Air Conditioning System (Service Information): Overview Toyota Matrix E140

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

1. INSPECT REFRIGERANT PRESSURE WITH MANIFOLD GAUGE SET HINT: This is a method where a manifold gauge set is used to help locate the problem. Read the manifold gauge pressure when the following conditions are established. Test conditions: Temperature at the air inlet with the switch set at RECIRC is 30 to 35°C (86 to 95°F). Engine is running at 1500 RPM. Blower speed control switch is at "HI". Temperature control dial is at "COOL". A/C switch is ON. Doors are fully open. Normally functioning refrigeration system GAUGE READING Pressure Side Refrigerant Volume Low 0.15 to 0.25 MPa (1.5 to 2.5 kgf/cm 2 , 21 to 36 psi) High 1.37 to 1.57 MPa (13.9 to 16.0 kgf/cm 2 , 198 to 227 psi) Moisture is present in refrigeration system. Symptom Probable Cause Diagnosis Corrective Action During operation, pressure on low pressure side cycles between normal and vacuum Moisture in the A/C system will freeze at the expansion valve orifice, causing the refrigeration cycle to temporarily stop After the system stops, and warms up again, the ice will melt and normal operation will be temporarily restored Cooler dryer (integrated into the condenser tank) in oversaturated state Moisture in the refrigeration system freezes at the expansion valve orifice and blocks circulation of refrigerant Replace the cooler dryer Remove moisture in the system by repeatedly evacuating air Supply a proper amount of new refrigerant Insufficient cooling Symptom Probable Cause Diagnosis Corrective Action Pressure is low on both low and high pressure sides Insufficient cooling performance Gas leakage from the refrigeration system Insufficient refrigerant Refrigerant leaking Check for gas leaks and repair if necessary Supply a proper amount of new refrigerant If the gauge indicates a pressure of close to 0, then it will be necessary to evacuate the system after repairing the leak Poor circulation of refrigerant Symptom Probable Cause Diagnosis Corrective Action Pressure is low on both low and high pressure sides Frost exists on pipe from condenser to unit Refrigerant flow is obstructed by dirt inside the pipes of the condenser core Receiver is clogged Replace the condenser Refrigerant does not circulate. Symptom Probable Cause Diagnosis Corrective Action Vacuum is indicated on low pressure side and very low pressure is indicated on high pressure side Frost or condensation is seen on piping on both sides of receiver/drier or expansion valve Refrigerant flow is obstructed by moisture or dirt in the refrigeration system Refrigerant flow is obstructed by gas leaking internally through the expansion valve Refrigerant does not circulate Check the expansion valve Replace the expansion valve Replace the condenser Evacuate air and supply a proper amount of new refrigerant For internal gas leak at the expansion valve, replace the expansion valve Refrigerant is overcharged or cooling effectiveness of the condenser is insufficient. Symptom Probable Cause Diagnosis Corrective Action Pressure is too high on both low and high pressure sides Unable to develop sufficient performance due to an excessive use of refrigeration system Cooling effectiveness of the condenser is insufficient Excessive refrigerant in cycle --> excessive refrigerant was added during recharging Condenser cooling effectiveness is insufficient --> condenser fins are clogged at the cooling fan Clean the condenser Check the operation of the condenser cooling fan If 1 and 2 are normal state, check the amount of refrigerant and supply the proper amount of refrigerant Air is present in the refrigeration system. Symptom Probable Cause Diagnosis Corrective Action Pressure is too high on both low and high pressure sides The low pressure piping is too hot to touch Air in the system Air present in the refrigeration system Insufficient vacuum purging Check compressor oil to see if it is dirty or insufficient Evacuate the system and recharge it with new or purified refrigerant Expansion valve malfunction Symptom Probable Cause Diagnosis Corrective Action Pressure is too high on both low and high pressure sides Frost or a large amount of condensation on piping on low pressure side Expansion valve may be sticking Excessive refrigerant in low pressure piping Expansion valve opened too wide Check expansion valve Insufficient compressor compression Symptom Probable Cause Diagnosis Corrective Action Pressure is too high both on low and high pressure sides Pressure is too low on high pressure side Internal leak in the compressor Low compression Leak from a damaged valve, or parts may be broken Replace the compressor Gauge readings (Reference)

