Power Mirror Control System (Diagnostics & Symptom Tests): Other Toyota Corolla XI

PRECAUTION [08/2013 - ]

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following system after the cable is reconnected. System Name See Procedure Air Conditioning System (for Automatic Air Conditioning System) Refer to «INITIALIZATION [08/2013 - ]»(ref-635429-S20696467122014070300000)
2. IGNITION SWITCH EXPRESSIONS The type of ignition switch used on this model differs depending on the specifications of the vehicle. The expressions listed in the table below are used in this section. Expression Ignition Switch (Position) Engine Switch (Condition) Ignition Switch off LOCK Off (Lock) Ignition Switch ACC ACC On (ACC) Ignition Switch ON ON On (IG) Engine Start START On (Start)

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. ELECTRICAL REMOTE CONTROL MIRROR FUNCTION
2. MIRROR HEATER FUNCTION (for Automatic Air Conditioning System) COMMUNICATION TABLE Sender Receiver Signal Communication Method Air Conditioning Control Assembly Air Conditioning Amplifier Assembly Mirror heater switch (rear window defogger switch) signal LIN
3. MIRROR HEATER FUNCTION (for Manual Air Conditioning System)

CAUTION / NOTICE / HINT

HINT

1. Use the following procedure to troubleshoot the power mirror control system.
2. *: Use the Techstream.

PROCEDURE

1. VEHICLE BROUGHT TO WORKSHOP Result Proceed to NEXT Result: 1 NEXT See step 2
2. CUSTOMER PROBLEM ANALYSIS HINT: In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points for problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Driving conditions, weather conditions How did it happen? Problem symptoms Result Proceed to NEXT Result: 1 NEXT See step 3
3. PRE-CHECK Measure the battery voltage. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. Check the fuses and relays. Check the connector connections and terminals to make sure that there are no abnormalities such as loose connections, deformation, etc. Result Proceed to NEXT Result: 1 NEXT See step 4
4. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-635721-S21359790562014070300000) Result Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B Result: 2 B See step 6 Result: 1 A See step 5
5. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check Refer to «OPERATION CHECK [08/2013 - ]»(ref-635721-S12457594032014070300000) Terminals of ECU Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635721-S17939459462014070300000) Data List / Active Test Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635721-S21588056902014070300000) Inspection Result Proceed to NEXT Result: 1 NEXT See step 6
6. REPAIR OR REPLACE Result Proceed to NEXT Result: 1 NEXT See step 7
7. CONFIRMATION TEST Result Proceed to NEXT Result: 1 NEXT END

TERMINALS OF ECU [08/2013 - ]

1. CHECK AIR CONDITIONING AMPLIFIER ASSEMBLY Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635713-S08436606722014070300000)
2. CHECK AIR CONDITIONING CONTROL ASSEMBLY Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635713-S08436606722014070300000)

Note. Inspect the fuses for circuits related to this system before performing the following procedure. If the battery voltage becomes low, mirror heater operation is canceled to prioritize supplying power to the power steering system. Refer to DATA LIST / ACTIVE TEST [08/2013 - ]

1. PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Air Conditioner / Active Test. Perform the Active Test according to the display on the Techstream. Body Electrical > Air Conditioner > Active Test Tester Display Measurement Item Control Range Diagnostic Note Defogger Relay (Rear) Mirror Heater OFF or ON - Body Electrical > Air Conditioner > Active Test Tester Display Defogger Relay (Rear) Result Result Proceed to Mirror heater operation on both mirrors is not normal A Mirror heater operation on RH side mirror is not normal B Mirror heater operation on LH side mirror is not normal C Result: 2 B See step 3 Result: 3 C See step 5 Result: 1 A See step 2
2. CHECK WINDOW DEFOGGER SYSTEM Check the window defogger system operation. Refer to «OPERATION CHECK [08/2013 - ]»(ref-635713-S39319481442014070300000) OK The window defogger system operates normally. Result Proceed to OK NG Result: 1 OK CHECK HARNESS AND CONNECTOR (DEFOGGER RELAY - OUTER REAR VIEW MIRROR ASSEMBLY RH/LH) Result: 2 NG GO TO WINDOW DEFOGGER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-635713-S24340855112014070300000)
3. CHECK HARNESS AND CONNECTOR (DEFOGGER RELAY - OUTER REAR VIEW MIRROR ASSEMBLY RH - BODY GROUND) Remove the DEFOGGER relay from the engine room relay block and junction block assembly. Disconnect the G2*1 or G3*2 outer rear view mirror assembly RH connector. *1: w/o Side Turn Signal Light *2: w/ Side Turn Signal Light Disconnect the H2*1 or H3*2 outer rear view mirror assembly LH connector. *1: w/o Side Turn Signal Light *2: w/ Side Turn Signal Light Measure the resistance according to the value(s) in the table below. Standard Resistance W/O SIDE TURN SIGNAL LIGHT Tester Connection Condition Specified Condition DEFOGGER relay holder terminal-3 - G2-1 (+) Always Below 1 ohms G2-2 (-) - Body Ground Always Below 1 ohms G2-1 (+) - Body Ground Always 10 kohms or higher DEFOGGER relay holder terminal-3 - Body Ground Always 10 kohms or higher W/ SIDE TURN SIGNAL LIGHT Tester Connection Condition Specified Condition DEFOGGER relay holder terminal-3 - G3-1 (+) Always Below 1 ohms G3-2 (-) - Body Ground Always Below 1 ohms G3-1 (+) - Body Ground Always 10 kohms or higher DEFOGGER relay holder terminal-3 - Body Ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. INSPECT OUTER MIRROR RH Remove the outer mirror RH. Refer to «REMOVAL [08/2013 - ]»(ref-635720-S30730911102014070300000) Inspect the outer mirror RH. Refer to «INSPECTION [08/2013 - ]»(ref-635720-S36993980442014070300000) OK Outer rear mirror RH is normal. Result Proceed to OK NG Result: 1 OK REPLACE OUTER REAR VIEW MIRROR ASSEMBLY RH. Refer to «REMOVAL [08/2013 - ]»(ref-635720-S28566686042014070300000) Result: 2 NG REPLACE OUTER MIRROR RH. Refer to «REMOVAL [08/2013 - ]»(ref-635720-S30730911102014070300000)
5. CHECK HARNESS AND CONNECTOR (DEFOGGER RELAY - OUTER REAR VIEW MIRROR ASSEMBLY LH - BODY GROUND) Remove the DEFOGGER relay from the engine room relay block and junction block assembly. Disconnect the H2*1 or H3*2 outer rear view mirror assembly LH connector. *1: w/o Side Turn Signal Light *2: w/ Side Turn Signal Light Disconnect the G2*1 or G3*2 outer rear view mirror assembly RH connector. *1: w/o Side Turn Signal Light *2: w/ Side Turn Signal Light Measure the resistance according to the value(s) in the table below. Standard Resistance W/O SIDE TURN SIGNAL LIGHT Tester Connection Condition Specified Condition DEFOGGER relay holder terminal-3 - H2-1 (+) Always Below 1 ohms H2-2 (-) - Body Ground Always Below 1 ohms H2-1 (+) - Body Ground Always 10 kohms or higher DEFOGGER relay holder terminal-3 - Body Ground Always 10 kohms or higher W/ SIDE TURN SIGNAL LIGHT Tester Connection Condition Specified Condition DEFOGGER relay holder terminal-3 - H3-1 (+) Always Below 1 ohms H3-2 (-) - Body Ground Always Below 1 ohms H3-1 (+) - Body Ground Always 10 kohms or higher DEFOGGER relay holder terminal-3 - Body Ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 6
6. INSPECT OUTER MIRROR LH Remove the outer mirror LH. Refer to «REMOVAL [08/2013 - ]»(ref-635720-S30730911102014070300000) Inspect the outer mirror LH. Refer to «INSPECTION [08/2013 - ]»(ref-635720-S36993980442014070300000) OK Outer rear mirror LH is normal. Result Proceed to OK NG Result: 1 OK REPLACE OUTER REAR VIEW MIRROR ASSEMBLY LH. Refer to «REMOVAL [08/2013 - ]»(ref-635720-S28566686042014070300000) Result: 2 NG REPLACE OUTER MIRROR LH. Refer to «REMOVAL [08/2013 - ]»(ref-635720-S30730911102014070300000)
