Automatic Transmission Diagnosis - U140E & U140F: Specifications Toyota Highlander I

Automatic Trans 5 illustrations ~218 words

SHIFT SPEED SPECIFICATIONS

Note. All specifications taken at wide open throttle except "D" position, 3rd-4th and 4th-3rd. See footnotes.

ApplicationMPH
"D" Position
1st-2nd33-39
2nd-3rd62-68
3rd-4th94-104
3rd-4th (1)24-29
4th-3rd (1)9-13
4th-3rd89-99
3rd-2nd57-63
2nd-1st27-31
"2" Position
1st-2nd33-39
3rd-2nd62-68
2nd-1st27-31
"L" Position
3rd-2nd62-68
2nd-1st29-34
(1) Fully closed throttle.
(1)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (CAMRY)

ApplicationMPH
"D" Position
1st-2nd38-42
2nd-3rd71-76
3rd-4th108-116
3rd-4th (1)21-25
4th-3rd (1)12-16
4th-3rd101-109
3rd-2nd66-71
2nd-1st25-29
"2" Position
1st-2nd38-42
3rd-2nd75-79
2nd-1st25-29
"L" Position
3rd-2nd75-79
2nd-1st33-37
(1) Fully closed throttle.
(1)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (ES 300)

ApplicationMPH
"D" Position
1st-2nd34-35
2nd-3rd58-63
3rd-4th93-101
3rd-4th (1)25-29
4th-3rd (1)9-13
4th-3rd89-96
3rd-2nd55-59
2nd-1st26-30
"2" Position
1st-2nd31-35
3rd-2nd58-63
2nd-1st26-30
"L" Position
3rd-2nd58-63
2nd-1st29-32
(1) Fully closed throttle.
(1)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (HIGHLANDER 2.4L - U140F)

ApplicationMPH
"D" Position
1st-2nd36-41
2nd-3rd68-73
3rd-4th104-112
3rd-4th (1)21-24
4th-3rd (1)11-15
4th-3rd98-107
3rd-2nd63-68
2nd-1st29-32
"2" Position
1st-2nd36-41
3rd-2nd70-75
2nd-1st29-32
"L" Position
3rd-2nd70-75
2nd-1st32-36
(1) Fully closed throttle.
(1)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (HIGHLANDER 3.0L - U140E)

ApplicationMPH
"D" Position
1st-2nd31-39
2nd-3rd64-69
3rd-4th98-106
3rd-4th (1)19-23
4th-3rd (1)11-14
4th-3rd92-100
3rd-2nd60-64
2nd-1st27-30
"2" Position
1st-2nd34-39
3rd-2nd66-70
2nd-1st27-30
"L" Position
3rd-2nd66-70
2nd-1st30-34
(1) Fully closed throttle.
(1)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (HIGHLANDER 3.0L - U140F)

ApplicationMPH
"D" Position
1st-2nd35-41
2nd-3rd67-73
3rd-4th103-112
3rd-4th (1)24-28
4th-3rd (1)11-15
4th-3rd96-106
3rd-2nd63-68
2nd-1st27-31
"2" Position
1st-2nd35-41
3rd-2nd69-75
2nd-1st27-31
"L" Position
3rd-2nd69-75
2nd-1st31-36
(1) Fully closed throttle.
(1)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (RAV4)

ApplicationMPH
"D" Position
1st-2nd36-41
2nd-3rd68-73
3rd-4th104-112
3rd-4th (1)21-24
4th-3rd (1)11-15
4th-3rd98-107
3rd-2nd63-68
2nd-1st29-32
"2" Position
1st-2nd36-41
3rd-2nd70-75
2nd-1st29-32
"L" Position
3rd-2nd70-75
2nd-1st32-36
(1) Fully closed throttle.
(1)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (RX 300 - U140E)

ApplicationMPH
"D" Position
1st-2nd34-39
2nd-3rd64-69
3rd-4th98-106
3rd-4th (1)19-23
4th-3rd (1)11-14
4th-3rd92-100
3rd-2nd60-64
2nd-1st27-30
"2" Position
1st-2nd34-39
3rd-2nd66-70
2nd-1st27-30
"L" Position
3rd-2nd66-70
2nd-1st30-34
(1) Fully closed throttle.
(1)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (RX 300 - U140F)

LOCK-UP SPEED SPECIFICATIONS

Note. Throttle valve opening is 5 percent for all lock-up specifications

ApplicationMPH
"D" Position (1)
Lock-Up On in 3rd (2)94-104
Lock-Up Off in 3rd (2)89-99
Lock-Up On in OD32-37
Lock-Up Off in OD30-35
(1) There is no lock-up in "L" or "2" position. (2) With OD switch off.
(1)There is no lock-up in "L" or "2" position.
(2)With OD switch off.

