PRECAUTION
Note. Perform the RESET MEMORY (AT initialization) when replacing the automatic transaxle assy, engine assy or ECM (See INITIALIZATION ).
HINT
Initialization can not be completed by only disconnecting the battery terminal.
DEFINITION OF TERMS
| Term | Definition |
|---|---|
| Monitor description | Description of what the ECM monitors and how it detects malfunctions (monitoring purpose and its details). |
| Related DTCs | A group of diagnostic trouble codes that are output by the ECM based on the same malfunction detection logic. |
| Typical enabling condition | Preconditions that allow the ECM to detect malfunctions. With all preconditions satisfied, the ECM sets the DTC when the monitored value(s) exceeds the malfunction threshold(s). |
| Sequence of operation | The priority order that is applied to monitoring, If multiple sensors and components are used to detect the malfunction. While another sensor is being monitored, the next sensor or component will not be monitored until the previous monitoring has concluded. |
| Required sensor/components | The sensors and components that are used by the ECM to detect malfunctions. |
| Frequency of operation | The number of times that the ECM checks for malfunctions per driving cycle. "Once per driving cycle" means that the ECM detects malfunction only one time during a single driving cycle. "Continuous" means that the ECM detects malfunction every time when enabling condition is met. |
| Duration | The minimum time that the ECM must sense a continuous deviation in the monitored value(s) before setting a DTC. This timing begins after the "typical enabling conditions" are met. |
| Malfunction thresholds | Beyond this value, the ECM will conclude that there is a malfunction and set a DTC. |
| MIL operation | MIL illumination timing after a defect is detected. "Immediately" means that the ECM Illuminates MIL the Instant the ECM determines that there is a malfunction. "2 driving cycle" means that the ECM Illuminates MIL if the same malfunction is detected again in the 2nd driving cycle. |
| Component operating range | Normal operation range of sensors and solenoids under normal driving conditions. Use these ranges as a reference. They cannot be used to judge if a sensor or solenoid is defective or not. |
DEFINITION OF TERMS
PART AND SYSTEM NAME LIST
This reference list indicates the part names used in this manual along with their definitions.
| Part and system name | Definition |
|---|---|
| Toyota HCAC system, Hydrocarbon adsorptive Catalyst (HCAC) system, HC adsorptive three-way catalyst | HC adsorptive three-way catalytic converter |
| Variable Valve Timing sensor, VVT sensor | Camshaft position sensor |
| Variable valve timing system, VVT system | Camshaft timing control system |
| Camshaft timing oil control valve, Oil control valve OCV VVT, VSV | Camshaft timing oil control valve |
| Variable timing and lift, VVTL | Camshaft timing and lift control |
| Crankshaft position sensor "A" | Crankshaft position sensor |
| Engine speed sensor | Crankshaft position sensor |
| THA | Intake air temperature |
| Knock control module | Engine knock control module |
| Knock sensor | Engine knock sensor |
| Mass or volume air flow circuit | Mass air flow sensor circuit |
| Vacuum sensor | Manifold air pressure sensor |
| Internal control module, Control module, Engine control ECU, PCM | Power train control module |
| FC idle | Deceleration fuel cut |
| Idle air control valve | Idle speed control |
| VSV for CCV, Canister close valve VSV for canister control | Evaporative emissions canister vent valve |
| VSV for EVAP, Vacuum switching valve assembly No. 1, EVAP VAV, Purge VSV | Evaporative emissions canister purge valve |
| VSV for pressure switching valve, Bypass VSV | Evaporative emission pressure switching valve |
| Vapor pressure sensor, EVAP pressure sensor, Evaporative emission control system pressure sensor | Fuel tank pressure sensor |
| Charcoal canister | Evaporative emissions canister |
| ORVR system | On-board refueling vapor recovery system |
| Intake manifold runner control | Intake manifold tuning system |
| Intake manifold runner valve, IMRV, IACV (runner valve) | Intake manifold tuning valve |
| Intake control VSV | Intake manifold tuning solenoid valve |
| AFS | Air fuel ratio sensor |
| O2 sensor | Heater oxygen sensor |
| Oxygen sensor pumping current circuit | Oxygen sensor output signal |
| Oxygen sensor reference ground circuit | Oxygen sensor signal ground |
| Accel position sensor | Accelerator pedal position sensor |
