PRECAUTION
Note. Perform the RESET MEMORY (AT Initialization) when replacing the automatic transaxle assy, engine assy or ECM (See INITIALIZATION ).
HINT
Initialization can not be completed by only disconnecting the battery terminal.
DEFINITION OF TERMS
| Term | Definition |
|---|---|
| Monitor description | Description of what the ECM monitors and how it detects malfunctions (monitoring purpose and its details). |
| Related DTCs | A group of diagnostic trouble codes that are output by the ECM based on the same malfunction detection logic. |
| Typical enabling condition | Preconditions that allow the ECM to detect malfunctions. With all preconditions satisfied, the ECM sets the DTC when the monitored value (s) exceeds the malfunction threshold (s). |
| Sequence of operation | The priority order that is applied to monitoring, if multiple sensors and components are used to detect the malfunction. While another sensor is being monitored, the next sensor or component will not be monitored until the previous monitoring has concluded. |
| Required sensor/components | The sensors and components that are used by the ECM to detect malfunctions. |
| Frequency of operation | The number of times that the ECM checks for malfunctions per driving cycle. "Once per driving cycle" means that the ECM detects malfunction only one time during a single driving cycle. "Continuous" means that the ECM detects malfunction every time when enabling condition is met. |
| Duration | The minimum time that the ECM must sense a continuous deviation in the monitored value (s) before setting a DTC. This timing begins after the "typical enabling conditions" are met. |
| Malfunction thresholds | Beyond this value, the ECM will conclude that there is a malfunction and set a DTC. |
| MIL operation | MIL illumination timing after a defect is detected. "Immediately" means that the ECM illuminates MIL the instant the ECM determines that there is a malfunction. "2 driving cycle" means that the ECM illuminates MIL if the same malfunction is detected again in the 2nd driving cycle. |
| Component operating range | Normal operation range of sensors and solenoids under normal driving conditions. Use these ranges as a reference. They cannot be used to judge if a sensor or solenoid is defective or not. |
DEFINITION OF TERM CHART
PART AND SYSTEM NAME LIST
This reference list indicates the part names used in this manual along with their definitions.
| Part and system name | Definition |
|---|---|
| Toyota HCAC system, Hydrocarbon adsorptive Catalyst (HCAC) system, HC adsorptive three-way catalyst | HC adsorptive three-way catalytic converter |
| Variable Valve Timing sensor, VVT sensor | Camshaft position sensor |
| Variable valve timing system, VVT system | Camshaft timing control system |
| Camshaft timing oil control valve, Oil control valve OCV, VVT, VSV | Camshaft timing oil control valve |
| Variable timing and lift, VVTL | Camshaft timing and lift control |
| Crankshaft position sensor "A" | Crankshaft position sensor |
| Engine speed sensor | Crankshaft position sensor |
| THA | Intake air temperature |
| Knock control module | Engine knock control module |
| Knock sensor | Engine knock sensor |
| Mass or volume air flow circuit | Mass air flow sensor circuit |
| Vacuum sensor | Manifold air pressure sensor |
| Internal control module, Control module, Engine control ECU, PCM | Power train control module |
| FC idle | Deceleration fuel cut |
| Idle air control valve | Idle speed control |
| VSV for CCV, Canister close valve VSV for canister control | Evaporative emissions canister vent valve |
| VSV for EVAP, Vacuum switching valve assembly No. 1, EVAP VAV, Purge VSV | Evaporative emissions canister purge valve |
| VSV for pressure switching valve, Bypass VSV | Evaporative emission pressure switching valve |
| Vapor pressure sensor, EVAP pressure sensor, Evaporative emission control system pressure sensor | Fuel tank pressure sensor |
| Charcoal canister | Evaporative emissions canister |
| ORVR system | On-board refueling vapor recovery system |
| Intake manifold runner control | Intake manifold tuning system |
| Intake manifold runner valve, IMRV, IACV (runner valve) | Intake manifold tuning valve |
| Intake control VSV | Intake manifold tuning solenoid valve |
| AFS | Air fuel ratio sensor |
| O2 sensor | Heater oxygen sensor |
| Oxygen sensor pumping current circuit | Oxygen sensor output signal |
| Oxygen sensor reference ground circuit | Oxygen sensor signal ground |
| Accel position sensor | Accelerator pedal position sensor |
| Throttle actuator control motor, Actuator control motor, Electronic throttle motor, Throttle control motor | Electronic throttle actuator |
| Electronic throttle control system, Throttle actuator control system | Electronic throttle control system |
| Throttle/pedal position sensor, Throttle/pedal position switch, Throttle position sensor/switch | Throttle position sensor |
| Turbo press sensor | Turbocharger pressure sensor |
| Turbo VSV | Turbocharger pressure control solenoid valve |
| P/S pressure switch | Power-steering pressure switch |
| VSV for ACM | Active control engine mount |
| Speed sensor, Vehicle speed sensor "A", Speed sensor for skid control ECU | Vehicle speed sensor |
| ATF temperature sensor, Trans, fluid temp, sensor, ATF temperature sensor "A" | Transmission fluid temperature sensor |
| Electronic controlled automatic transmission, ECT | Electronically controlled automatic |
| Intermediate shaft speed sensor "A" | Counter gear speed sensor |
PART AND SYSTEM NAME LIST
| Part and system name | Definition |
|---|---|
| Output speed sensor | Output shaft speed sensor |
| Input speed sensor, Input turbine speed sensor "A", Speed sensor (NT), Turbine speed sensor | Input turbine speed sensor |
| PNP switch, NSW | Park/neutral position switch |
| Pressure control solenoid | Transmission pressure control solenoid |
| Shift solenoid | Transmission shift solenoid valve |
| Transmission control switch, Shift lock control unit | Shift lock control module |
| Engine immobilizer system, Immobilizer system | Vehicle anti-theft system |
PART AND SYSTEM NAME LIST
Scheme 384
SYSTEM DIAGRAM
The configuration of the electronic control system in the U151E/U151F automatic transaxles is as shown in the following chart.
