Differential: Removal & Installation Toyota Highlander I рестайлинг

Differentials & Drive Axles 2 illustrations ~678 words

REPLACEMENT

HINT

  1. Differential components (See «DIFFERENTIAL (4WD)»(ref-226419-S01937532582006032900000) )
  2. Rear drive shaft components (See «DRIVE SHAFT / PROPELLER SHAFT / AXLE»(ref-226420-S22110396222006032900000) )
  3. Replace the RH side following the same procedures as with the LH side.

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. REMOVE REAR WHEEL
  2. REMOVE PROPELLER W/CENTER BEARING SHAFT ASSY (2AZ-FE ENGINE TYPE) (SEE «PROPELLER W/CENTER BEARING SHAFT ASSY (4WD)»(ref-226420-S07628102592006032900000) ) SST 09325-20010
  3. REMOVE EXHAUST PIPE ASSY (2AZ-FE ENGINE TYPE) (SEE «REPLACEMENT»(ref-226411-S41569326612006032800000) ) HINT: Perform this procedure only when removing the RH side.
  4. REMOVE EXHAUST PIPE ASSY (3MZ-FE ENGINE TYPE) (SEE «REPLACEMENT»(ref-226411-S18540808582006032800000) )
  5. REMOVE REAR DIFFERENTIAL FILLER PLUG Using a hexagon wrench (10 mm), remove the filler plug and gasket.
  6. REMOVE REAR DIFFERENTIAL DRAIN PLUG Using a hexagon wrench (10 mm), remove the drain plug and gasket, and drain the oil.
  7. SEPARATE SPEED SENSOR REAR LH (SEE «REAR DRIVE SHAFT (4WD)»(ref-226420-S25944618802006032900000) )
  8. REMOVE REAR AXLE SHAFT LH NUT (SEE «REAR DRIVE SHAFT (4WD)»(ref-226420-S25944618802006032900000) )
  9. SEPARATE REAR SUSPENSION ARM ASSY NO. 1 LH (SEE «REAR SUSPENSION ARM ASSY NO. 1 LH (4WD)»(ref-226417-S38142031992006032800000) )
  10. SEPARATE STRUT ROD ASSY REAR (SEE «STRUT ROD ASSY REAR»(ref-226417-S24117223062006032800000) )
  11. SEPARATE REAR SUSPENSION ARM ASSY NO. 2 LH (SEE «REAR SUSPENSION ARM ASSY NO. 2 LH (4WD)»(ref-226417-S00541242622006032800000) )
  12. REMOVE REAR DRIVE SHAFT ASSY LH (SEE «REAR DRIVE SHAFT (4WD)»(ref-226420-S25944618802006032900000) )
  13. REMOVE REAR DIFFERENTIAL SIDE GEAR SHAFT SEAL OIL Using SST, remove the oil seal. SST 09308-00010
  14. INSTALL REAR DIFFERENTIAL SIDE GEAR SHAFT SEAL OIL Using SST and a hammer, install a new oil seal until it is flush with the carrier end surface. Oil seal drive in depth: 0 +/- 0.5 mm (0 +/- 0.019 in.) Apply MP grease to the oil seal lip. SST 09550-00032, 09950-70010 (09951-07200)
  15. INSTALL REAR DRIVE SHAFT ASSY LH (SEE «REAR DRIVE SHAFT (4WD)»(ref-226420-S25944618802006032900000) )
  16. TEMPORARILY TIGHTEN REAR SUSPENSION ARM ASSY NO. 2 LH (SEE «REAR SUSPENSION ARM ASSY NO. 2 LH (4WD)»(ref-226417-S00541242622006032800000) )
  17. TEMPORARILY TIGHTEN STRUT ROD ASSY REAR (SEE «STRUT ROD ASSY REAR»(ref-226417-S24117223062006032800000) )
