Lighting System (Interior) (Diagnostics & Circuit Tests): Overview Toyota Matrix E140

Scheme 4

Scheme 5

SYSTEM DESCRIPTION

1. ILLUMINATED ENTRY SYSTEM The illuminated entry system provides convenience when getting in or out of the vehicle at night. This function is controlled by the main body ECU. The operations and conditions of this control are described below. Operation Condition Fade in When any of the following conditions is met, the personal light*1, center room light and rear room light fade in. Any door is opened. Any door is unlocked when the ignition switch is off and all doors are closed. Ignition switch is turned from ACC to off when all doors are closed. Fade out immediately When either of the following conditions is met, the personal light*1, center room light and rear room light fade out. Ignition switch is turned from off to ACC or ON when all doors are closed. All doors are locked when the ignition switch is off. Illuminate for approximately 15 seconds, and then fade out All doors are closed when the ignition switch is off. Fade out (Battery saving control) When all of the following conditions are met, the main body ECU turns off the lights. A key is not inserted in the ignition key cylinder. There is no change in the condition of the doors for 20 minutes. When any of the following conditions is met, the battery save timer will be cleared. A key is inserted in the ignition key cylinder. Any of the doors is opened. HINT: *1: w/ Sliding Roof

OPERATION CHECK

1. INSPECT ILLUMINATED ENTRY SYSTEM OPERATION NOTE: Perform this inspection with the customizable functions at their default settings. HINT: The illuminated entry system illuminates the lights below: Personal light*1 Center room light Rear room light The operations and conditions of this control are described below. Operation Condition Fade in When any of the following conditions is met, the personal light*1, center room light and rear room light fade in. Any door is opened. Any door is unlocked when the ignition switch is off and all doors are closed. Ignition switch is turned from ACC to off when all doors are closed. Fade out immediately When either of the following conditions is met, the personal light*1, center room light and rear room light fade out. Ignition switch is turned from off to ACC or ON when all doors are closed. All doors are locked when the ignition switch is off. Illuminate for approximately 15 seconds, and then fade out All doors are closed when the ignition switch is off. Fade out (Battery saving control) When all of the following conditions are met, the main body ECU turns off the lights. A key is not in the actuation area There is no change in the condition of the doors for 20 minutes. When any of the following conditions is met, the battery save timer will be cleared. A key is inserted in the ignition key cylinder. Any of the doors is opened. HINT: *1: w/ Sliding Roof

DESCRIPTION

The main body ECU receives the IG signal to control the illuminated entry system.

Scheme 6

Scheme 7

1. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Data List. Read the display on the Techstream. MAIN BODY (MAIN BODY ECU) Tester Display Measurement Item/Range Normal Condition Diagnostic Note IG SW Ignition switch IG signal/ON or OFF ON: Ignition switch ON OFF: Ignition switch off - OK Normal conditions listed above are displayed. NG --> See step 2 OK --> See step 4
2. INSPECT FUSE (ECU-IG NO. 1) Remove the ECU-IG No. 1 fuse from the instrument panel junction block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition ECU-IG No. 1 fuse Always Below 1 ohms NG --> REPLACE FUSE OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (IG POWER SOURCE CIRCUIT) Measure the voltage between the loading slot of the fuse and body ground. Standard Voltage Tester Connection Switch Condition Specified Condition ECU-IG No. 1 fuse terminal - Body ground Ignition switch off Below 1 V Ignition switch ON 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)
4. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-427550-S40003482832011101200000)

The main body ECU receives the ACC signal to control the illuminated entry system.

Scheme 8

Scheme 9

1. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Data List. Read the display on the Techstream. MAIN BODY (MAIN BODY ECU) Tester Display Measurement Item/Range Normal Condition Diagnostic Note ACC SW Ignition switch ACC signal/ON or OFF ON: Ignition switch ACC OFF: Ignition switch off - OK Normal conditions listed above are displayed. NG --> See step 2 OK --> See step 4
2. INSPECT FUSE (ACC) Remove the ACC fuse from the instrument panel junction block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition ACC fuse Always Below 1 ohms NG --> REPLACE FUSE OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (ACC POWER SOURCE CIRCUIT) Measure the voltage between the loading slot of the fuse and body ground. Standard Voltage Tester Connection Switch Condition Specified Condition ACC fuse terminal - Body ground Ignition switch off Below 1 V Ignition switch ACC 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)
4. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-427550-S40003482832011101200000)

The main body ECU detects the condition of the door courtesy switches.