Scheme 48

Scheme 49

1. RECOVER REFRIGERANT FROM REFRIGERATION SYSTEM Start up the engine. Turn the A/C switch on. Operate the cooler compressor at an engine speed of approximately 1000 RPM for 5 to 6 minutes to circulate the refrigerant. This causes most of the compressor oil from the various components of the A/C system to collect in the A/C compressor. Stop the engine. Recover the refrigerant from the A/C system using a refrigerant recovery unit.
2. CHARGE WITH REFRIGERANT Perform vacuum purging using a vacuum pump. Charge with refrigerant HFC-134a (R134a). Standard 410 to 470 g (14.5 to 16.6 oz.) SST: 09985-20010 09985-02010 09985-02050 09985-02060 09985-02070 09985-02080 09985-02090 09985-02110 09985-02130 09985-02140 09985-02150 NOTE: Do not turn the A/C on before charging with refrigerant. Doing so will cause the cooler compressor to work without refrigerant, resulting in overheating of the cooler compressor. HINT: Ensure that sufficient refrigerant is available to recharge the system when using a refrigerant recovery unit. Refrigerant recovery units are not always able to recover 100% of the refrigerant from an A/C system.
3. WARM UP ENGINE Keep the A/C switch on for at least 2 minutes to warm up the compressor. NOTE: Be sure to warm up the compressor when turning the A/C on after removing and installing the cooler refrigerant lines (including the compressor), to prevent damage to the compressor.
4. INSPECT FOR REFRIGERANT LEAK After recharging with refrigerant, inspect for refrigerant leaks using a halogen leak detector. Carry out the test under the following conditions: Turn the ignition switch off. Secure good ventilation (the halogen leak detector may react to volatile gases which are not refrigerant, such as evaporated gasoline and exhaust gas). Repeat the test 2 or 3 times. Make sure that there is some refrigerant remaining in the refrigeration system. When the compressor is off: approx. 392 to 588 kPa (3.9 to 5.9 kgf/cm 2 , 57 to 85 psi) Using a halogen leak detector, inspect for refrigerant leaks from the refrigerant lines. Bring the halogen leak detector close to the drain hose with the detector's power off, and then turn the detector on. HINT: After the blower motor has stopped, let the cooling unit stand for more than 15 minutes. Bring the halogen leak detector sensor under the drain hose. When bringing the halogen leak detector close to the drain hose, make sure that the halogen leak detector does not react to volatile gases. If it is not possible to avoid interference from volatile gases, the vehicle should be lifted up to allow testing. If a refrigerant leak is not detected from the drain hose, remove the blower motor control from the cooling unit. Insert the halogen leak detector sensor into the unit and perform the test. Disconnect the pressure switch connector and leave it for approximately 20 minutes. Bring the halogen leak detector close to the pressure switch and perform the test.