| Throttle actuator control motor, Actuator control motor, Electronic throttle motor, Throttle control motor | Electronic throttle actuator |
| Electronic throttle control system, Throttle actuator control system | Electronic throttle control system |
| Throttle/pedal position sensor, Throttle/pedal position switch, Throttle position sensor/switch | Throttle position sensor |
| Turbo press sensor | Turbocharger pressure sensor |
| Turbo VSV | Turbocharger pressure control solenoid valve |
| P/S pressure switch | Power-steering pressure switch |
| VSV for ACM | Active control engine mount |
| Speed sensor, Vehicle speed sensor "A", Speed sensor for skid control ECU | Vehicle speed sensor |
| ATF temperature sensor, Trans, fluid temp, sensor, ATF temperature sensor "A" | Transmission fluid temperature sensor |
| Electronic controlled automatic transmission, ECT | Electronically controlled automatic |
| Intermediate shaft speed sensor "A" | Counter gear speed sensor |
PART AND SYSTEM NAME LIST
| Part and system name | Definition |
|---|---|
| Output speed sensor | Output shaft speed sensor |
| Input speed sensor, Input turbine speed sensor "A", Speed sensor (NT), Turbine speed sensor | Input turbine speed sensor. |
| PNP switch, NSW | Park/neutral position switch |
| Pressure control solenoid | Transmission pressure control solenoid |
| Shift solenoid | Transmission shift solenoid valve |
| Transmission control switch, Shift lock control unit | Shift lock control module |
| Engine immobilizer system, Immobilizer system | Vehicle anti-theft system |
PART AND SYSTEM NAME LIST
Scheme 248
SYSTEM DIAGRAM
The configuration of the electronic control system in the U241E/U140F automatic transaxles is as shown in the following chart.
Scheme 249
INITIALIZATION
- RESET MEMORY
| CAUTION | Perform the RESET MEMORY (AT initialization) when replacing the automatic transaxle assy, engine assy or ECM. |
Note. Hand-held tester only
HINT
The ECM memorizes the condition that the ECT controls the automatic transaxle assy and engine assy according to those characteristics. Therefore, when the automatic transaxle assy, engine assy, or ECM has been replaced, it is necessary to reset the memory so that the ECM can memorize the new information. Reset procedure is as follows.
- Turn the ignition switch off.
- Connect the hand-held tester to the DLC3.
- Turn the ignition switch to the ON position and push the hand-held tester main switch on.
- Select the item "DIAGNOSIS/ENHANCED OBD II".
- Perform the reset memory procedure from the ENGINE menu.
| CAUTION | After performing the RESET MEMORY, be sure to perform the ROAD TEST (See ROAD TEST ) described earlier. |
HINT
The ECM is learned by performing the ROAD TEST.
Scheme 250
LIST OF DISABLE A MONITOR
HINT
This table indicates ECM monitoring status for the items in the upper columns if the DTCs in each line on the left are being set.
As for the "X" mark, when the DTC on the left is stored, detection of the DTC in the upper column is not performed.
Scheme 251
Scheme 252
Scheme 253
Scheme 254
Scheme 255
Scheme 256
MONITOR DRIVE PATTERN
- MONITOR DRIVE PATTERN FOR ECT TEST
- Perform this drive pattern as one method to simulate the detection conditions of the ECT malfunctions. (The DTCs may not be detected due the actual driving conditions. And some codes may not be detected through this drive pattern).
HINT
Preparation for driving
- Warm up the engine sufficiently. (Engine coolant temperature is 60°C (140°F) or higher)
- Drive the vehicle when the atmospheric temperature is -10°C (14°F) or higher. (Malfunction is not detected when the atmospheric temperature is -10°C (14°F) or less)
Driving note
- Drive the vehicle through all gears. Stop -> 1st -> 2nd -> 3rd -> O/D -> O/D (lockup ON).
- Repeat the above driving pattern three times or more.
Note. The monitor status can be checked using the OBD II scan tool. When using the hand-held tester, monitor status can be found In the "ENHANCED OBD II/DATA LIST" or under "CARB OBD II". In the event that the drive pattern must be interrupted (possibly due to traffic conditions or other factors) the drive pattern can be resumed and, in most cases, the monitor can be completed.
| CAUTION | Perform this drive pattern on a level road as much as possible and strictly observe the posted speed limits and traffic laws while driving. |
Scheme 257
HINT
*1: Drive at such a speed in the uppermost gear, to engage lockup. The vehicle can be driven at a speed lower than that in the above diagram under the lockup condition.
