REPLACEMENT
HINT
Installation is in the reverse order of removal.
Scheme 98
- REMOVE ASSIST STRAP HOLE COVER (SEE «OVERHAUL»(ref-226451-S30255961772006032900000) )
- REMOVE ASSIST STRAP ASSY RH (SEE «OVERHAUL»(ref-226451-S30255961772006032900000) )
- REMOVE BACK DOOR TRIM PANEL ASSY (SEE «OVERHAUL»(ref-226451-S30255961772006032900000) )
- REMOVE BACK DOOR LOCK ASSY (SEE «OVERHAUL»(ref-226451-S30255961772006032900000) )
- REMOVE BACK DOOR HANDLE ASSY OUTSIDE (SEE «OVERHAUL»(ref-226451-S30255961772006032900000) )
- REMOVE LUGGAGE COMPARTMENT DOOR GARNISH SUB-ASSY OUTSIDE (SEE «LUGGAGE COMPARTMENT DOOR GARNISH SUB-ASSY OUT»(ref-226452-S37729339232006032900000) )
- REMOVE LICENSE PLATE LAMP ASSY Remove the 4 screws and the 2 license plate lamp lenses. Remove the license plate lamp assy from the luggage compartment door garnish sub-assy outside.
- INSTALL BACK DOOR LOCK ASSY (SEE «OVERHAUL»(ref-226451-S30255961772006032900000) )
HINT
Installation is in the reverse order of removal.
Scheme 99
- REMOVE BACK WINDOW PANEL TRIM UPPER (SEE «OVERHAUL»(ref-226451-S30255961772006032900000) )
- REMOVE CENTER STOP LAMP SOCKET & WIRE Disconnect the connector, and remove the center stop lamp socket & wire.
- REMOVE CENTER STOP LAMP ASSY Remove the 2 screws. Disengage the 4 claws, and remove the center stop lamp assy.
- REMOVE CENTER STOP LAMP GASKET
- INSTALL CENTER STOP LAMP ASSY Remove adhesive tape from the body. Wipe off stains with a cleaner. Install the center stop lamp assy with the 2 screws.
HINT
Installation is in the reverse order of removal.
Scheme 100
- REMOVE STEERING COLUMN COVER LWR (SEE «OVERHAUL»(ref-226425-S14118475362006032900000) )
- REMOVE STEERING COLUMN COVER UPR (SEE «OVERHAUL»(ref-226425-S14118475362006032900000) )
- REMOVE HEADLAMP DIMMER SWITCH ASSY Disconnect the connector. Using a screwdriver, disengage the claw, and remove the headlamp dimmer switch assy. NOTE: Pressing the claw hard breaks the claw. HINT: Tape the screwdriver tip before use.