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

1. PRECAUTION Refer to «PRECAUTION»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
2. TURN FRONT WHEELS TO FACE STRAIGHT AHEAD
3. RECOVER REFRIGERANT FROM REFRIGERATION SYSTEM See step 1
4. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION»(ref-427508-S03121118652011101200000).
5. DISCONNECT SUCTION PIPE SUB-ASSEMBLY Remove the bolt and slide the hook connector. Disconnect the suction pipe sub-assembly. Remove the O-ring from the suction hose sub-assembly. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent entry of moisture and foreign matter.
6. DISCONNECT LIQUID PIPE SUB-ASSEMBLY Disconnect the liquid pipe sub-assembly. Remove the O-ring from the liquid pipe sub-assembly. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent entry of moisture and foreign matter.
7. DISCONNECT HEATER OUTLET WATER HOSE Using pliers, grip the claws of the clip and slide the clip to disconnect the heater outlet water hose. NOTE: Do not apply excessive force to the heater outlet water hose. Prepare a drain pan or cloth in case the coolant leaks.
8. DISCONNECT HEATER INLET WATER HOSE HINT: Disconnection procedure for the heater inlet water hose is the same as that for the heater outlet water hose.
9. REMOVE STEERING WHEEL ASSEMBLY Refer to «REMOVAL»(ref-427306-S29509278522011101200000)
10. REMOVE CENTER INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 8»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
11. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 9»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
12. REMOVE METER HOOD SUB-ASSEMBLY. Refer to «REMOVAL - Step 3»(ref-427467-S37010129322011101200000)
13. REMOVE COMBINATION METER ASSEMBLY. Refer to «REMOVAL - Step 4»(ref-427467-S37010129322011101200000)
14. DISCONNECT FRONT DOOR OPENING TRIM WEATHERSTRIP LH . Refer to «REMOVAL - Step 12»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
15. REMOVE FRONT PILLAR GARNISH LH . Refer to «REMOVAL - Step 13»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
16. DISCONNECT FRONT DOOR OPENING TRIM WEATHERSTRIP RH . Refer to «REMOVAL - Step 14»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
17. REMOVE FRONT PILLAR GARNISH RH . Refer to «REMOVAL - Step 17»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
18. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL ASSEMBLY . Refer to «REMOVAL - Step 16»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
19. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transaxle) . Refer to «REMOVAL - Step 17»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
20. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transaxle) . Refer to «REMOVAL - Step 18»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
21. REMOVE CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (for Manual Transaxle) . Refer to «REMOVAL - Step 19»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
22. REMOVE CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (for Automatic Transaxle) . Refer to «REMOVAL - Step 20»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
23. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «REMOVAL - Step 21»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
24. REMOVE NO. 1 INSTRUMENT PANEL BOX DOOR SUB-ASSEMBLY . Refer to «REMOVAL - Step 22»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
25. DISCONNECT INSTRUMENT PANEL WIRE ASSEMBLY. Refer to «REMOVAL - Step 3»(ref-427307-S21172454222011101200000)
26. REMOVE UPPER INSTRUMENT PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 24»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
27. REMOVE RADIO RECEIVER ASSEMBLY WITH BRACKET. Refer to «REMOVAL - Step 2»(ref-427547-S31633980412011101200000)
28. REMOVE NAVIGATION ANTENNA CORD SUB-ASSEMBLY (w/ Navigation Antenna). Refer to «REMOVAL - Step 2»(ref-427552-S37590185762011101200000)
29. REMOVE AIR CONDITIONING PANEL ASSEMBLY See step 6
30. REMOVE FRONT UPPER CONSOLE BOX . Refer to «REMOVAL - Step 28»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
31. REMOVE NO. 2 SWITCH HOLE BASE . Refer to «REMOVAL - Step 29»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
32. REMOVE CONSOLE BOX CARPET
33. REMOVE FRONT CONSOLE BOX ASSEMBLY (for 2WD) . Refer to «REMOVAL - Step 4»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
34. REMOVE FRONT CONSOLE BOX ASSEMBLY (for 4WD) . Refer to «REMOVAL - Step 5»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
35. REMOVE FRONT NO. 1 CONSOLE BOX INSERT . Refer to «REMOVAL - Step 33»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
36. REMOVE FRONT NO. 2 CONSOLE BOX INSERT . Refer to «REMOVAL - Step 34»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
37. REMOVE LOWER CENTER INSTRUMENT PANEL FINISH PANEL (for Manual Transaxle) . Refer to «REMOVAL - Step 35»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
38. REMOVE LOWER CENTER INSTRUMENT PANEL FINISH PANEL (for Automatic Transaxle) . Refer to «REMOVAL - Step 36»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