Note. It is necessary to drive the vehicle for approximately 30 minutes to detect DTC P0711 (ATF temperature sensor malfunction).
FAIL-SAFE CHART
- FAIL-SAFE
This function minimizes the loss of the ECT functions when any malfunction occurs in each sensor or solenoid.
- ATF (Automatic Transmission Fluid) temperature sensor: When the ATF temperature sensor has a malfunction, O/D upshift is prohibited.
- Counter gear speed sensor NC (Speed sensor NC): When the counter gear speed sensor has a malfunction, O/D upshift is prohibited.
- Shift solenoid valve DSL: When the solenoid valve DSL has a malfunction, the current to the solenoid valve is stopped. This stops lockup control, then fuel economy decreases.
- Shift solenoid valve SL1, SL2 and S4
Fail safe function
If either of the shift solenoid valve circuits develops an open or short, the ECM turns the other shift solenoid "ON" and "OFF" in order to shift into the gear positions shown in the table below.
Manual shifting as shown in the following table must be done (In case of a short circuit, the ECM stops sending the current to the short circuit solenoid).
Even if starting the engine in the fail-safe mode, the gear position remain in the same position.
Scheme 258
Scheme 259
Scheme 260
- DATA LIST HINT: According to the DATA LIST displayed by the OBD II scan tool or hand-held tester, you can read the value of the switch, sensor, actuator and so on without parts removal. Reading the DATA LIST as the first step of troubleshooting is one method to shorten labor time. Warm up the engine. Turn the ignition switch off. Connect the OBD II scan tool or hand-held tester to the DLC3. Turn the ignition switch to the ON position. Push the "ON" button of the OBD II scan tool or the hand-held tester. When you use hand-held tester: Select the item "DIAGNOSIS/ENHANCED OBD II/DATA LIST". According to the display on tester, read the "DATA LIST".
- ACTIVE TEST
HINT
Performing the ACTIVE TEST using the hand-held tester allows the relay, VSV, actuator and so on to operate without parts removal. Performing the ACTIVE TEST as the first step of troubleshooting is one method to shorten labor time.
It is possible to display the DATA LIST during the ACTIVE TEST.
- Warm up the engine.
- Turn the ignition switch off.
- Connect the hand-held tester to the DLC3.
- Turn the ignition switch to the ON position.
- Push the "ON" button of the hand-held tester.
- Select the item "DIAGNOSIS/ENHANCED OBD II/ACTIVE TEST".
- According to the display on tester, perform the "ACTIVE TEST".
Scheme 261
HINT
The pressure values in ACTIVE TEST and HYDRAULIC TEST are different from each other.
MONITOR STRATEGY
| Related DTCs | P0705: Park/neutral position switch/Verify switch input |
|---|---|
| Required sensors/Components | Park/neutral position switch |
| Frequency of operation | Continuous |
| Duration | 2 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
TYPICAL ENABLING CONDITIONS
Condition (A) and (B)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Ignition switch | ON |
| Battery voltage | 10.5 V or more |
TYPICAL ENABLING CONDITIONS CHART
TYPICAL MALFUNCTION THRESHOLDS
Either of the following conditions is met: Condition (A) or (B)
Condition (A)
| Number of the following signal input at the same time | 2 or more |
|---|---|
| NSW switch | ON |
| R switch | ON |
| D switch | ON |
| 2 switch | ON |
| L switch | ON |
TYPICAL MALFUNCTION THRESHOLDS CHART
Condition (B)
| Number of the following signal input at the same time | 2 or more |
|---|---|
| P switch | ON |
| R switch | ON |
| N switch | ON |