Scheme 385
MECHANICAL SYSTEM TESTS
- PERFORM MECHANICAL SYSTEM TESTS
Scheme 386
- Measure the stall speed. The object of this test is to check the overall performance of the transaxle and engine by measuring the stall speeds in the D positions. NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature 50 to 80°C (122 to 176°F). Do not continuously run this test for longer than 10 seconds. To ensure safety, do this test in a wide, clear level area which provides good traction. The stall test should always be carried out in pairs. One technician should observe the conditions of wheels or wheel stoppers outside the vehicle while the other is doing the test. Chock the 4 wheels. Connect an OBD II scan tool or hand-held tester to the DLC3. Fully apply the parking brake. Keep your left foot pressed firmly on the brake pedal. Start the engine. Shift into the D position. Press all the way down on the accelerator pedal with your right foot. Quickly read the stall speed at this time. Stall speed: U151E: 2,240 +/- 150 RPM U151F: 2,550 +/- 150 RPM Evaluation
- Measure the time lag.
- When the shift lever is shifted while the engine is idling, there will be a certain time lapse or lag before the shock can be felt. This is used for checking the condition of the direct clutch, forward clutch, and 1st and reverse brake. NOTE: Perform the test at the normal operating ATF temperature 50 to 80°C (122 to 176°F). Be sure to allow 1 minute interval between tests. Perform the test three times, and measure the time lags. Calculate the average value of the three time lags.
- Connect an OBD II scan tool or hand-held tester to the DLC3.
- Fully apply the parking brake.
- Start and warm up the engine and check idle speed. Idle speed: approx. 700 RPM (In N position and A/C OFF)
- Shift the lever from N to D position. Using a stop watch, measure the time from when the lever is shifted until the shock is felt. Time lag: N --> D less than 1.2 seconds
- In the same way, measure the time lag for N --> R.
Time lag: N --> R less than 1.5 seconds
Evaluation (If N --> D or N --> R time lag is longer than the specified)
Scheme 387
INITIALIZATION
- RESET MEMORY
| CAUTION | Perform the RESET MEMORY (AT initialization) when replacing the automatic transaxle assy, engine assy or ECM. |
Note. Hand-held tester only
HINT
The ECM memorizes the condition that the ECT controls the automatic transaxle assy and engine assy according to those characteristics. Therefore, when the automatic transaxle assy, engine assy, or ECM has been replaced, it is necessary to reset the memory so that the ECM can memorize the new information. Reset procedure is as follows.
- Turn the ignition switch off.
- Connect the hand-held tester to the DLC3.
- Turn the ignition switch to the ON position and push the hand-held tester main switch on.
- Select the item "DIAGNOSIS/ENHANCED OBD II".
- Perform the reset memory procedure from the ENGINE menu.
| CAUTION | After performing the RESET MEMORY, be sure to perform the ROAD TEST (See ROAD TEST ) described earlier. |
HINT
The ECM is learned by performing the ROAD TEST.
Scheme 388
LIST OF DISABLE A MONITOR
HINT
This table indicates ECM monitoring status for the items in the upper columns if the DTCs in each line on the left are being set.
As for the "X" mark, when the DTC on the left is stored, detection of the DTC in the upper column is not performed.
Scheme 389
Scheme 390
Scheme 391
Scheme 392
Scheme 393
Scheme 394
MONITOR DRIVE PATTERN
- MONITOR DRIVE PATTERN FOR ECT TEST
- Perform this drive pattern as one method to simulate the detection conditions of the ECT malfunctions. (The DTCs may not be detected due the actual driving conditions. And some codes may not be detected through this drive pattern).
HINT
Preparation for driving
- Warm up the engine sufficiently. (Engine coolant temperature is 60°C (140°F) or higher)
- Drive the vehicle when the atmospheric temperature is -10°C (14°F) or higher. (Malfunction is not detected when the atmospheric temperature is -10°C (14°F) or less)
Driving note
- Drive the vehicle through all gears. Stop --> 1st --> 2nd --> 3rd --> 4th --> 5th --> 5th (lock up ON).
- Repeat the above driving pattern three times or more.
