Tilt Steering Column: Overview Toyota Echo I

Steering Column 9 illustrations ~339 words

Scheme 5

Scheme 5: COMPONENTS
Scheme 5: COMPONENTS

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Remove steering wheel pad : Place the front wheels facing straight ahead. Using a torx socket wrench, loosen the 2 torx screws until the groove along the screw circumference catches on the screw case. Pull out the wheel pad from the steering wheel and disconnect the AIRBAG connector. Disconnect the connector.
  2. Remove steering wheel : Remove the steering wheel set nut. Place match-marks on the steering wheel and main shaft assembly. Using SST, remove the steering wheel. SST 09950-50013 (09951-05010, 09952-05010, 09953-05020, 09954-05021)
  3. Remove column lower cover : Remove the 3 screws and column lower cover.
  4. Remove spiral cable, light control switch and headlight dimmer switch, wiper and washer switch and column upper cover : Disconnect the 3 connectors from the spiral cable, light control switch and headlight dimmer switch and wiper and washer switch. Disconnect the AIRBAG connector from the spiral cable. Push the claw and pull out the light control switch and headlight dimmer switch. Employ the same manner described above to the wipe and washer switch. NOTE: Do not disassemble the spiral cable or apply oil to it. Slide the column upper cover and remove the spiral cable. Remove the column upper cover.
  5. A/T, remove key interlock cable. See «SHIFT INTERLOCK SYSTEMS»(ref-144214).
  6. Remove No. 2 column hole cover : Remove the clip and No. 2 column hole cover.
  7. Disconnect sliding yoke : Place match-marks on the sliding yoke and No. 3 intermediate shaft assembly. Loosen the bolt A and remove the bolt B, then disconnect the sliding yoke.
  8. Remove steering column assembly : Disconnect the connectors. Remove the lower mount bolt, 2 upper mount bolts and steering column assembly.
  9. Remove sliding yoke : Remove the bolt A and sliding yoke.
  10. Remove No. 2 intermediate shaft assembly

Scheme 13

Scheme 13
Scheme 13
  1. Place match-marks on the No. 2 intermediate shaft assembly and main shaft assembly.
  2. Remove the bolt and No. 2 intermediate shaft assembly.