| D switch | ON |
| 2 switch | ON |
| L switch | ON |
TYPICAL MALFUNCTION THRESHOLDS CHART
COMPONENT OPERATING RANGE
| Park/neutral position switch | The park/neutral position switch sends only one signal to the ECM. |
COMPONENT OPERATING RANGE CHART
Scheme 262
| Related DTCs | P0710: ATF temperature sensor/Range check (Fluttering) P0712: ATF temperature sensor/Range check (Low resistance) P0713: ATF temperature sensor/Range check (High resistance) |
|---|---|
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 0.5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
P0710: Range check (Fluttering)
P0712: Range check (Low resistance)
| The monitor will run whenever these DTCs are not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| The typical enabling condition is not available. |
TYPICAL ENABLING CONDITIONS CHART
P0713: Range check (Low resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Time after engine start | 15min. or more |
RANGE CHECK (LOW RESISTANCE) CHART
P0710: Range check (Low resistance)
| TFT (transmission fluid temperature) sensor | Less than 79 ohm or More than 15 kohm |
TFT (TRANSMISSION FLUID TEMPERATURE) SENSOR SPECIFICATION
P0712: Range check (Low resistance)
| TFT (transmission fluid temperature) sensor | Less than 79 ohm |
RANGE CHECK (LOW RESISTANCE) CHART
P0713: Range check (High resistance)
| TFT (transmission fluid temperature) sensor | More than 156 kohm |
RANGE CHECK (HIGH RESISTANCE) CHART
| TFT (transmission fluid temperature) | Atmospheric temperature-approx. 130°C (266°F) |
COMPONENT OPERATING RANGE CHART
Scheme 263
| Related DTCs | P0711: ATF temperature sensor/Rationality check |
|---|---|
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 3 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Time after engine start | 16 min.and 40 sec. or more |
| ECT (Engine coolant temperature) | 15°C (5°F) or more |
| TFT (transmission fluid temperature) sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| IAT (Intake air temperature) sensor circuit | Not circuit malfunction |
| Time after engine start | 18 min. and 20 sec. |
| Driving distance after engine start | 9 km/h (5.6 mph) |
| IAT (12 sec. after engine start) | 10°C (14°F) or more |
| ECT (12 sec, after engine start) | 10°C (14°F) or more |
TYPICAL ENABLING CONDITIONS CHART
| TFT (transmission fluid temperature) | Less than 10°C (50°F) |
TYPICAL MALFUNCTION THRESHOLDS CHART
| TFT (transmission fluid temperature) | Atmospheric temperature - approx. 130°C (266°F) |
COMPONENT OPERATING RANGE CHART
Scheme 264
| Related DTCs | P0717: Speed sensor (NT)/Verify pulse input |
|---|---|
| Required sensors/Components | Speed sensor (NT), Speed sensor (NC) |
| Frequency of operation | Continuous |
| Duration | 5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift change | Shift change is completed and before starting next shift change operation |
| ECM selected gear | 2nd, 3rd or 4th |
| Output shaft RPM | 1,000 RPM or more |
| NSW switch | OFF |
| R switch | OFF |
| L switch | OFF |
| Engine | Running |
TYPICAL ENABLING CONDITIONS CHART
| Sensor signal RPM | Less than 300 RPM |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Speed sensor (NT) | Turbine speed is equal to engine speed when lockup ON |
COMPONENT OPERATING RANGE CHART
Scheme 265
Scheme 266
Scheme 267
Scheme 268
- INSPECT SPEED SENSOR INSTALLATION Check the speed sensor installation. OK: The installation bolt is tightened properly and there is no clearance between the sensor and transaxle case. NG: REPLACE SPEED SENSOR (NT) OK: Go to next step.