Note. The monitor status can be checked using the OBD II scan tool. When using the hand-held tester, monitor status can be found in the "ENHANCED OBD II/DATA LIST" or under "CARB OBD II". In the event that the drive pattern must be interrupted (possibly due to traffic conditions or other factors) the drive pattern can be resumed and, in most cases, the monitor can be completed.
| CAUTION | Perform this drive pattern on a level road as much as possible and strictly observe the posted speed limits and traffic laws while driving. |
Scheme 395
HINT
*1: Drive at such a speed in the uppermost gear, to engage lock up. The vehicle can be driven at a speed lower than that in the above diagram under the lock up condition.
Note. It is necessary to drive the vehicle for approximately 30 minutes to detect DTC P0711 (ATF temperature sensor malfunction).
FAIL-SAFE CHART
- FAIL-SAFE
This function minimizes the loss of the ECT functions when any malfunction occurs in each sensor or solenoid.
- ATF (Automatic Transmission Fluid) temperature sensor: When the ATF temperature sensor has a malfunction, 5th upshift is prohibited.
- Counter gear speed sensor NC (Speed sensor NC): When the counter gear speed sensor has a malfunction, 5th upshift is prohibited.
- Shift solenoid valve DSL: When the solenoid valve DSL has a malfunction, the current to the solenoid valve is stopped. This stops lock up control, then fuel economy decreases.
- Shift solenoid valve SL1, SL2, SL3 and S4
Fail safe function
If either of the shift solenoid valve circuits develops an open or short, the ECM turns the other shift solenoid "ON" and "OFF" in order to shift into the gear positions shown in the table below.
Manual shifting as shown in the following table must be done (In case of a short circuit, the ECM stops sending the current to the short circuit solenoid).
Even if starting the engine in the fail-safe mode, the gear position remain in the same position.
circle: ON triangle: According to Flex Lock up X: OFF
>: Condition in the normal operation is shown on the left of "-->".
Condition in the fail-safe mode is shown on the right of "-->".
Scheme 396
Scheme 397
- DATA LIST HINT: According to the DATA LIST displayed by the OBD II scan tool or hand-held tester, you can read the value of the switch, sensor, actuator and so on without parts removal. Reading the DATA LIST as the first step of troubleshooting is one method to shorten labor time. Warm up the engine. Turn the ignition switch off. Connect the OBD II scan tool or hand-held tester to the DLC3. Turn the ignition switch to the ON position. Push the "ON" button of the OBD II scan tool or the hand-held tester. When you use hand-held tester: Select the item "DIAGNOSIS/ENHANCED OBD II/DATA LIST". According to the display on tester, read the "DATA LIST".
- ACTIVE TEST
HINT
Performing the ACTIVE TEST using the hand-held tester allows the relay, VSV, actuator and so on to operate without parts removal. Performing the ACTIVE TEST as the first step of troubleshooting is one method to shorten labor time.
It is possible to display the DATA LIST during the ACTIVE TEST.
Scheme 398
- Warm up the engine.
- Turn the ignition switch off.
- Connect the hand-held tester to the DLC3.
- Turn the ignition switch to the ON position.
- Push the "ON" button of the hand-held tester.
- Select the item "DIAGNOSIS/ENHANCED OBD II/ACTIVE TEST".
- According to the display on tester, perform the "ACTIVE TEST".
*: "LINE PRESS UP" in the ACTIVE TEST is performed to check the line pressure changes by connecting the SST to the automatic transaxle, which is used in the HYDRAULIC TEST (See HYDRAULIC TEST ) as well.
HINT
The pressure values in ACTIVE TEST and HYDRAULIC TEST are different from each other.
