PRECAUTION

1. PRECAUTION OF HEADLAMP BULB REPLACEMENT If even a thin film of oil is left on the surface of the halogen lamp, the bulb may be damaged because the lamp will burn at a higher temperature. Handle any halogen lamp with great care. Dropping, hitting or damaging the bulb, in any way, may result in it exploding and shattering because the internal pressure is high. Always prepare a new bulb for immediate replacement. While replacing the bulb, the lens may attract dust and moisture if removed from the vehicle for too long. Always use a bulb of the same wattage for replacement. Firmly reinstall the socket after bulb replacement. The lens may become cloudy or the light cavity may fill with water through the gaps around the socket.

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

1. INSPECT TURN SIGNAL FLASHER CIRCUIT Disconnect the connector from the turn signal flasher relay. Measure the voltage according to the value(s) in the table below. Standard: Reconnect the connector to the turn signal flasher. Measure the voltage according to the valve(s) in the table below. Standard
2. INSPECT TOWING CONVERTER RELAY Measure the voltage according to the value(s) in the table below.

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

1. HEADLAMP DIMMER SWITCH ASSY Inspect light control switch. Measure the resistance according to the value(s) in the table below. Standard: LIGHT CONTROL SWITCH SPECIFIED CONDITION Tester connection Condition Specified condition 12 - 16 13 - 16 14 - 16 OFF 10 kohm or higher 14 - 16 TAIL Below 1 ohm 13 - 16 14 - 16 HEAD Below 1 ohm 12 - 16 AUTO Below 1 ohm Inspect headlamp dimmer switch. Measure the resistance according to the value(s) in the table below. Standard: HEADLAMP DIMMER SWITCH SPECIFIED CONDITION Tester connection Condition Specified condition 16 - 17 LOW Below 1 ohm 7 - 16 HIGH Below 1 ohm 7 - 16 8 - 16 FLASH Below 1 ohm Inspect turn signal switch. Measure the resistance according to the value(s) in the table below. Standard: TURN SIGNAL SWITCH SPECIFIED CONDITION Tester connection Condition Specified condition 2 - 3 Right turn Below 1 ohm 1 - 2 2 - 3 Neutral 10 kohm or higher 1 - 2 Left turn Below 1 ohm w/Front Fog Lamp: Inspect front fog light switch. Measure the resistance according to the value(s) in the table below. Standard: W/FRONT FOG LAMP SPECIFIED CONDITION Tester connection Condition Specified condition 10 - 11 OFF 10kohm or higher 10 - 11 ON Below 1 ohm
2. HAZARD WARNING SWITCH ASSY w/o navigation system: Measure the resistance according to the value(s) in the table below. Standard: HAZARD WARNING SWITCH W/O NAVIGATION SYSTEM SPECIFIED CONDITION Tester connection Condition Specified condition A10-8 - A10-11 OFF 10 kohm or higher A10-8 - A10-11 ON Below 1 ohm w/ navigation system: Measure the resistance according to the value(s) in the table below. Standard: HAZARD WARNING SWITCH W/ NAVIGATION SYSTEM SPECIFIED CONDITION Tester connection Condition Specified condition M3-3 - M3-8 OFF 10 kohm or higher M3-3 - M3-8 ON Below 1ohm
3. FRONT DOOR COURTESY LAMP SWITCH ASSY Measure the resistance according to the value(s) in the table below. Standard: FRONT DOOR COURTESY LAMP SWITCH ASSY RESISTANCE Tester connection Condition Specified condition 1 - Body ground OFF (When shaft is pressed) 10 kohm or higher 1 - Body ground ON (When shaft is not pressed) Below 1 ohm
4. REAR DOOR COURTESY LAMP SWITCH ASSY Measure the resistance according to the value(s) in the table below. Standard: REAR DOOR COURTESY LAMP SWITCH ASSY RESISTANCE Tester connection Condition Specified condition 1-Body ground OFF (When shaft is pressed) 10 kohm or higher 1-Body ground ON (When shaft is not pressed) Below 1 ohm
5. BACK DOOR LOCK ASSY Inspect back door courtesy lamp switch assy. Measure the resistance according to the value(s) in the table below. Standard: BACK DOOR LOCK ASSY RESISTANCE Tester connection Condition Specified condition 1 - 2 Back door is closed 10 kohm or higher 1 - 2 Back door is open Below 1 ohm
6. ROOM LAMP ASSY NO.1 Measure the resistance according to the value(s) in the table below. Standard: ROOM LAMP ASSY NO.1 RESISTANCE Tester connection Condition Specified condition 1 - 2 1 - 3 OFF 10 kohm or higher Connect the positive (+) lead from the battery to the terminal 1 and negative (-) lead to the terminal 2, then check that the lamp comes on when the switch is in the DOOR position. Connect the positive (+) lead from the battery to the terminal 1 and negative (-) lead to the terminal 3, then check that the lamp comes on when the switch is in the ON position.
