| A/C Compressor Bolt | 18 (24) |
| Axle Shaft Nut | 159 (216) |
| Ball Joint-To-Knuckle Nut | 72 (98) |
| Camshaft Bearing Cap Bolt (1) |
| No. 1 | 17 (23) |
| No. 2 | (2) |
| Camshaft Sprocket Bolt | 47 (64) |
| Connecting Rod Nut |
| Step 1 | 11 (15) |
| Step 2 | (4) |
| Crankshaft Pulley Bolt | 94 (128) |
| Cylinder Head Bolt (3) |
| Step 1 | 21 (29) |
| Step 2 | (4) |
| Step 3 | (4) |
| Drive Plate Bolt | 65 (88) |
| Engine Coolant Drain Union | 26 (35) |
| Engine Hanger At Cylinder Head Bolt | 28 (38) |
| Exhaust Manifold Nut | 20 (27) |
| Exhaust Manifold-To-Cylinder Block Brace Bolt | 27 (37) |
| Exhaust Pipe-To-Exhaust Manifold Bolt | 46 (62) |
| Exhaust Pipe-To-Tailpipe Clamp Bolt | 24 (32) |
| Flywheel Bolt |
| Step 1 | 36 (49) |
| Step 2 | (4) |
| Fuel Pipe-To-Cylinder Head Bolt | 14 (19) |
| Intake Manifold Bolt/Nut | 22 (30) |
| Knock Sensor | 29 (39) |
| Left (Transaxle Side) Engine Mount Bracket-To-Insulator Bolt | 36 (49) |
| Left (Transaxle Side) Engine Mount Bracket-To-Transaxle Bolt | 47 (64) |
| Main Bearing Cap Bolt (5) |
| Step 1 | 16 (22) |
| Step 2 | (4) |
| No. 1 Oil Pan Bolt | 18 (24) |
| Oil Filter Union | 22 (30) |
| Oil Pan No.1 Bolts | 18 (24) |
| Oil Pan Drain Plug | 28 (38) |
| Oxygen Sensor-To-Exhaust Pipe | 32 (43) |
| Plug At Timing Cover | 11 (15) |
| Power Steering Pump Adjusting Bracket Bolt | 32 (43) |
| Power Steering Pump Mounting Bracket-To-Cylinder Head Bolt | 32 (43) |
| Rear (Firewall Side) Engine Mount Through-Bolt | 36 (49) |
| Right Engine Mount Bracket-To-Timing Chain Cover Bolt | 41 (55) |
| Right Engine Mount-To-Body Bolt | 33 (45) |
| Right Engine Mount-To-Bracket On Cylinder Block Bolt/Nut | 38 (52) |
| Spark Plug | 13 (18) |
| Throttle Body Bolt/Nut | 22 (30) |
| Tie Rod Nut | 36 (49) |
| Timing Chain Cover Plug | 11 (15) |
| Torque Converter Bolt | 20 (27) |
| Valve Timing Controller Bolt | 47 (64) |
| Water Pump Pulley | 11 (15) |
| Wheel Lug Nut | 76 (103) |
| INCH Lbs. (N.m) |
| ABS Speed Sensor Bolt | 71 (8) |
| Air Cleaner Case Bolt | 66 (7.5) |
| Camshaft Position Sensor Retaining Bolt | 71 (8) |
| Clutch Release Cylinder Bolt | 106 (12) |
| Coolant Inlet Nut | 80 (9) |
| Crankshaft Position Sensor Bolt (8) |
| Bolt "A" | 66 (7.5) |
| Bolt "B" | 97 (11) |
| Ignition Coil Bolt | 80 (9) |
| Oil Pan No.2 Bolts | 80 (9) |
| Oil Control Valve Bolt | 71 (8) |
| Oil Pump Cover Bolt | 80 (9) |
| Oil Pump Cover Screw | 97 (11) |
| Oil Pump Strainer Bolt | 97 (11) |
| Outer Front Cowl Top Panel Bolt | 71 (8) |
| Timing Chain Cover Bolts (6) |
| A, C, E & G | 97 (11) |
| B, D & F | (7) |
| Timing Chain Tensioner Bolt | 80 (9) |
| Timing Chain Vibration Dampener Bolt | 80 (9) |
| Valve Cover Nut | 89 (10) |
| Water By-Pass Pipe Bolt | 80 (9) |
| Water Filler Bolt | 66 (7.5) |
| Water Pump Bolt/Nut | 97 (11) |
| (1) Tighten bolts to specification in sequence. see scheme 10 (2) Tighten to 89 INCH Lbs (10 N.m). (3) Tighten bolts to specification in sequence. see scheme 5 (4) Tighten an additional 90 degrees. (5) Tighten bolts to specification in sequence. see scheme 16 (6) see scheme 8(7) Tighten to 18 Ft. Lbs (24 N.m). (8) Tighten bolts to specification in sequence. (Scheme 7) |