MONITOR STRATEGY
| Related DTCs | P0705: Park/neutral position switch/Verify switch input |
|---|---|
| Required sensors/Components | Park/neutral position switch |
| Frequency of operation | Continuous |
| Duration | 2 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
TYPICAL ENABLING CONDITIONS
Condition (A)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Ignition switch | ON |
| Battery voltage | 10.5 V or more |
TYPICAL ENABLING CONDITIONS CHART
Condition (B)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Ignition switch | ON |
| Battery voltage | 10.5 V or more |
TYPICAL ENABLING CONDITIONS CHART
TYPICAL MALFUNCTION THRESHOLDS
One of the following conditions is met: Condition (A) or (B)
Condition (A)
| Number of the following signal input at the same time | 2 or more |
|---|---|
| P switch | ON |
| R switch | ON |
| N switch | ON |
| D switch | ON |
| 3 switch | ON |
| 2 switch | ON |
TYPICAL MALFUNCTION THRESHOLDS CHART
Condition (B)
| Number of the following signal input at the same time | 2 or more |
|---|---|
| NSW switch | ON |
| R switch | ON |
| D switch | ON |
| 3 switch | ON |
| 2 switch | ON |
TYPICAL MALFUNCTION THRESHOLDS CHART
COMPONENT OPERATING RANGE
| Park/neutral Position switch | The park/neutral position switch sends only one signal to the ECM. |
COMPONENT OPERATING RANGE CHART
Scheme 399
| Related DTCs | P0710: ATF temperature sensor/Range check (Fluttering) P0712: ATF temperature sensor/Range check (Low resistance) P0713: ATF temperature sensor/Range check (High resistance). |
|---|---|
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 0.5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
P0710: Range check (Fluttering)
P0712: Range check (Low resistance)
| The monitor will run whenever these DTCs are not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| The typical enabling condition is not available. |
TYPICAL ENABLING CONDITIONS CHART
P0713: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Time after engine start | 15 min. or more |
HIGH RESISTANCE CHART
P0710: Range check (Fluttering)
| TFT (transmission fluid temperature) sensor | Less than 79 ohms or More than 156 kohms |
TYPICAL MALFUNCTION THRESHOLDS CHART
P0712: Range check (Low resistance)
| TFT (transmission fluid temperature) sensor | Less than 79 ohms |
TYPICAL MALFUNCTION THRESHOLDS CHART
P0713: Range check (High resistance)
| TFT (transmission fluid temperature) sensor | More than 156 kohms |
TYPICAL MALFUNCTION THRESHOLDS CHART
| TFT (transmission fluid temperature) | Atmospheric temperature - approx. 130°C (266°F) |
COMPONENT OPERATING RANGE CHART
Scheme 400
| Related DTCs | P0711: ATF temperature sensor/Rationality check |
|---|---|
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 3 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Time after engine start | 16 min. and 40 sec. or more |
| ECT (Engine coolant temperature) | 15°C (5°F) or more |
| TFT (transmission fluid temperature) sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| IAT (Intake air temperature) sensor circuit | Not circuit malfunction |
| Time after engine start | 18 min. and 20 sec. |
| Driving distance after engine start | 9 km (5.6 mile) or more |
| IAT (12 sec. after starting engine) | 10°C (14°F) or more |
| ECT (12 sec. after starting engine) | 10°C (14°F) or more |
TYPICAL ENABLING CONDITIONS CHART
| TFT (transmission fluid temperature) | Less than 10°C (50°F) |
TYPICAL MALFUNCTION THRESHOLDS CHART
| TFT (transmission fluid temperature) | Atmospheric temperature to approx. 130°C (266°F) |
COMPONENT OPERATING RANGE CHART
Scheme 401
| Related DTCs | P0717: Speed sensor (NT)/Verify pulse input |
|---|---|
| Required sensors/Components | Speed sensor (NT), Speed sensor (NC). |
| Frequency of operation | Continuous |
| Duration | 5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift change | Shift change is completed and before starting next shift change operation |
| ECM selected gear | 2nd, 3rd, 4th or 5th |
| Output shaft RPM | 1,000 RPM or more |
| NSW switch | OFF |
| R switch | OFF |
| L switch | OFF |
| Engine | Running |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Sensor signal RPM | Less than 300 RPM |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Speed sensor (NT) | Turbine speed is equal to engine speed when lock up ON |
COMPONENT OPERATING RANGE CHART
Scheme 402
Scheme 403
Scheme 404
- INSPECT SPEED SENSOR INSTALLATION Check the speed sensor installation. OK: The installation bolt is tightened properly and there is no clearance between the sensor and transaxle case. NG: REPLACE SPEED SENSOR (NT) OK: GO TO NEXT STEP
- INSPECT SPEED SENSOR (NT) Disconnect the speed sensor connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Condition Specified Condition 1-2 560 to 680 ohms NG: REPLACE SPEED SENSOR (NT) OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (SPEED SENSOR - ECM)
- Connect the speed sensor connector.
- Disconnect the ECM connector.
- Measure the resistance according to the value (s) in the table below. Standard: Tester Connection Specified Condition 20°C (68°F) (Standard:) Tester Connection Specified Condition 20°C (68°F) E8 -27 (NT+) - E8 - 35 (NT-) 560 to 680 ohms
- Measure the resistance according to the value (s) in the table below.