39. REMOVE NO. 1 SWITCH HOLE BASE . Refer to «REMOVAL - Step 37»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
40. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 38»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
41. REMOVE FRONT DOOR SCUFF PLATE LH . Refer to «REMOVAL - Step 10»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
42. REMOVE COWL SIDE TRIM BOARD LH . Refer to «REMOVAL - Step 11»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
43. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (w/ Instrument Panel Under Cover) . Refer to «REMOVAL - Step 41»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
44. REMOVE FRONT DOOR SCUFF PLATE RH . Refer to «REMOVAL - Step 14»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
45. REMOVE COWL SIDE TRIM BOARD RH . Refer to «REMOVAL - Step 15»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
46. DISCONNECT SHIFT LEVER ASSEMBLY (for Manual Transaxle) . Refer to «REMOVAL - Step 44»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
47. DISCONNECT SHIFT LEVER ASSEMBLY (for Automatic Transaxle) . Refer to «REMOVAL - Step 45»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
48. REMOVE LOWER STEERING COLUMN COVER. Refer to «REMOVAL - Step 12»(ref-427306-S00218874552011101200000)
49. REMOVE UPPER STEERING COLUMN COVER. Refer to «REMOVAL - Step 13»(ref-427306-S00218874552011101200000)
50. REMOVE TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY. Refer to «REMOVAL - Step 14»(ref-427306-S00218874552011101200000)
51. REMOVE RADIO WIRE SUB-ASSEMBLY. Refer to «REMOVAL - Step 2»(ref-427547-S04503869002011101200000)
52. REMOVE LOWER INSTRUMENT PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 50»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
53. REMOVE COLUMN HOLE COVER SILENCER SHEET. Refer to «REMOVAL - Step 15»(ref-427306-S00218874552011101200000)
54. SEPARATE NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY (for 2WD). Refer to «REMOVAL - Step 16»(ref-427306-S00218874552011101200000)
55. SEPARATE NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY (for 4WD). Refer to «REMOVAL - Step 17»(ref-427306-S00218874552011101200000)
56. REMOVE INSTRUMENT PANEL SUB REINFORCEMENT. Refer to «REMOVAL - Step 18»(ref-427306-S00218874552011101200000)
57. REMOVE NO. 2 AIR DUCT SUB-ASSEMBLY. Refer to «REMOVAL - Step 19»(ref-427306-S00218874552011101200000)
58. REMOVE TRANSPONDER KEY AMPLIFIER (w/ Engine Immobilizer System). Refer to «REMOVAL - Step 20»(ref-427306-S00218874552011101200000)
59. REMOVE STOP LIGHT SWITCH ASSEMBLY. Refer to «REMOVAL - Step 1»(ref-427461-S21636496762011101200000)
60. REMOVE STEERING POST ASSEMBLY. Refer to «REMOVAL - Step 22»(ref-427306-S00218874552011101200000)
61. REMOVE POWER STEERING ECU ASSEMBLY . Refer to «REMOVAL - Step 2»(/toyota/matrix/e140-2008-2014/remont/manual-power-steering/#power-steering-system-service-information)
62. REMOVE AIR CONDITIONING AMPLIFIER ASSEMBLY See step 2
63. REMOVE REAR NO. 3 AIR DUCT (w/ Rear Air Duct) Remove the clip. Turn back the floor carpet. Disengage the 2 claws and remove the rear No. 3 air duct.
64. REMOVE REAR NO. 2 AIR DUCT (w/ Rear Air Duct) Remove the clip. Turn back the floor carpet. Disengage the 2 claws and remove the rear No. 2 air duct.
65. REMOVE REAR NO. 1 AIR DUCT (w/ Rear Air Duct) Disengage the 4 claws and remove the rear No. 1 air duct.
66. REMOVE CENTER INSTRUMENT PANEL REGISTER CONNECTOR ASSEMBLY Disengage the 6 claws and remove the center instrument panel register connector assembly.
67. REMOVE NO. 1 AIR DUCT SUB-ASSEMBLY Remove the 2 nuts and the No. 1 air duct sub-assembly.
68. REMOVE CENTER INSTRUMENT PANEL TO COWL BRACE Remove the 2 bolts and the center instrument panel to cowl brace.
69. REMOVE INSTRUMENT PANEL BRACE SUB-ASSEMBLY Remove the 2 bolts. Disconnect the connector. Disengage each clamp. Remove the 2 screws. Remove the 2 bolts, the 2 nuts, and the instrument panel brace sub-assembly.
70. REMOVE HEATER COVER (w/ Cover) Disengage the 4 claws and remove the heater cover.
71. REMOVE INSTRUMENT PANEL REINFORCEMENT ASSEMBLY Disengage each clamp and the wire harness. Disconnect each connector. Disengage each clamp. Remove the 9 bolts, and disengage the wire harness and junction block. Remove the 7 bolts. Remove the 3 bolts and the instrument panel reinforcement assembly.
72. REMOVE AIR CONDITIONING UNIT Disengage the drain cooler hose. Remove the bolt, the nut, and the air conditioning unit. NOTE: Be sure to support the air conditioning unit assembly when removing it because failure to do so may cause the bracket of the air conditioning unit assembly to break. When disassembling the air conditioning unit, eliminate static electricity by touching the vehicle body to prevent the components from being damaged.
73. REMOVE NO. 3 AIR DUCT SUB-ASSEMBLY Disengage the 2 claws and remove the No. 3 air duct sub-assembly.
74. REMOVE BLOWER ASSEMBLY (w/o PTC Heater) Remove the 3 screws and the blower assembly.
75. REMOVE BLOWER ASSEMBLY (w/ PTC Heater) Disengage each clamp. Remove the screw and disengage the quick heater connector. Remove the 3 screws and the blower assembly.

