Tilt Steering Column: Overhaul Toyota Echo I

Steering Column 20 illustrations ~1120 words

DISASSEMBLY

Note. When using a vise, do not overtighten it.

Scheme 14

Scheme 14: DISASSEMBLY
Scheme 14: DISASSEMBLY

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Remove column upper bracket and column upper clamp : Using a centering punch, mark the center of the 2 tapered-head bolts. Using a 3 - 4 mm (0.12 - 0.16 in.) drill, drill into the 2 bolts. Using a screw extractor, remove the 2 bolts, column upper bracket and column upper clamp.
  2. Remove bracket spacer and 2 No. 1 support collars : Using an extension bar and a hammer, tap out the bracket spacer. Using a screwdriver, remove the 2 No. 1 support collars.
  3. Remove tilt lever and break away bracket : NOTE: This bolt is left-handed one. Remove the No. 2 tilt lever lock bolt and No. 1 support reinforce. NOTE: This nut is left-handed one. Remove the adjusting nut, tilt lever, stopper, tilt lever lock bolt and break away bracket. Remove the clamp and No. 2 support collar from the break away bracket.
  4. Remove main shaft bushing : Using a screwdriver and hammer, tap out the main shaft bushing.
  5. Remove main shaft assembly .
  1. Using a snap ring expander, remove the snap ring on the upper side.
  2. Remove the main shaft assembly.
  3. Using a snap ring expander, remove the snap ring on the lower side.

Scheme 20

Scheme 20: INSPECTION
Scheme 20: INSPECTION

Scheme 21

Scheme 21
Scheme 21
  1. Inspect steering lock operation : Check that the steering lock mechanism operates properly.
  2. If necessary, replace key cylinder : NOTE: Make sure the key is at the ACC position. Place the ignition key at the ACC position. Push down the stop pin with a screwdriver, and pull out the cylinder. Install a new cylinder.
  3. Inspect ignition switch . See «IGNITION SWITCH/STEERING LOCK»(ref-172837) .
  4. If necessary, replace ignition switch : Remove the 2 screws and ignition switch from the column upper bracket. Install a new ignition switch with the 2 screws.
  5. Inspect key unlock warning switch . See «IGNITION SWITCH/STEERING LOCK»(ref-172837) .
  6. If necessary, replace key unlock warning switch : Slide the key unlock warning switch out of the column upper bracket. Slide a new key unlock warning switch in the column upper bracket.
  7. Inspect bearing

Check the bearing rotation condition and check for abnormal noise.

If the bearing is worn or damaged, replace the column tube.

Scheme 22

Scheme 22
Scheme 22

REASSEMBLY

Note. When using a vise, do not overtighten it.

Scheme 23

Scheme 23: REASSEMBLY
Scheme 23: REASSEMBLY

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. Coat parts indicated by arrows with molybdenum disulfide lithium base grease . See «COMPONENTS»(ref-172948-S11214112772005030700000) .
  2. Install main shaft assembly : Using a snap ring expander, install a new snap ring on the lower side. Install the main shaft assembly. Using a snap ring expander, install a new snap ring on the upper side.
  3. Install main shaft bushing : Coat a new bushing with molybdenum disulfide lithium base grease. Using SST and a hammer, tap in the main shaft bushing. SST 09612-22011
  4. Install break away bracket and tilt lever : Install the clamp and No. 2 support collar to the break away bracket. NOTE: Align the holes in the column tube with the projections of the tilt lever lock bolt and stopper. Install the break away bracket, tilt lever lock bolt, stopper and tilt lever. Install the adjusting nut by rotating it counterclockwise in the specified torque so that the locking load (load applied to when a knob is operated) of the tilt lever will be 43 - 91 N (4.4 - 9.3 kgf, 9.7 - 20.5lbf). Torque: 9 N.m - 14 N.m (90 kgf.cm - 145 kgf.cm, 80 in.lbf - 10 ft.lbf) NOTE: Align the No. 1 support reinforce with the nut to eliminate looseness by turning the No. 1 support reinforce counterclockwise a little, then torque the No. 2 tilt lever lock bolt. Install the No. 1 support reinforce with the No. 2 tilt lever lock bolt by turning it counterclockwise. Torque: 5.4 N.m (55 kgf.cm, 48 in..lbf)
  5. Install 2 No. 1 support collars and bracket spacer : Install 2 new No. 1 support collars. Using an extension bar and a hammer, drive in the bracket spacer.
  6. Install column upper bracket and column upper clamp

Scheme 27

Scheme 27
Scheme 27
  1. Install the column upper bracket and column upper clamp with 2 new tapered-head bolts.
  2. Tighten the 2 tapered-head bolts until the bolt heads break off.

Scheme 28

Scheme 28: INSTALLATION
Scheme 28: INSTALLATION

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33
  1. Install No. 2 intermediate shaft assembly : Align the match-marks on the No. 2 intermediate shaft assembly and main shaft assembly. Install the No. 2 intermediate shaft assembly with the bolt. Torque: 28 N.m (290 kgf.cm, 21 ft.lbf)
  2. Install sliding yoke : Temporarily install the sliding yoke to the No. 2 intermediate shaft assembly with the bolt A.
  3. Install steering column : Install the steering column assembly with the lower mount bolt and 2 upper mount bolts. Torque: 21 N.m (210 kgf.cm, 15 ft.lbf) Connect the connectors.
  4. Connect sliding yoke : Align the match-marks on the sliding yoke and No. 3 intermediate shaft assembly. Install the bolt B. Torque: 28 N.m (290 kgf.cm, 21 ft.lbf) Torque the bolt A. Torque: 28 N.m (290 kgf.cm, 21 ft.lbf)
  5. Install No. 2 column hole cover : Install the No. 2 column hole cover with the clip.
  6. A/T, install key interlock cable . See «SHIFT INTERLOCK SYSTEMS»(ref-144214) .
  7. Install column upper cover, light control switch and headlight dimmer switch, wiper and washer switch and spiral cable : Install the column upper cover. Slide the column upper cover and install the spiral cable. Push into the light control switch and headlight dimmer switch until the claw is latched. Employ the same manner described above to the wiper and washer switch. Connect the AIRBAG connector to the spiral cable. Connect the 3 connectors to the spiral cable, light control switch and headlight dimmer switch and wiper and washer switch.
  8. Install column lower cover : Install the column lower cover with the 3 screws.
  9. Center spiral cable : Check that the front wheels are facing straight ahead. Turn the cable counterclockwise by hand until it becomes harder to turn. NOTE: The cable will rotate about 2.5 turns to either left or right of the center. Then rotate the cable clockwise about 2.5 turns to align the marks.
  10. Install steering wheel : Align the match-marks on the steering wheel and main shaft assembly. Install the steering wheel set nut. Torque: 50 N.m (510 kgf.cm, 37 ft.lbf)
  11. Install steering wheel pad : Connect the connector. Connect the AIRBAG connector. Install the steering wheel pad after confirming that the circumference groove of the torx screws is caught on the screw case. Using a torx socket wrench, torque the 2 screws. Torque: 8.8 N.m (90 kgf.cm, 78 in..lbf)
  12. Check steering wheel center point