Standard (Check for short)
Scheme 405
Scheme 406
- NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) )
- OK: REPLACE ECM (See «ECM (3MZ-FE)»(ref-226406-S19281283152006032800000) )
| Related | DTCs P0724: Stop light switch/Rationality |
|---|---|
| Required sensors/Components | Stop light switch, Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | GO and STOP 5 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC Is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| GO (Vehicle speed is 30 km/h (18.63 mph) or more) | Once |
| STOP (Vehicle speed is less than 3 km/h (1.86 mph)) | Once |
TYPICAL ENABLING CONDITIONS CHART
| Brake switch Remain ON during | GO and STOP 5 times |
TYPICAL MALFUNCTION THRESHOLDS CHART
Scheme 407
| Related | DTCs P0741: Shift solenoid valve DSL/OFF malfunction P0741: Shift solenoid valve DSL/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve DSL, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE), Throttle position sensor (VPA1), Mass air flow sensor (MAF), Transmission temperature sensor (THO1), Engine coolant temperature sensor (ECT) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction; 3.5 sec.; ON malfunction; 1.8 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
ALL
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 10°C (50°F) or more |
| TFT (Transmission fluid temperature) | 20°C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve SL3 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve DSL circuit | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction
| ECM lock up command | ON |
|---|---|
| Duration time from lock up on command | 3 sec. or more |
| ECM selected gear | 3rd, 4th or 5th |
| Vehicle speed | 25 km/h (15.5 mph) or more |
MALFUNCTION CHART
ON malfunction
| ECM lock up command | OFF |
|---|---|
| ECM selected gear | 3rd, 4th or 5th |
| Throttle valve opening angle | 10% or more |
| Vehicle speed | 25 to 60 km/h (15.5 to 37.3 mph) |
MALFUNCTION CHART
Either of the following conditions is met: OFF malfunction or ON malfunction
OFF malfunction
| Engine speed - Input (turbine) speed | 100 RPM or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction
| Difference between engine speed and input (turbine) speed | Less than 35 RPM |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Related DTCs | P0746: Shift solenoid valve SL1/OFF malfunction Shift solenoid valve SL1/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve SL1, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | 0.8 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
ALL
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 10°C (50°F) or more |
| TFT (Transmission fluid temperature) | 20°C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve SL3 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve DSL circuit | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | Less than 40 km/h (24.9 mph) |
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction
| ECM selected gear | 2nd |
|---|---|
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TESTER CONNECTION SPECIFIED CONDITION CHART
Either of the following conditions Is met: OFF malfunction or ON malfunction
OFF malfunction
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
| Input (turbine) speed/Intermediate shaft speed | 1.49 to 1.63 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction
| Input (turbine) speed/Intermediate shaft speed | 2.72 to 2.86 |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Related | DTCs P0748: Shift solenoid valve SL1/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SL1 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 10 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Output signal duty | 100% |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Output signal duty | Less than 100% |
COMPONENT OPERATING RANGE CHART
Scheme 408
Scheme 409
Scheme 410
Scheme 411
Scheme 412
- INSPECT TRANSMISSION WIRE (SM) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 6 (SL1+) -13 (SL1-) 5.0 to 5.6 ohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): NG Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value (s) in the table below. Standard: Tester Connection Specified Condition 2°C (68°F) - Standard: Tester Connection Specified Condition 20°C (68°F) E8-19 (SL1+) - E8-18 (SL1-) 5.0 to 5.6 ohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: REPLACE ECM (See «ECM (3MZ-FE)»(ref-226406-S19281283152006032800000) )
- INSPECT SHIFT SOLENOID VALVE (SL1)
- Remove the shift solenoid valve SL1.
- Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 1 - 2 5.0 to 5.6 ohms
- Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve.
OK
The solenoid makes an operating noise.
Scheme 413
- NG: REPLACE SHIFT SOLENOID VALVE (SL1)
- OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U151E/U151F)»(ref-226424-S02755560862006032900000) )
| Related DTCs | P0766: Shift solenoid valve S4/ON malfunction Shift solenoid valve S4/OFF malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve S4, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction (A) and ON malfunction (B); 1 sec.; OFF malfunction (B); 1.2 sec.; ON malfunction (A); 0.8 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
All
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 10°C (50°F) or more |
| TFT (Transmission fluid temperature) | 20° C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve SL3 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve DSL circuit | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (A)
| ECM selected gear | 5th |
|---|---|
| Throttle valve opening angle | 5% or more |
| Vehicle speed | 10 km/h (6.2 mph) or more |
TESTER CONNECTION SPECIFIED CONDITION CHART
OFF malfunction (B)
| ECM lock up command | ON |
|---|---|
| ECM selected gear | 3rd, 4th or 5th |
| Throttle valve opening angle | 10% or more |
| Vehicle speed | 25 to 100 km/h (15.5 to 62.1 mph) |
TESTER CONNECTION SPECIFIED CONDITION CHART
ON malfunction (A)
| ECM selected gear | 4th or 5th |
|---|---|
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TESTER CONNECTION SPECIFIED CONDITION CHART
ON malfunction (B)
| ECM selected gear | 4th |
|---|---|
| Throttle valve opening angle | 5% or more |
| Vehicle speed | 10 km/h (6.2 mph) or more |
TESTER CONNECTION SPECIFIED CONDITION CHART
Either of the following conditions is met
OFF malfunction (A) and (B), or ON malfunction (A) and (B)
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
OFF malfunction (A)
| Intermediate shaft speed/Output speed | 1.44 to 1.58 |
TYPICAL MALFUNCTION THRESHOLDS CHART
OFF malfunction (B)
| Difference between engine speed and input (turbine) speed | Less than 35 RPM |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (A)