  18. TEMPORARILY TIGHTEN REAR SUSPENSION ARM ASSY NO. 1 LH (SEE «REAR SUSPENSION ARM ASSY NO. 1 LH (4WD)»(ref-226417-S38142031992006032800000) )
  19. INSTALL REAR AXLE SHAFT LH NUT (SEE «REAR DRIVE SHAFT (4WD)»(ref-226420-S25944618802006032900000) ) SST 09930-00010
  20. INSTALL SPEED SENSOR REAR LH (SEE «REAR DRIVE SHAFT (4WD)»(ref-226420-S25944618802006032900000) )
  21. STABILIZE SUSPENSION (SEE «STRUT ROD ASSY REAR»(ref-226417-S24117223062006032800000) )
  22. FULLY TIGHTEN REAR SUSPENSION ARM ASSY NO. 2 LH (SEE «REAR SUSPENSION ARM ASSY NO. 2 LH (4WD)»(ref-226417-S00541242622006032800000) )
  23. FULLY TIGHTEN STRUT ROD ASSY REAR (SEE «STRUT ROD ASSY REAR»(ref-226417-S24117223062006032800000) )
  24. FULLY TIGHTEN REAR SUSPENSION ARM ASSY NO. 1 LH (SEE «REAR SUSPENSION ARM ASSY NO. 1 LH (4WD)»(ref-226417-S38142031992006032800000) )
  25. INSTALL EXHAUST PIPE ASSY (3MZ-FE ENGINE TYPE) (SEE «REPLACEMENT»(ref-226411-S18540808582006032800000) ) HINT: Perform this procedure only when removing the RH side.
  26. INSTALL EXHAUST PIPE ASSY (2AZ-FE ENGINE TYPE) (SEE «REPLACEMENT»(ref-226411-S41569326612006032800000) ) HINT: Perform this procedure only when removing the RH side.
  27. INSTALL PROPELLER W/CENTER BEARING SHAFT ASSY (2AZ-FE ENGINE TYPE) (SEE «PROPELLER W/CENTER BEARING SHAFT ASSY (4WD)»(ref-226420-S07628102592006032900000) ) HINT: Perform this procedure only when removing the RH side.
  28. FULLY TIGHTEN PROPELLER W/CENTER BEARING SHAFT ASSY (2AZ-FE ENGINE TYPE) (SEE «PROPELLER W/CENTER BEARING SHAFT ASSY (4WD)»(ref-226420-S07628102592006032900000) ) HINT: Perform this procedure only when removing the RH side. SST 09370-50010
  29. INSTALL REAR DIFFERENTIAL DRAIN PLUG Using a hexagon wrench (10 mm), install the drain plug and a new gasket. Torque: 49 N.m (500 kgf.cm, 36 ft.lbf)
  30. ADD DIFFERENTIAL OIL Fill the rear differential carrier assy with hypoid gear oil. Oil grade: Hypoid gear oil API GL-5 Recommended oil viscosity: Above -18°C (0°F) SAE 90 Below -18°C (0°F) SAE 80W or 80W-90 Capacity: 0.9 +/- 0.05 liters (0.95 +/- 0.05 US qts, 0.79 +/- 0.04 imp. qts)
  31. INSPECT DIFFERENTIAL OIL (SEE «DIFFERENTIAL OIL (4WD)»(ref-226419-S29984255452006032900000) )
  32. INSTALL REAR DIFFERENTIAL FILLER PLUG Using a hexagon wrench (10 mm), install the filler plug and a new gasket. Torque: 49 N.m (500 kgf.cm, 36 ft.lbf)
  33. INSTALL REAR WHEEL Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf)
  34. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (SEE «REAR WHEEL ALIGNMENT»(ref-226417-S21042245802006032800000) )
  35. CHECK FOR EXHAUST GAS LEAKS HINT: Perform this procedure only when removing the RH side.
  36. CHECK ABS SPEED SENSOR SIGNAL (SEE «PRE-CHECK»(ref-226383-S26855084272006032700000) )