LOCK-UP SPEED SPECIFICATIONS (CAMRY)

ApplicationMPH
"D" Position (1)
Lock-Up On in 3rd (2)49-53
Lock-Up Off in 3rd (2)44-48
Lock-Up On in OD37-40
Lock-Up Off in OD32-36
(1) There is no lock-up in "L" or "2" position. (2) With OD switch off.
(1)There is no lock-up in "L" or "2" position.
(2)With OD switch off.

LOCK-UP SPEED SPECIFICATIONS (ES 300)

ApplicationMPH
"D" Position (1)
Lock-Up On in 3rd (2)60-65
Lock-Up Off in 3rd (2)58-63
Lock-Up On in OD35-39
Lock-Up Off in OD34-38
(1) There is no lock-up in "L" or "2" position. (2) With OD switch off.
(1)There is no lock-up in "L" or "2" position.
(2)With OD switch off.

LOCK-UP SPEED SPECIFICATIONS (HIGHLANDER 2.4L - U140F)

ApplicationMPH
"D" Position (1)
Lock-Up On in 3rd (2)104-113
Lock-Up Off in 3rd (2)98-107
Lock-Up On in OD50-55
Lock-Up Off in OD48-53
(1) There is no lock-up in "L" or "2" position. (2) With OD switch off.
(1)There is no lock-up in "L" or "2" position.
(2)With OD switch off.

LOCK-UP SPEED SPECIFICATIONS (HIGHLANDER 3.0L - U140E)

ApplicationMPH
"D" Position (1)
Lock-Up On in 3rd (2)98-106
Lock-Up Off in 3rd (2)92-100
Lock-Up On in OD47-52
Lock-Up Off in OD44-48
(1) There is no lock-up in "L" or "2" position. (2) With OD switch off.
(1)There is no lock-up in "L" or "2" position.
(2)With OD switch off.

LOCK-UP SPEED SPECIFICATIONS (HIGHLANDER 3.0L - U140F)

ApplicationMPH
Lock-Up On in OD35-39
Lock-Up Off in OD34-38

LOCK-UP SPEED SPECIFICATIONS (RAV4)

ApplicationMPH
"D" Position (1)
Lock-Up On in 3rd (2)104-113
Lock-Up Off in 3rd (2)98-107
Lock-Up On in OD50-55
Lock-Up Off in OD48-53
(1) There is no lock-up in "L" or "2" position. (2) With OD switch off.
(1)There is no lock-up in "L" or "2" position.
(2)With OD switch off.

LOCK-UP SPEED SPECIFICATIONS (RX 300 - U140E)

ApplicationMPH
"D" Position (1)
Lock-Up On in 3rd (2)98-106
Lock-Up Off in 3rd (2)92-100
Lock-Up On in OD47-52
Lock-Up Off in OD44-48
(1) There is no lock-up in "L" or "2" position. (2) With OD switch off.
(1)There is no lock-up in "L" or "2" position.
(2)With OD switch off.

LOCK-UP SPEED SPECIFICATIONS (RX 300 - U140F)

TORQUE CONVERTER LOCK-UP

Road test vehicle. Increase vehicle speed until lock-up should occur. To confirm lock-up operation, very lightly depress brake pedal with left foot and release while maintaining constant speed. Monitor vehicle tachometer. Transaxle should downshift into 3rd gear and then upshift into lock-up once brake pedal is released. Ensure lock-up speeds are within specification. See LOCK-UP SPEED SPECIFICATIONS .

TORQUE SPECIFICATIONS

ApplicationINCH Lbs. (N.m)
Manual Detent Spring Top Bolt106 (12)
Parking Lock Pawl Clamp Bolt87 (9.8)
Park/Neutral Position Switch
Bolt48 (5.4)
Nut61 (6.9)
Shift Control Cable Nut133 (15)
Shift Control Lever Bolt61 (6.9)
Shift Control Lever Lock Tab Nut61 (6.9)
Solenoid Connector Bolt48 (5.4)
Speed Sensor Bolt97 (11)

TORQUE SPECIFICATIONS

ELECTRONIC COMPONENT SPECIFICATIONS

ApplicationOhms
Counter Gear & Input Turbine Speed Sensor560-680
Shift Solenoids DSL & S411-15
Shift Solenoid SLT5.0-5.6
Shift Solenoids SL1 & SL25.1-5.5

COMPONENT RESISTANCE SPECIFICATIONS

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53
