SST
09880-10021 THS Charger Set - (09881-10041) THS Charger - 09881-10081 THS Charger AC Cable (Plug Type A with GFCI For North America) - 09882-10070 Low Voltage Cable - 09882-10080 High Voltage Cable - (91553-80616) Bolt - 09883-00010 Interlock Cover
Scheme 135
Scheme 136
RECOMMENDED TOOLS
09003-2C100 Insulated Tool Set - (09012-4C100) Insulated Deep Socket 8mm - (09012-4C110) Insulated Deep Socket 10mm - (09021-1C200) Insulated Ratchet Handle - (09072-2C100) Insulated Torque Wrench 5-25N m - 09080-1C111 Toyota Electrical Tester Set - 09080-2C101 Test Lead Set - 09080-2C111 AC/DC 400A Probe Set - 09230-40010 Radiator Cap Tester - 09231-40030 Radiator Cap Tester Adapter Set C
Scheme 137
Scheme 137: RECOMMENDED TOOLS
Scheme 138
EQUIPMENT
| Radiator cap tester | |
|---|
| Torque wrench | |
| Auxiliary battery | |
| Insulated gloves | |
| Tape | |
| Plastic bag | |
| Megohmmeter | NOTE: Be sure to set the megohmmeter to 500 V when performing this test. Using a setting higher than 500 V can result in damage to the component being inspected. |
| Milliohmmeter | |
| NOTE |
|---|
| Be sure to set the megohmmeter to 500 V when performing this test. Using a setting higher than 500 V can result in damage to the component being inspected. |
COOLANT
| Capacity | Classification |
|---|
| 1.6 liters (1.7 US qts, 1.4 Imp. qts) | Use only "TOYOTA Super Long Life Coolant" or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, non-borate coolant with long-life hybrid organic acid technology (coolant with long-life hybrid organic acid technology consists of a combination of low phosphates and organic acids). |