- INSPECT SPEED SENSOR (NT) Disconnect the speed sensor connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard: TOYOTA made: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) 1 - 2 560 to 620 ohm Standard: AISIN made: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 1 - 2 560 to 680 ohm NG: REPLACE SPEED SENSOR (NT) OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (SPEED SENSOR - ECM) Connect the speed sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard: TOYOTA made: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) E8 - 27 (NT+) - E8 - 35 (NT-) 500 to 620 ohm Standard: AISIN made: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) E8 - 27 (NT+) - E8 - 35 (NT-) 560 to 680 ohm Measure the resistance according to the value(s) in the table below. Standard (Check for short): TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition E8 - 27 (NT+) - Body ground 10 kohm or higher E8 - 35 (NT-) - Body ground up arrow NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: REPLACE ECM (See «ECM (2AZ-FE)»(ref-226406-S08140964062006032800000) )
| Related DTCs | P0724: Stop light switch/Range check/Rationality |
|---|---|
| Required sensors/Components | Stop light switch, Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | GO and STOP 5 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC Is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| GO (Vehicle speed is 30 km/h (18.63 mph) or more) | Once |
| STOP (Vehicle speed is less than 3 km/h (1.86 mph)) | Once |
TYPICAL ENABLING CONDITIONS CHART
| Brake switch | Remain ON during GO and STOP 5 times |
TYPICAL MALFUNCTION THRESHOLDS CHART
Scheme 269
| Related DTCs | P0741: Shift solenoid valve DSL/OFF malfunction Shift solenoid valve DSL/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve DSL, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE), Throttle position sensor (VPA1), Mass air flow sensor (MAF), Transmission temperature sensor (THO1), Engine coolant temperature sensor (ECT) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction 3.5 sec. ON malfunction 1.8 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
ALL
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 60°C (140°F) or more |
| TFT (Transmission fluid temperature) | 20°C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Shift solenoid valve DSL circuit | Not circuit malfunction |
| Electronic throttle system | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction
| ECM lockup command | ON |
|---|---|
| ECM selected gear | 3rd or 4th |
| Vehicle speed | 25 km/h (15.5 mph) or more |
MALFUNCTION CHART
ON malfunction
| ECM lockup command | OFF |
|---|---|
| ECM selected gear | 3rd or 4th |
| Throttle valve opening angle | 8% or more |
| Vehicle speed | 25 to 60 km/h (15,5 to 37.2 mph) |
MALFUNCTION CHART
Either of the following conditions is met: OFF malfunction or ON malfunction
OFF malfunction
| Engine speed - Input (turbine) speed | 100 RPM or more |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
Vehicle speed must be under 10 km/h (6.2 mph) once before 2nd detection
| Difference between engine speed and input (turbine) speed | Less than 35 RPM |
TESTER SPECIFIED CONDITION CHART
| Related DTCs | P0746: Shift solenoid valve SL1/OFF malfunction Shift solenoid valve SL1/ON malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve SL1, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction, ON malfunction (A) 0.8 sec. ON malfunction (B) 1 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
ALL
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 60°C (140°F) or more |
| TFT (Transmission fluid temperature) | 20°C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Electronic throttle system | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | 10 to 40 km/h (6.2 to 24.9 mph) |
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
MALFUNCTION CHART
ON malfunction (A)
| ECM selected gear | 2nd |
|---|---|
| Vehicle speed | 10 km/h (6.2 mph) or more |
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
MALFUNCTION CHART
ON malfunction (B)
| ECM lockup command | OFF |
|---|---|
| ECM selected gear | 3rd or 4th |
MALFUNCTION CHART
Either of the following conditions is met: OFF malfunction, or ON malfunction and (B)
2 detections are necessary per driving cycle
1 st detection; temporary flag ON
2nd detection; pending fault code ON
OFF malfunction
| Input (turbine) speed/Intermediate shaft speed | 1.49 to 1.63 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction (A)
| Input (turbine) speed/Intermediate shaft speed | 2.72 to 2.86 |
MALFUNCTION CHART
ON malfunction (B)
| Engine speed - Input (tubine) speed | 250 RPM or more |
ENGINE SPEED SPECIFICATION
| Related DTCs | P0748: Shift solenoid valve SL1/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SL1 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 10 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Output signal duty | 100% |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Output signal duty | Less than 100% |
COMPONENT OPERATING RANGE CHART
Scheme 270
Scheme 271
Scheme 272
- INSPECT TRANSMISSION WIRE (SL1) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 5 (SL1+) - 10 (SL1-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table below. Standard (Check for short): TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition SL1+ - Body ground 10 kohm or higher SL1- - Body ground up arrow NG: Go to step 3 OK
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) E8 - 19 (SL1+) - E8 - 18 (SL1-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table below. Standard (Check for short): TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition E8 - 19 (SL1+) - Body ground 10 kohm or higher E8 - 18 (SL1-) - Body ground up arrow NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK REPLACE ECM (See «ECM (2AZ-FE)»(ref-226406-S08140964062006032800000) )
- INSPECT SHIFT SOLENOID VALVE (SL1)
- Remove the shift solenoid valve SL1.
- Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) 1-2 5.0 to 5.6 ohm
- Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve.
OK
The solenoid makes an operating noise.