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

1. REMOVE TRANSPONDER KEY ECU. Refer to «REMOVAL - Step 2»(ref-427559-S09116032532011101200000)
2. REMOVE NO. 2 HEATER CONTROL CABLE SUB-ASSEMBLY Using a screwdriver with its tip taped, disengage the claw and remove the No. 2 heater control cable sub-assembly.
3. REMOVE AIR MIX DAMPER CONTROL CABLE SUB-ASSEMBLY Using a screwdriver with its tip taped, disengage the claw and remove the air mix damper control cable sub-assembly.
4. REMOVE QUICK HEATER ASSEMBLY (w/ PTC Heater) Disengage each clamp. Remove the 2 screws. Remove the quick heater assembly as shown in the illustration.
5. REMOVE CONSOLE MOUNTING BRACKET RH Disengage the 2 claws to remove the console mounting bracket RH.
6. REMOVE CONSOLE MOUNTING BRACKET LH Remove the screw and the console mounting bracket LH.
7. REMOVE DRAIN COOLER HOSE Remove the drain cooler hose from the air conditioning radiator assembly.
8. REMOVE HEATER RADIATOR UNIT SUB-ASSEMBLY Remove the screw and the clamp. Remove the heater radiator unit sub-assembly from the air conditioning unit assembly.
9. REMOVE COOLER EXPANSION VALVE Using a 4 mm hexagon wrench, remove the 2 hexagon bolts and cooler expansion valve.
10. REMOVE NO. 1 COOLER EVAPORATOR SUB-ASSEMBLY Remove the 4 screws. Disengage the 4 claws and remove the lower heater case. Disengage the clamp, and remove the No. 1 cooler evaporator sub-assembly together with the No. 1 cooler thermistor. Remove the 2 O-rings from the No. 1 cooler evaporator sub-assembly.
11. REMOVE NO. 1 COOLER THERMISTOR Remove the No. 1 cooler thermistor from the No. 1 cooler evaporator sub-assembly.

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. INSTALL NO. 1 COOLER THERMISTOR Install the No. 1 cooler thermistor as shown in the illustration. Part Length A 34.3 mm 1.35 in. B 20.9 mm 0.823 in. C 50 mm 1.96 in. NOTE: Be sure to insert the thermistor only once because reinserting it will not allow it to be firmly secured. When reusing the evaporator, insert the thermistor one row next to the one that has been used previously (X in the illustration). After inserting the thermistor, do not apply excessive force to the wire. Directly insert the thermistor until the edge of plastic case "a" comes into contact with evaporator "b".
2. INSTALL NO. 1 COOLER EVAPORATOR SUB-ASSEMBLY Sufficiently apply compressor oil to 2 new O-rings and the fitting surfaces. Install the 2 O-rings to the No. 1 cooler evaporator sub-assembly. Compressor oil ND-OIL 8 or equivalent NOTE: Keep the O-rings and O-ring fitting surfaces clean from dirt or any foreign objects. Install the No. 1 cooler evaporator sub-assembly together with the No. 1 cooler thermistor as a set. Engage the clamp. Engage the 4 claws as shown in the illustration. Install the lower heater case with the 4 screws.
3. INSTALL COOLER EXPANSION VALVE Using a 4 mm hexagon wrench, install the cooler expansion valve with the 2 hexagon bolts. Torque: 3.5 N*m (36 kgf*cm, 31 in.*lbf)
4. INSTALL HEATER RADIATOR UNIT SUB-ASSEMBLY Install the heater radiator unit sub-assembly to the air conditioning unit assembly. Install the clamp with the screw.
5. INSTALL DRAIN COOLER HOSE Install the drain cooler hose to the air conditioning unit assembly.
6. INSTALL CONSOLE MOUNTING BRACKET LH Install the console mounting bracket LH with the screw.
7. INSTALL CONSOLE MOUNTING BRACKET RH Engage the 2 claws to install the console mounting bracket RH.
8. INSTALL QUICK HEATER ASSEMBLY (w/ PTC Heater) Install the quick heater assembly as shown in the illustration. Install the 2 screws. Engage each clamp.
9. INSTALL AIR MIX DAMPER CONTROL CABLE SUB-ASSEMBLY Position the gear of the air mix damper control cable sub-assembly and the unit gear as shown in the illustration, and install the air mix damper control cable sub-assembly.
10. INSTALL NO. 2 HEATER CONTROL CABLE SUB-ASSEMBLY Position the gear of the No. 2 heater control cable sub-assembly and the unit link as shown in the illustration, and install the No. 2 heater control cable sub-assembly.
11. INSTALL TRANSPONDER KEY ECU. Refer to «INSTALLATION - Step 1»(ref-427559-S12875196902011101200000)