| Input (turbine) speed/Intermediate shaft speed | 0.64 to 0.74 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (B)
| Intermediate shaft speed/Output speed | 1.02 to 1.16 |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Related | DTCs P0771: Shift solenoid valve SR/Rationality check |
|---|---|
| Required sensors/Components | Shift solenoid valve SR, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction (A); 1 sec.; OFF malfunction (B); 3.5 sec.; ON malfunction (A) Continuous ON malfunction (B) and (C); 0.8 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
All
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 10°C (50°F) or more |
| TFT (Transmission fluid temperature) | 20°C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve SL3 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve DSL circuit | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (A)
| ECM selected gear | 5th |
|---|---|
| Throttle valve opening angle | 5% or more |
| Vehicle speed | 10 km/h (6.2 mph) or more |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (B)
| ECM lock up command | ON |
|---|---|
| ECM selected gear | 3rd, 4th or 5th |
| Vehicle speed | 25 km/h (15.5 mph) |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction (A)
| ECM lock up command | OFF |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction (B)
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | Less than 40 km/h (24.9 mph) |
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction (C)
| ECM selected gear | 3rd |
|---|---|
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction (D)
| ECM selected gear | 4th or 5th |
|---|---|
| Duration time from shift command of ECM | 15 sec, or more |
TYPICAL ENABLING CONDITIONS CHART
Either of the following conditions is met
OFF malfunction (A) and (B), or ON malfunction (A), (B), (C) and (D)
OFF malfunction (A)
| Intermediate shaft speed/Output speed | 1.44 to 1.58 |
TYPICAL MALFUNCTION THRESHOLDS CHART
OFF malfunction (B)
| Engine speed - Input (turbine) speed When condition "OFF malfunction (A)" of shift solenoid "D" Is detected; When condition "OFF malfunction (A)" of shift solenoid "D" Is not detected | 75 RPM or more; 100 RPM or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (A)
| Difference between engine speed and input (turbine) speed | 150 RPM or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (B)
| Input (turbine) speed/Intermediate shaft speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (C)
| Input (turbine) speed/Intermediate shaft speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (D)
| Input (turbine) speed/Intermediate shaft speed | 0.64 to 0.74 |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Related DTCs | P0776: Shift solenoid valve SL2/OFF malfunction Shift solenoid valve SL2/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve SL2, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction (A); 1.8 sec.; OFF malfunction (B) and (C); 0.8 sec.; ON malfunction (A) and (B); 0.8 sec. ON malfunction (C) 0.4 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
All
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 10°C (50°F) or more |
| TFT (Transmission fluid temperature) | 20°C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve SL3 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve DSL circuit | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (A)
| ECM lock up command | OFF |
|---|---|
| Vehicle speed | Less than 60 km/h (37.3 mph) |
| Throttle valve opening angle | 10% or more |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (B)
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | Less than 40 km/h (24.9 mph) |
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (C)
| ECM selected gear | 3rd |
|---|---|
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (D)
| ECM select gear | 4th or 5th |
|---|---|
| Duration time from shift command of EC | 15 sec. or more |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction (A)
| ECM select gear | 1st |
|---|---|
| Vehicle speed | Less than 40 km/h (24.9 mph) |
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction (B)
| ECM selected gear | 3rd |
|---|---|
| Throttle valve opening angle | 7.0% or more at output speed 1,400 RPM (Varies with engine speed) |
| Malfunction of pressure control solenoid "B" (SL2) and "C" (SL3) | Not detected |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction (C)
| Throttle valve opening angle | 7.0% or more at output speed 1,050 RPM (Varies with engine speed) |
|---|---|
| Malfunction of pressure control solenoid "B" (SL2) | Not detected |
TYPICAL ENABLING CONDITIONS CHART
Either of the following conditions is met
OFF malfunction (A), (B), (C) and (D), or ON malfunction (A), (B) and (C)
OFF malfunction (A)
| Difference between engine speed and input (turbine) speed | Less than 35 RPM |
TYPICAL MALFUNCTION THRESHOLDS CHART
OFF malfunction (B)
| Input (turbine) speed/Intermediate shaft speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS CHART
OFF malfunction (C)
| Input (turbine) speed/Intermediate shaft speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS CHART
OFF malfunction (D)
| Input (turbine) speed/Intermediate shaft speed | 0.64 to 0.74 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (A)
| Input (turbine) speed/Intermediate shaft speed | 2.72 to 2.86 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (B)
| Input (turbine) speed - Intermediate shaft speed | 700 RPM or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (C)
| Input (turbine) speed - Intermediate shaft speed | Less than -500 RPM or 700 RPM or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Related | DTCs P0778: Shift solenoid valve SL2/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SL2 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Solenoid current cut status | Not cut |
| Battery voltage | 11 V or more |
| CPU commanded duty ratio to SL2 | 19% or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Solenoid status from IC | Fail (Open or short) |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Output signal duty | Less than 100% |
COMPONENT OPERATING RANGE CHART
Scheme 414
Scheme 415
Scheme 416
Scheme 417
Scheme 418
- INSPECT TRANSMISSION WIRE (SL2) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) 5 (SL2+) - 12 (SL2-) 5.0 to 5.6 ohms Measure the resistance according to the value (s) in the table below. OK: Standard (Check for short): NG Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connects Specified Condition 20°C (68°F) E8 - 15 (SL2+) - E8 - 14 (SL2-) 5.0 to 5.6 ohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: REPLACE ECM (See «ECM (3MZ-FE)»(ref-226406-S19281283152006032800000) )
- INSPECT SHIFT SOLENOID VALVE (SL2)
- Remove the shift solenoid valve SL2.
- Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connects Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms
- Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve.
OK
The solenoid makes an operating noise.
Scheme 419
- NG: REPLACE SHIFT SOLENOID VALVE (SL2)
- OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U151E/U151F)»(ref-226424-S02755560862006032900000) )
| Related DTCs | P0793: Speed sensor (NC)/Verify pulse input |
|---|---|
| Required sensors/Components | Speed sensor (NC), Speed sensor (NT), Park/neutral position switch |
| Frequency of operation | Continuous |
| Duration | 5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Engine | Running |
| NSW switch | OFF |
| Output shaft RPM | 1,000 RPM or more |
TYPICAL ENABLING CONDITIONS CHART
| Sensor signal RPM | Less than 300 RPM |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Counter gear speed sensor (NC) | [HINT] 3rd when shift lever position is D position (After warming up the engine); Intermediate shaft speed (NC) becomes close to the engine speed. |
COMPONENT OPERATING RANGE CHART
Scheme 420
| Related | DTCs P0796: Shift solenoid valve SL3/OFF malfunction Shift solenoid valve SL3/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve SL3, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction (A); 0.8 sec.; OFF malfunction (B); 1 sec.; ON malfunction (A) and (B); 0.8 sec. ON malfunction (C) 0.4 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
All
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 10°C (50°F) or more |
| TFT (Transmission fluid temperature) | 20°C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve SL3 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Shift solenoid valve SR circuit | Not circuit malfunction |
| Shift solenoid valve DSL circuit | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (A)
| ECM selected gear | 4th or 5th |
|---|---|
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction (B)
| ECM selected gear | 4th |
|---|---|
| Throttle valve opening angle | 5% or more |
| Vehicle speed | 10 km/h (6.2 mph) or more |
TYPICAL ENABLING CONDITIONS CHART
ON malfunction (A)
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | Less than 40 km/h (24.9 mph) |
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
TESTER CONNECTION SPECIFIED CONDITION CHART
ON malfunction (B)
| ECM selected gear | 3rd |
|---|---|
| Throttle valve opening angle | 7.0% or more at output speed 1,400 RPM (Varies with engine speed) |
| Malfunction of pressure control solenoid "B" (SL2) and "C" (SL3) | Not detected |
TESTER CONNECTION SPECIFIED CONDITION CHART
ON malfunction (C)
| Throttle valve opening angle | 7.0% or more at output speed 1,050 RPM (Varies with engine speed) |
|---|---|
| Malfunction of pressure control solenoid "B" (SL2) | Not detected |
TESTER CONNECTION SPECIFIED CONDITION CHART
Either of the following conditions is met
OFF malfunction (A) and (B), or ON malfunctions (A), (B) and (C)
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
OFF malfunction (A)
| Input (turbine) speed/Intermediate shaft speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS CHART
OFF malfunction (B)
| Intermediate shaft speed/Output speed | 1.02 to 1.16 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (A)
| Input (turbine) speed/Intermediate shaft speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (B)
| Input (turbine) speed -Intermediate shaft speed | 700 RPM or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (C)
| Input (turbine) speed -Intermediate shaft speed | Less than -500 RPM or 700 RPM or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Related DTCs | P0798: Shift solenoid valve SL3/Range check |
|---|---|
| Required sowers/Components | Shift solenoid valve SL3 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 10 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Output signal duty | 100% |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Output signal duty | Less than 100% |
COMPONENT OPERATING RANGE CHART
Scheme 421
Scheme 422
Scheme 423
Scheme 424
Scheme 425
Scheme 426
- INSPECT TRANSMISSION WIRE (SL3) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 4 (SL3+) - 11 (SL3-) 5.0 to 5.6 ohms Measure the resistance according to the value (s) in the table below. NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSlON WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition acre (68°F) E8 - 17 (SL3+) - E8 - 16 (SL3-) 5.0 to 5.6 fl Measure the resistance according to the value (s) in the table below. NG: REPAIR OR REPLACE HARNESS OR/CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: REPLACE ECM (See «ECM (3MZ-FE)»(ref-226406-S19281283152006032800000) )
- INSPECT SHIFT SOLENOID VALVE (SL3) Remove the shift solenoid valve SL3. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) 1-2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (SL3) OK: GO TO NEXT STEP REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U151E/U151F)»(ref-226424-S02755560862006032900000) )
| Related DTCs | P0982: Shift solenoid valve S4/Range check (Low resistance) P0983: Shift solenoid valve S4/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve S4 |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
P0982: Range check (Low resistance)
| The monitor will run whenever this DTC is not present | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S4 | ON |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
P0983: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S4 | OFF |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
P0982: Range check (Low resistance)
| Shift solenoid valve S4 resistance | 8 ohms or less |
TYPICAL MALFUNCTION THRESHOLDS CHART
P0983: Range check (High resistance)
| Shift solenoid valve S4 resistance | 100 kohms or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Shift solenoid valve S4 | Resistance: 11 to 15 ohms at 20°C (66°F) |
COMPONENT OPERATING RANGE
Scheme 427
Scheme 428
Scheme 429
Scheme 430
