Differential: Diagnosis Toyota Highlander I рестайлинг

Differentials & Drive Axles 14 illustrations ~746 words

PROBLEM SYMPTOMS TABLE

Use the table below to help you find the cause of the problem. The causes of the problem are listed in order of probability in the "Suspected Area" column. Check each part in order. If necessary, replace these parts.

Scheme 1

Scheme 1: PROBLEM SYMPTOMS TABLE
Scheme 1: PROBLEM SYMPTOMS TABLE

Scheme 2

Scheme 2: COMPONENTS
Scheme 2: COMPONENTS

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: ADJUSTMENT
Scheme 4: ADJUSTMENT
  1. INSPECT DIFFERENTIAL OIL Stop the vehicle on the level place. Remove the differential filler plug and gasket. Check that the oil surface is within 5 mm (0.20 in.) from the lowest position of the inner surface of the differential filler plug opening. NOTE: Excessively large or small amount of oil may cause troubles. After replacing oil, drive the vehicle and check the oil level. HINT: If necessary, fill the rear differential carrier assy with hypoid gear oil. Oil grade: Hypoid gear oil API GL-5 Recommended oil viscosity: Above -18°C (0°F) SAE 90 Below -18°C (0°F) SAE 80W or 80W-90 Capacity: 0.9 +/- 0.05 liters (0.95 +/- 0.05 US qts, 0.79 +/- 0.04 Imp. qts) Check for oil leakage when the oil level is low. Install the differential filler plug and a new gasket. Torque: 49 N.m (500 kgf.cm, 36 ft.lbf)

Scheme 5

Scheme 5: REPLACEMENT
Scheme 5: REPLACEMENT

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. REMOVE EXHAUST PIPE ASSY (2AZ-FE ENGINE TYPE) (SEE «REPLACEMENT»(ref-226411-S41569326612006032800000) )
  2. REMOVE EXHAUST PIPE ASSY (3MZ-FE ENGINE TYPE) (SEE «REPLACEMENT»(ref-226411-S18540808582006032800000) )
  3. REMOVE PROPELLER W/CENTER BEARING SHAFT ASSY (SEE «PROPELLER W/CENTER BEARING SHAFT ASSY (4WD)»(ref-226420-S07628102592006032900000) )
  4. REMOVE REAR DIFFERENTIAL FILLER PLUG Using a hexagon wrench (10 mm), remove the filler plug and gasket.
  5. REMOVE REAR DIFFERENTIAL DRAIN PLUG Using a hexagon wrench (10 mm), remove the drain plug and gasket, drain the oil.
  6. REMOVE REAR DRIVE PINION NUT Using a chisel and a hammer, unstake the staked part of the nut. Using SST to hold the flange, remove the nut. SST 09330-00021
  7. REMOVE REAR DRIVE PINION COMPANION FLANGE SUB-ASSY REAR Using SST, remove the companion flange. SST 09950-30012 (09951-03010, 09953-03010, 09954-03010, 09955-03030, 09956-03020)
  8. REMOVE REAR DIFFERENTIAL DUST DEFLECTOR Using SST and a press, remove the dust deflector. SST 09950-00020, 09950-60010 (09951-00360), 09950-70010 (09951-07150)
  9. REMOVE REAR DIFFERENTIAL CARRIER OIL SEAL Using SST, remove the oil seal. SST 09308-10010
  10. REMOVE REAR DIFFERENTIAL DRIVE PINION OIL SLINGER
  11. REMOVE REAR DRIVE PINION FRONT TAPERED ROLLER BEARING Using SST, remove the front tapered roller bearing. SST 09556-22010
  12. REMOVE REAR DIFFERENTIAL DRIVE PINION BEARING SPACER
  13. INSTALL REAR DIFFERENTIAL DRIVE PINION BEARING SPACER Install a new bearing spacer.
  14. INSTALL REAR DRIVE PINION FRONT TAPERED ROLLER BEARING Install the tapered roller bearing.
  15. INSTALL REAR DIFFERENTIAL DRIVE PINION OIL SLINGER Install the oil slinger.
  16. INSTALL REAR DIFFERENTIAL CARRIER OIL SEAL Using SST and a hammer, install a new oil seal. Oil seal drive in depth: 2.0 +/- 0.3 mm (0.079 +/- 0.012 in.) Coat MP grease to the oil seal lip. SST 09554-22010
  17. INSTALL REAR DIFFERENTIAL DUST DEFLECTOR Using SST and a press, install a new dust deflector. SST 09223-00010 NOTE: Be careful not to damage the dust deflector.
  18. INSTALL REAR DRIVE PINION COMPANION FLANGE SUB-ASSY REAR Using SST, install the companion flange on the shaft. SST 09950-30012 (09951-03010, 09953-03010, 09954-03010, 09955-03030, 09956-03020) NOTE: Apply hypoid gear oil to the SST center bolt tip and threads before use.
  19. INSTALL REAR DRIVE PINION NUT Coat the threads of a new nut with hypoid gear oil LSD. Using SST to hold the flange, torque the nut. SST 09330-00021 Torque: 108 N.m (1,100 kgf.cm, 80 ft.lbf)
  20. INSPECT DIFFERENTIAL DRIVE PINION PRELOAD (SEE «DIFFERENTIAL CARRIER ASSY REAR (4WD)»(ref-226419-S25954733402006032900000) )
  21. INSTALL REAR DRIVE PINION NUT Using a chisel and a hammer, stake the drive pinion nut.
  22. INSTALL PROPELLER W/CENTER BEARING SHAFT ASSY (SEE «PROPELLER W/CENTER BEARING SHAFT ASSY (4WD)»(ref-226420-S07628102592006032900000) )
  23. INSTALL REAR DIFFERENTIAL DRAIN PLUG Using a hexagon wrench (10 mm), install the drain plug and a new gasket. Torque: 49 N.m (500 kgf.cm, 36 ft.lbf)
  24. ADD DIFFERENTIAL OIL Fill the rear differential carrier assy with hypoid gear oil. Oil grade: Hypoid gear oil API GL-5 Recommended oil viscosity: Above -18°C (0°F) SAE 90 Below -18°C (0°F) SAE 80W or 80W-90 Capacity: 0.9 +/- 0.05 liters (0.95 +/- 0.05 US qts, 0.79 +/- 0.04 Imp. qts)
  25. INSPECT DIFFERENTIAL OIL (SEE «DIFFERENTIAL OIL (4WD)»(ref-226419-S29984255452006032900000) )
  26. INSTALL REAR DIFFERENTIAL FILLER PLUG Using a hexagon wrench (10 mm), install the filler plug and a new gasket. Torque: 49 N.m (500 kgf.cm, 36 ft.lbf)
  27. INSTALL EXHAUST PIPE ASSY (2AZ-FE ENGINE TYPE) (SEE «REPLACEMENT»(ref-226411-S41569326612006032800000) )
  28. INSTALL EXHAUST PIPE ASSY (3MZ-FE ENGINE TYPE) (SEE «REPLACEMENT»(ref-226411-S18540808582006032800000) )