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

1. INSTALL BLOWER ASSEMBLY (w/o PTC Heater) Install the blower assembly with the 3 screws.
2. INSTALL BLOWER ASSEMBLY (w/ PTC Heater) Install the blower assembly with the 3 screws. Engage the quick heater connector and install the screw. Engage each clamp.
3. INSTALL NO. 3 AIR DUCT SUB-ASSEMBLY Engage the 2 claws to install the No. 3 air duct sub-assembly.
4. TEMPORARILY TIGHTEN AIR CONDITIONING UNIT Engage the drain cooler hose. Temporarily tighten the air conditioning unit with the bolt and the nut. NOTE: Be sure to support the air conditioning unit assembly when removing it because failure to do so may cause the bracket of the air conditioning unit assembly to break. When installing the air conditioning unit, eliminate static electricity by touching the vehicle body to prevent the components from being damaged.
5. INSTALL INSTRUMENT PANEL REINFORCEMENT ASSEMBLY Install the instrument panel reinforcement assembly with the 7 bolts. Torque: 24 N*m (245 kgf*cm, 18 ft.*lbf) Connect each connector. Engage each clamp. Engage the wire harness and junction block with the 9 bolts. Torque: 8.4 N*m (86 kgf*cm, 74 in.*lbf) Engage each clamp and the wire harness.
6. INSTALL AIR CONDITIONING UNIT Install the 3 bolts. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) HINT: Tighten the bolts in the order shown in the illustration. Install the bolt. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Install the air conditioning unit with the nut. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Engage the drain cooler hose.
7. INSTALL HEATER COVER (w/ Cover) Engage the 4 claws to install the heater cover.
8. INSTALL INSTRUMENT PANEL BRACE SUB-ASSEMBLY Install the 2 bolts and the 2 nuts. Install the instrument panel brace sub-assembly with the 2 screws. Screw Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Engage each clamp. Connect the connector. Install the 2 bolts. Torque: 8.4 N*m (86 kgf*cm, 74 in.*lbf)
9. INSTALL CENTER INSTRUMENT PANEL TO COWL BRACE Install the center instrument panel to cowl brace with the 2 bolts.
10. INSTALL NO. 1 AIR DUCT SUB-ASSEMBLY Install the No. 1 air duct sub-assembly with the 2 nuts. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
11. INSTALL CENTER INSTRUMENT PANEL REGISTER CONNECTOR ASSEMBLY Engage the 6 claws to install the center instrument panel register connector assembly.
12. INSTALL REAR NO. 1 AIR DUCT (w/ Rear Air Duct) Engage the 4 claws to install the rear No. 1 air duct.
13. INSTALL REAR NO. 2 AIR DUCT (w/ Rear Air Duct) Engage the 2 claws and install the rear No. 2 air duct. Install the floor carpet and engage the clip.
14. INSTALL REAR NO. 3 AIR DUCT (w/ Rear Air Duct) Engage the 2 claws and install the rear No. 3 air duct. Install the floor carpet and engage the clip.
15. INSTALL AIR CONDITIONING AMPLIFIER ASSEMBLY See step 1
16. INSTALL POWER STEERING ECU ASSEMBLY . Refer to «INSTALLATION - Step 1»(/toyota/matrix/e140-2008-2014/remont/manual-power-steering/#power-steering-system-service-information)
17. INSTALL STEERING POST ASSEMBLY. Refer to «INSTALLATION - Step 2»(ref-427306-S12806507802011101200000)
18. TURN FRONT WHEELS TO FACE STRAIGHT AHEAD
19. CONNECT NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY (for 2WD). Refer to «INSTALLATION - Step 4»(ref-427306-S12806507802011101200000)
20. CONNECT NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY (for 4WD). Refer to «INSTALLATION - Step 5»(ref-427306-S12806507802011101200000)
21. INSTALL STOP LIGHT SWITCH ASSEMBLY. Refer to «INSTALLATION - Step 1»(ref-427461-S21799291712011101200000)
22. INSTALL NO. 2 AIR DUCT SUB-ASSEMBLY. Refer to «INSTALLATION - Step 7»(ref-427306-S12806507802011101200000)
23. INSTALL INSTRUMENT PANEL SUB REINFORCEMENT. Refer to «INSTALLATION - Step 8»(ref-427306-S12806507802011101200000)
24. INSTALL COLUMN HOLE COVER SILENCER SHEET. Refer to «INSTALLATION - Step 9»(ref-427306-S12806507802011101200000)