Scheme 10

Scheme 11

1. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Data List. Read the display on the Techstream. MAIN BODY (MAIN BODY ECU) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door Courtesy SW Driver side door courtesy switch signal/ON or OFF ON: Driver side door is open OFF: Driver side door is closed - P Door Courtesy SW Front passenger side door courtesy switch signal/ON or OFF ON: Front passenger side door is open OFF: Front passenger side door is closed - RR Door Courtesy SW Rear door courtesy switch RH signal/ON or OFF ON: Rear door RH is open OFF: Rear door RH is closed - RL Door Courtesy SW Rear door courtesy switch LH signal/ON or OFF ON: Rear door LH is open OFF: Rear door LH is closed - Back Door Courtesy SW Back door courtesy switch signal/ON or OFF ON: Back door is open OFF: Back door is closed - OK Normal conditions listed above are displayed. NG --> See step 2 OK --> See step 4
2. INSPECT DOOR COURTESY SWITCH Inspect the front door courtesy switch. Refer to «INSPECTION»(/toyota/matrix/e140-2008-2014/remont/interiorillumination-lights/#lighting-system-interior-service-information) , rear door courtesy switch. Refer to «INSPECTION»(/toyota/matrix/e140-2008-2014/remont/interiorillumination-lights/#lighting-system-interior-service-information) , and back door courtesy switch. Refer to «INSPECTION»(/toyota/matrix/e140-2008-2014/remont/interiorillumination-lights/#lighting-system-interior-service-information) . OK Door courtesy switches are normal. NG --> REPLACE DOOR COURTESY SWITCH OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (INSTRUMENT PANEL JUNCTION BLOCK - SWITCH) Disconnect the E63 main body ECU connector. Disconnect the 2A and 2E instrument panel junction block connectors. Disconnect the P1 door lock assembly connector. Disconnect each door courtesy switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Driver Side Front Passenger Side Rear LH Side Rear RH Side Back Door Tester Connection Condition Specified Condition 2A-21 (DCTY) - L18-1 Always Below 1 ohms L18-1 - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition 2E-20 (PCTY) - M15-1 Always Below 1 ohms M15-1 - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition E63-13 (LCTY) - L19-1 Always Below 1 ohms L19-1 - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition 2E-19 (RCTY) - M16-1 Always Below 1 ohms M16-1 - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition 2A-7 (BCTY) - P1-4 Always Below 1 ohms P1-4 - Body ground Always 10 kohms or higher P1-3 - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)
4. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-427550-S40003482832011101200000)

The main body ECU receives door unlock detection switch signal to control the illuminated entry system.

Scheme 12

The illuminated entry system controls the personal light*1, center room light and rear room light according to the door courtesy switch, door lock position switch, and ignition switch conditions.

HINT

*1: w/ Sliding Roof

Scheme 13

Scheme 14

1. PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Active Test. Check the operation. MAIN BODY (MAIN BODY ECU) Tester Display Test Part Control Range Diagnostic Note Illuminated Entry System Personal light*1, center room light and rear room light ON/OFF Personal switch OFF, interior light switch in DOOR position, and all doors are closed HINT: *1: w/ Sliding Roof OK Each light fades in. NG --> See step 2 OK --> See step 4
2. INSPECT FUSE (DOME) Remove the DOME fuse from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Display Condition Specified Condition DOME fuse Always Below 1 ohms NG --> REPLACE FUSE OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (BATTERY - INSTRUMENT PANEL JUNCTION BLOCK) Disconnect the 2K instrument panel junction block assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition 2K-2 (ILE) - Body ground Always 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)
4. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-427550-S40003482832011101200000)