- INSPECT TRANSMISSION WIRE (S4) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 3 - Body ground 11 to 15 ohms NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) E8 - 10 (S4) - Body ground 11 to 15 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: GO TO NEXT STEP REPLACE ECM (See «ECM (3MZ-FE)»(ref-226406-S19281283152006032800000) )
- INSPECT SHIFT SOLENOID VALVE (S4) Remove the shift solenoid valve S4. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 20 X (68°F) Solenoid Connector (S4) - Solenoid Body (S4) 11 TO 15 ohms Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (S4) OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U151E/U151F)»(ref-226424-S02755560862006032900000) )
| Related DTCs | P0985: Shift solenoid valve SR/Range check (Low resistance) P0986: Shift solenoid valve SR/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve SR |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
P0985: Range check (Low resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve SR | ON |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
P0986: Range check (High resistance)
| The monitor will run whenever this DTC is not present | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve SR | OFF |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
P0985: Range check (Low resistance)
| Shift solenoid valve SR resistance | 8 ohms or less |
TYPICAL MALFUNCTION THRESHOLDS CHART
P0986: Range check (High resistance)
| Shift solenoid valve SR resistance | 100 kohms or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Shift solenoid valve SR | Resistance: 11 to 15 ohms at 20°C (66°F) |
COMPONENT OPERATING RANGE CHART
Scheme 431
Scheme 432
Scheme 433
Scheme 434
- INSPECT TRANSMISSION WIRE (SR) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Specified Condition Tester Connection 2°C (68°F) 9 - Body ground 11 to 15 ohms NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) E8 - 9 (SR) - Body ground 11 to 15 ohms NG: REPAIR OR REPLACE HARNESS OR/CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: REPLACE ECM (See «ECM (3MZ-FE)»(ref-226406-S19281283152006032800000) )
- INSPECT SHIFT SOLENOID VALVE (SR) Remove the shift solenoid valve SR. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition °C (68°F) Solenoid Connector (SR) - Solenoid Body (SR) 11 to 15 ohms Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (SR) OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U151E/U151F)»(ref-226424-S02755560862006032900000) )
| Related DTCs | P2716: Shift solenoid valve SLT/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SLT |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Solenoid current cut status | Not cut |
| Battery voltage | 11 V or more |
| CPU commanded duty ratio to SLT | 19% or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Solenoid status from IC | Fail (Open or short) |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Shift solenoid valve SLT | Resistance: 5.0 to 5.6 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 435
Scheme 436
Scheme 437
Scheme 438
Scheme 439
Scheme 440
- INSPECT TRANSMISSION WIRE (SLT) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection 20°C (68°F) Specified Condition 2 (SLT+) - 8 (SLT-_) 5.0 to 5.6 ohms Measure the resistance according to the value (s) in the table below. NG: Go to step 3 OK
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connector. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection 20° C (68°F) Specified Condition E8 - 13 (SLT+) - E8 - 12 (SLT-) 5.0 to 5.6 ohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: GO TO NEXT STEP REPLACE ECM (See «ECM (3MZ-FE)»(ref-226406-S19281283152006032800000) )
- INSPECT SHIFT SOLENOID VALVE (SLT) Remove the shift solenoid valve (SLT). Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection 20° C (68°F) Specified Condition 1-2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (SLT) OK: GO TO NEXT STEP REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U151E/U151F)»(ref-226424-S02755560862006032900000) )
| Readers DTCs | P2769: Shift solenoid valve DSL/Range check (Low resistance) P2770: Shift solenoid valve DSL/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve DSL |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
P2769: Range check (Low resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve DSL | ON |
| Solenoid current cut status | Not cut |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
P2770: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve DSL | ON |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
P2769: Range check (Low resistance)
| Shift solenoid valve DSL resistance | 8 ohms or less |
TYPICAL MALFUNCTION THRESHOLDS CHART
P2770: Range check (High resistance)
| Shift solenoid valve DSL resistance | 100 kohms or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Shift solenoid valve DSL | Resistance: 11 to 13 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 441
Scheme 442
Scheme 443
Scheme 444
- INSPECT TRANSMISSION WIRE (DSL) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection 20°C (68°F) Specified Condition 10 - Body ground 11 to 13 ohms NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector. Disconnect the ECM connector. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection 2O°C (68°F) Specified Condition E8 - 11 (DSL) Body ground 11 to 13 ft NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: GO TO NEXT STEP REPLACE ECM (See «ECM (3MZ-FE)»(ref-226406-S19281283152006032800000) )
- INSPECT SHIFT SOLENOID VALVE (DSL) Remove the shift solenoid valve DSL. Measure the resistance according to the value (s) in the table below. Standard: TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (DSL) Solenoid Body (DSL) 11 to 13 ohms Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body. OK: The solenoid valve makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (DSL) OK: GO TO NEXT STEP REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U151E/U151F)»(ref-226424-S02755560862006032900000) )