25. INSTALL TRANSPONDER KEY AMPLIFIER (w/ Engine Immobilizer System). Refer to «INSTALLATION - Step 10»(ref-427306-S12806507802011101200000)
26. INSTALL LOWER INSTRUMENT PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 1»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
27. INSTALL RADIO WIRE SUB-ASSEMBLY. Refer to «INSTALLATION - Step 4»(ref-427547-S37898914982011101200000)
28. INSTALL TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY. Refer to «INSTALLATION - Step 11»(ref-427306-S12806507802011101200000)
29. INSTALL UPPER STEERING COLUMN COVER. Refer to «INSTALLATION - Step 12»(ref-427306-S12806507802011101200000)
30. INSTALL LOWER STEERING COLUMN COVER. Refer to «INSTALLATION - Step 13»(ref-427306-S12806507802011101200000)
31. CONNECT SHIFT LEVER ASSEMBLY (for Manual Transaxle) . Refer to «INSTALLATION - Step 6»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
32. CONNECT SHIFT LEVER ASSEMBLY (for Automatic Transaxle) . Refer to «INSTALLATION - Step 7»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
33. INSTALL COWL SIDE TRIM BOARD LH . Refer to «INSTALLATION - Step 81»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
34. INSTALL FRONT DOOR SCUFF PLATE LH . Refer to «INSTALLATION - Step 82»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
35. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (w/ Instrument Panel Under Cover) . Refer to «INSTALLATION - Step 10»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
36. INSTALL COWL SIDE TRIM BOARD RH . Refer to «INSTALLATION - Step 85»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
37. INSTALL FRONT DOOR SCUFF PLATE RH . Refer to «INSTALLATION - Step 86»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
38. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 13»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
39. INSTALL NO. 1 SWITCH HOLE BASE . Refer to «INSTALLATION - Step 14»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
40. INSTALL LOWER CENTER INSTRUMENT PANEL FINISH PANEL (for Manual Transaxle) . Refer to «INSTALLATION - Step 15»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
41. INSTALL LOWER CENTER INSTRUMENT PANEL FINISH PANEL (for Automatic Transaxle) . Refer to «INSTALLATION - Step 16»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
42. INSTALL FRONT NO. 1 CONSOLE BOX INSERT . Refer to «INSTALLATION - Step 17»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
43. INSTALL FRONT NO. 2 CONSOLE BOX INSERT . Refer to «INSTALLATION - Step 18»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
44. INSTALL FRONT CONSOLE BOX ASSEMBLY (for 2WD) . Refer to «INSTALLATION - Step 1»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
45. INSTALL FRONT CONSOLE BOX ASSEMBLY (for 4WD) . Refer to «INSTALLATION - Step 2»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
46. INSTALL CONSOLE BOX CARPET
47. INSTALL NO. 2 SWITCH HOLE BASE . Refer to «INSTALLATION - Step 22»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
48. INSTALL FRONT UPPER CONSOLE BOX . Refer to «INSTALLATION - Step 23»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
49. INSTALL AIR CONDITIONING PANEL ASSEMBLY See step 1
50. INSTALL NAVIGATION ANTENNA CORD SUB-ASSEMBLY (w/ Navigation Antenna). Refer to «INSTALLATION - Step 1»(ref-427552-S31543295102011101200000)
51. INSTALL RADIO RECEIVER ASSEMBLY WITH BRACKET. Refer to «INSTALLATION - Step 4»(ref-427547-S38217956272011101200000)
52. INSTALL UPPER INSTRUMENT PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 1»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
53. CONNECT INSTRUMENT PANEL WIRE ASSEMBLY. Refer to «INSTALLATION - Step 5»(ref-427307-S24622081112011101200000)
54. INSTALL NO. 1 INSTRUMENT PANEL BOX DOOR SUB-ASSEMBLY . Refer to «INSTALLATION - Step 3»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
55. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «INSTALLATION - Step 4»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
56. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (for Manual Transaxle) . Refer to «INSTALLATION - Step 5»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
57. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (for Automatic Transaxle) . Refer to «INSTALLATION - Step 6»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
58. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transaxle) . Refer to «INSTALLATION - Step 7»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
59. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transaxle) . Refer to «INSTALLATION - Step 8»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
60. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL ASSEMBLY . Refer to «INSTALLATION - Step 9»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
61. INSTALL FRONT PILLAR GARNISH LH . Refer to «INSTALLATION - Step 79»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
62. CONNECT FRONT DOOR OPENING TRIM WEATHERSTRIP LH . Refer to «INSTALLATION - Step 80»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
63. INSTALL FRONT PILLAR GARNISH RH . Refer to «INSTALLATION - Step 83»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
64. CONNECT FRONT DOOR OPENING TRIM WEATHERSTRIP RH . Refer to «INSTALLATION - Step 84»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
65. INSTALL COMBINATION METER ASSEMBLY. Refer to «INSTALLATION - Step 1»(ref-427467-S12262416502011101200000)
66. INSTALL METER HOOD SUB-ASSEMBLY. Refer to «INSTALLATION - Step 2»(ref-427467-S12262416502011101200000)
67. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 16»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
68. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(/toyota/matrix/e140-2008-2014/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
69. TURN FRONT WHEELS TO FACE STRAIGHT AHEAD
70. ADJUST SPIRAL CABLE. Refer to «INSTALLATION - Step 23»(ref-427307-S22606437992011101200000)
71. INSTALL STEERING WHEEL ASSEMBLY Refer to «INSTALLATION»(ref-427306-S23451500522011101200000)
72. INSPECT STEERING WHEEL CENTER POINT
73. INSTALL HEATER OUTLET WATER HOSE Install the water hose and attach the clip.
74. INSTALL HEATER INLET WATER HOSE Use the same procedure described for the heater outlet water hose.
75. INSTALL LIQUID PIPE SUB-ASSEMBLY Remove the attached vinyl tape from the tube. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the liquid pipe sub-assembly. Compressor oil ND-OIL 8 or equivalent Install the O-ring on the liquid pipe sub-assembly. Install the liquid pipe sub-assembly.
76. INSTALL SUCTION PIPE SUB-ASSEMBLY Remove the attached vinyl tape from the hose. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the suction hose sub-assembly. Compressor oil ND-OIL 8 or equivalent Install the O-ring on the suction hose sub-assembly. Move the hook connector in the direction indicated by the arrow in the illustration. Insert the pipe joint into the fitting hole securely and tighten the bolt. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
77. CHARGE WITH REFRIGERANT See step 2
78. ADD ENGINE COOLANT (for 2AZ-FE). Refer to «REPLACEMENT - Step 2»(ref-427457-S17658117032011101200000)
79. ADD ENGINE COOLANT (for 2ZR-FE). Refer to «REPLACEMENT - Step 2»(ref-427482-S20059146522011101200000)
80. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
81. INSPECT FOR COOLANT LEAK (for 2AZ-FE) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/matrix/e140-2008-2014/remont/cooling-system-mechanical/#cooling-system-2az-fe-inspection)
82. INSPECT FOR COOLANT LEAK (for 2ZR-FE) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/toyota/matrix/e140-2008-2014/remont/cooling-system-mechanical/#cooling-system-2zr-fe-inspection)
83. INSPECT STEERING PAD. Refer to «INSTALLATION - Step 5»(ref-427307-S42148190442011101200000)
84. INSPECT SRS WARNING LIGHT Refer to «DIAGNOSIS SYSTEM»(ref-427508-S19102318712011101200000)
85. WARM UP ENGINE See step 3
86. INSPECT FOR REFRIGERANT LEAK See step 4

Scheme 115

Scheme 116

See also:
• PRECAUTION
• REMOVAL - Step 2
• ON-VEHICLE INSPECTION - Step 1
• ON-VEHICLE INSPECTION - Step 1
• REMOVAL - Step 2