Scheme 273
- NG: REPLACE SHIFT SOLENOID VALVE (SL1)
OK: GO TO NEXT STEP
REPAIR OR REPLACE TRANSMISSION WIRE (See TRANSMISSION WIRE (U241E/U140F) )
| Related DTCs | P0766: Shift solenoid valve S4/ON malfunction Shift solenoid valve S4/OFF malfunction |
|---|---|
| Required sensors/Components | Shift solenoid valve S4, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
All
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 60°C (140°F) or more |
| TFT (Transmission fluid temperature) | 20°C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Electronic throttle system | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction
| ECM selected gear | 4th |
|---|---|
| Throttle valve opening angle | 5% or more |
| Vehicle speed | 10 km/h (6.2 mph) or more |
MALFUNCTION CHART
ON malfunction
| ECM selected gear | 3rd |
|---|---|
| Throttle valve opening angle | 5% or more |
| Vehicle speed | 10 km/h (6.2 mph) or more |
MALFUNCTION CHART
Either of the following conditions is met: OFF malfunction or ON malfunction
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
OFF malfunction
| Intermediate shaft speed/Output speed | 1.34 to 1.48 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction
| Intermediate shaft speed/Output speed | 0.95 to 1.09 |
MALFUNCTION CHART
All
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 60°C (140°F) or more |
| TFT (Transmission fluid temperature) | 20°C (-4°F) or more |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Electronic throttle system | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS CHART
OFF malfunction
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | 10 km/h (6.2 mph) or more |
| Throttle valve opening angle | 15% or more 4.5% or more at engine speed 1,900 RPM (Vary with engine speed) |
MALFUNCTION CHART
ON malfunction
| ECM selected gear | 3rd or 4th |
|---|---|
| Vehicle speed | 10 km/h (6.2 mph) or more |
| Throttle valve opening angle | 4.5% or more at engine speed 1,900 RPM (Varies with engine speed) |
MALFUNCTION CHART
Either of the following conditions is met: OFF malfunction or ON malfunction
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
OFF malfunction
| Input (turbine) speed/Intermediate shaft speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS CHART
ON malfunction
| Input (turbine) speed/Intermediate shaft speed | 1.49 to 1.63 |
SPEED/INTERMEDIATE SHAFT SPEED SPECIFICATION
| Related DTCs | P0778: Shift solenoid valve SL2/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SL2 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 10 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Output signal duty | 100% |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Output signal duty | Less than 100% |
COMPONENT OPERATING RANGE CHART
Scheme 274
Scheme 275
Scheme 276
Scheme 277
- INSPECT TRANSMISSION WIRE (SL2) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) 4 (SL2+) - 9 (SL2-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table below. Standard (Check for short): TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 4 (SL2+) - Body ground 10 kohm or higher 9 (SL2-) - Body ground up arrow NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) E8 - 15 (SL2+) - E8 - 14 (SL2-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table below. Standard (Check for short): NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: REPLACE ECM (See «ECM (2AZ-FE)»(ref-226406-S08140964062006032800000) )
- INSPECT SHIFT SOLENOID VALVE (SL2)
- Remove the shift solenoid valve SL2.
- Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) 1-2 5.0 to 5.6 ohm
- Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve.
OK
The solenoid makes an operating noise.
Scheme 278
- NG: REPLACE SHIFT SOLENOID VALVE (SL2)
- OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U241E/U140F)»(ref-226424-S12705736732006032900000) )
| Related DTCs | P0793: Speed sensor (NC)/Verify pulse input |
|---|---|
| Required sensors/Components | Speed sensor (NC), Speed sensor (NT), NSW switch |
| Frequency of operation | Continuous |
| Duration | 5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Engine | Running |
| NSW switch | OFF |
| Output shaft RPM | 1,000 RPM or more |
TYPICAL ENABLING CONDITIONS CHART
| Sensor signal RPM | Less than 300 RPM |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Counter gear speed sensor (NC) | [HINT] 4th (O/D) when shift lever position is D position (After warming up the engine); Intermediate shaft speed (NC) becomes close to the engine speed. |
COMPONENT OPERATING RANGE CHART
Scheme 279
| Related DTCs | P0982: Shift solenoid valve S4/Range check (Low resistance) P0983: Shift solenoid valve S4/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve S4 |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
P0982: Range check (Low resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S4 | ON |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
P0983: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S4 | ON |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS
P0982: Range check (Low resistance)
| Shift solenoid valve S4 resistance | 8 ohm or less |
TYPICAL MALFUNCTION THRESHOLDS CHART
P0983: Range check (High resistance)
| Shift solenoid valve S4 resistance | 100 kohm or more |
RESISTANCE CHART
| Shift solenoid valve S4 | Resistance: 11 to 15 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 280
Scheme 281
Scheme 282
- INSPECT TRANSMISSION WIRE (S4) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20 °C (68°F) 8 - Body ground 11 to 15 ohm NG Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) E8 - 11 (S4) - Body ground 11 to 15 ohm NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: REPLACE ECM (See «ECM (2AZ-FE)»(ref-226406-S08140964062006032800000) )
- INSPECT SHIFT SOLENOID VALVE (S4)
- Remove the shift solenoid valve S4.
- Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S4) - Solenoid Body (S4) 11 to 15 ohm
- Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body.
OK
The solenoid makes an operating noise.
Scheme 283
- NG: REPLACE SHIFT SOLENOID VALVE (S4)
- OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U241E/U140F)»(ref-226424-S12705736732006032900000) )
| Related DTCs | P2716: Shift solenoid valve SLT/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SLT |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY CHART
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 11 V or more |
| Solenoid current cut status | Not cut |
| CPU commanded duty ratio to SLT | 19% or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
| Solenoid status from IC | Fail (Open or short) |
TYPICAL MALFUNCTION THRESHOLDS CHART
| Shift solenoid valve SLT | Resistance: 5.0 to 5.6 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 284
Scheme 285
Scheme 286
Scheme 287
Scheme 288
- INSPECT TRANSMISSION WIRE (SLT) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) 2 (SLT+) - 7 (SLT-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table below. Standard (Check for short): NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) E8 - 13 (SLT+) - E8 - 12 (SLT-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table below. Standard (Check for short): NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: REPLACE ECM (See «ECM (2AZ-FE)»(ref-226406-S08140964062006032800000) )
- INSPECT SHIFT SOLENOID VALVE (SLT)
- Remove the shift solenoid valve (SLT).
- Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohm
- Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve.
OK
The solenoid makes an operating noise.
Scheme 289
- NG: REPLACE SHIFT SOLENOID VALVE (SLT)
- OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U241E/U140F)»(ref-226424-S12705736732006032900000) )
| Related DTCs | P2769: Shift solenoid valve DSL/Range check (Low resistance) P2770: Shift solenoid valve DSL/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve DSL |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY CHART
P2769: Range check (Low resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Solenoid current cut status | Not cut |
| Shift solenoid valve DSL | ON |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS CHART
P2770: Range check (High resistance)
| The monitor will run whenever this DTC is not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve DSL | ON |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
HIGH RESISTANCE CHART
P2769: Range check (Low resistance)
| Shift solenoid valve DSL resistance | 8 ohm or less |
LOW RESISTANCE CHART
P2770: Range check (High resistance)
| Shift solenoid valve DSL resistance | 100 kohm or more |
SHIFT SOLENOID VALVE DSL RESISTANCE CHART
| Shift solenoid valve DSL | Resistance: 11 to 13 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE CHART
Scheme 290
Scheme 291
Scheme 292
Scheme 293
- INSPECT TRANSMISSION WIRE (DSL) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) 3 - Body ground 11 to 13 ohm NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) E8 - 9 (DSL) - Body ground 11 to 13 ohm NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-226376-S04488228162006032500000) ) OK: REPLACE ECM (See «ECM (2AZ-FE)»(ref-226406-S08140964062006032800000) )
- INSPECT SHIFT SOLENOID VALVE (DSL)
- Remove the shift solenoid valve DSL.
- Measure the resistance according to the value(s) in the table below. Standard: TESTER SPECIFIED CONDITION CHART Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (DSL) - Solenoid Body (DSL) 11 to 13°
- Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body.
OK
The solenoid valve makes an operating noise.
- NG: REPLACE SHIFT SOLENOID VALVE (DSL)
- OK: REPAIR OR REPLACE TRANSMISSION WIRE (See «TRANSMISSION WIRE (U241E/U140F)»(ref-226424-S12705736732006032900000) )
