During initialization of the power window regulator motor ECU, when the window position or initialization complete status cannot be properly read from the EEPROM during fail-safe mode, the LED illuminates as shown in the illustration. For driver door: LIN communication failure HINT: If the LIN communication line malfunctions (communication stop), the power window control system prohibits operation as follows: POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Power Window Operation Condition Ignition switch ON (IG) Manual up o* Manual down o Auto up (hold switch at auto up position) o* Auto up o* Auto down o HINT: o: Operates *: Jam protection can operate. LIN communication failure and pulse sensor failure HINT: If the LIN communication line malfunctions (communication stop) and the pulse sensor for the jam protection function has problems, the power window control system prohibits operation as follows: POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Power Window Operation Condition Always Manual up X Manual down X Auto up (hold switch at auto up position) X Auto up X Auto down X HINT: X: Operation prohibited When the jam protection function does not operate due to the LIN communication failure, the manual up and auto up functions will not operate. LIN communication failure and abnormal window position learned value or initialization failure HINT: If the LIN communication line malfunctions (communication stop) and the window position or the learned value is abnormal, the power window control system prohibits operation as follows: POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Power Window Operation Condition Always Manual up o* Manual down o Auto up (hold switch at auto up position) o* Auto up X Auto down X HINT: o: Operates X: Operation prohibited *: Jam protection can operate and window reverses upon reaching the fully closed position.

DATA LIST / ACTIVE TEST [12/2013 - ]

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Body Electrical / D-Door Motor or Main Body / Data List. Read the Data List according to the display on the Techstream. D-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Auto SW Driver door power window auto switch signal / ON or OFF ON: Driver door power window auto switch operated OFF: Driver door power window auto switch not operated - D Door P/W Up SW Driver door power window manual up switch signal / ON or OFF ON: Driver door power window manual up switch operated OFF: Driver door power window manual up switch not operated - D Door P/W Down SW Driver door power window manual down switch signal / ON or OFF ON: Driver door power window manual down switch operated OFF: Driver door power window manual down switch not operated - Glass Position (Close - 1/4) Margin for jam protection triggering force of window glass within range of fully closed to 1/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (1/4 - 2/4) Margin for jam protection triggering force of window glass within range of 1/4 to 1/2 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (2/4 - 3/4) Margin for jam protection triggering force of window glass within range of 1/2 to 3/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (3/4 - Open) Margin for jam protection triggering force of window glass within range of 3/4 to fully open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Number of Trouble Codes Number of trouble codes / Min.: 0 or Max.: 255 Number of DTCs will be displayed - MAIN BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note FR Door Courtesy SW Front door courtesy light switch RH / ON or OFF OFF: Front door RH closed ON: Front door RH open - FL Door Courtesy SW Front door courtesy light switch LH / ON or OFF OFF: Front door LH closed ON: Front door LH open - Communication D-Door Motor Connection status between power window regulator motor assembly LH (for driver door) and main body ECU (multiplex network body ECU) / OK or STOP OK: Normal communication STOP: Communication stopped
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the ignition switch to ON (IG). Turn the Techstream on. Enter the following menus: Body Electrical / D-Door Motor or Main Body / Active Test. Perform the Active Test according to the display on the Techstream. WARNING: Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam protection function will not operate. D-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Power window OFF / UP / DOWN - MAIN BODY Tester Display Test Part Control Range Diagnostic Note IG OFF P/W Control Permission Output Power window OFF / ON Perform this Active Test with the ignition switch off

DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]

POWER WINDOW CONTROL SYSTEM