7. ROOM LAMP ASSY NO.2 Measure the resistance according to the value(s) in the table below. Standard: ROOM LAMP ASSY NO.2 RESISTANCE Tester connection Condition Specified condition 1 - 2 1 - 3 OFF 10 kohm or higher Connect the positive (+) lead from the battery to the terminal 1 and negative (-) lead to the terminal 2, then check that the lamp comes on when the switch is in the DOOR position. Connect the positive (+) lead from the battery to the terminal 1 and negative (-) lead to the terminal 3, then check that the lamp comes on when the switch is in the ON position.
8. MAP LAMP ASSY Inspect the map lamp in the overhead J/B. Connect the positive (+) lead from the battery to terminal 12 and negative (-) lead to terminal 1, then check that the lamp comes on when the switch is in the ON position. Connect the positive (+) lead from the battery to terminal 12 and negative (-) lead to terminal 7, then check that the lamp comes on when the switch is in the DOOR position.
9. COURTESY LAMP ASSY Connect the positive (+) lead from the battery to terminal 1 and negative (-) lead to terminal 2, then check that the lamp comes on.
10. LH VISOR ASSY Connect the positive (+) lead from the battery to one of the terminals and the negative (-) lead to other terminal, then check that the lamp comes on when the switch is in the ON position.
11. RH VISOR ASSY Connect the positive (+) lead from the battery to one of the terminals and the negative (-) lead to other terminal, then check that the lamp comes on when the switch is in the ON position.
12. GLOVE BOX LAMP ASSY Connect the positive (+) lead from the battery to one of the terminals and the negative (-) lead to other terminal, then check that the lamp comes on when the switch is in the ON position.
13. KEY CYLINDER LAMP w/ Theft deterrent system: Connect the positive (+) lead from the battery to terminal 2 and negative (-) lead to terminal 6, then check that the lamp comes on. w/o Theft deterrent system: Connect the positive (+) lead from the battery to terminal 2 and negative (-) lead to terminal 1, then check that the lamp comes on.
14. HEADLAMP RELAY Measure the resistance according to the value(s) in the table below. Standard: HEADLAMP RELAY SPECIFIED CONDITION Tester connection Specified condition 3 - 5 10 kohm or higher 3 - 5 Below 1 ohm (When battery voltage is applied to terminals 1 - 2)
15. TAIL LAMP RELAY Measure the resistance according to the value(s) in the table below. Standard: TAIL LAMP RELAY SPECIFIED CONDITION Tester connection Specified condition 3 - 5 10 kohm or higher 3 - 5 Below 1 ohm (When battery voltage is applied to terminals 1 - 2)
16. FOG LAMP RELAY Measure the resistance according to the value(s) in the table below. Standard: FOG LAMP RELAY SPECIFIED CONDITION Tester connection Specified condition 3 - 5 10 kohm or higher 3 - 5 Below 1 ohm (When battery voltage is applied to terminals 1 - 2)
17. DRL NO.2 RELAY Measure the resistance according to the value(s) in the table below. Standard: DRL NO.2 RELAY SPECIFIED CONDITION Tester connection Specified condition 3 - 5 10 kohm or higher 3 - 5 Below 1 ohm (When battery voltage is applied to terminals 1 - 2)
18. DRL NO.3 RELAY Measure the resistance according to the value(s) in the table below. Standard: DRL NO.3 RELAY SPECIFIED CONDITION Tester connection Specified condition 3 - 5 10 kohm or higher 3 - 5 Below 1 ohm (When battery voltage is applied to terminals 1 -2) 3 - 4 10 kohm or higher (When battery voltage is applied to terminals 1 - 2)
19. DRL NO.4 RELAY Measure the resistance according to the value(s) in the table below. Standard: DRL NO.4 RELAY SPECIFIED CONDITION Tester connection Specified condition 3 - 5 10 kohm or higher 3 - 5 Below 1 ohm (When battery voltage is applied to terminals 1 - 2)
20. STOP LAMP SWITCH ASSY Measure the resistance according to the value(s) in the table below. Standard: STOP LAMP SWITCH ASSY SPECIFIED CONDITION Tester connection Switch position Specified resistance 1 - 2 Switch pin free Below 1 ohm 3 - 4 Switch pin free 10 kohm or higher 1 - 2 Switch pin pushed in 10 kohm or higher 3 - 4 Switch pin pushed in Below 1 ohm

Scheme 148
